描述
ULTEM Resin 2400F is a 40% glass fiber reinforced, amorphous polyetherimide (PEI) engineering thermoplastic manufactured by SABIC. As an authorized distributor and trader, we supply genuine SABIC materials with full traceability. For more product options and company information, please visit our website at https://szrqchem.com/.
ULTEM 2400F is a standard flow, 40% glass fiber reinforced grade specifically designed for food contact applications. Key attributes include:
-
40% Glass Fiber Reinforcement – Delivers the highest stiffness and creep resistance among food-grade ULTEM materials
-
FDA & EU Food Contact Compliant – Approved for food contact applications; NSF 51 listed and WRAS certified
-
High Heat Resistance – Glass transition temperature (Tg) of 217°C
-
Inherent Flame Retardancy – UL94 V-0 (0.25mm) and 5VA ratings without halogenated additives
-
Highest Stiffness & Strength – Tensile modulus of 11,500-11,720 MPa; tensile strength of 159-179 MPa
-
Excellent Dimensional Stability – Low creep sensitivity and ultra-low shrinkage (0.10-0.30%)
-
Low Smoke & Toxicity – Suitable for aerospace and mass transit applications
-
Good Chemical Resistance – Resists automotive fluids, aircraft fluids, alcohols, acids, and weak aqueous solutions
-
Hydrolytic Stability – Good resistance to moisture and hydrolysis
-
RoHS Compliant – Meets environmental compliance standards
-
No PFAS Intentionally Added – Safe for environmentally conscious applications
Key Features of ULTEM 2400F
-
40% Glass Fiber Reinforced – Provides the highest stiffness, strength, and dimensional stability among food-grade ULTEM grades; the highest rigidity within Food-Grade ULTEM Materials
-
FDA & EU Food Contact Compliant – Approved for food contact applications by US FDA and European Food Contact regulations; NSF 51 listed and WRAS certified for food equipment and potable water systems
-
Standard Flow – Designed for injection molding with stable flow characteristics; MVR of 5 cm³/10min at 360°C/5kg; MFR of 5.2 g/10min at 337°C/6.6kg
-
High Heat Resistance – Glass transition temperature of 217°C; UL RTI of 170°C; Vicat softening temperature of 217°C
-
Inherent Flame Retardancy – UL94 V-0 (0.25mm) and 5VA ratings without halogenated additives; UL Yellow Card available
-
Highest Mechanical Strength – Tensile modulus of 11,500-11,720 MPa; tensile strength of 159-179 MPa; flexural modulus of 10,000 MPa; flexural strength of 228 MPa
-
Excellent Dimensional Stability – Ultra-low shrinkage (0.10-0.30%); low creep sensitivity; good dimensional stability across a broad temperature range
-
Good Chemical Resistance – Resists automotive and aircraft fluids, aliphatic hydrocarbons, alcohols, acids, and weak aqueous solutions
-
Hydrolytic Stability – Good resistance to moisture and hydrolysis
-
Good Impact Resistance – Unnotched Izod impact of 29 kJ/m²; Charpy impact of 30-32 kJ/m²
-
Good Metal Adhesion – Suitable for applications requiring metal bonding
-
Low Smoke & Low Toxicity – Inherently low smoke and toxicity
-
RoHS Compliant – Meets environmental compliance standards
-
ECO Conforming – Meets environmental compliance standards
-
Versatile Processing – Suitable for injection molding
Typical Applications for ULTEM 2400F
| Industry | Typical Applications |
|---|---|
| Food Processing Equipment | Food contact equipment, food processing machinery, food & beverage applications – FDA & NSF 51 compliant |
| Fluid Handling & Water Systems | Potable water systems, fluid handling components – WRAS certified |
| Flexible Food Packaging | Food packaging, consumer packaging – FDA & EU food contact approved |
| Aerospace | Aircraft interiors – low smoke and toxicity; FAR 25.853 compliant |
| Electrical & Electronics | High-temperature connectors, IC sockets, electrical components – UL94 V-0 |
| Consumer Goods | Home & commercial appliances, personal accessories, home decoration |
| Automotive | Under-hood sensors, connectors, heavy truck, motorcycle |
| Industrial | High-performance structural components, high-load industrial systems |
| Semiconductor | High-temperature wafer carriers, sockets |
| Building & Construction | Building components, water management |
| Mass Transportation | Rail, recreational/specialty vehicles, buses |
| Medical | Not for medical applications requiring biocompatibility. Alternative grade HU2400 available |
Typical Properties
| Property | ULTEM 2400F | Unit | Test Method |
|---|---|---|---|
| Density | 1.61 | g/cm³ | ISO 1183 |
| MVR (360°C/5kg) | 5.0 | cm³/10min | ISO 1133 |
| MFR (337°C/6.6kg) | 5.2 | g/10min | ASTM D1238 |
| Glass Transition Temperature (Tg) | 217 | °C | |
| Vicat Softening Temperature | 217 | °C | |
| UL RTI (Elec/Imp/Str) | 170 | °C | UL 746B |
| Tensile Modulus | 11,500-11,720 | MPa | ISO 527 |
| Tensile Strength (Break) | 159-179 | MPa | ISO 527 |
| Elongation at Break | 2.0-2.5 | % | ISO 527 |
| Flexural Modulus | 10,000 | MPa | ISO 178 |
| Flexural Strength | 228 | MPa | ISO 178 |
| Izod Impact (Unnotched, ISO) | 29 | kJ/m² | ISO 180/1U |
| Charpy Impact (Unnotched) | 30-32 | kJ/m² | ISO 179/1eU |
| Mold Shrinkage (Flow, 3.2mm) | 0.10-0.30 | % | SABIC Method |
| Taber Abrasion (CS-17, 1kg) | – | mg/1000cy | SABIC Method |
| Volume Resistivity | – | Ω·cm | IEC 60093 |
| Dielectric Strength (in oil) | – | kV/mm | IEC 60243-1 |
| UL 94 Flammability | V-0 (0.25mm), 5VA | – | UL 94 |
| FDA Compliance | Yes | – | US FDA |
| EU Food Contact Compliance | Yes | – | EU Regulations |
| NSF 51 Listing | Yes | – | NSF 51 |
| WRAS Certification | Yes | – | WRAS |
| RoHS Compliance | Yes | – |
Important Notes on Typical Data:
-
Values listed are typical and sourced from SABIC official data sheets. They do not constitute binding product specification.
-
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
-
Final performance depends on processing conditions, mold design, and part geometry.
-
SABIC official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Parameter | Recommended Conditions |
|---|---|
| Drying | 150°C for 4-6 hours |
| Recommended Moisture | <0.02% |
| Hopper Temperature | 80-100°C |
| Front Zone Temperature | 380-420°C |
| Nozzle Temperature | 370-410°C |
| Mold Temperature | 135-165°C |
| Back Pressure | 0.3-0.7 MPa |
| Screw Speed | 40-70 rpm |
| Shot Size | 40-60% of cylinder capacity |
Critical Processing Warnings:
-
Drying: ULTEM 2400F is hygroscopic and must be dried to <0.02% moisture before processing. Dry at 150°C for 4-6 hours.
-
Melt Temperature: Recommended melt temperature range is 370-420°C. Avoid excessive residence times to prevent thermal degradation.
-
Mold Temperature: Higher mold temperatures (135-165°C) improve flow and reduce residual stress.
-
Gate Design: Use large gates and runners to minimize flow resistance and reduce molded-in stress.
-
Regrind: Regrind can be used up to 20-25% with virgin material, provided it is clean and properly dried.
-
Food Contact Compliance: This material is US FDA and EU Food Contact approved.
-
Not for Medical Applications: Effective June 2007, this grade is no longer supported with biocompatibility information and should not be used for medical applications which require biocompatibility. For medical applications, please use alternative grade HU2400.
Related Products
-
Explore PEI / Polyetherimide – Browse all ULTEM PEI resin options
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| SABIC Official TDS | Complete physical, thermal, and mechanical properties of ULTEM 2400F |
| SABIC Official SDS | GHS-compliant chemical safety documentation |
| UL Yellow Card | UL certification |
| FDA Compliance Declaration | US FDA food contact compliance |
| EU Food Contact Compliance | European food contact compliance |
| NSF 51 Listing | Food equipment certification |
| WRAS Certification | Water Regulations Advisory Scheme certification |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| Processing Guide | Detailed processing guidelines for ULTEM resins |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (ULTEM 2400F) and document type you require.
FAQ
Q1: What is ULTEM 2400F and what is it used for?
A: ULTEM 2400F is a 40% glass fiber reinforced polyetherimide (PEI) resin manufactured by SABIC with FDA & EU food contact compliance, NSF 51 listing, and WRAS certification. It offers the highest stiffness among food-grade ULTEM grades. It is widely used in food processing equipment, fluid handling systems, flexible food packaging, aerospace interiors, electrical/electronic components, automotive under-hood applications, and high-load industrial systems.
Q2: Is ULTEM 2400F FDA compliant?
A: Yes. ULTEM 2400F is US FDA and European Food Contact approved. It is also NSF 51 listed and WRAS certified.
Q3: What is the glass fiber content of ULTEM 2400F?
A: ULTEM 2400F contains 40% glass fiber reinforcement.
Q4: What is the glass transition temperature of ULTEM 2400F?
A: The glass transition temperature (Tg) is 217°C.
Q5: What is the density of ULTEM 2400F?
A: The density is 1.61 g/cm³.
Q6: Is ULTEM 2400F flame retardant?
A: Yes. ULTEM 2400F is inherently flame retardant with UL94 V-0 (0.25mm) and 5VA ratings without halogenated additives.
Q7: What is the tensile modulus of ULTEM 2400F?
A: The tensile modulus is 11,500-11,720 MPa.
Q8: What is the shrinkage of ULTEM 2400F?
A: Mold shrinkage (flow, 3.2mm) is 0.10-0.30%.
Q9: What processing methods can be used for ULTEM 2400F?
A: ULTEM 2400F is processed by injection molding.
Q10: Is ULTEM 2400F RoHS compliant?
A: Yes. ULTEM 2400F is RoHS compliant.
Q11: Can ULTEM 2400F be used for medical applications?
A: No. Effective June 2007, this grade is no longer supported with biocompatibility information and should not be used for medical applications which require biocompatibility. For medical applications, please use alternative grade HU2400.
Q12: What is the difference between ULTEM 2400 and ULTEM 2400F?
A: The key difference is that ULTEM 2400F is FDA & EU food contact compliant, while the standard ULTEM 2400 grade does not carry this certification. Both grades contain 40% glass fiber reinforcement and share similar mechanical, thermal, and electrical properties.
Q13: What is the lead time for orders?
A: Regular orders ship within 7-10 working days after payment confirmation. Large-volume or urgent orders can be negotiated separately.
CTA (Call to Action)
Ready to order ULTEM 2400F?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (food processing, fluid handling, aerospace, electrical, etc.)
-
Processing method (injection molding)
-
Color requirement (recognized colors available)
-
Document requirement (TDS, SDS, UL, FDA compliance, NSF 51, WRAS, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, SABIC official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working-days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates (e.g., FDA, EU, NSF 51, WRAS, UL, RoHS) on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original SABIC typical values for ULTEM 2400F. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on processing conditions, mold design, and part geometry. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for product failure caused by improper processing or improper usage. Always reference the latest SABIC official TDS of ULTEM 2400F as the definitive specification.
