描述
CYROLITE MD H12 UV Transparent Medical Diagnostic Acrylic
Material: PMMA-based Polymer
UV Transmission: ≥87.7% (340nm)
Haze: <1%
Flexural Modulus: 3.4 GPa
Packing: 1500 lb boxes
CYROLITE MD H12 delivers ≥87.7% UV transmission at 340nm, 92% light transmission with <1% haze, and high rigidity (3.4 GPa) — purpose-built for UV spectroscopy medical diagnostics.
CYROLITE MD H12 is a UV transparent medical diagnostic acrylic polymer specifically designed for UV spectroscopy applications in the medical diagnostic industry. With UV light transmission of ≥87.7% at 340nm, 92% total light transmission, and haze below 1%, this material delivers exceptional optical performance for precise fluid evaluation. Its high rigidity — with flexural modulus of 3.4 GPa and tensile modulus of 3.2 GPa — ensures excellent dimensional stability for precision diagnostic components.
CYROLITE MD H12 offers maximum flow characteristics with a melt flow rate of 7.0 g/10min (230°C/3.8kg), enabling efficient filling of complex diagnostic molds. It provides outstanding scratch resistance, superior optical clarity, and a total cost-of-use advantage over glass. Meeting USP Class VI (colorless) and ISO 10993-1 biocompatibility requirements, this material is suitable for patient-contact diagnostic devices. Processable on standard injection molding equipment with 3-zone general purpose screws. Typical applications include cuvettes, rotors, well plates, diagnostic test packs, microfluidics, and crystallography trays where UV transparency and optical clarity are critical.
Genuine Roehm CYROLITE Imported Stock and Technical Support
We supply stable spot inventory of genuine CYROLITE MD H12 UV transparent medical diagnostic acrylic. Official TDS, batch COA, and biocompatibility documentation (USP Class VI, ISO 10993) are available for medical diagnostic applications.
Request CYROLITE MD H12 Quotation, TDS, and Sample
Complete TDS, COA, and regulatory documentation available
Core Advantages of CYROLITE MD H12
- Exceptional UV transparency — ≥87.7% transmission at 340nm for UV spectroscopy
- Superior optical clarity — 92% light transmission with <1% haze
- High rigidity — flexural modulus 3.4 GPa, tensile modulus 3.2 GPa
- Excellent dimensional stability — precise and consistent component geometry
- Outstanding scratch resistance — durable optical surfaces
- Maximum flow characteristics — MFR 7.0 g/10min for complex mold filling
- Medical grade compliance — USP Class VI (colorless) and ISO 10993-1
- Cost-effective alternative to glass — total cost-of-use advantage
Main Applications
- Cuvettes — UV spectroscopy sample holders
- Rotors — diagnostic instrument components
- Well plates — multi-well sample testing plates
- Diagnostic test packs — integrated diagnostic devices
- Microfluidics — precision fluid handling components
- Crystallography trays — protein crystallization applications
Full Technical Parameters
| Property | Typical Value | Test Method |
| Material Type | PMMA-based polymer | — |
| Medical Compliance | USP Class VI (colorless), ISO 10993-1 | — |
| UV Transmission (340nm) | ≥87.7% | ASTM D1003 |
| Light Transmission (3.2mm) | 92% | ASTM D1003 |
| Haze (3.2mm) | <1% | ASTM D1003 |
| Tensile Strength | 65.5 MPa | ASTM D638 |
| Tensile Modulus | 3.2 GPa | ASTM D638 |
| Flexural Strength | 117.2 MPa | ASTM D790 |
| Flexural Modulus | 3.4 GPa | ASTM D790 |
| Notched Izod Impact (23°C) | 19 J/m | ASTM D256 |
| Vicat Softening Point | 105°C | ASTM D1525 |
| HDT (1.8 MPa) | 95°C | ASTM D648 |
| MFR (230°C/3.8kg) | 7.0 g/10min | ASTM D1238 |
| Specific Gravity | 1.19 | ASTM D792 |
| Water Absorption | 0.3% max | ASTM D570 |
| Mold Shrinkage | 0.004-0.006 in/in | ASTM D955 |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Recommended Processing Conditions
| Parameter | Recommended Value |
| Processing Method | Injection Molding |
| Screw Type | 3-zone general purpose screw |
| Melt Temperature | 230-250°C (typical) |
| Mold Temperature | 50-80°C (typical) |
Handling and Storage Recommendations
| Storage Rules | Store in dry, cool conditions away from direct sunlight and heat sources. |
| Packaging | 1500 lb gaylor boxes; other packaging available on request. |
| Operation Protection | Follow standard safety practices for handling thermoplastic pellets. Use appropriate PPE during processing. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | CYROLITE MD H12 original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
| Biocompatibility | USP Class VI and ISO 10993-1 documentation | Request Documentation |
Frequently Asked Questions
What is CYROLITE MD H12?
CYROLITE MD H12 is a UV transparent medical diagnostic acrylic polymer with 92% light transmission, <1% haze, and ≥87.7% UV transmission at 340nm, designed for UV spectroscopy medical diagnostic applications.
What is the UV transmission of CYROLITE MD H12?
CYROLITE MD H12 offers ≥87.7% UV light transmission at 340nm, making it ideal for UV spectroscopy applications in medical diagnostics.
What is the optical clarity of CYROLITE MD H12?
CYROLITE MD H12 delivers 92% light transmission with haze of less than 1%, providing exceptional optical clarity for diagnostic applications.
What medical certifications does CYROLITE MD H12 hold?
CYROLITE MD H12 meets USP Class VI (colorless) and ISO 10993-1 biocompatibility requirements, making it suitable for medical diagnostic applications.
What applications is CYROLITE MD H12 suitable for?
CYROLITE MD H12 is ideal for cuvettes, rotors, well plates, diagnostic test packs, microfluidics, and crystallography trays requiring UV spectroscopy and optical clarity.
What is the melt flow rate of CYROLITE MD H12?
CYROLITE MD H12 has a melt flow rate of 7.0 g/10min (230°C/3.8kg), offering excellent flow characteristics for injection molding of complex diagnostic components.
What is the rigidity of CYROLITE MD H12?
CYROLITE MD H12 offers high rigidity with a flexural modulus of 3.4 GPa and tensile modulus of 3.2 GPa, providing excellent dimensional stability for precision diagnostic components.
Related CYROLITE Products
Compare CYROLITE medical grade polymers for different application requirements.
| Product | Key Feature | UV Transmission | Haze | Flexural Modulus | Core Application |
| MD H12 | UV transparency + high rigidity | ≥87.7% | <1% | 3.4 GPa | UV spectroscopy, diagnostics |
| GS-90 | High clarity + gamma stable | — | 3.0% | 2.3 GPa | Y-sites, luer locks |
| CG-97 | Lipid resistant + gamma stable | — | 5.0% | 1.8 GPa | Needle hubs, IV filters |
Get CYROLITE MD H12 Bulk Pricing and Technical Support
We supply genuine CYROLITE MD H12 UV transparent medical diagnostic acrylic for cuvettes, microfluidics, and diagnostic applications. Contact us for bulk pricing, sample availability, technical documents, and application support.
Request CYROLITE MD H12 Technical Details
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
