Xylan 1514 is a waterborne, PTFE-based dry film lubricant coating from Whitford Corporation (now PPG). As an authorized distributor and trader, we supply genuine materials with full traceability and direct access to official technical documentation. The coating features a water-based formulation for reduced environmental impact and is suitable for use on fasteners and general industrial components .
Unlike Xylan 1424 (offshore fastener standard), Xylan 1425 (extreme pressure with MoS₂), or Xylan 1070 (solvent-based fastener coating), Xylan 1514 is distinguished by its highest lubricity within the series and its UV resistance for outdoor, high-visibility applications .
Xylan 1514 is the most lubricious coating in the Xylan 1500 series. When stain resistance and non-stick release properties are critical to product performance, Xylan 1514 is the specified choice . The coating provides excellent low friction and self-lubrication, reducing wear and enabling smooth, galling-free assembly of threaded fasteners .
The coating offers corrosion resistance and some abrasion resistance in addition to its friction-reducing properties . The PTFE-based resin matrix provides excellent release and anti-stick properties, making it suitable for applications where components are exposed to high-fat, high-sugar, or protein-containing environments . The coating operates continuously from -250°C to 285°C (-418°F to 545°F) .
Key Features of Xylan 1514 Coating
-
Highest Lubricity in the Series – The most lubricious Xylan 1514 coating; provides ultra-low friction for smooth operation
-
UV Resistance – Resists sunlight degradation; suitable for outdoor, high-visibility applications
-
Excellent Non-Stick Properties – Provides stain resistance and easy-clean, non-stick release; recommended when non-stick and stain resistance are critical
-
Waterborne/VOC Compliant – Environmentally friendly water-based formulation; low VOC content; higher safety factor than solvent-based coatings
-
Wide Temperature Range – Operates from -250°C to 285°C (-418°F to 545°F)
-
Good Corrosion Protection – Provides corrosion resistance in aggressive environments; salt spray resistance
-
Abrasion Resistance – Offers some abrasion resistance in addition to friction reduction and corrosion protection
-
Decorative High-Visibility Finish – Designed for highly visible, decorative applications; multiple color options
-
FDA Compliant – Suitable for use in food processing environments
-
Resin-Bonded Durability – Thermoset fluoropolymer matrix provides durable, long-lasting protection
Typical Applications for Xylan 1514 Coating
| Industry | Typical Components & Considerations |
|---|---|
| Fasteners | Bolts, nuts, screws, connectors – high lubricity reduces assembly torque by up to 70%; corrosion protection |
| Aerospace | Fasteners, engine components – temperature stability, low friction, high visibility |
| Automotive | Valve bodies, fasteners, engine components – self-lubrication, chemical resistance |
| Oil & Gas | Threaded components, connectors – corrosion resistance, high-visibility identification |
| Food Processing | Bakeware, conveyor chains, molds – non-stick properties; FDA compliant |
| General Industrial | Pumps, valves, sliding components – friction reduction, stain resistance, easy-clean surfaces |
Typical Properties of Xylan 1514 Coating
| Property | Typical Value | Test Method |
|---|---|---|
| Coefficient of Friction | Lowest in series | ASTM D1894 |
| Maximum Service Temperature | 285°C (545°F) | — |
| Minimum Service Temperature | -250°C (-418°F) | — |
| Standard Cure Temperature | 525°F (275°C) | — |
| Alternative Cure (LC Version) | 400°F (205°C) | — |
| Coating Thickness | 20 – 30 μm (typical) | — |
| Salt Spray Resistance | Up to 5,000 hours | ASTM B117 |
| UV Resistance | Excellent | — |
| Color | Multiple colors available | — |
| Package Size | 20 kg pails | — |
| Shelf Life | 18 months | — |
Important Notes on Typical Data:
Values listed are typical and sourced from manufacturer data sheets. They do not constitute binding product specification.
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
Final performance depends on substrate preparation, application method, and curing conditions.
Manufacturer official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for Xylan 1514 Coating
Xylan 1514 is designed for fasteners and general components, primarily for corrosion protection and ease of assembly torque control .
| Step | Process |
|---|---|
| Surface Preparation | Degrease (acetone or isopropanol) → grit-blast (Sa2.5, Ra 1.5–4.0 μm) → zinc/manganese phosphate (recommended for steel) |
| Coating Preparation | Slow-speed mechanical stirring; dilute with deionized water only |
| Application | Dip-spin (for fasteners) or conventional spray (HVLP) |
| Flash-off | Room temperature air dry |
| Curing | 290–320°C (554–608°F) for 20–30 minutes (substrate temperature) |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight. Shelf life: 18 months |
Critical Processing Warnings:
Surface Preparation: Proper surface preparation is critical for adhesion. Degrease thoroughly and grit-blast to Sa2.5 grade with Ra 1.5–4.0 μm .
Phosphate Pretreatment: Zinc or manganese phosphate is recommended for steel fasteners to maximize corrosion resistance and adhesion .
Coating Mixing: Use only deionized water for dilution. Never use tap water, as minerals and impurities can destabilize the coating .
Curing: Cure temperature is substrate temperature, not oven temperature. Cure time depends on part mass and oven characteristics. Always verify with test pieces .
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight.
Related Products
Explore Xylan Industrial Coatings – Browse all Xylan coating options
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Xylan 1514 Coating
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Xylan 1514 |
| Manufacturer Official SDS | GHS-compliant chemical safety documentation |
| Distributor Authorization Certificate | Proof of our authorized-distributor qualification, available upon request |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
Email: ruiqingchem@gmail.com
Online form: Our contact page
We reply within one working business day. Please clearly state product (Xylan 1514) and document type you require.
FAQ about Xylan 1514 Coating
Q1: What is Xylan 1514?
A: Xylan 1514 is a waterborne PTFE-based dry film coating from Whitford (PPG), featuring the highest lubricity in the Xylan 1500 series. It provides excellent non-stick and stain resistance, UV resistance, and corrosion protection for fasteners and industrial components .
Q2: How does Xylan 1514 differ from Xylan 1424?
A: Xylan 1514 is distinguished by its highest lubricity and UV resistance, making it suitable for highly visible outdoor applications. Xylan 1424 is primarily specified for offshore fastener corrosion protection .
Q3: What is the temperature range of Xylan 1514?
A: Xylan 1514 operates continuously from -250°C to 285°C (-418°F to 545°F) .
Q4: What is the curing temperature for Xylan 1514?
A: Standard cure temperature is 275°C (525°F). The LC (low-cure) version cures at 205°C (400°F) .
Q5: Is Xylan 1514 suitable for food processing applications?
A: Yes, Xylan 1514 is FDA compliant and suitable for use in high-fat, high-sugar, or protein-containing food processing environments .
Q6: What are the typical applications for Xylan 1514?
A: Typical applications include fasteners, connectors, valves, food processing equipment, general industrial components, and outdoor hardware requiring high lubricity, UV resistance, and non-stick properties .
