ULTEM Resin AR9300 is a 30% glass fiber reinforced, amorphous polyetherimide (PEI) engineering thermoplastic manufactured by SABIC. As an authorized distributor and trader, we supply genuine SABIC materials with full traceability.
ULTEM AR9300 is a standard flow, 30% glass fiber reinforced grade specifically engineered for aerospace and mass transportation applications requiring strict flame, smoke, and toxicity (FST) compliance. It delivers the highest stiffness and strength in the AR series. Key attributes include:
-
30% Glass Fiber Reinforcement – Provides the highest stiffness, strength, and dimensional stability in the AR series
-
Standard Flow – Consistent molding performance for complex aerospace components
-
High Heat Resistance – Glass transition temperature (Tg) of 217°C
-
Aerospace FST Compliance – Meets FAR 25.853 and OSU 65/65 with low toxicity, smoke, and flame evolution
-
Highest Stiffness & Strength – Tensile modulus of 8,960 MPa; tensile strength of 155 MPa
-
Excellent Dimensional Stability – Low creep sensitivity, low shrinkage, and low warpage
-
Low Smoke & Toxicity – NBS smoke density of 5; OSU total heat release of 5 kW·min/m²
-
Good Chemical Resistance – Resists many chemicals and provides hydrolytic stability
-
Good Metal Adhesion – Suitable for applications requiring metal bonding
-
ECO Conforming – Meets environmental compliance standards; PFAS-free
-
Sustainable Option – ISCC+ certified bio-based offerings available
-
Versatile Processing – Suitable for injection molding
Key Features of ULTEM AR9300
-
30% Glass Fiber Reinforced – Provides the highest stiffness, strength, and dimensional stability in the AR series; significantly improved rigidity compared to AR9100 (10% glass) and AR9200 (20% glass)
-
Aerospace FST Compliance – Meets FAR 25.853 and OSU 65/65 with low toxicity, smoke, and flame evolution; Vertical Burn (60s) passes at 0 seconds; Vertical Burn (12s) passes at 0 seconds
-
Standard Flow – Designed for injection molding with consistent flow behavior; MFI of 4.2 g/10min (337°C/6.6kg)
-
High Heat Resistance – Glass transition temperature of 217°C; heat deflection temperature of 212°C at 1.82 MPa; Vicat softening temperature of 210-220°C
-
Highest Mechanical Strength – Tensile modulus of 8,960 MPa; tensile strength at break of 155 MPa; flexural modulus of 9,650 MPa; flexural strength of 241 MPa
-
Low Shrinkage – Mold shrinkage of 0.20-0.40% (flow, 3.2mm) for excellent dimensional stability
-
Good Impact Resistance – Notched Izod impact of 117 J/m; reverse notch Izod impact of 534 J/m
-
Low Smoke & Low Toxicity – NBS smoke density (Ds 4 min) of 5; OSU total heat release of 5 kW·min/m²; OSU peak heat release of 40 kW/m²
-
Excellent Dimensional Stability – Low creep sensitivity, low shrinkage, and low warpage
-
Good Chemical & Hydrolytic Resistance – Excellent resistance to many chemicals and moisture
-
Good Metal Adhesion – Suitable for applications requiring metal bonding
-
ECO Conforming – Meets environmental compliance standards; PFAS-free (no PFAS intentionally added during manufacturing)
-
Sustainable Option – ISCC+ certified renewable bio-based solutions available
-
Versatile Processing – Suitable for injection molding
Typical Applications for ULTEM AR9300
| Industry | Typical Applications |
|---|---|
| Aerospace | Aircraft interiors, cabin interiors, aircraft seating – FAR 25.853 & OSU 65/65 compliant |
| Defense | Defense applications requiring FST compliance |
| Mass Transportation | Rail systems, mass transit interiors |
| Additive Manufacturing | Additive manufacturing applications |
| Electrical & Electronics | High-temperature connectors, electronic housings |
| Industrial | High-performance structural applications |
Typical Properties
| Property | ULTEM AR9300 | Unit | Test Method |
|---|---|---|---|
| Physical | |||
| Specific Gravity / Density | 1.49 | g/cm³ | ASTM D792 |
| Mold Shrinkage, Flow (3.2mm) | 0.20 – 0.40 | % | SABIC Method |
| Melt Flow Rate (MFR) – 337°C/6.6kg | 4.2 | g/10min | ASTM D1238 |
| Mechanical | |||
| Tensile Modulus | 8,960 | MPa | ASTM D638 |
| Tensile Strength (Break) | 155 | MPa | ASTM D638 |
| Elongation at Break | 3.0 | % | ASTM D638 |
| Flexural Modulus (100mm span) | 9,650 | MPa | ASTM D790 |
| Flexural Strength (Yield) | 241 | MPa | ASTM D790 |
| Izod Impact (Notched, 23°C) | 117 | J/m | ASTM D256 |
| Izod Impact (Reverse Notched, 3.2mm) | 534 | J/m | ASTM D256 |
| Thermal | |||
| Glass Transition Temperature (Tg) | 217 | °C | |
| Heat Deflection Temp. (1.82MPa, 6.4mm) | 212 | °C | ASTM D648 |
| Vicat Softening Temperature (Rate A/50) | 220 | °C | ISO 306 |
| Vicat Softening Temperature (Rate B/50) | 210 | °C | ISO 306 |
| Thermal Conductivity | 0.23 | W/m-°C | ISO 8302 |
| Flame Characteristics | |||
| FAA Flammability, FAR 25.853 A/B | NATURAL (Pass) | – | FAR 25.853 |
| OSU Total Heat Release (2 min) | 5 | kW·min/m² | FAR 25.853 |
| OSU Peak Heat Release (5 min) | 40 | kW/m² | FAR 25.853 |
| Vertical Burn (60s) passes at | 0 | Seconds | FAR 25.853 |
| Vertical Burn (12s) passes at | 0 | Seconds | FAR 25.853 |
| NBS Smoke Density (Flaming, Ds 4 min) | 5 | – | ASTM E662 |
| NBS Smoke Density (Flaming, Dmax) | 5 | – | ASTM E662 |
| Regulatory | |||
| ECO Conforming | Yes | – | |
| PFAS-Free | Yes | – |
Important Notes on Typical Data:
-
Values listed are typical and sourced from SABIC official data sheets. They do not constitute binding product specification.
-
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
-
Final performance depends on processing conditions, mold design, and part geometry.
-
SABIC official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines (Injection Molding)
| Parameter | Recommended Conditions | |
|---|---|---|
| Drying | ||
| Drying Temperature | 150°C | |
| Drying Time | 4 – 6 hours | |
| Drying Time (Cumulative) | 24 hours | |
| Maximum Moisture Content | ≤0.02% | |
| Injection Molding | ||
| Melt Temperature | 365 – 390°C | |
| Nozzle Temperature | 360 – 380°C | |
| Zone 1 (Rear) Temperature | 345 – 365°C | |
| Zone 2 (Middle) Temperature | 355 – 375°C | |
| Zone 3 (Front) Temperature | 365 – 390°C | |
| Mold Temperature | 135 – 165°C | |
| Back Pressure | 0.3 – 0.7 MPa | |
| Screw Speed | 40 – 70 rpm | |
| Shot to Cylinder Size | 40 – 60% | |
| Vent Depth | 0.025 – 0.076 mm | |
| Hopper Temperature | 80 – 120°C |
Critical Processing Warnings:
-
Drying: ULTEM AR9300 is hygroscopic and must be dried to <0.02% moisture before processing. Dry at 150°C for 4-6 hours.
-
Melt Temperature: Recommended melt temperature range is 365-390°C. Avoid excessive residence times to prevent thermal degradation.
-
Mold Temperature: Higher mold temperatures (135-165°C) improve flow and reduce residual stress.
-
Gate Design: Use large gates and runners to minimize flow resistance and reduce molded-in stress.
-
Regrind: Regrind can be used up to 20-25% with virgin material, provided it is clean and properly dried.
-
Aerospace Compliance: This grade is specifically designed to meet FAR 25.853 and OSU 65/65 requirements for aerospace applications.
-
PFAS-Free: This product does not contain PFAS intentionally added during manufacturing.
AR Series Comparison
| Property | AR9100 | AR9110 | AR9200 | AR9300 |
|---|---|---|---|---|
| Glass Fiber Content | 10% | 10% | 20% | 30% |
| Flow Type | Standard | Enhanced | Standard | Standard |
| Density (g/cm³) | 1.32-1.34 | 1.40 | 1.40-1.42 | 1.49 |
| Tensile Modulus (MPa) | 4,340 | 4,480 | 6,960 | 8,960 |
| Tensile Strength (MPa) | 110-119 | 102-106 | 151 | 155 |
| Flexural Modulus (MPa) | 5,030 | 4,830 | 7,230 | 9,650 |
| Notched Izod (J/m) | 69 | 58-59 | 101 | 117 |
| HDT @ 1.82MPa (°C) | 207 | 208 | 211 | 212 |
| FAR 25.853 / OSU 65/65 | Yes | Yes | Yes | Yes |
Related Products
-
Explore PEI / Polyetherimide – Browse all ULTEM PEI resin options
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| SABIC Official TDS | Complete physical, thermal, and mechanical properties of ULTEM AR9300 |
| SABIC Official SDS | GHS-compliant chemical safety documentation |
| FAR 25.853 / OSU 65/65 Compliance | Aerospace flame, smoke, and toxicity certification |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| Processing Guide | Detailed processing guidelines for ULTEM resins |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (ULTEM AR9300) and document type you require.
FAQ
Q1: What is ULTEM AR9300 and what is it used for?
A: ULTEM AR9300 is a 30% glass fiber reinforced polyetherimide (PEI) resin manufactured by SABIC, specifically engineered for aerospace and mass transportation applications requiring strict flame, smoke, and toxicity (FST) compliance. It is the highest stiffness grade in the AR series and is widely used in aircraft interiors, rail systems, defense applications, and industrial applications.
Q2: What is the glass fiber content of ULTEM AR9300?
A: ULTEM AR9300 contains 30% glass fiber reinforcement.
Q3: What flame, smoke, and toxicity standards does ULTEM AR9300 meet?
A: ULTEM AR9300 meets FAR 25.853 and OSU 65/65 with low toxicity, smoke, and flame evolution. It has very low smoke density (NBS Ds 4 min of 5) and low heat release (OSU total of 5 kW·min/m², peak of 40 kW/m²).
Q4: What is the glass transition temperature of ULTEM AR9300?
A: The glass transition temperature (Tg) is 217°C.
Q5: What is the density of ULTEM AR9300?
A: The density is 1.49 g/cm³.
Q6: What is the tensile strength of ULTEM AR9300?
A: Tensile strength at break is 155 MPa.
Q7: What is the tensile modulus of ULTEM AR9300?
A: The tensile modulus is 8,960 MPa.
Q8: What is the melt flow rate of ULTEM AR9300?
A: The Melt Flow Rate (MFR) is 4.2 g/10min at 337°C, 6.6kg.
Q9: What is the heat deflection temperature of ULTEM AR9300?
A: Heat deflection temperature is 212°C at 1.82 MPa (6.4mm, unannealed).
Q10: What is the shrinkage of ULTEM AR9300?
A: Mold shrinkage (flow, 3.2mm) is 0.20-0.40%.
Q11: What processing methods can be used for ULTEM AR9300?
A: ULTEM AR9300 is suitable for injection molding.
Q12: Is ULTEM AR9300 PFAS-free?
A: Yes. ULTEM AR9300 is PFAS-free – it does not contain PFAS intentionally added during manufacturing.
Q13: Is ULTEM AR9300 ECO conforming?
A: Yes. ULTEM AR9300 is ECO Conforming.
Q14: What is the difference between ULTEM AR9200 (20% glass) and AR9300 (30% glass)?
A: ULTEM AR9300 contains 30% glass fiber reinforcement compared to 20% in AR9200, providing significantly higher stiffness (tensile modulus 8,960 MPa vs 6,960 MPa) and strength (155 MPa vs 151 MPa). Both grades meet FAR 25.853 and OSU 65/65 requirements for aerospace applications.
Q15: What is the lead time for orders?
A: Regular orders ship within 7-10 working days after payment confirmation. Large-volume or urgent orders can be negotiated separately.
CTA (Call to Action)
Ready to order ULTEM AR9300?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (aerospace interiors, rail, defense, additive manufacturing, etc.)
-
Processing method (injection molding)
-
Color requirement (custom colors available via ColorXpress)
-
Bio-based preference (standard or ISCC+ certified renewable grade)
-
Document requirement (TDS, SDS, FAR 25.853 compliance, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, SABIC official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working-days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates (e.g., FAR 25.853, RoHS) on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original SABIC typical values for ULTEM AR9300. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on processing conditions, mold design, and part geometry. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for product failure caused by improper processing or improper usage. Always reference the latest SABIC official TDS of ULTEM AR9300 as the definitive specification.
