Galden HT80 80 °C Low Viscosity PFPE Heat Transfer Fluid
Material: PFPE (Perfluoropolyether)
Boiling Point: 80℃
Pour Point: -110℃
Viscosity (25℃): 0.570 cSt
Packing: 5 KG / drum
Galden HT80 is an ultra-low-viscosity perfluoropolyether (PFPE) heat transfer fluid within the Galden HT series. It delivers the second-lowest viscosity in the HT series at 0.570 cSt and a pour point of -110 °C. Produced by Syensqo, formerly Solvay, this inert, dielectric and non‑flammable fluid has a boiling point of 80 °C. It offers an excellent balance of flow performance and low-temperature capability for medium-temperature thermal management tasks.
Galden HT80 provides exceptional flow characteristics when compared with higher‑viscosity HT90 (1.50 cSt) and HT110 (0.770 cSt). Its -110 °C pour point is the second-lowest in the HT series, after HT55, enabling reliable pumpability even under extreme cold conditions. This makes Galden HT80 an ideal choice for systems that require near-ultra-low viscosity and dependable cold‑start operation at medium temperatures up to 80 °C.
🔹 Genuine Syensqo Imported Stock & Heat Transfer Support
We supply stable spot inventory of genuine Galden HT80 PFPE heat transfer fluid. Complete official TDS, SDS and batch COA documents are available for semiconductor, chemical, pharmaceutical, and electronics cooling applications. Contact us for competitive bulk pricing and technical guidance on heat transfer system design.
📩 Request Galden HT80 Quotation, TDS & Sample
✅ Complete SDS & customs clearance documents provided
Core Advantages of Galden HT80 PFPE Heat Transfer Fluid
- Second-lowest viscosity (0.570 cSt) in the entire HT series — exceptional flow and thermal response
- Second-lowest pour point (-110 °C) in the entire HT series — excellent extreme-low-temperature pumpability
- 80 °C boiling point — ideal for medium-temperature heat transfer applications
- Volume resistance of 1.0×10¹⁵ ohms·cm for safe energized cooling
- Low surface tension (16 dyne/cm) for complete wetting and heat transfer
- Non-flammable and chemically inert for hazardous environments
- 430 amu low molecular weight — fastest heat transfer response in the HT series after HT55
Main Applications
- Semiconductor processing and manufacturing equipment
- Chemical and pharmaceutical temperature control systems
- Vapor phase heating and thermal management
- Transformer cooling and high-voltage equipment
- Supercomputer and data center liquid cooling
- Recirculating chiller systems
- Nuclear and high-reliability thermal management applications
Full Technical Parameters (Syensqo Official Data)
| Property | Typical Value | Test Condition |
| Base Material | Perfluoropolyether (PFPE) | — |
| Visual Appearance | Clear Colorless Liquid | Ambient 25℃ |
| Boiling Point | 80℃ | Standard Atmosphere |
| Pour Point | -110℃ | ASTM D97 |
| Density (25℃) | 1.69 g/cm³ | 25℃ |
| Average Molecular Weight | 430 amu | GPC Test |
| Kinematic Viscosity (25℃) | 0.570 cSt | 25℃ |
| Surface Tension (25℃) | 16 dyne/cm | 25℃ |
| Vapor Pressure (25℃) | 105 torr | 25℃ |
| Heat of Vaporization | 17.0 cal/g | At Boiling Point |
| Specific Heat Capacity (25℃) | 0.23 cal/g/℃ | 25℃ |
| Thermal Conductivity (25℃) | 0.065 W/m/K | 25℃ |
| Solubility of Air | 26.0 ml gas/100ml liquid | — |
| Solubility of Water | < 10.0 wppm | — |
| Refractive Index | 1.28 | — |
| Dielectric Constant (25℃) | 1.89 | ASTM D150 |
| Dielectric Strength (2.54mm gap, 25℃) | 40 kV | ASTM D149 |
| Volume Resistivity (25℃) | 1.0×10¹⁵ ohms·cm | ASTM D257 |
| Dissipation Factor (1 kHz) | 2.0×10⁻⁴ | ASTM D150 |
Note: All listed figures are typical lab test reference values instead of binding factory specifications. Complete independent qualification testing is required before mass production deployment.
Handling and Storage Recommendations
| Storage Rules | Store sealed original containers in a dry, well-ventilated area away from heat sources and direct sunlight |
| Forbidden Environments | Avoid exposure to open flames, strong oxidizing agents and reactive metal powders |
| Operation Protection | Maintain adequate ventilation; wear nitrile protective gloves and anti-splash safety goggles during handling |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | Galden HT80 original factory technical data sheet | Request TDS |
| SDS | Safety data sheet covering transport, storage and handling guidelines | Request SDS |
| COA | Batch specific certificate of analysis for incoming goods inspection | Request COA |
Frequently Asked Questions
How does Galden HT80 compare with other Galden HT series fluids?
Galden HT80 offers the second-lowest viscosity (0.570 cSt) and the second-lowest pour point (-110 °C) in the entire HT series, after HT55. It provides a higher boiling point (80 °C) than HT55, making it ideal for medium-temperature applications that require near-ultra-low viscosity and excellent low-temperature performance.
What makes Galden HT80 unique in the HT series?
Galden HT80 combines ultra-low viscosity (0.570 cSt) with an exceptionally low pour point of -110 °C. It is the lowest viscosity HT grade with a boiling point above 70 °C, offering excellent flow and low-temperature pumpability for medium-temperature thermal management.
What is the boiling point of Galden HT80?
Galden HT80 has a boiling point of 80 °C. Its kinematic viscosity is 0.570 cSt at 25 °C. These properties deliver excellent flow and heat transfer performance for medium-temperature applications.
Is Galden HT80 suitable for direct contact with electronics?
Yes. Galden HT80 is inert, dielectric and non-flammable. It offers volume resistance of 1.0×10¹⁵ ohms·cm, dielectric strength of 40 kV and dielectric constant of 1.89. These properties ensure safe operation with sensitive electronic equipment.
What is the recommended storage condition for Galden HT80?
Store sealed original containers in a dry, well-ventilated area away from heat sources and direct sunlight. Keep containers tightly closed when not in use to prevent contamination.
What technical documents are available for Galden HT80?
We supply original factory TDS, SDS and batch COA. These documents support heat transfer system qualification and quality assurance.
Related Galden HT Series Heat Transfer Fluids
Compare Galden HT series heat transfer fluids for different temperature and viscosity requirements.
| Product Grade | Boiling Point | Viscosity (25℃) | Pour Point | Core Application |
| Galden HT55 | 55℃ | 0.45 cSt | < -125℃ | Ultra Low Viscosity Cooling |
| Galden HT80 | 80℃ | 0.570 cSt | -110℃ | Near-Ultra Low Viscosity Medium Temperature |
| Galden HT90 | 90℃ | 1.50 cSt | -95℃ | Medium Temperature Heat Transfer |
| Galden HT110 | 110℃ | 0.770 cSt | -100℃ | Low Viscosity Medium Temperature |
| Galden HT170 | 170℃ | 1.80 cSt | -97℃ | Low Viscosity High Temperature |
| Galden HT200 | 200℃ | 2.40 cSt | -85℃ | Balanced Performance Grade |
| Galden HT270 | 270℃ | 14.0 cSt | — | Ultra-High Temperature Heat Transfer |
Get Galden HT80 Bulk Pricing & Heat Transfer Support
We stock genuine Syensqo Galden HT80 PFPE heat transfer fluid for medium-temperature thermal management applications. Reach out for competitive pricing, lab trial samples and complete technical certification files.
Request Galden HT80 Heat Transfer Fluid Technical Details
Disclaimer: All technical figures displayed are lab reference data and not legally binding product specifications. Buyers must carry out independent compatibility and cycle testing prior to bulk order placement. Minor performance deviation may exist across different production batches.
