PLEXIGLAS 7N PMMA Molding Compound High Heat Optical Grade
Material: PMMA (Acrylic)
Light Transmission: 92%
Refractive Index: 1.49
Vicat: 103°C
Packing: 25kg bag / 500kg box
PLEXIGLAS 7N is an amorphous thermoplastic PMMA molding compound that combines excellent optical properties with high heat resistance and outstanding mechanical performance. With a Vicat softening temperature of 103°C, stress at break of 73 MPa, and light transmission of 92%, PLEXIGLAS 7N delivers superior performance for demanding optical and technical applications. It is AMECA listed, making it particularly suitable for automotive lighting and other regulated optical components.
PLEXIGLAS 7N offers excellent flow characteristics (MVR 6 cm³/10min at 230°C/3.8kg), good moldability, and exceptional optical clarity with haze below 0.5%. Its high heat deflection temperature (HDT 100°C at 0.45 MPa) ensures dimensional stability in elevated temperature environments. Typical applications include automotive lighting, optical waveguides, luminaire covers, instrument cluster covers, optical lenses, and displays. With free colorability due to crystal clarity and excellent weather resistance, PLEXIGLAS 7N is a versatile choice for high-performance optical and technical components.
Genuine Röhm PLEXIGLAS Imported Stock and Technical Support
We supply stable spot inventory of genuine PLEXIGLAS 7N PMMA molding compound. Official TDS, batch COA, and AMECA documentation are available for automotive, optical, and technical injection molding applications.
Request PLEXIGLAS 7N Quotation, TDS, and Sample
Complete TDS, COA, and technical documentation available
Core Advantages of PLEXIGLAS 7N PMMA Molding Compound
- High heat resistance: Vicat 103°C — improved thermal stability vs PLEXIGLAS 6N
- High light transmission: 92% — excellent optical clarity with haze <0.5%
- AMECA listed — certified for automotive lighting and optical applications
- High mechanical strength — tensile modulus 3200 MPa, stress at break 73 MPa
- High heat deflection: HDT 100°C (0.45 MPa) — excellent dimensional stability
- Refractive index: 1.49 — ideal for optical and lens applications
- Excellent flow: MVR 6 cm³/10min — good moldability for complex geometries
- Excellent weather resistance — UV stable for outdoor and long-term use
Main Applications
- Automotive lighting — headlamp lenses, interior lighting, signal lamps (AMECA compliant)
- Optical waveguides — light transmission components
- Instrument cluster covers — dashboard display protection
- Optical lenses — precision optical components
- Displays — screen covers and display windows
- Luminaire covers — lighting diffusers and covers
Full Technical Parameters
| Property | Typical Value | Test Method |
| Material Type | Amorphous thermoplastic (PMMA) | — |
| Density | 1.19 g/cm³ | ISO 1183 |
| Tensile Modulus (1mm/min) | 3200 MPa | ISO 527 |
| Stress at Break (5mm/min) | 73 MPa | ISO 527 |
| Strain at Break (5mm/min) | 3.5% | ISO 527 |
| Charpy Impact Strength (23°C) | 20 kJ/m² | ISO 179/1eU |
| Vicat Softening Temperature (B/50) | 103°C | ISO 306 |
| Glass Transition Temperature | 110°C | ISO 11357 |
| HDT (0.45 MPa) | 100°C | ISO 75 |
| HDT (1.8 MPa) | 95°C | ISO 75 |
| CTE (0-50°C) | 8 × 10⁻⁵ /°C | ISO 11359 |
| MVR (230°C/3.8kg) | 6 cm³/10min | ISO 1133 |
| Luminous Transmittance (d=3mm) | 92% | ISO 13468-2 |
| Haze | <0.5% | ASTM D1003 |
| Refractive Index (589nm/23°C) | 1.49 | ISO 489 |
| Flammability (UL 94, 1.5mm) | HB | IEC 60695-11-10 |
| Fire Class | E | DIN EN 13501-1 |
| AMECA Listing | Yes | — |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Recommended Processing Conditions
| Parameter | Recommended Value |
| Predrying Temperature | ≤93°C |
| Predrying Time (Desiccant Dryer) | 2-3 hours |
| Melt Temperature | 220-260°C |
| Mold Temperature (Injection Molding) | 55-85°C |
| Screw Type | 3-zone general purpose screw for engineering thermoplastics |
Handling and Storage Recommendations
| Storage Rules | Store in dry, cool conditions away from direct sunlight and heat sources. |
| Packaging | 25kg polyethylene bags or 500kg boxes with PE lining. |
| Predrying | Dry at ≤93°C for 2-3 hours before processing. Moisture can cause surface defects. |
| Operation Protection | Follow standard safety practices for handling thermoplastic pellets. Use appropriate PPE during processing. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | PLEXIGLAS 7N original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
Frequently Asked Questions
What is PLEXIGLAS 7N?
PLEXIGLAS 7N is an amorphous thermoplastic PMMA molding compound with high heat deflection temperature, very good mechanical properties, and excellent optical clarity. It is AMECA listed for automotive lighting applications.
What is the Vicat softening temperature of PLEXIGLAS 7N?
PLEXIGLAS 7N has a Vicat softening temperature (B/50) of 103°C, higher than PLEXIGLAS 6N (96°C), offering improved heat resistance for demanding applications.
What is the light transmission of PLEXIGLAS 7N?
PLEXIGLAS 7N has a luminous transmittance of 92% (3mm thickness), haze <0.5%, and a refractive index of 1.49, making it ideal for optical applications.
What is the difference between PLEXIGLAS 6N and 7N?
PLEXIGLAS 7N offers higher heat resistance (Vicat 103°C vs 96°C), higher strength (73 MPa vs 67 MPa), lower MVR (6 vs 12), and is AMECA listed for automotive optical applications.
What applications is PLEXIGLAS 7N suitable for?
PLEXIGLAS 7N is ideal for automotive lighting, optical waveguides, luminaire covers, instrument cluster covers, optical lenses, and displays requiring higher heat resistance and AMECA compliance.
What are the recommended processing conditions for PLEXIGLAS 7N?
Recommended conditions: predrying at ≤93°C for 2-3 hours, melt temperature 220-260°C, mold temperature 55-85°C. Use 3-zone general purpose screws for engineering thermoplastics.
Is PLEXIGLAS 7N AMECA listed?
Yes. PLEXIGLAS 7N is AMECA listed, making it suitable for automotive lighting and optical applications requiring regulatory compliance.
Related PLEXIGLAS Products
Compare PLEXIGLAS molding compounds for different application requirements.
| Product | Material | Vicat B/50 | Stress at Break | MVR | AMECA | Core Application |
| PLEXIGLAS 7N | PMMA | 103°C | 73 MPa | 6 | ✅ | Automotive lighting, high heat |
| PLEXIGLAS 6N | PMMA | 96°C | 67 MPa | 12 | ❌ | Optical injection molding |
