Micromax 4361 Resistor Paste, Cermet Trimmers
Type: Resistor Paste
Application: Cermet Trimmers / Potentiometers
Resistivity: 1 MΩ/sq
Firing: 850°C / 30 min
Shelf Life: 6 months
MacDermid Alpha Micromax 4361 is a high-ohm resistor paste from the 4300 Series, designed for cermet trimmers and potentiometers with 1MΩ/sq sheet resistivity — the highest resistance in the 4300 Series. Featuring fast 30-minute 850°C firing and CRV less than 1% per TDS specifications.
Micromax 4361 is a high-ohm resistor paste from the 4300 Series, specifically designed for high-performance cermet trimmers and potentiometers. This composition offers a sheet resistivity of 1MΩ/sq — the highest resistance in the 4300 Series. The paste delivers excellent contact resistance variation (CRV) of less than 1%, superior rotational life, and outstanding solder dip stability. It is suitable for various wiper materials including stainless steel, providing design flexibility for trimmer and potentiometer applications.
The paste is optimized for 325-mesh screens with 10-16 μm emulsion thickness, producing a dried film thickness of 23-27 μm. Drying is performed at 150°C for 10-15 minutes. The fast 30-minute firing cycle with a 10-minute peak at 850°C improves production throughput. The composition is compatible with high silver containing conductors including Micromax 7780 terminations. Available in 100G and 1000G containers.
Genuine MacDermid Alpha Micromax Imported Stock & Technical Support
We maintain stable inventory of authentic MacDermid Alpha Micromax 4361 resistor paste. Factory-original TDS and batch-specific COA can be provided upon request for your trimmer and potentiometer projects.
Request Sample, TDS & Quotation
Complete TDS, COA, and regulatory documentation available
Key Features of MacDermid Alpha Micromax 4361
- 1MΩ/sq highest-ohm sheet resistivity — highest resistance in the 4300 Series per TDS specifications
- Fast 30-minute firing profile — 10-minute peak at 850°C for high-throughput production per TDS specifications
- CRV less than 1% — excellent contact resistance variation for reliable trimmer performance per TDS specifications
- Excellent rotational life — stable performance after 200 cycles per TDS specifications
- Stainless steel wiper compatible — suitable for various wiper materials per TDS specifications
- High-Ag conductor compatible — compatible with Micromax 7780 and high silver containing conductors per TDS specifications
- Cadmium free — formulated without intentional addition of cadmium per TDS specifications
- 325 mesh printable — optimized for standard stainless steel screens with 10-16 μm emulsion per TDS specifications
Primary Applications
- Cermet trimmers — highest-resistance resistor elements for high-performance trimmers per TDS specifications
- Potentiometers — resistive elements for potentiometer applications per TDS specifications
- Variable resistors — highest-resistance variable resistor elements for demanding applications
- Stainless steel wiper applications — compatible with stainless steel and other wiper materials per TDS specifications
Full Technical Specifications
| Property | Typical Value | TDS Reference |
| Product Type | Thick film resistor paste | TDS: Resistor paste |
| Application | Cermet trimmers, potentiometers | TDS: Variable resistor |
| Packaging Specification | 100G, 1000G | — |
| Resistivity | 1 MΩ/sq | TDS: 1M — Highest in 4300 Series |
| Viscosity (Brookfield HAT 10 rpm) | 120-200 Pa.s | TDS: 120 to 200 Pa.s |
| Recommended Mesh | 325 mesh | TDS: 325 mesh |
| Emulsion Thickness | 10-16 μm | TDS: 10 to 16 μm |
| Recommended Film Thickness | 23-27 μm | TDS: 23 to 27 μm |
| Leveling Time | 10-15 min | TDS: 10-15 min |
| Drying Temperature | 150°C | TDS: 150°C |
| Drying Time | 10-15 min | TDS: 10-15 min |
| Firing Peak Temperature | 850°C | TDS: 850°C peak |
| Firing Cycle | 30 min | TDS: 30 min (10 min at peak) |
| HTCR (25-125°C) | 0±200 ppm/°C | TDS: 0±200 |
| CTCR (-55-25°C) | 0±200 ppm/°C | TDS: 0±200 |
| CRV | <1% | TDS: <1 |
| Rotational Life (200 cycles) | <1% ΔR | TDS: <1 |
| Short Term Overload Voltage | 330 V/mm | TDS: 330 |
| Standard Working Voltage | 132 V/mm | TDS: 132 |
| Maximum Rated Power Dissipation | 0.2 mW/mm² | TDS: 0.2 |
| Resistivity Tolerance | 300k-1.2M Ω | TDS: 300K-1.2M |
| Termination Compatibility | Micromax 7780 / high-Ag conductors | TDS: 7780 termination |
| Wiper Compatibility | Stainless steel and other wiper materials | TDS: various wiper materials |
| Substrate Compatibility | 96% alumina | TDS: 96% alumina |
| Thinner | Micromax 8250 | TDS: 8250 |
| Shelf Life | 6 months | TDS: 6 months |
| Storage Temperature | 5-30°C | TDS: 5-30°C |
Note: All listed values are typical and may vary by batch. Independent qualification testing is required prior to production use.
Recommended Processing Conditions
| Parameter | Recommended Value | TDS Reference |
| Mixing Prior to Use | Slow gentle hand-stirring with clean spatula, 0.5-1 minute | TDS: 0.5-1 minute |
| Optimal Printing Temperature | 20-23°C | TDS: 20-23°C |
| Screen Mesh | 325 mesh stainless steel | TDS: 325 mesh |
| Emulsion Thickness | 10-16 μm | TDS: 10-16 μm |
| Dried Film Thickness | 23-27 μm | TDS: 23-27 μm |
| Leveling Time | 10-15 minutes at room temperature | TDS: 10-15 min |
| Drying Temperature | 150°C | TDS: 150°C |
| Drying Time | 10-15 minutes | TDS: 10-15 min |
| Firing Peak Temperature | 850°C | TDS: 850°C |
| Total Firing Cycle | 30 minutes (10 min at peak) | TDS: 30 min |
| Firing Atmosphere | Air (oxidizing) | TDS: air oxidizing |
| Substrate | 96% alumina | TDS: 96% alumina |
| Termination | Micromax 7780 / high-Ag conductors | TDS: 7780 termination |
Handling and Storage Recommendations
| Storage Rules | Store in tightly sealed containers in clean, stable environment at 5-30°C. | TDS: 5-30°C |
| Shelf Life | 6 months in unopened containers from date of shipment. | TDS: 6 months |
| Pre-use Preparation | Thoroughly mix prior to use. Some settling may occur during storage. | — |
| Thinning | Not normally required; use Micromax 8250 thinner sparingly for evaporative losses. | TDS: 8250 |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | MacDermid Alpha Micromax 4361 original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
| SDS | Safety Data Sheet for handling and storage | Request SDS |
Frequently Asked Questions
What is Micromax 4361?
Micromax 4361 is a high-ohm resistor paste from the 4300 Series, designed for cermet trimmers and potentiometers with 1MΩ/sq resistivity — the highest in the 4300 Series — with fast 30-minute 850°C firing per TDS specifications.
What is the resistivity of Micromax 4361?
1MΩ/sq — the highest resistance in the 4300 Series per TDS specifications.
What is the firing cycle for Micromax 4361?
A fast 30-minute firing cycle with a 10-minute peak hold at 850°C per TDS specifications.
What is the CRV performance of Micromax 4361?
CRV is less than 1% per TDS specifications.
What mesh screen is recommended for Micromax 4361?
325 mesh stainless steel screens with 10-16 μm emulsion thickness per TDS specifications.
What wiper materials are compatible with Micromax 4361?
Various wiper materials including stainless steel per TDS specifications.
What packaging options are available for Micromax 4361?
Standard 100G and 1000G containers. Bulk supply options are available upon request.
