Xylan 1424 is a waterborne/VOC-compliant, resin-bonded PTFE-based dry film lubricant coating from Whitford Corporation (now PPG) . As an authorized distributor and trader, we supply genuine materials with full traceability and direct access to official technical documentation.
Unlike Xylan 1070 (solvent-based, 3,000+ hours salt spray) or Xylan 1420 (waterborne barrier coating), Xylan 1424 is the most widely specified PTFE fastener coating globally and the North Sea offshore standard . It is a waterborne/VOC-compliant grade that delivers proven corrosion protection and friction control for demanding offshore and subsea applications .
Xylan 1424 is a single-coat, thermosetting system primarily formulated for fasteners to prevent corrosion and facilitate make-up torque . It provides the optimal balance of corrosion protection, friction control, and environmental compliance.
This coating performs reliably across a wide temperature range from -195°C to 285°C . It offers over 1,500 hours salt spray resistance when applied over zinc phosphate pretreatment , making it the go-to solution for offshore oil & gas, petrochemical, and subsea bolting applications.
Key Features of Xylan 1424 Coating
-
Waterborne/VOC Compliant – Environmentally friendly formulation meeting VOC regulations in the USA and globally
-
Superior Corrosion Protection – Over 1,500 hours salt spray resistance (ASTM B117) over zinc phosphate; up to 2,500+ hours in optimized systems
-
Controlled Low Friction – Coefficient of friction of 0.05–0.10; reduces torque by up to 70% compared to bare fasteners
-
Anti-Galling Protection – Prevents thread seizure during assembly and disassembly, especially for stainless steel and alloy bolts
-
Consistent Torque-Tension Performance – Reduced nut factor (K factor) of 0.10–0.12, ensuring uniform bolt load across flanged connections
-
Excellent Chemical Resistance – Resists mineral oils, greases, petroleum, jet fuel, Skydrol, and other hydraulic fluids
-
Single-Coat Application – Resin-bonded, thermosetting single-layer system reduces application complexity and cost
-
Wide Temperature Range – Operates from -195°C to 285°C (-319°F to 545°F)
-
Multiple Color Options – Available in orange, red, black, silver, grey, and custom colors; high visibility options for safety and traceability
-
Disassembly After Service – Bolts can be removed years after installation without cutting or heating
-
Proven in Harsh Environments – Resists acid rain, salt spray, and chemical exposure; NORSOK M-501 compliant for offshore applications
Typical Applications for Xylan 1424 Coating
| Industry | Typical Components & Considerations |
|---|---|
| Offshore Oil & Gas | Stud bolts, flanged connections, subsea fasteners – North Sea standard; 1,500+ hours salt spray; consistent torque |
| Petrochemical | Threaded fasteners, valves, pipe fittings – chemical resistance and anti-galling |
| Marine | Boat trailer fasteners, marine hardware – saltwater corrosion resistance |
| Wind Energy | High-strength bolts, tower connections – corrosion protection and torque control |
| General Industrial | Fasteners, piston casings, compressors, sliding components – friction reduction and long-term corrosion protection |
Typical Properties of Xylan 1424 Coating
| Property | Typical Value | Test Method |
|---|---|---|
| Coefficient of Friction | 0.05 – 0.10 | ASTM D1894 |
| Maximum Service Temperature | 285°C (545°F) | — |
| Minimum Service Temperature | -195°C (-319°F) | — |
| Coating Thickness | 20 – 40 μm (0.8 – 1.5 mils) | — |
| Salt Spray Resistance (over zinc phosphate) | 1,500+ hours (up to 2,500+ hours optimized) | ASTM B117 |
| Relative Density | Approx. 1.05 g/cm³ | — |
| Color | Multiple colors (orange, red, black, silver, grey) | — |
| Package Size | 20 kg pails | — |
| Shelf Life | 18 months | — |
Important Notes on Typical Data:
Values listed are typical and sourced from manufacturer data sheets. They do not constitute binding product specification.
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
Final performance depends on substrate preparation, application method, and curing conditions.
Manufacturer official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for Xylan 1424 Coating
| Step | Process |
|---|---|
| Surface Preparation | Degrease (acetone or isopropanol) → grit-blast (Sa2.5, Ra 1.5–4.0 μm) → zinc/manganese phosphate (recommended) |
| Coating Preparation | Slow-speed mechanical stirring; dilute with deionized water only |
| Application | Dip-spin (for fasteners) or conventional spray (HVLP) |
| Flash-off | Room temperature air dry |
| Curing | 290–320°C (554–608°F) for 20–30 minutes (substrate temperature) |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight. Shelf life: 18 months |
Critical Processing Warnings:
Surface Preparation: Proper surface preparation is critical for adhesion. Degrease thoroughly and grit-blast to Sa2.5 grade with Ra 1.5–4.0 μm . Zinc or manganese phosphate is recommended for steel fasteners to maximize corrosion resistance .
Coating Mixing: Use only deionized water for dilution. Never use tap water, as minerals and impurities can destabilize the coating .
Curing: Cure temperature is substrate temperature, not oven temperature. Cure time depends on part mass and oven characteristics. Always verify with test pieces .
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight.
