Micromax 0001 Thick Film Chip Resistor Paste, ESD Stable, Cadmium Free
Type: Chip Resistor Paste
Pack: 100G / 1000G
Viscosity: 80-180 Pa.s
Firing: 850°C / 30 min
Mesh: 250-325
Shelf Life: 6 months
Micromax 0001 provides excellent ESD stability, tightly controlled TCR and fast firing at 850°C — developed for chip resistor manufacturing and compatible with high silver termination materials.
Micromax 0001 thick film chip resistor paste is formulated for mass production of chip resistors. It maintains stable electrical performance to support cost optimization, miniaturized resistor designs and reliable process matching with high silver termination materials. Key strengths include superior ESD resistance, consistent TCR, low Quan-Tech noise and stable performance through thermal cycling.
This resistor paste can be homogeneously blended with adjacent product grades to achieve a wide resistance range without deteriorating electrical properties. Formulated for high-precision screen printing up to 30 cm/sec, it allows co-firing with matched termination materials at a peak temperature of 850°C. The cadmium-free, nickel-free and phthalate-free formulation meets global environmental standards including RoHS and REACH. Standard packaging options are 100G and 1000G.
Genuine Micromax Imported Stock and Technical Support
We hold stable spot inventory of authentic Micromax 0001 chip resistor paste. Original factory TDS and batch COA can be provided for electronic component manufacturing projects.
Request Sample, TDS & Quotation
Complete TDS, COA, and regulatory documentation available
Core Advantages of Micromax 0001
- Excellent ESD stability — robust electrostatic discharge protection for finished chip resistors
- Tightly controlled TCR — consistent resistance output across temperature fluctuations
- Fast firing profile — 850°C peak with 30-minute full cycle for higher production throughput
- High resolution printing — optimized for 250-325 mesh at printing speeds up to 30 cm/sec
- High silver termination compatible — validated for Ag/Pd termination systems
- Fully blendable — broad resistance coverage without sacrificing electrical performance
- Excellent thermal cycle stability — reliable operation under repeated temperature cycling
- RoHS, REACH compliant; Cadmium/Nickel/Phthalate free — satisfies international environmental compliance rules
Main Applications
- Chip Resistors — thick film chip resistor mass manufacturing
- Hybrid Circuits — resistor networks inside hybrid microcircuits
- Surface Mount Devices — SMD resistor component production
- Automotive Electronics — resistors requiring reliable thermal cycle endurance
Full Technical Parameters
| Property | Typical Value | Test / Reference |
| Product Type | Thick film chip resistor paste | — |
| Application | Chip resistor manufacturing | — |
| Packaging Specification | 100G, 1000G | Standard packing |
| Viscosity (Brookfield HAT 10 rpm) | 80-180 Pa.s | SC4-14/6R, 25°C |
| Recommended Mesh | 250-325 mesh | — |
| Emulsion Thickness | 10-15 μm | — |
| Dried Film Thickness | 18-22 μm | Avoid >22 μm for laser trimmability |
| Printing Speed | Up to 30 cm/sec | — |
| Firing Peak Temperature | 850°C | 30 min total, 10 min at peak |
| ESD Stability | Excellent | 100pF / 1500Ω network |
| TCR Control | Well controlled | 25°C to 125°C / -55°C |
| Thermal Cycle Stability | Excellent | — |
| Termination Compatibility | High silver terminations (Micromax 5426 Ag/Pd) | — |
| Substrate Compatibility | 96% alumina, Micromax QM44 dielectric | — |
| Blendability | Fully blendable between adjacent members | — |
| Environmental Compliance | RoHS, REACH, Cadmium free, Nickel free, Phthalate free | — |
| Shelf Life | 6 months in unopened containers | — |
| Storage Temperature | 5-30°C | — |
Note: All listed values are typical and may vary by batch. Independent qualification testing is required prior to production use.
Recommended Processing Conditions
| Parameter | Recommended Value |
| Screen Mesh | 250-325 mesh |
| Emulsion Thickness | 10-15 μm |
| Dried Film Thickness | 18-22 μm |
| Printing Speed | Up to 30 cm/sec |
| Firing Peak Temperature | 850°C |
| Total Firing Cycle | 30 minutes (10 min at peak) |
| Substrate | 96% alumina or Micromax QM44 dielectric |
Handling and Storage Recommendations
| Storage Rules | Store in tightly sealed containers in clean, stable environment at 5-30°C. |
| Shelf Life | 6 months in unopened containers from date of shipment. |
| Operation Protection | Follow standard safety practices for handling electronic paste materials. Settling may occur — mix thoroughly prior to use. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | Micromax 0001 original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
| SDS | Safety Data Sheet for handling and storage | Request SDS |
Frequently Asked Questions
What is Micromax 0001?
Micromax 0001 is a thick film chip resistor paste designed for mass chip resistor production. It features excellent ESD stability, tightly controlled TCR, fast firing at 850°C, and cadmium, nickel and phthalate free formulation.
What is the viscosity of Micromax 0001?
Micromax 0001 viscosity ranges from 80-180 Pa.s, tested with Brookfield HAT 10 rpm, SC4-14/6R at 25°C ± 0.2°C.
What is the recommended firing profile for Micromax 0001?
Micromax 0001 supports fast firing process: total 30-minute cycle with 850°C peak temperature held for 10 minutes. It can be co-fired with compatible termination materials.
What screen mesh is recommended for Micromax 0001?
Micromax 0001 is optimized for 250-325 mesh screens with 10-15 μm emulsion thickness, delivering dried film thickness of 18-22 μm.
What is Quan-Tech noise and how does Micromax 0001 perform?
Quan-Tech noise evaluates electrical noise generated inside thick film resistors. Micromax 0001 achieves low Quan-Tech noise to preserve signal integrity for precision measurement and sensing circuits.
Is Micromax 0001 RoHS and REACH compliant?
Yes. Micromax 0001 excludes cadmium, nickel and phthalate, complying with RoHS and REACH regulations. Trace impurities may exist in raw materials.
What packaging sizes are available for Micromax 0001?
Micromax 0001 chip resistor paste is available in 100G and 1000G standard packaging. Please contact our sales team for bulk supply schedule.
How should Micromax 0001 be stored?
Keep Micromax 0001 sealed tightly and stored in a clean, stable environment between 5-30°C. Unopened containers carry a 6-month shelf life starting from shipment date.
What terminations are compatible with Micromax 0001?
Micromax 0001 is engineered for high silver termination systems. Standard performance data is collected using Micromax 5426 Ag/Pd termination paste.
Get Micromax 0001 Bulk Pricing and Technical Support
We supply genuine Micromax 0001 chip resistor paste for electronic component manufacturing. Contact us for bulk pricing, sample availability, technical documents, and application support.
Inquire Bulk Price & Technical Support
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
