描述
VESTAMID E62-S3 is a heat- and light-stabilized polyether block copolyamide (PEBA) elastomer from Evonik Operations GmbH. It is a PA 12 elastomer consisting of PA 12 segments and softening polyether segments, belonging to the VESTAMID E series of thermoplastic elastomers (TPE). The material is free of volatile or migrating plasticizer.
This grade is especially developed for sport shoe soles, offering good impact strength at low temperatures. The PA12-based PEBA elastomer combines the major properties of PA 12 with elastomer characteristics, providing flexibility, high impact strength at cold temperatures, and excellent recovery.
Compared to other contending thermoplastic elastomers, PA 12 elastomers are distinguished by their low density, high resistance to chemicals and solvents, easy processability and coloring, and excellent impact strength at low temperatures. Their hardness and flexibility can be varied over a wide range, and their mechanical properties are only slightly temperature-dependent.
The material has good resistance to hydrolysis/hot water, wear/abrasion, and fatigue. It is also resistant to oils, greases, fuels, hydraulic fluids, salt solutions, and many solvents, with excellent stress crack resistance.
Typical applications include sport shoe soles, alpine ski boots, noiseless gears, and conveyor belts.
For more VESTAMID grades and technical information, please visit our Engineering Plastics product page.
Key Features
| # | Feature | Benefit |
|---|---|---|
| 1 | PA12-Based PEBA Elastomer | Combines PA12 properties with elastomer flexibility |
| 2 | Heat, UV & Light Stabilized | Maintains properties under thermal, UV, and light exposure |
| 3 | Free of Volatile/Migrating Plasticizer | No plasticizer migration concerns for sensitive applications |
| 4 | Excellent Low-Temperature Impact Strength | No break in Charpy unnotched impact tests at -30°C |
| 5 | High Tensile Modulus | 370 MPa for structural rigidity |
| 6 | Low Density | 1.03 g/cm³ – among the lowest of commercial polyamides |
| 7 | Good Chemical Resistance | Resistant to oils, greases, fuels, hydraulic fluids, and solvents |
| 8 | Hydrolysis Resistant | Good resistance to hot water and hydrolysis |
| 9 | Fatigue Resistant | Suitable for cyclic loading applications |
| 10 | Abrasion Resistant | Good wear resistance for durable components |
| 11 | Good Colorability & Printability | Can be easily colored and decorated by heat transfer printing |
| 12 | Automotive Approved | Meets FORD WSS-M4D930-A1 specification |
Typical Applications
| Industry | Typical Components & Considerations |
|---|---|
| Sport Shoe Soles | Functional elements of sports shoes – utilizing low-temperature impact strength, high modulus, and heat/light stabilization |
| Alpine Ski Boots | Ski boot components – requiring cold impact resistance and durability |
| Noiseless Gears | Gears requiring quiet operation and wear resistance |
| Conveyor Belts | Conveyor belt components – utilizing fatigue resistance and abrasion resistance |
| Automotive | Components meeting FORD WSS-M4D930-A1 specification, fuel lines, air lines, and vibration damping components |
| Industry & Building Construction | Components requiring chemical resistance and durability |
Typical Properties
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.03 g/cm³ | ISO 1183 |
| Water Absorption (Saturation, 23°C) | 1.1% | ISO 62 |
| Molding Shrinkage – Parallel | 0.60 – 1.1% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.90 – 1.4% | ISO 294-4 |
| Viscosity Number | 190 cm³/g | ISO 307 |
| MVR (240°C/2.16 kg) | 20 cm³/10 min | ISO 1133 |
| Mechanical | ||
| Tensile Modulus | 370 MPa | ISO 527-2 |
| Tensile Strength at Break | 42 MPa | ISO 527-2 |
| Tensile Stress at 50% Strain | 23 MPa | ISO 527-2 |
| Tensile Strain at Break | > 200% | ISO 527-2 |
| Tensile Creep Modulus (1000 h) | 200 MPa | ISO 899-1 |
| Shore D Hardness | 62 | ISO 868 |
| Impact | ||
| Charpy Notched Impact (23°C) | 120 kJ/m² (Partial Break) | ISO 179/1eA |
| Charpy Notched Impact (-30°C) | 8 kJ/m² (Complete Break) | ISO 179/1eA |
| Charpy Unnotched Impact (23°C) | No Break | ISO 179/1eU |
| Charpy Unnotched Impact (-30°C) | No Break | ISO 179/1eU |
| Thermal | ||
| HDT @ 1.80 MPa (Unannealed) | 45°C | ISO 75-2/A |
| HDT @ 0.45 MPa (Unannealed) | 100°C | ISO 75-2/B |
| Vicat Softening Temperature (Method A) | 165°C | ISO 306/A |
| Vicat Softening Temperature (Method B) | 110°C | ISO 306/B |
| CTE – Parallel (23-55°C) | 2.0 × 10⁻⁴ /°C | ISO 11359-2 |
| CTE – Transverse (23-55°C) | 2.0 × 10⁻⁴ /°C | ISO 11359-2 |
| Electrical | ||
| Surface Resistivity | 1.0 × 10¹⁴ ohms | IEC 60093 |
| Volume Resistivity | 1.0 × 10¹² ohm·cm | IEC 60093 |
| Dielectric Strength | 39 kV/mm | IEC 60243-1 |
| Relative Permittivity (100 Hz) | 9.0 | IEC 60250 |
| Relative Permittivity (1 MHz) | 4.0 | IEC 60250 |
| Dissipation Factor (100 Hz) | 0.10 | IEC 60250 |
| Dissipation Factor (1 MHz) | 0.12 | IEC 60250 |
| Comparative Tracking Index (CTI) | 600 V | IEC 60112 |
| Flammability | ||
| Flammability @ 1.6 mm | HB | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for VESTAMID E62-S3.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Pigmentation – The use of colorants or pigmentation may affect property values.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for VESTAMID E62-S3. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Suggested Max Moisture | ≤ 0.10% |
| Processing (Melt) Temperature | 190 – 230°C |
| Optimum Melt Temperature | 200°C |
| Optimum Mold Temperature | 35°C |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at ≤ 30°C |
Critical Processing Warnings
⚠️ Drying Requirement – VESTAMID E62-S3 should be dried prior to processing to ensure maximum part quality. Suggested maximum moisture content is ≤ 0.10%.
⚠️ Processing Temperature – The recommended processing (melt) temperature range is 190–230°C. Avoid exceeding 230°C to prevent material degradation.
⚠️ Pigmentation – The use of colorants or pigmentation may affect property values. Validate performance with colored batches for critical applications.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Comparison: VESTAMID E62-S3 vs. VESTAMID E62-S1
| Feature | VESTAMID E62-S3 | VESTAMID E62-S1 |
|---|---|---|
| Material Type | PEBA Elastomer | PEBA Elastomer |
| Shore D Hardness | 62 | 62 |
| Key Feature | Heat, UV & light stabilized | Heat stabilized |
| Tensile Modulus | 370 MPa | 389 MPa |
| Tensile Strength | 42 MPa | 23 MPa |
| Density | 1.03 g/cm³ | 1.03 g/cm³ |
| MVR (240°C/2.16 kg) | 20 cm³/10 min | 20 cm³/10 min |
| Processing Temp | 190 – 230°C | 190 – 230°C |
| Primary Application | Sport shoe soles, alpine ski boots | Sport shoe soles, conveyor belts |
Related Products
-
Engineering Plastics – Browse all engineering plastic materials
-
VESTAMID E62-S1 – Heat stabilized PEBA elastomer for sport shoe soles
-
VESTAMID E55-S3 – Medium hardness PEBA elastomer for sport shoe soles and alpine ski boots
-
VESTAMID E47-S3 – Lower hardness PEBA elastomer for flexible applications
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (VESTAMID E62-S3) and document type you require.
FAQ
Q1: What is VESTAMID E62-S3?
A: VESTAMID E62-S3 is a heat- and light-stabilized polyether block copolyamide (PEBA) elastomer from Evonik, based on PA 12 segments and polyether segments, specifically developed for sport shoe soles.
Q2: Is VESTAMID E62-S3 a PA12 grade?
A: It is a PA12-based PEBA elastomer (polyether block copolyamide), not a standard PA12 compound. It combines PA12 properties with elastomer flexibility.
Q3: What are the key features?
A: PA12-based PEBA elastomer; heat, UV & light stabilized; free of volatile/migrating plasticizer; excellent low-temperature impact strength; high tensile modulus (370 MPa); low density (1.03 g/cm³); good chemical resistance; hydrolysis resistant; fatigue resistant; abrasion resistant.
Q4: What are the typical applications?
A: Sport shoe soles, alpine ski boots, noiseless gears, conveyor belts, automotive fuel lines, air lines, and components requiring chemical resistance and vibration damping.
Q5: What is the hardness?
A: Shore D 62 (ISO 868).
Q6: What is the density?
A: 1.03 g/cm³ (ISO 1183).
Q7: What is the tensile modulus?
A: 370 MPa (ISO 527-2).
Q8: What is the tensile strength?
A: 42 MPa at break (ISO 527-2).
Q9: What is the elongation at break?
A: > 200% (ISO 527-2).
Q10: What is the low-temperature impact performance?
A: Charpy unnotched impact tests show “No Break” at both 23°C and -30°C (ISO 179/1eU).
Q11: What is the recommended processing temperature?
A: Processing (melt) temperature: 190–230°C. Optimum mold temperature: 35°C.
Q12: What is the water absorption?
A: 1.1% at saturation, 23°C (ISO 62).
Q13: What regions is this grade available in?
A: Europe and North America.
Q14: Is this material free of plasticizer?
A: Yes, the material is free of volatile or migrating plasticizer.
Q15: What is the MVR?
A: 20 cm³/10 min (240°C/2.16 kg, ISO 1133).
Q16: Is VESTAMID E62-S3 hydrolysis resistant?
A: Yes, it exhibits resistance to hydrolysis/hot water.
Q17: What is the CTI?
A: 600 V (IEC 60112).
Q18: What is the shelf life?
A: At least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Q19: Is VESTAMID E62-S3 suitable for injection molding?
A: Yes, it is processed by injection molding.
Q20: What is the molding shrinkage?
A: 0.60–1.1% parallel and 0.90–1.4% transverse (ISO 294-4).
