描述
VESTAMID E62-S3 BK V303579 is a heat- and light-stabilized polyether block copolyamide (PEBA) elastomer from Evonik Operations GmbH, supplied in black color. It is a PA 12 elastomer consisting of PA 12 segments and softening polyether segments, belonging to the VESTAMID E series of thermoplastic elastomers (TPE). The material is free of volatile or migrating plasticizer.
This grade is especially developed for sport shoe soles, offering good impact strength at low temperatures. The PA12-based PEBA elastomer combines the major properties of PA 12 with elastomer characteristics, providing flexibility, high impact strength at cold temperatures, and excellent recovery.
Compared to other contending thermoplastic elastomers, PA 12 elastomers are distinguished by their low density, high resistance to chemicals and solvents, easy processability and coloring, and excellent impact strength at low temperatures. Their hardness and flexibility can be varied over a wide range, and their mechanical properties are only slightly temperature-dependent.
The material has good resistance to hydrolysis/hot water, wear/abrasion, and fatigue. It is also resistant to oils, greases, fuels, hydraulic fluids, salt solutions, and many solvents, with excellent stress crack resistance.
Typical applications include sport shoe soles, alpine ski boots, noiseless gears, conveyor belts, and automotive components.
For more VESTAMID grades and technical information, please visit our Engineering Plastics product page.
Key Features of VESTAMID E62-S3 BK V303579
| # | Feature | Benefit |
|---|---|---|
| 1 | PA12-Based PEBA Elastomer | Combines PA12 properties with elastomer flexibility |
| 2 | Heat & Light Stabilized | Maintains properties under thermal, UV, and light exposure |
| 3 | Black Color | Pre-colored black for aesthetic and functional applications |
| 4 | Free of Volatile/Migrating Plasticizer | No plasticizer migration concerns for sensitive applications |
| 5 | Excellent Low-Temperature Impact Strength | Good impact strength at cold temperatures |
| 6 | High Tensile Modulus | 405 MPa (ISO 527) for structural rigidity |
| 7 | Low Density | 1.03 g/cm³ – among the lowest of commercial polyamides |
| 8 | Good Chemical Resistance | Resistant to oils, greases, fuels, hydraulic fluids, and solvents |
| 9 | Hydrolysis Resistant | Good resistance to hot water and hydrolysis |
| 10 | Fatigue Resistant | Suitable for cyclic loading applications |
| 11 | Abrasion Resistant | Good wear resistance for durable components |
| 12 | Fuel Resistant | Suitable for automotive fuel contact applications |
Typical Applications for VESTAMID E62-S3 BK V303579
| Industry | Typical Components & Considerations |
|---|---|
| Sport Shoe Soles | Functional elements of sports shoes – utilizing low-temperature impact strength, high modulus, and heat/light stabilization |
| Alpine Ski Boots | Ski boot components – requiring cold impact resistance and durability |
| Noiseless Gears | Gears requiring quiet operation and wear resistance |
| Conveyor Belts | Conveyor belt components – utilizing fatigue resistance and abrasion resistance |
| Automotive | Fuel lines, air lines, gear shift knobs, pulleys, levers, gears, bearings, fuel tank liners – requiring chemical resistance and vibration damping |
| Industry & Building Construction | Components requiring chemical resistance and durability |
Typical Properties of VESTAMID E62-S3 BK V303579
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.03 g/cm³ | ISO 1183 |
| Melt Volume-Flow Rate (MVR, 230°C/2.16 kg) | 9.0 cm³/10 min | ISO 1133 |
| Melt Mass-Flow Rate (MFR, 230°C/2.16 kg) | 12 g/10 min | ISO 1133 |
| Mechanical | ||
| Tensile Modulus | 405 MPa | ISO 527 |
| Yield Stress | 24 MPa | ISO 527 |
| Yield Strain | 30% | ISO 527 |
| Nominal Strain at Break | >50% | ISO 527 |
| Tensile Stress at Break | 42 MPa | ISO 527-2 |
| Shore D Hardness | 62 | ISO 7619-1 |
| Impact | ||
| Charpy Notched Impact (23°C) | 95 kJ/m² | ISO 179/1eA |
| Thermal | ||
| Melting Temperature | ~178°C | ISO 11357 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for VESTAMID E62-S3 BK V303579.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Pigmentation – The use of colorants or pigmentation may affect property values.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for VESTAMID E62-S3 BK V303579. Request the latest official TDS from our sales team.
Processing Guidelines for VESTAMID E62-S3 BK V303579
| Step | Process |
|---|---|
| Processing Methods | Injection Molding, Profile Extrusion |
| Drying Recommended | Yes |
| Suggested Max Moisture | ≤ 0.10% |
| Processing (Melt) Temperature | 190 – 230°C |
| Optimum Melt Temperature | 200°C |
| Mold Temperature | 35°C |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at ≤ 30°C |
Critical Processing Warnings for VESTAMID E62-S3 BK V303579
⚠️ Drying Requirement – VESTAMID E62-S3 BK V303579 should be dried prior to processing to ensure maximum part quality. Suggested maximum moisture content is ≤ 0.10%.
⚠️ Processing Temperature – The recommended processing (melt) temperature range is 190–230°C. Avoid exceeding 230°C to prevent material degradation.
⚠️ Pigmentation – The use of colorants or pigmentation may affect property values. Validate performance with colored batches for critical applications.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Comparison: VESTAMID E62-S3 BK V303579 vs. VESTAMID E62-S1
| Feature | VESTAMID E62-S3 BK V303579 | VESTAMID E62-S1 |
|---|---|---|
| Material Type | PEBA Elastomer | PEBA Elastomer |
| Shore D Hardness | 62 | 62 |
| Key Feature | Heat, UV & light stabilized, black color | Heat stabilized |
| Tensile Modulus | 405 MPa | 389 MPa |
| Density | 1.03 g/cm³ | 1.03 g/cm³ |
| MVR (230°C/2.16 kg) | 9.0 cm³/10 min | — |
| Processing Temp | 190 – 230°C | 190 – 230°C |
| Primary Application | Sport shoe soles, automotive components | Sport shoe soles, conveyor belts |
Related Products
-
Engineering Plastics – Browse all engineering plastic materials
-
VESTAMID E62-S3 – Natural color version of this grade
-
VESTAMID E62-S1 – Heat stabilized PEBA elastomer for sport shoe soles
-
VESTAMID E55-S3 – Medium hardness PEBA elastomer for sport shoe soles and alpine ski boots
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for VESTAMID E62-S3 BK V303579
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (VESTAMID E62-S3 BK V303579) and document type you require.
FAQ about VESTAMID E62-S3 BK V303579
Q1: What is VESTAMID E62-S3 BK V303579?
A: VESTAMID E62-S3 BK V303579 is a heat- and light-stabilized polyether block copolyamide (PEBA) elastomer from Evonik, based on PA 12 segments and polyether segments, supplied in black color, specifically developed for sport shoe soles.
Q2: Is VESTAMID E62-S3 BK V303579 a PA12 grade?
A: It is a PA12-based PEBA elastomer (polyether block copolyamide), not a standard PA12 compound. It combines PA12 properties with elastomer flexibility.
Q3: What are the key features?
A: PA12-based PEBA elastomer; heat, UV & light stabilized; black color; free of volatile/migrating plasticizer; excellent low-temperature impact strength; high tensile modulus (405 MPa); low density (1.03 g/cm³); good chemical resistance; hydrolysis resistant; fuel resistant.
Q4: What are the typical applications?
A: Sport shoe soles, alpine ski boots, noiseless gears, conveyor belts, automotive fuel lines, air lines, and components requiring chemical resistance and vibration damping.
Q5: What is the hardness?
A: Shore D 62 (ISO 7619-1).
Q6: What is the density?
A: 1.03 g/cm³ (ISO 1183).
Q7: What is the tensile modulus?
A: 405 MPa (ISO 527).
Q8: What is the yield stress?
A: 24 MPa (ISO 527).
Q9: What is the low-temperature impact performance?
A: The material has good impact strength at low temperatures.
Q10: What is the recommended processing temperature?
A: Processing (melt) temperature: 190–230°C. Optimum mold temperature: 35°C.
Q11: What is the MVR?
A: 9.0 cm³/10 min (230°C/2.16 kg, ISO 1133).
Q12: What regions is this grade available in?
A: Europe and North America.
Q13: Is this material free of plasticizer?
A: Yes, the material is free of volatile or migrating plasticizer.
Q14: What is the shelf life?
A: At least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Q15: Is VESTAMID E62-S3 BK V303579 suitable for injection molding?
A: Yes, it is processed by injection molding and profile extrusion.
Q16: Is VESTAMID E62-S3 BK V303579 fuel resistant?
A: Yes, it is fuel resistant.
CTA (Call to Action)
Ready to order VESTAMID E62-S3 BK V303579?
To get a precise quotation and professional technical support for VESTAMID E62-S3 BK V303579, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (sport shoe soles, alpine ski boots, automotive components, etc.)
-
Document requirements (TDS, SDS, COA)
Sample Policy:
-
Samples of VESTAMID E62-S3 BK V303579 are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, the manufacturer’s official TDS serves as the authoritative benchmark.
Take action now:
📧 Email Us – ruiqingchem@gmail.com
📝 Send Inquiry – Use our quick inquiry form
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
