Xylan 1054 is a solvent-based, resin-bonded, thermosetting PTFE dry film lubricant coating from Whitford Corporation (now PPG). As an authorized distributor and trader, we supply genuine materials with full traceability and direct access to official technical documentation.
Unlike Xylan 1010 (high PTFE lubricity), Xylan 1014 (hardness-focused), and Xylan 1052 (extreme pressure with PTFE+MoS₂), Xylan 1054 uses a unique combination of MoS₂ (molybdenum disulfide) and graphite as its primary lubricants. This formulation is specifically designed for long-term lubrication and wear applications where the non-stick release and chemical resistance properties of PTFE are not required.
Xylan 1054 is engineered for applications requiring reliable wear resistance under broad conditions of pressure and speed, making it a versatile choice across multiple industrial sectors. The coating performs reliably across a wide temperature range, from cryogenic conditions up to 260°C (500°F).
Typical applications include fasteners, bearings, sliding components, valve springs, and general industrial parts requiring long-term lubrication and wear resistance.
Key Features of Xylan 1054 Coating
-
Dual Lubricant System – Uses MoS₂ and graphite as lubricants for long-term lubrication and wear resistance
-
PTFE-Free Option – Designed for applications where PTFE properties are not required
-
Excellent Wear Resistance – Provides durable lubrication under broad pressure and speed conditions
-
Good Corrosion Protection – Protects metal substrates from rust and corrosion
-
Wide Temperature Range – Suitable for cryogenic to 260°C (500°F) environments
-
Solvent-Based Formulation – Provides excellent wetting, leveling, and adhesion to properly prepared metal substrates
-
Resin-Bonded Durability – Resin-bonded lubricants stay on the job, providing long-term protection
Typical Applications for Xylan 1054 Coating
| Industry | Typical Components & Considerations |
|---|---|
| Fasteners | Bolts, nuts, screws – long-term lubrication and wear resistance |
| Bearings | Plain bearings, bushings – broad pressure and speed conditions |
| Automotive | Engine components, transmission parts – temperature stability and wear resistance |
| General Industrial | Sliding components, valve springs, mating surfaces – long-term lubrication |
Typical Properties of Xylan 1054 Coating
| Property | Typical Value | Test Method |
|---|---|---|
| Coefficient of Friction | Low and predictable | — |
| Maximum Service Temperature | Up to 260°C (500°F) | — |
| Minimum Service Temperature | -195°C (-320°F) | — |
| Coating Thickness | 15 – 25 μm | — |
| Color | Green | — |
| Shelf Life | 18 months | — |
| Package Size | 20 kg pails | — |
Important Notes on Typical Data:
Values listed are typical and sourced from manufacturer data sheets. They do not constitute binding product specification.
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
Final performance depends on substrate preparation, application method, and curing conditions.
Manufacturer official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for Xylan 1054 Coating
| Step | Process |
|---|---|
| Surface Preparation | Alkaline cleaning or acetone degreasing + grit-blast (Sa2.5 grade, Ra 3–6 μm) |
| Primer Application (Optional) | Apply Xylan® 1 or Xylan® 2 primer, dry film thickness 2.5–5 μm, cure at 380°C for 5–10 minutes |
| Topcoat Application | Apply Xylan 1054 by spray (conventional or HVLP) or dip coating |
| Curing | Cure at approximately 380°C for 15–20 minutes (substrate temperature) |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight. Shelf life: 18 months |
Critical Processing Warnings:
Surface Preparation: Proper surface preparation is critical for adhesion. Ensure surfaces are clean, dry, and properly roughened to Sa2.5 grade, Ra 3–6 μm.
Curing: Cure time depends on part mass and oven characteristics. Always verify with test pieces.
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight. Shelf life: 18 months.
Related Products
Explore Xylan Industrial Coatings – Browse all Xylan coating options
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Xylan 1054 Coating
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Xylan 1054 |
| Manufacturer Official SDS | GHS-compliant chemical safety documentation |
| Distributor Authorization Certificate | Proof of our authorized-distributor qualification, available upon request |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
Email: ruiqingchem@gmail.com
Online form: Our contact page
We reply within one working business day. Please clearly state product (Xylan 1054) and document type you require.
FAQ about Xylan 1054 Coating
Q1: What is Xylan 1054?
A: Xylan 1054 is a solvent-based, resin-bonded thermosetting PTFE dry film coating from Whitford (PPG) that uses MoS₂ and graphite as the primary lubricants. It is designed for long-term lubrication and wear applications where PTFE properties are not required.
Q2: How does Xylan 1054 differ from Xylan 1052?
A: Xylan 1052 uses a dual lubrication system of PTFE and MoS₂ for extreme pressure applications up to 150,000 psi. Xylan 1054 uses MoS₂ and graphite as lubricants and is designed for long-term wear applications when PTFE properties are not required.
Q3: How does Xylan 1054 differ from Xylan 1010 or 1014?
A: Xylan 1010 is optimized for low friction, Xylan 1014 for hardness and abrasion resistance. Xylan 1054 is formulated with MoS₂ and graphite for long-term wear resistance in applications where PTFE’s non-stick properties are not needed.
Q4: What is the maximum service temperature of Xylan 1054?
A: Xylan 1054 can withstand temperatures from cryogenic conditions up to 260°C (500°F).
Q5: What color is Xylan 1054?
A: Xylan 1054 is typically green in color.
Q6: Is primer required for Xylan 1054?
A: In most cases, Xylan 1054 requires a primer (Xylan® 1 or Xylan® 2) for optimal adhesion. The primer should be applied at 2.5–5 μm dry film thickness and cured before applying the topcoat.
