描述
NORYL CN1134 Resin is a 20% mineral and glass fiber reinforced blend of polyphenylene ether (PPE) and polystyrene (PS). Manufactured by SABIC, this high modulus, injection moldable grade contains non-brominated, non-chlorinated flame retardant and carries a UL94 flame rating of V1 at 1.5mm.
NORYL CN1134 Resin exhibits good dimensional stability, low moisture absorption, and high rigidity. It is an excellent candidate for printer chassis and electric vehicle battery (EV) applications. This product does not contain PFAS intentionally added during the manufacturing process. Physical property data is determined using test methods established by ASTM International and ISO, the globally recognized standards organizations.
For more NORYL grades and technical information, please visit our PPO/PPE product page.
Key Features of NORYL CN1134 Resin
-
20% Mineral & Glass Fiber Reinforced – Enhanced stiffness and dimensional stability
-
High Modulus – Excellent rigidity for structural applications
-
Non-Halogenated Flame Retardant – Non-brominated, non-chlorinated system
-
UL94 V-1 Rated – Flame rating at 1.5mm thickness
-
Good Dimensional Stability – Precise part geometry with low warpage
-
Low Moisture Absorption – One of the lowest water absorption rates among engineering thermoplastics
-
High Rigidity – Suitable for structural and load-bearing components
-
Low Specific Gravity – Lightweight compared to many other engineering plastics
-
Amorphous – Low shrinkage characteristics
-
Hydrolytic Stability – Resists degradation in wet environments
-
No PFAS Intentionally Added
Typical Applications for NORYL CN1134 Resin
| Industry | Typical Components & Considerations |
|---|---|
| Electrical & Electronics | Printer chassis, office machines, ATM components, mobile phones, computers, tablets |
| Automotive | Electric vehicle (EV) battery components, under-the-hood applications |
| Industrial | Electrical components, document handling equipment |
| Drones | Structural components |
Typical Properties of NORYL CN1134 Resin
| Property | Value | Test Method |
|---|---|---|
| Specific Gravity | 1.23 g/cm³ | ASTM D792 |
| Water Absorption (23°C/24hrs) | 0.07% | ASTM D570 |
| Mold Shrinkage, Flow (3.2mm) | 0.25 – 0.35% | SABIC Method |
| Melt Flow Rate (300°C/2.16kg) | 22 g/10 min | ASTM D1238 |
| Tensile Stress, Yield | 98 MPa | SABIC – Japan Method |
| Tensile Strain, Break | 7% | SABIC – Japan Method |
| Flexural Modulus | 5880 MPa | ASTM D790 |
| Flexural Stress | 137 MPa | ASTM D790 |
| Notched Izod Impact (23°C) | 68 J/m | ASTM D256 |
| HDT, 1.82 MPa (6.4mm, unannealed) | 106°C | ASTM D648 |
| CTE (-30°C to 30°C) | 0.000025 – 0.000035 1/°C | TMA |
| Relative Temp Index, Elec | 65°C | UL 746B |
| Flammability | V-1 (≥1.5mm) | UL 94 |
| UL Yellow Card Link | E207780-228541 | UL |
Important Notes on Typical Data:
Values listed are typical and sourced from manufacturer data sheets. They do not constitute binding product specification.
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
Final performance depends on processing conditions and part design.
Manufacturer official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for NORYL CN1134 Resin
| Step | Process |
|---|---|
| Drying | Dry at 80 – 100°C for 2 – 4 hours prior to processing |
| Melt Temperature | 270 – 300°C |
| Nozzle Temperature | 280 – 300°C |
| Front – Zone 3 Temperature | 280 – 300°C |
| Middle – Zone 2 Temperature | 270 – 290°C |
| Rear – Zone 1 Temperature | 260 – 280°C |
| Mold Temperature | 70 – 90°C |
| Back Pressure | 0.5 – 1.2 MPa |
| Screw Speed | 40 – 80 rpm |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings:
Drying: Proper drying is critical to prevent hydrolysis and achieve optimal mechanical properties.
Injection Molding: NORYL CN1134 is specifically designed for injection molding.
Storage: Store in original, sealed packaging in a cool, dry place away from direct sunlight.
Related Products
Explore Engineering Plastics – Browse all engineering plastic materials
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for NORYL CN1134 Resin
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of NORYL CN1134 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| UL Yellow Card | E207780-228541 – UL safety certification |
Request any document above by:
Email: ruiqingchem@gmail.com
Online form: Our contact page
We reply within one working business day. Please clearly state product (NORYL CN1134) and document type you require.
FAQ about NORYL CN1134 Resin
Q1: What is NORYL CN1134?
A: NORYL CN1134 is a 20% mineral and glass fiber reinforced blend of polyphenylene ether (PPE) and polystyrene (PS) from SABIC. It is a high modulus, injection moldable grade with non-halogenated flame retardancy and UL94 V-1 rating at 1.5mm.
Q2: What are the key features of NORYL CN1134?
A: It offers high rigidity, good dimensional stability, low moisture absorption, non-brominated/non-chlorinated flame retardancy, UL94 V-1 rating, and low specific gravity.
Q3: What are the typical applications for NORYL CN1134?
A: Typical applications include printer chassis, office machines, electric vehicle (EV) battery components, automotive under-the-hood parts, mobile phones, computers, and tablets.
Q4: What is the flame rating of NORYL CN1134?
A: UL94 V-1 at 1.5mm thickness.
Q5: What is the recommended drying condition for NORYL CN1134?
A: Dry at 80–100°C for 2–4 hours prior to processing.
Q6: What is the recommended melt temperature for NORYL CN1134?
A: 270–300°C.
Q7: What forming process is used for NORYL CN1134?
A: Injection molding.
Q8: Is NORYL CN1134 halogen-free?
A: Yes, it contains non-brominated, non-chlorinated flame retardant.
Q9: Does NORYL CN1134 contain PFAS?
A: No, this product does not contain PFAS intentionally added during the manufacturing process.
Q10: What is the lead time for orders?
A: Regular orders ship within 7-10 working days after payment confirmation. Large-volume orders can be negotiated separately.
CTA (Call to Action)
Ready to order NORYL CN1134?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (printer chassis, EV battery, electronics, etc.)
-
Document requirement (TDS, SDS, COA, UL docs, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, manufacturer official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us – ruiqingchem@gmail.com
-
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original manufacturer typical values for NORYL CN1134. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on processing conditions and part design. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for product failure caused by improper processing or improper usage. Always reference the latest manufacturer official TDS of NORYL CN1134 as the definitive specification.
