VESTAMID E55-S3 is a heat- and light-stabilized polyether block copolyamide (PEBA) elastomer from Evonik Operations GmbH. It is based on PA 12 segments and softening polyether segments, belonging to the VESTAMID E series of thermoplastic elastomers (TPE). The material is free of volatile or migrating plasticizer.
This grade is especially developed for sport shoe soles, offering good impact strength at low temperatures. The PA12-based PEBA elastomer combines the major properties of PA 12 with elastomer characteristics, providing flexibility, high impact strength at cold temperatures, and excellent recovery.
Compared to other contending thermoplastic elastomers, PA 12 elastomers are distinguished by their low density, high resistance to chemicals and solvents, easy processability and coloring, and excellent impact strength at low temperatures. Their hardness and flexibility can be varied over a wide range, and their mechanical properties are only slightly temperature-dependent.
Typical applications include alpine ski boots, sports shoe soles, pneumatic lines, rolls, and technical films.
For more VESTAMID grades and technical information, please visit our Engineering Plastics product page.
Key Features
| # | Feature | Benefit |
|---|---|---|
| 1 | PA12-Based PEBA Elastomer | Combines PA12 properties with elastomer flexibility |
| 2 | Heat, UV & Light Stabilized | Maintains properties under thermal, UV, and light exposure |
| 3 | Free of Volatile/Migrating Plasticizer | No plasticizer migration concerns for sensitive applications |
| 4 | Excellent Low-Temperature Impact Strength | Good impact strength at cold temperatures |
| 5 | High Elasticity | Elongation at break >200% |
| 6 | Low Density | 1.03 g/cm³ – among the lowest of commercial polyamides |
| 7 | Good Chemical Resistance | Resistant to chemicals and solvents |
| 8 | Easy Processability & Colorability | Suitable for injection molding and profile extrusion |
| 9 | Good Overmolding Capability | Easy to overmold for multi-material components |
| 10 | Heat Transfer Printable | Can be decorated easily by means of heat transfer printing |
| 11 | Fatigue Resistant | Suitable for cyclic loading applications |
| 12 | Abrasion Resistant | Good wear resistance for durable components |
Typical Applications
| Industry | Typical Components & Considerations |
|---|---|
| Sport Shoe Soles | Functional elements of sports shoes – utilizing low-temperature impact strength, elasticity, and heat/light stabilization |
| Alpine Ski Boots | Ski boot components – requiring cold impact resistance and durability |
| Pneumatic Lines | Pneumatic tubing and lines – requiring flexibility and chemical resistance |
| Rolls | Industrial rolls and rollers – utilizing abrasion resistance and elasticity |
| Technical Films | Flexible technical films requiring good impact strength and chemical resistance |
Typical Properties
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.03 g/cm³ | ISO 1183 |
| Water Absorption (Saturation, 23°C) | ~1.4% | ISO 62 |
| Molding Shrinkage – Parallel | 0.8% | ISO 294-4 |
| Molding Shrinkage – Normal | 1.3% | ISO 294-4 |
| MVR (240°C/2.16 kg) | 36 cm³/10 min | ISO 1133 |
| Mechanical | ||
| Tensile Modulus | 215 MPa | ISO 527 |
| Tensile Creep Modulus (1000h) | 100 MPa | ISO 899-1 |
| Tensile Strength at Break | 27 MPa | ISO 527 |
| Elongation at Break | >200% | ISO 527 |
| Shore D Hardness | 55 | ISO 868 |
| Impact | ||
| Charpy Notched Impact (23°C) | No Break | ISO 179/1eA |
| Charpy Notched Impact (-30°C) | No Break | ISO 179/1eA |
| Charpy Unnotched Impact (23°C) | No Break | ISO 179/1eU |
| Electrical | ||
| Dielectric Strength | 34 kV/mm | IEC 60243-1 |
| Comparative Tracking Index (CTI) | 600 V | IEC 60112 |
| Flammability | ||
| Flammability @ 1.6 mm | HB | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Pigmentation – The use of colorants or pigmentation may affect property values.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Processing Methods | Injection Molding, Profile Extrusion |
| Drying Recommended | Yes |
| Suggested Max Moisture | ≤ 0.10% |
| Processing (Melt) Temperature | 190 – 230°C |
| Mold Temperature | 80°C (for shrinkage test) |
| Ejection Temperature | 160°C |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at ≤ 30°C |
Critical Processing Warnings
⚠️ Drying Requirement – This material should be dried prior to processing to ensure maximum part quality. Suggested maximum moisture content is ≤ 0.10%.
⚠️ Processing Temperature – The recommended processing (melt) temperature range is 190–230°C. Avoid exceeding 230°C to prevent material degradation.
⚠️ Pigmentation – The use of colorants or pigmentation may affect property values. Validate performance with colored batches for critical applications.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Comparison: VESTAMID E55-S3 vs. VESTAMID E47-S3
| Feature | VESTAMID E55-S3 | VESTAMID E47-S3 |
|---|---|---|
| Material Type | PEBA Elastomer | PEBA Elastomer |
| Shore D Hardness | 55 | 47 |
| Key Feature | Higher hardness, higher modulus | Lower hardness, higher flexibility |
| Tensile Modulus | 215 MPa | 130 MPa |
| Tensile Strength | 27 MPa | 27 MPa |
| Elongation at Break | >200% | 450% |
| Density | 1.03 g/cm³ | 1.02 g/cm³ |
| MVR (240°C/2.16 kg) | 36 cm³/10 min | 65 cm³/10 min |
| Processing Temp | 190 – 230°C | 180 – 220°C |
| Primary Application | Sport shoe soles, alpine ski boots | Sport shoe soles, packaging films |
Related Products
-
Engineering Plastics – Browse all engineering plastic materials
-
VESTAMID E47-S3 – Lower hardness PEBA elastomer for flexible applications
-
VESTAMID E40-S3 – Lower hardness PEBA elastomer for flexible applications
-
VESTAMID E58-S4 – Higher hardness PEBA elastomer for demanding applications
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| UL Yellow Card | UL safety certification (UL 94 HB) |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (VESTAMID E55-S3) and document type you require.
FAQ
Q1: What is this PEBA elastomer?
A: VESTAMID E55-S3 is a heat- and light-stabilized polyether block copolyamide (PEBA) elastomer from Evonik, based on PA 12 segments and polyether segments, specifically developed for sport shoe soles.
Q2: Is this a PA12 grade?
A: It is a PA12-based PEBA elastomer (polyether block copolyamide), not a standard PA12 compound. It combines PA12 properties with elastomer flexibility.
Q3: What are the key features?
A: PA12-based PEBA elastomer; heat, UV & light stabilized; free of volatile/migrating plasticizer; excellent low-temperature impact strength; high elasticity; low density (1.03 g/cm³); good chemical resistance; fatigue resistant; abrasion resistant; good overmolding capability.
Q4: What are the typical applications?
A: Sport shoe soles, alpine ski boots, pneumatic lines, rolls, and technical films.
Q5: What is the hardness?
A: Shore D 55 (ISO 868).
Q6: What is the density?
A: 1.03 g/cm³ (ISO 1183).
Q7: What is the tensile modulus?
A: 215 MPa (ISO 527).
Q8: What is the elongation at break?
A: >200% (ISO 527).
Q9: What is the low-temperature impact performance?
A: Charpy notched and unnotched impact tests show “No Break” at both 23°C and -30°C.
Q10: What is the recommended processing temperature?
A: Processing (melt) temperature: 190–230°C.
Q11: What is the water absorption?
A: Approximately 1.4% at saturation, 23°C (ISO 62).
Q12: What regions is this grade available in?
A: Europe and North America.
Q13: Is this material free of plasticizer?
A: Yes, the material is free of volatile or migrating plasticizer.
Q14: What is the melting temperature?
A: Approximately 143°C.
Q15: What is the CTI?
A: 600 V (IEC 60112).
Q16: What is the shelf life?
A: At least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Q17: Is it suitable for injection molding?
A: Yes, it is suitable for both injection molding and profile extrusion.
Q18: What is the molding shrinkage?
A: 0.8% parallel and 1.3% normal (ISO 294-4).
Q19: What is the MVR?
A: 36 cm³/10 min (240°C/2.16 kg, ISO 1133).
Q20: What is the ejection temperature?
A: 160°C.
