描述
VESTAMID Care ML17 is an unfilled, low viscosity polyamide 12 (PA12) resin from Evonik Operations GmbH, specifically developed for medical applications. It belongs to Evonik’s VESTAMID Care product line, which offers USP Class VI certified materials for the medical industry.
VESTAMID Care ML17 is resistant to body fluids and toxicologically safe. It is suitable for both injection molding and extrusion processes, offering excellent processability and colorability across a wide processing window.
This grade is developed for medical technology applications, with biocompatibility tested following ISO 10993-1 recommendations for surface medical devices with up to 30 days body contact. The material fulfills the requirements of USP <88> Class VI and has been tested by independent, certified laboratories.
For more VESTAMID grades and technical information, please visit our PA12/Polyamide 12 product page.
Key Features of VESTAMID Care ML17
| # | Feature | Benefit |
|---|---|---|
| 1 | Unfilled / Low Viscosity | Excellent flow for thin-wall and complex part molding; suitable for extrusion |
| 2 | USP Class VI Compliant | Meets highest biocompatibility standards for medical applications |
| 3 | ISO 10993 Compliant | Tested for cytotoxicity, sensitization, irritation, and acute systemic toxicity |
| 4 | Up to 30 Days Body Contact | Approved for surface medical devices with up to 30 days body contact |
| 5 | High Flexibility & Elasticity | Excellent flexibility for catheters, tubing, and flexible components |
| 6 | Good Rebound Properties | Resilient and durable in demanding applications |
| 7 | High Impact Resistance | Excellent toughness and durability |
| 8 | High Abrasion Resistance | Excellent wear resistance for long-lasting components |
| 9 | Low Sliding Friction | Good sliding properties for moving parts |
| 10 | High Chemical Resistance | Resistant to chemicals and body fluids |
| 11 | High Dimensional Stability | Excellent dimensional stability for precision components |
| 12 | Gamma and EtO Sterilizable | Compatible with conventional sterilization methods |
| 13 | Plasticizer-Free | No plasticizer migration concerns for medical applications |
| 14 | Easy Processability & Colorability | Suitable for injection molding and extrusion; can be easily colored |
Biocompatibility & Regulatory Compliance
VESTAMID Care ML17 has undergone comprehensive biocompatibility testing to ensure safety for medical applications:
| Standard | Test Description |
|---|---|
| USP Class VI | Acute Systemic Toxicity, Intracutaneous Reactivity, Muscle Implantation |
| ISO 10993-5 | Cytotoxicity |
| ISO 10993-10 | Sensitization (Maximization test according to Magnusson and Kligman) |
| ISO 10993-10 | Irritation (Intracutaneous Reactivity) |
| ISO 10993-11 | Acute Systemic Toxicity |
| ASTM F756-08 | Hemocompatibility |
Typical Applications for VESTAMID Care ML17
| Industry | Typical Components & Considerations |
|---|---|
| Catheters | Medical catheters and angioplasty balloon catheters – utilizing biocompatibility, flexibility, and high bursting strength |
| Medical Tubing & Hoses | Flexible tubing and hoses – utilizing high flexibility, rebound properties, and chemical resistance |
| Encapsulation | Encapsulant for electronic components in medical devices |
| Medical Device Housings | Housing parts for monitoring and imaging devices – utilizing dimensional stability and impact resistance |
| Durable Medical Equipment | Components for durable medical equipment – utilizing toughness and chemical resistance |
| Healthcare Products | Care products requiring biocompatibility and high flexibility |
Typical Properties of VESTAMID Care ML17
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density (23°C) | 1.02 g/cm³ | ISO 1183 |
| Water Absorption (Saturation, 23°C) | 1.5% | Similar to ISO 62 |
| Moisture Absorption (23°C, 50% RH) | 0.70% | Similar to ISO 62 |
| Molding Shrinkage – Parallel | 0.7% | ISO 294-4, 2577 |
| Molding Shrinkage – Transverse | 1.2% | ISO 294-4, 2577 |
| Melt Volume Rate (MVR) | 21 cm³/10 min (210°C/2.16kg) | ISO 1133 |
| Viscosity Number | 140 cm³/g | ISO 307 |
| Mechanical | ||
| Tensile Modulus | 1,400 MPa | ISO 527-2 |
| Tensile Stress at Yield | 45.0 MPa | ISO 527-2 |
| Tensile Strain at Yield | 5.0% | ISO 527-2 |
| Nominal Tensile Strain at Break | >50% | ISO 527-1/-2 |
| Impact | ||
| Charpy Notched Impact (23°C) | Complete Break | ISO 179/1eA |
| Charpy Notched Impact (-30°C) | Complete Break | ISO 179/1eA |
| Thermal | ||
| Melting Temperature | 178°C | ISO 11357-3 |
| Glass Transition Temperature | 45°C | ISO 11357-2 |
| HDT @ 0.45 MPa | 110°C | ISO 75-2/B |
| HDT @ 1.80 MPa | 50.0°C | ISO 75-2/A |
| Vicat Softening Temperature (Method A) | 170°C | ISO 306/A |
| Vicat Softening Temperature (Method B) | 140°C | ISO 306/B |
| CTE – Flow (23-55°C) | 1.5×10⁻⁴ cm/cm/°C | ISO 11359-2 |
| Electrical | ||
| Volume Resistivity | 1.0×10¹¹ Ω·m | IEC 62631-3-1 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for VESTAMID Care ML17.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for VESTAMID Care ML17. Request the latest official TDS from our sales team.
📌 Regulatory Compliance – For medical applications, always verify current regulatory certifications (USP Class VI, ISO 10993) remain valid for your specific application and region.
Processing Guidelines for VESTAMID Care ML17
| Step | Process |
|---|---|
| Processing Methods | Injection Molding, Extrusion |
| Drying Recommended | Yes |
| Drying Temperature | 80 – 90°C |
| Drying Time | 4 – 6 hours |
| Suggested Max Moisture | ≤ 0.10% |
| Melt Temperature | 210 – 270°C |
| Optimum Melt Temperature | 230 – 250°C |
| Mold Temperature | 40 – 80°C |
| Injection Pressure | Medium to high |
| Hold Pressure | 30 – 70 MPa |
| Injection Velocity | Medium |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for VESTAMID Care ML17
⚠️ Drying Requirement – VESTAMID Care ML17 requires drying prior to processing to prevent hydrolytic degradation. The recommended drying conditions are 80–90°C for 4–6 hours.
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.10%. Proper drying is essential to prevent void formation and ensure optimal part quality.
⚠️ Melt Temperature – The recommended melt temperature range is 210–270°C, with an optimum of 230–250°C. Avoid exceeding 270°C to prevent material degradation.
⚠️ Mold Temperature – A mold temperature range of 40–80°C is recommended. Higher mold temperatures promote higher crystallinity and better dimensional stability.
⚠️ Medical Grade – The “Care” designation indicates this grade is specifically developed for medical applications. For medical applications, ensure all processing and handling procedures maintain material purity and compliance.
⚠️ Low Viscosity – This grade features low viscosity for excellent flow in thin-wall and complex part molding. Adjust processing parameters accordingly to optimize fill and reduce pressure requirements.
⚠️ Sterilization – This grade is compatible with gamma and EtO sterilization. For medical applications, validate sterilization methods with actual part geometry.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. For subsequent storage, the material should be stored dry until processed.
Comparison: VESTAMID Care ML17 vs. VESTAMID Care ML16
| Feature | VESTAMID Care ML17 | VESTAMID Care ML16 |
|---|---|---|
| Filler Content | Unfilled | Unfilled |
| Viscosity | Low | Lower |
| Key Feature | Higher flexibility & rebound | Highest flow |
| Tensile Modulus | 1,400 MPa | 1,400 MPa |
| Tensile Strength (Yield) | 45 MPa | 43 MPa |
| Elongation at Break | >50% | 350% |
| Density | 1.02 g/cm³ | 1.02 g/cm³ |
| Molding Shrinkage | 0.7% | 0.90% |
| MVR | 21 cm³/10 min | 46 cm³/10 min |
| Viscosity Number | 140 cm³/g | — |
| Primary Application | Catheters, flexible tubing, encapsulation | High-flow thin-wall parts |
Related Products
-
PA12/Polyamide 12 – View our full range of PA12 products
-
Engineering Plastics – Browse all engineering plastic materials
-
VESTAMID Care ML16 – Lower viscosity unfilled PA12 for high-flow medical applications
-
VESTAMID Care ML-GB30 – 30% glass bead filled PA12 for rigid medical housings
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for VESTAMID Care ML17
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of VESTAMID Care ML17 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for VESTAMID Care ML17 |
| Biocompatibility Certification | USP Class VI and ISO 10993 documentation |
| Medical Device Compliance | FDA and EU medical device requirements documentation |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (VESTAMID Care ML17) and document type you require.
FAQ about VESTAMID Care ML17
Q1: What is VESTAMID Care ML17?
A: VESTAMID Care ML17 is an unfilled, low viscosity polyamide 12 (PA12) resin from Evonik, specifically developed for medical applications.
Q2: What does the “Care” designation mean?
A: The “Care” designation indicates this grade is specifically developed for medical applications, with biocompatibility tested following ISO 10993-1 recommendations.
Q3: What are the key features of VESTAMID Care ML17?
A: Unfilled; low viscosity; USP Class VI & ISO 10993 compliant; high flexibility & elasticity; good rebound properties; high impact resistance; high abrasion resistance; low sliding friction; high chemical resistance; gamma and EtO sterilizable; plasticizer-free.
Q4: What are the typical applications for VESTAMID Care ML17?
A: Catheters, angioplasty balloon catheters, flexible medical tubing and hoses, encapsulation, medical device housings, monitoring and imaging devices, and durable medical equipment.
Q5: What is the recommended drying condition for VESTAMID Care ML17?
A: Dry at 80–90°C for 4–6 hours. Maximum residual moisture should be ≤ 0.10%.
Q6: What is the density of VESTAMID Care ML17?
A: 1.02 g/cm³.
Q7: What is the tensile modulus of VESTAMID Care ML17?
A: 1,400 MPa.
Q8: What regions is VESTAMID Care ML17 available in?
A: North America and Europe.
Q9: Is VESTAMID Care ML17 USP Class VI compliant?
A: Yes, it fulfills the requirements of USP <88> Class VI.
Q10: Is VESTAMID Care ML17 ISO 10993 compliant?
A: Yes, it has been tested for cytotoxicity, sensitization, irritation, and acute systemic toxicity following ISO 10993 recommendations.
Q11: What sterilization methods are compatible with VESTAMID Care ML17?
A: It is compatible with gamma and EtO sterilization.
Q12: Is VESTAMID Care ML17 suitable for extrusion?
A: Yes, it is suitable for both injection molding and extrusion.
Q13: What is the molding shrinkage of VESTAMID Care ML17?
A: 0.7% parallel and 1.2% transverse.
Q14: What is the melt temperature range for VESTAMID Care ML17?
A: 210–270°C, with an optimum of 230–250°C.
Q15: What is the viscosity number of VESTAMID Care ML17?
A: 140 cm³/g (ISO 307).
Q16: What is the difference between VESTAMID Care ML17 and VESTAMID Care ML16?
A: VESTAMID Care ML17 has a higher viscosity than ML16 (MVR 21 vs. 46 cm³/10 min), offering slightly higher tensile strength (45 vs. 43 MPa) and better rebound properties. ML16 is optimized for highest flow in thin-wall parts, while ML17 is optimized for flexibility and rebound in catheters and flexible tubing.
