描述
Fortron 1140L4 DW is a 40% glass fiber reinforced polyphenylene sulfide (PPS) injection molding grade from Celanese Corporation. This grade is recognized as the strongest and toughest product available in the Fortron PPS portfolio . It has been specifically developed for use in drinking water applications , making it a unique and highly capable engineering material.
The “DW” suffix designates its suitability for drinking water contact, which sets this grade apart from other 40% glass reinforced PPS products. Fortron 1140L4 DW exhibits excellent heat and chemical resistance, good electrical properties, and is inherently flame-retardant . The high hardness and rigidity at elevated temperatures allow for good load bearing performance .
With 40% glass fiber reinforcement, this PPS grade delivers exceptional stiffness and strength, including a tensile modulus of 14,700 MPa and tensile strength of 195 MPa . It exhibits outstanding heat resistance with a heat deflection temperature (HDT) of 270°C at 1.80 MPa .
This product has good weldability due to the modest filler level . It provides high dimensional stability, low and balanced molding shrinkage (0.3% flow, 0.6% transverse) , very low moisture absorption (0.02%), and a continuous use temperature up to 240°C .
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron 1140L4 DW
-
40% Glass Fiber Reinforcement – Highest glass loading for exceptional stiffness and strength
-
Strongest & Toughest Grade Available – Unmatched mechanical performance in the Fortron PPS portfolio
-
Drinking Water Approved – Specifically developed for drinking water contact applications – the “DW” designation
-
Excellent Heat Resistance – HDT of 270°C at 1.80 MPa; melting temperature of 280°C; continuous use up to 240°C
-
High Stiffness – Tensile modulus of 14,700 MPa; flexural modulus of 14,000 MPa
-
High Strength – Tensile strength of 195 MPa
-
Inherent Flame Retardancy – V-0 at 0.38mm and 1.5mm thickness; 5VA at 3.0mm; Oxygen Index 47%
-
Excellent Chemical Resistance – Resists all solvents below 200°C, acids, bases, automotive fuels, and petroleum fluids at elevated temperatures
-
Good Weldability – Exhibits good weldability in secondary operations
-
Very Low Moisture Absorption – 0.02% water absorption, ensuring stability in humid environments
-
Regulatory Compliance – RoHS, PFOS, and PFOA compliant; drinking water certifications
-
Global Supply – Available across North America, Europe, Asia Pacific, Latin America, Africa & Middle East
Typical Applications for Fortron 1140L4 DW
| Industry | Typical Components & Considerations |
|---|---|
| Drinking Water Contact | Pump housings, valves, fittings – specially developed for potable water applications |
| Automotive | Heaters, pumps, valves, fuel rails – components requiring strength and resistance to aggressive chemicals |
| Electrical & Electronics | Bobbins, lamp housings, brush holders – high-strength electrical components |
| Industrial | Distillation column packings, microwave oven rings – high temperature and chemical resistance applications |
| Pump & Valve Components | High-strength parts requiring corrosion resistance and dimensional stability |
| Bearings & Gears | High-strength, wear-resistant mechanical components |
Typical Properties of Fortron 1140L4 DW
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.66 – 1.70 g/cm³ | ISO 1183 |
| Water Absorption (Saturation) | 0.02% | ISO 62 |
| Molding Shrinkage – Parallel | 0.3% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.6% | ISO 294-4 |
| Mechanical | ||
| Tensile Modulus | 14,700 MPa | ISO 527 |
| Tensile Stress at Break | 195 MPa | ISO 527 |
| Tensile Strain at Break | 1.8% | ISO 527 |
| Flexural Modulus | 14,000 MPa | ISO 178 |
| Flexural Strength | 280 MPa | ISO 178 |
| Impact | ||
| Charpy Notched Impact (23°C) | 10 kJ/m² | ISO 179/1eA |
| Charpy Unnotched Impact (23°C) | 53 kJ/m² | ISO 179/1eU |
| Hardness, Rockwell M | 100 | ISO 2039-2 |
| Thermal | ||
| Melting Temperature | 280°C | ISO 11357 |
| Glass Transition Temperature | 90°C | ISO 11357 |
| HDT @ 1.80 MPa | 270°C | ISO 75 |
| HDT @ 8.00 MPa | 215°C | ISO 75 |
| CTE – Parallel | 26 × 10⁻⁶/K | ISO 11359 |
| CTE – Transverse | 42 × 10⁻⁶/K | ISO 11359 |
| Continuous Use Temperature | Up to 240°C | — |
| Electrical | ||
| Volume Resistivity | >1×10¹³ Ω·m | IEC 62631 |
| Surface Resistivity | 6.6×10¹¹ Ω | IEC 62631 |
| Relative Permittivity (1MHz) | 4.1 | IEC 62631 |
| Dielectric Strength | 18 kV/mm | IEC 60243 |
| Comparative Tracking Index (CTI) | 125 V | UL 746A |
| Flammability | ||
| Flammability @ 0.38mm | V-0 | UL 94 |
| Flammability @ 1.5mm | V-0 | UL 94 |
| Flammability @ 3.0mm | 5VA | UL 94 |
| Oxygen Index | 47% | ISO 4589 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron 1140L4 DW.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for Fortron 1140L4 DW. Request the latest official TDS from our sales team.
Processing Guidelines for Fortron 1140L4 DW
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 120 – 140°C |
| Drying Time | 3 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Dew Point Requirement | ≤ -30°C |
| Rear Barrel Temperature | 290 – 300°C |
| Middle Barrel Temperature | 310 – 320°C |
| Front Barrel Temperature | 330 – 340°C |
| Nozzle Temperature | 330 – 340°C |
| Optimum Melt Temperature | 330 – 340°C |
| Mold Temperature | 140 – 160°C |
| Hold Pressure | 30 – 70 MPa |
| Back Pressure | < 3.0 MPa |
| Screw Speed | 0.2 – 0.3 m/s |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for Fortron 1140L4 DW
⚠️ Drying Requirement – Fortron 1140L4 DW requires drying prior to processing. Dry at 120-140°C for 3-4 hours using a dehumidified air dryer with dew point ≤ -30°C . The time between drying and processing should be as short as possible.
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02% . Proper drying is essential to prevent void formation and ensure optimal part quality.
⚠️ Melt Temperature – The recommended melt temperature range is 330-340°C. Avoid exceeding 340°C to prevent material degradation .
⚠️ Reinforced Grade – Contains 40% glass fiber reinforcement, which may require consideration for equipment wear and proper screw design.
⚠️ Drinking Water Compliance – This grade is specifically developed for drinking water applications. Ensure all secondary processing and assembly materials also meet drinking water compliance requirements .
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. For subsequent storage, the material should be stored dry until processed.
⚠️ High Temperature Performance – Maintains continuous use temperature up to 240°C with excellent load bearing performance at elevated temperatures .
Comparison: Fortron 1140L4 DW vs. Fortron 1140L0 vs. Fortron 1132L4
| Feature | Fortron 1140L4 DW | Fortron 1140L0 | Fortron 1132L4 |
|---|---|---|---|
| Glass Fiber Content | 40% | 40% | 30% |
| Key Feature | Strongest & toughest, drinking water approved | Extrusion grade, rods/slabs | High strength |
| Primary Processing | Injection Molding | Extrusion | Injection Molding |
| Tensile Modulus | 14,700 MPa | 7,600-12,000 MPa | 12,000 MPa |
| Tensile Strength | 195 MPa | 124-185 MPa | 175 MPa |
| HDT @ 1.80 MPa | 270°C | 240°C | 260°C |
| Density | 1.66-1.70 g/cm³ | 1.65-1.66 g/cm³ | 1.58 g/cm³ |
| Special Feature | Drinking water contact acceptable | Good weldability | High strength |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron 1140L0 – 40% glass reinforced PPS for extrusion (rods, slabs, profiles)
-
Fortron 1132L4 – 30% glass reinforced PPS for high-strength injection molding
-
Fortron 1131L4 – 30% glass reinforced, low flash PPS
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron 1140L4 DW
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Fortron 1140L4 DW |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for Fortron 1140L4 DW |
| UL Yellow Card | UL safety certification (UL94 V-0, 5VA) |
| Drinking Water Compliance Certificate | Certification for drinking water contact applications |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron 1140L4 DW) and document type you require.
FAQ about Fortron 1140L4 DW
Q1: What is Fortron 1140L4 DW?
A: Fortron 1140L4 DW is a 40% glass fiber reinforced PPS injection molding grade from Celanese, recognized as the strongest and toughest product in the Fortron PPS portfolio .
Q2: What does the “DW” suffix mean?
A: The “DW” suffix indicates that this grade has been specifically developed for drinking water contact applications .
Q3: What are the key features of Fortron 1140L4 DW?
A: 40% glass reinforcement; strongest and toughest grade available; drinking water approved; tensile strength 195 MPa; HDT 270°C; V-0 at 0.38mm; 5VA at 3.0mm; excellent chemical resistance; good weldability .
Q4: What are the typical applications for Fortron 1140L4 DW?
A: Drinking water pumps, valves, fittings; automotive heaters, pumps, fuel rails; electrical components (bobbins, lamp housings); industrial pump and valve components; bearings and gears .
Q5: What is the recommended drying condition for Fortron 1140L4 DW?
A: Dry at 120-140°C for 3-4 hours using a dehumidified air dryer with dew point ≤ -30°C. Maximum residual moisture ≤ 0.02% .
Q6: What is the density of Fortron 1140L4 DW?
A: 1.66 – 1.70 g/cm³ .
Q7: What is the HDT @ 1.80 MPa of Fortron 1140L4 DW?
A: 270°C .
Q8: What regions is Fortron 1140L4 DW available in?
A: North America, Europe, Asia Pacific, Latin America, Africa & Middle East .
Q9: Is Fortron 1140L4 DW flame retardant?
A: Yes. V-0 at 0.38mm and 1.5mm; 5VA at 3.0mm; Oxygen Index 47% .
Q10: What is the difference between Fortron 1140L4 DW and Fortron 1140L0?
A: Both have 40% glass reinforcement. Fortron 1140L4 DW is designed for injection molding with drinking water approval and offers the strongest/toughest performance (tensile 195 MPa, HDT 270°C). Fortron 1140L0 is an extrusion grade for rods, slabs, and profiles .
Q11: Is Fortron 1140L4 DW RoHS compliant?
A: Yes, it complies with RoHS and REACH regulations .
Q12: Can Fortron 1140L4 DW be welded?
A: Yes, this product has good weldability due to its modest filler level .
