Xylan 1070 is an organic solvent-based, low-friction PTFE dry film coating from Whitford Corporation (now PPG), developed in the early 1970s primarily for coating threaded fasteners . As an authorized distributor and trader, we supply genuine materials with full traceability and direct access to official technical documentation.
Unlike Xylan 1010 (high PTFE lubricity), Xylan 1014 (hardness-focused), Xylan 1052 (extreme pressure with MoS₂), Xylan 1054 (MoS₂+graphite long-term wear), and Xylan 1058 (FEP-based mold coatings), Xylan 1070 is the most widely used general-purpose fastener coating across the Xylan portfolio . It is the industry standard for stud bolts and threaded fasteners, offering the optimal balance of friction control, corrosion protection, and cost-effectiveness.
Xylan 1070 is typically applied over a zinc phosphate or zinc plating pretreatment, forming a barrier coating system that delivers exceptional corrosion protection—up to 3,000 to 5,000 hours in neutral salt spray tests . The coating provides consistent torque-tension performance, reducing the nut factor (K factor) to approximately 0.10-0.12, compared to 0.20 for bare steel and 0.15 for moly-lubricated bolts .
The coating performs reliably across a wide temperature range, from cryogenic conditions (-195°C) up to 260°C continuously, and intermittently to 285°C . It is trusted across major industries including oil & gas, petrochemical, wind energy, and general industrial applications requiring reliable bolting connections .
Key Features of Xylan 1070 Coating
-
Superior Corrosion Protection – Delivers up to 3,000–5,000 hours salt spray protection when applied over proper pretreatments like zinc phosphate or zinc plating
-
Low & Predictable Friction – Coefficient of friction as low as 0.02–0.12, providing consistent torque-to-tension performance
-
Anti-Galling Protection – Prevents thread seizure during assembly and disassembly, especially for stainless steel and alloy bolts
-
Wide Temperature Range – Continuous service from -195°C to 260°C (-319°F to 500°F); intermittent up to 285°C (545°F)
-
Multiple Color Options – Available in blue, green, black, gray, and custom colors for product identification and color-coding
-
Resin-Bonded Durability – Thermoset fluoropolymer matrix provides durable, long-lasting protection
-
Pliability – Coating will bend freely and repeatedly without breaking
-
Solvent-Based Formulation – Provides excellent wetting, leveling, and adhesion to properly prepared metal substrates
-
Industry Standard – Most widely used Xylan fastener coating; specified by major EPC projects for bolting applications
Typical Applications for Xylan 1070 Coating
| Industry | Typical Components & Considerations |
|---|---|
| Oil & Gas | Stud bolts, nuts, flanged connections – corrosion protection, consistent torque, disassembly after years of service |
| Petrochemical | Threaded fasteners, valves – chemical resistance and anti-galling in aggressive environments |
| Wind Energy | High-strength bolts – corrosion resistance and torque control |
| General Industrial | Fasteners, bolts, nuts – general-purpose low friction and corrosion protection |
| Valves & Pipelines | Valve stem bolts, pipe fittings – reliable bolting connections under pressure |
Typical Properties of Xylan 1070 Coating
| Property | Typical Value | Test Method |
|---|---|---|
| Coefficient of Friction | Static 0.124 / Dynamic 0.047 | ASTM G99 |
| K Factor (Nut Factor) | 0.10–0.12 | — |
| Maximum Service Temperature (Continuous) | 260°C (500°F) | — |
| Maximum Service Temperature (Intermittent) | 285°C (545°F) | — |
| Minimum Service Temperature | -195°C (-319°F) | — |
| Coating Thickness | 15 – 25 μm (typical); 20–40 μm range | ASTM D7091 |
| Corrosion Resistance | 3,000 – 5,000 hours salt spray | ASTM B117 |
| Pencil Hardness | 2H – 4H | ASTM D3363 |
| Adhesion | 5B (No loss of adhesion) | ASTM D3359 |
| Dielectric Strength | 1.5 – 2.0 kV/25µ | — |
| Colors | Blue, green, black, gray, custom | — |
Important Notes on Typical Data:
Values listed are typical and sourced from manufacturer data sheets. They do not constitute binding product specification.
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
Final performance depends on substrate preparation, application method, and curing conditions.
Manufacturer official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for Xylan 1070 Coating
| Step | Process |
|---|---|
| Surface Preparation | Grit-blasting to Sa2.5 (near-white metal) per ISO 8501-1; or zinc phosphate / zinc plating pretreatment |
| Primer Application (Recommended) | Apply inorganic zinc or organic binder primer (e.g., Whitford primer 4090), cure at 150–200°C |
| Topcoat Application | Apply Xylan 1070 by spray (conventional air spray or HVLP) or dip coating |
| Curing | Cure at 220°C – 345°C (401°F – 653°F) substrate temperature |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight. Shelf life: 18 months |
Critical Processing Warnings:
Surface Preparation: Proper surface preparation is critical for adhesion and corrosion performance. For maximum corrosion resistance (3,000+ hours salt spray), apply over zinc phosphate or zinc plating pretreatment .
Cure Test: Cure completeness should be verified using Whitford test method 115B (solvent resistance test). No white precipitate or stain should appear after testing .
Adhesion Test: Perform cross-hatch tape test per ASTM D3359. Acceptance criteria: 5B classification (no loss of adhesion) .
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight. Shelf life: 18 months.
Related Products
Explore Xylan Industrial Coatings – Browse all Xylan coating options
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Xylan 1070 Coating
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Xylan 1070 |
| Manufacturer Official SDS | GHS-compliant chemical safety documentation |
| Distributor Authorization Certificate | Proof of our authorized-distributor qualification, available upon request |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
Email: ruiqingchem@gmail.com
Online form: Our contact page
We reply within one working business day. Please clearly state product (Xylan 1070) and document type you require.
FAQ about Xylan 1070 Coating
Q1: What is Xylan 1070?
A: Xylan 1070 is an organic solvent-based, low-friction PTFE dry film coating from Whitford (PPG), developed primarily for coating threaded fasteners. It is the most widely used general-purpose fastener coating, providing consistent torque control, corrosion protection, and anti-galling properties .
Q2: How does Xylan 1070 differ from Xylan 1010?
A: Xylan 1010 is optimized for low friction and abrasion resistance. Xylan 1070 is specifically formulated for threaded fasteners, with a primary focus on corrosion protection (3,000-5,000 hours salt spray), consistent torque-tension performance, and anti-galling properties .
Q3: What is the corrosion resistance of Xylan 1070?
A: When applied over proper pretreatments like zinc phosphate, Xylan 1070 delivers up to 3,000–5,000 hours of salt spray protection (ASTM B117) .
Q4: What is the operating temperature range of Xylan 1070?
A: Xylan 1070 operates continuously from -195°C to 260°C (-319°F to 500°F), and intermittently up to 285°C (545°F) .
Q5: What colors are available for Xylan 1070?
A: Xylan 1070 is available in blue, green, black, gray, and custom colors to meet color-coding and identification requirements .
Q6: What is the recommended coating thickness for Xylan 1070?
A: The typical dry film thickness is 15–25 μm, with a general range of 20–40 μm depending on application requirements .
