3M Novec 1700 Electronic Grade Coating Moisture Corrosion Protection
Type: Electronic Grade Fluoropolymer
Solids: 2.0 wt%
Dielectric Constant: 3.2
VOC Status: Exempt
Packing: 5KG / 20KG drum
3M Novec 1700 Electronic Grade Coating is a single-component fluorinated polymer solution designed for moisture and corrosion protection of printed circuit boards and electronic components. Diluted in 3M Novec 7100DL Engineered Fluid, this low-viscosity, low-surface-tension coating solution dries to an ultrathin, transparent film with excellent hydrophobic and oleophobic properties. It provides effective repellency against water, hydrocarbons, silicones, photoresists, and corrosive gases, making it an ideal choice for protecting sensitive electronics in harsh environments.
Novec 1700 requires no curing — it dries quickly at room temperature and can be handled in under two minutes. The coating adheres well to a wide range of substrates including metals, glass, ceramics, polymers, and laminates, and offers solder-through repairability for easy rework. With a dielectric constant of 3.2 at 1 kHz and dielectric breakdown strength of 2000 V/mil, it provides excellent electrical insulation. Environmentally, it is nonflammable, non-ozone-depleting, low in toxicity, low GWP, RoHS compliant, and VOC exempt (per U.S. EPA). Its long shelf life (4 years) and ease of application by spray, dip, brush, or selective dispensing make it a cost-effective alternative to traditional conformal coatings.
Genuine 3M Imported Stock and Technical Support
We supply stable spot inventory of genuine 3M Novec 1700 electronic grade coating. Official TDS, SDS, and batch COA documents are available for PCB protection, anti-migration, and anti-corrosion applications.
Request Novec 1700 Coating Quotation, TDS, SDS, and Sample
Complete SDS, COA, and technical documentation available
Core Advantages of 3M Novec 1700 Electronic Grade Coating
- Ultrathin transparent protection — 0.1-1.0 micron coating preserves component aesthetics and heat dissipation
- Hydrophobic and oleophobic — water contact angle 105°, hexadecane angle 65°, repels liquids and contaminants
- No curing required — dries at room temperature in minutes, no post-application bake
- Solder-through repairability — components can be reworked without removing the coating
- Excellent dielectric properties — dielectric constant 3.2, breakdown strength 2000 V/mil
- VOC exempt (U.S. EPA) — environmentally compliant for electronics manufacturing
- Low GWP and zero ODP — sustainable alternative to traditional solvent-borne coatings
- RoHS compliant and halogen-free — meets global environmental regulations
Main Applications
- PCB moisture and corrosion protection — for consumer, industrial, and automotive electronics
- Anti-migration coating — prevents migration of lubricants and photoresists in displays and spindle motors
- Anti-stiction and anti-wetting — for MEMS, sensors, and optical components
- Conformal coating alternative — easy-to-apply replacement for traditional conformal coatings
- Protection against corrosive gases — for components exposed to harsh industrial or marine environments
Full Technical Parameters
| Property | Typical Value | Test Method |
| Coating Type | Fluorinated polymer in HFE solvent | — |
| Solids Content | 2.0 wt% | — |
| Appearance (Solution) | Clear colorless liquid | Visual |
| Coating Appearance | Transparent, colorless | Visual |
| Density (23°C) | 1.5 g/ml | ASTM D891 |
| Viscosity | 0.91 cP | — |
| Boiling Point | 61°C | ASTM D1120-94 |
| Flash Point | None | Closed cup |
| Coating Thickness | 0.1-1.0 microns | — |
| Glass Transition Temperature | 44.5°C | DSC |
| Water Contact Angle (static) | 105° | Goniometer |
| Hexadecane Contact Angle | 65° | Goniometer |
| Refractive Index | 1.39 | — |
| Dielectric Constant (@1kHz, 30% RH) | 3.2 | ASTM D150 |
| Dissipation Factor (@1kHz, 30% RH) | 0.002 | ASTM D150 |
| Dielectric Breakdown Strength | 2000 V/mil | ASTM D149 |
| Thermal Conductivity | 0.1 W/m·K | — |
| CTE (TMA) | 70 μm/(m·°C) | TMA |
| Thermal Stability | Up to 175°C for 24 hours | MIL-B-81744A |
| Solder-Through Repairability | Yes | — |
| Flammability | UL 94 V-0 | UL 94 |
| VOC Status | Exempt (U.S. EPA) | — |
| RoHS | Compliant | — |
| Shelf Life | 4 years | — |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Handling and Storage Recommendations
| Storage Conditions | Store at 16-27°C (60-80°F) and <60% R.H. in original unopened containers. |
| Shelf Life | 4 years from date of manufacture when stored as recommended. |
| Application Precautions | Keep water out of coating bath. Surfaces must be clean and dry before application. |
| Thermal Limits | Do not heat solution above 150°C; dry film should not exceed 225°C to avoid decomposition. |
| Removal | Use 3M Novec 72DA Engineered Fluid (preferred) or Novec 7200 Engineered Fluid. |
| Operation Protection | Use with adequate ventilation and appropriate PPE. Read SDS before use. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | 3M Novec 1700 original factory technical data sheet | Request TDS |
| SDS | Safety data sheet covering transport, storage, and handling guidelines | Request SDS |
| COA | Batch-specific certificate of analysis with solids and purity specifications | Request COA |
Frequently Asked Questions
What is 3M Novec 1700 Electronic Grade Coating?
3M Novec 1700 is a single-component fluorinated polymer coating diluted in Novec 7100DL solvent. It provides ultrathin, transparent moisture and corrosion protection for printed circuit boards and electronic components with excellent hydrophobic and oleophobic properties.
How is Novec 1700 coating applied?
Novec 1700 can be applied by spray, dip, brush, or selective dispensing. It dries quickly at room temperature without curing, and the film can be handled in under two minutes.
What is the coating thickness of Novec 1700?
Novec 1700 provides an ultrathin coating with thickness ranging from 0.1 to 1.0 microns, depending on the application method.
Is Novec 1700 coating repairable?
Yes. Novec 1700 allows solder-through repairability, meaning coated components can be reworked and re-soldered without removing the coating.
Is Novec 1700 coating removable?
Yes. The coating can be removed using 3M Novec 72DA Engineered Fluid (preferred) or Novec 7200 Engineered Fluid.
What is the shelf life of Novec 1700 coating?
Novec 1700 has a shelf life of four years from date of manufacture when stored in original unopened container at 16-27°C and <60% RH.
Is Novec 1700 coating environmentally friendly?
Yes. Novec 1700 is nonflammable, non-ozone-depleting, low in toxicity, low GWP, RoHS compliant, and VOC exempt per U.S. EPA.
Related 3M Novec Products
Compare 3M Novec electronic grade coatings and engineered fluids.
| Product | Type | Solids | Application |
| Novec 1700 | Electronic Grade Coating | 2.0 wt% | PCB moisture/corrosion protection |
| Novec 7100DL | Engineered Fluid | — | High purity solvent |
| Novec 72DA | Cleaning Solvent | — | Defluxing, coating removal |
Get 3M Novec 1700 Coating Bulk Pricing and Technical Support
We supply genuine 3M Novec 1700 electronic grade coating for PCB protection, anti-migration, and anti-corrosion applications. Contact us for bulk pricing, sample availability, technical documents, and application support.
Request Novec 1700 Coating Technical Details
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
