描述
Fortron 4184L4 is a 53% mineral and glass fiber reinforced polyphenylene sulfide (PPS) injection molding grade from Celanese Corporation. This grade is recognized as the strongest and toughest glass/mineral reinforced product available in the Fortron PPS portfolio .
The high filler content of 53% (combined mineral and glass) provides exceptional mechanical properties, rigidity, and low creep, making it ideal for high-load applications. It offers excellent heat resistance at high loads, outstanding electrical properties, and inherent flame retardancy without halogenated additives .
As a linear, semi-crystalline PPS, Fortron 4184L4 is relatively impermeable to gases, hydrocarbons, and other liquids compared to other materials. It provides high dimensional stability, low coefficient of friction, low shrinkage (0.3% parallel, 0.6% transverse) , high continuous use temperature (160°C to 240°C), and very low moisture absorption (0.02%) .
This grade exhibits excellent resistance to corrosion, hydrolysis, oxidation, heat, and paraffin buildup. It shows excellent chemical resistance to all solvents below 200°C, acids, bases, typical and alternative automotive fuels, and petroleum fluids at elevated temperatures . The material complies with RoHS, PFOS, and PFOA regulations and is suitable for lead-free soldering and metal replacement applications .
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron 4184L4
-
53% Mineral/Glass Reinforcement – Highest filler content in the Fortron PPS portfolio for exceptional stiffness and low creep
-
Strongest & Toughest Grade – Strongest and toughest glass/mineral reinforced product available
-
High Stiffness – Tensile modulus of 16,600 MPa; flexural modulus of 16,200 MPa
-
High Strength – Tensile strength of 160-165 MPa; flexural strength of 250 MPa
-
Excellent Heat Resistance – HDT of 270°C at 1.80 MPa; melting temperature of 280°C
-
Inherent Flame Retardancy – V-0 at 0.8mm and 1.5mm thickness
-
Low Creep – Excellent creep resistance due to mineral content
-
Excellent Chemical Resistance – Resists all solvents below 200°C, acids, bases, automotive fuels, and petroleum fluids
-
Very Low Moisture Absorption – 0.02% water absorption, ensuring dimensional stability
-
Good Dimensional Stability – Low shrinkage (0.3% parallel, 0.6% transverse)
-
Excellent Electrical Properties – Volume resistivity >1×10¹³ Ω·m; dielectric strength of 27 kV/mm
-
Regulatory Compliance – RoHS, PFOS, and PFOA compliant
-
Global Supply – Available across North America, Europe, Asia Pacific, Latin America, Africa & Middle East
Typical Applications for Fortron 4184L4
| Industry | Typical Components & Considerations |
|---|---|
| Electrical & Electronics | Bobbins, connectors, solenoid valves, coil formers – requiring V-0 flammability, excellent electrical properties, and dimensional stability |
| High-Load Applications | Components requiring exceptional strength, stiffness, and low creep at elevated temperatures |
| Automotive | Under-the-hood components, fuel system parts – requiring chemical resistance to fuels and heat at elevated temperatures |
| Metal Replacement | Applications requiring metal replacement with high-performance polymer and high rigidity |
| Lead-Free Soldering | Electronic components suitable for lead-free soldering processes |
Typical Properties of Fortron 4184L4
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.80 g/cm³ (1800 kg/m³) | ISO 1183 |
| Water Absorption (Saturation) | 0.02% | ISO 62 |
| Molding Shrinkage – Parallel | 0.3% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.6% | ISO 294-4 |
| Mechanical | ||
| Tensile Modulus | 16,600 MPa | ISO 527 |
| Tensile Stress at Break | 160 – 165 MPa | ISO 527 |
| Tensile Strain at Break | 1.4% | ISO 527 |
| Flexural Modulus | 16,200 MPa | ISO 178 |
| Flexural Strength | 250 MPa | ISO 178 |
| Compressive Modulus | 16,200 MPa | ISO 604 |
| Compressive Strength | 245 MPa | ISO 604 |
| Impact | ||
| Charpy Notched Impact (23°C) | 7 kJ/m² | ISO 179/1eA |
| Charpy Unnotched Impact (23°C) | 29 kJ/m² | ISO 179/1eU |
| Izod Notched Impact (23°C) | 7 kJ/m² | ISO 180/1A |
| Hardness, Rockwell M | 100 | ISO 2039-2 |
| Thermal | ||
| Melting Temperature | 280°C | ISO 11357 |
| Glass Transition Temperature | 90°C | ISO 11357 |
| HDT @ 1.80 MPa | 270°C | ISO 75 |
| HDT @ 8.00 MPa | 215°C | ISO 75 |
| CTE – Parallel | 24 × 10⁻⁶/K | ISO 11359 |
| CTE – Transverse | 32 × 10⁻⁶/K | ISO 11359 |
| Electrical | ||
| Volume Resistivity | >1×10¹³ Ω·m | IEC 62631 |
| Surface Resistivity | >1×10¹⁵ Ω | IEC 62631 |
| Dielectric Strength | 27 kV/mm | IEC 60243 |
| Relative Permittivity (1MHz) | 4.7 | IEC 62631 |
| Dissipation Factor (1MHz) | 20 × 10⁻⁴ | IEC 62631 |
| Flammability | ||
| Flammability @ 0.8mm | V-0 | UL 94 |
| Flammability @ 1.5mm | V-0 | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron 4184L4.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for Fortron 4184L4. Request the latest official TDS from our sales team.
Processing Guidelines for Fortron 4184L4
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 130 – 140°C |
| Drying Time | 3 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Dew Point Requirement | ≤ -30°C |
| Melt Temperature Range | 320 – 340°C |
| Optimum Melt Temperature | 330°C |
| Mold Temperature | 140 – 160°C |
| Manifold Temperature | 330 – 340°C |
| Hold Pressure | 30 – 70 MPa |
| Back Pressure | ≤ 3 MPa |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for Fortron 4184L4
⚠️ Drying Requirement – Fortron 4184L4 requires drying prior to processing. Predrying in a dehumidified air dryer at 130–140°C for 3–4 hours is recommended . The time between drying and processing should be as short as possible. Use of dry air dryers with dew point ≤ -30°C is recommended .
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02% . Proper drying is essential to prevent void formation and ensure optimal part quality.
⚠️ Melt Temperature – The recommended melt temperature range is 320–340°C. Avoid exceeding 340°C to prevent material degradation .
⚠️ Highest Filler Content Grade – With 53% mineral/glass reinforcement, Fortron 4184L4 has the highest filler content in the Fortron PPS portfolio. This requires careful consideration for equipment wear and proper screw design. A shut-off nozzle is preferred.
⚠️ High Load Applications – This grade is specifically designed for high-load applications where exceptional strength, stiffness, and low creep are required . Ensure proper part design to maximize the material’s high-performance characteristics.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. For subsequent storage, the material should be stored dry until processed.
Comparison: Fortron 4184L4 vs. Fortron 1140L4 vs. Fortron 1342L4
| Feature | Fortron 4184L4 | Fortron 1140L4 | Fortron 1342L4 |
|---|---|---|---|
| Filler Content | 53% (Mineral + Glass) | 40% Glass | 40% Glass + PTFE |
| Key Feature | Strongest & toughest glass/mineral product | Standard injection molding | Low wear / low friction |
| Tensile Modulus | 16,600 MPa | 14,700 MPa | 14,400 MPa |
| Tensile Strength | 160-165 MPa | 195-200 MPa | 165 MPa |
| Flexural Modulus | 16,200 MPa | 14,000-14,500 MPa | 13,700 MPa |
| HDT @ 1.80 MPa | 270°C | 265-270°C | 270°C |
| Density | 1.80 g/cm³ | 1.60-1.65 g/cm³ | 1.69 g/cm³ |
| Creep Resistance | Excellent (mineral content) | Good | Good |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron 1140L4 – 40% glass reinforced PPS, standard injection molding grade
-
Fortron 1140L6 – 40% glass reinforced PPS, easy flow for thin-wall applications
-
Fortron 1342L4 – PTFE-modified, low-wear 40% glass reinforced PPS
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron 4184L4
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Fortron 4184L4 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for Fortron 4184L4 |
| UL Yellow Card | UL safety certification (E107854) |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron 4184L4) and document type you require.
FAQ about Fortron 4184L4
Q1: What is Fortron 4184L4?
A: Fortron 4184L4 is a 53% mineral and glass fiber reinforced PPS injection molding grade from Celanese, recognized as the strongest and toughest glass/mineral reinforced product available in the Fortron PPS portfolio .
Q2: What are the key features of Fortron 4184L4?
A: 53% mineral/glass reinforcement; strongest & toughest grade available; tensile modulus 16,600 MPa; HDT 270°C; V-0 at 0.8mm; excellent heat resistance at high loads; low creep; excellent chemical resistance; very low moisture absorption (0.02%) .
Q3: What are the typical applications for Fortron 4184L4?
A: Electronic components (bobbins, connectors, solenoid valves), high-load structural components, automotive under-the-hood parts, metal replacement applications, and lead-free soldering applications .
Q4: What is the recommended drying condition for Fortron 4184L4?
A: Dry at 130–140°C for 3–4 hours using a dehumidified air dryer with dew point ≤ -30°C. Maximum residual moisture should be ≤ 0.02% .
Q5: What is the density of Fortron 4184L4?
A: 1.80 g/cm³ (1800 kg/m³), the highest among standard injection molding Fortron grades due to the 53% mineral/glass filler content .
Q6: What is the HDT @ 1.80 MPa of Fortron 4184L4?
A: 270°C .
Q7: What regions is Fortron 4184L4 available in?
A: North America, Europe, Asia Pacific, Latin America, Africa & Middle East .
Q8: Is Fortron 4184L4 flame retardant?
A: Yes, V-0 at 0.8mm and 1.5mm thickness (UL 94) .
Q9: What is the difference between Fortron 4184L4 and Fortron 1140L4?
A: Fortron 4184L4 has 53% mineral/glass reinforcement (vs. 40% glass in 1140L4), making it the strongest and toughest grade with higher stiffness (16,600 MPa vs. 14,700 MPa) and higher density (1.80 vs. 1.60-1.65 g/cm³). It is specifically designed for high-load applications requiring excellent creep resistance .
Q10: Is Fortron 4184L4 RoHS compliant?
A: Yes, it complies with RoHS, PFOS, and PFOA regulations .
Q11: What colors are available for Fortron 4184L4?
A: Black (SD3002 BLACK) .
Q12: What does the “53” in the designation mean?
A: The “53” indicates the total filler content – 53% combined mineral and glass fiber reinforcement .
CTA (Call to Action)
Ready to order Fortron 4184L4?
To get a precise quotation and professional technical support for Fortron 4184L4, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (injection molding, electronic components, automotive, high-load parts, etc.)
-
Document requirements (TDS, SDS, COA, UL docs)
Sample Policy:
-
Samples of Fortron 4184L4 are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, the manufacturer’s official TDS serves as the authoritative benchmark.
Take action now:
📧 Email Us – ruiqingchem@gmail.com
📝 Send Inquiry – Use our quick inquiry form
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original manufacturer typical values for Fortron 4184L4 . Our company acts as supplier/trader rather than original manufacturer. Final performance depends on processing conditions and part design. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for product failure caused by improper processing or improper usage. Always reference the latest manufacturer official TDS of Fortron 4184L4 as the definitive specification.
