ULTEM Resin 2210F is a 20% glass fiber reinforced, amorphous polyetherimide (PEI) engineering thermoplastic manufactured by SABIC. As an authorized distributor and trader, we supply genuine SABIC materials with full traceability. For more product options and company information, please visit our website at https://szrqchem.com/.
ULTEM 2210F is a 20% glass fiber reinforced, enhanced flow grade specifically designed for food contact applications. Key attributes include:
-
20% Glass Fiber Reinforcement – Provides high stiffness, strength, and dimensional stability
-
Enhanced Flow – Improved flow characteristics for easier processing and better mold filling
-
FDA Food Contact Compliant – US FDA approved in recognized colors
-
High Heat Resistance – Glass transition temperature (Tg) of 217°C; RTI of 170°C
-
Inherent Flame Retardancy – UL94 V-0 (0.4mm) and 5VA (1.9mm) ratings
-
High Stiffness & Strength – Tensile modulus of 6,800 MPa; tensile strength of 140 MPa
-
Excellent Dimensional Stability – Low creep sensitivity and low shrinkage (0.30-0.50%)
-
Low Smoke & Toxicity – Inherently low smoke and toxicity; combustion products are no more toxic than wood
-
Good Chemical Resistance – Resists automotive fluids, aircraft fluids, alcohols, acids, and weak aqueous solutions
-
ECO Conforming & RoHS Compliant – Meets environmental compliance standards
Key Features of ULTEM 2210F
-
FDA Food Contact Compliant – US FDA Food Contact compliant in recognized colors. This material is food contact compliant in most jurisdictions – exceptions may exist, request a declaration for details
-
20% Glass Fiber Reinforced – Provides significantly increased stiffness, strength, and dimensional stability compared to unreinforced grades
-
Enhanced Flow – Improved flow characteristics for easier processing and better mold filling of complex, thin-walled parts
-
High Heat Resistance – Glass transition temperature of 217°C; heat deflection temperature of 205°C at 1.8 MPa; Vicat softening temperature of 218-223°C; UL RTI of 170°C
-
Inherent Flame Retardancy – UL94 V-0 (0.4mm) and 5VA (1.9mm) ratings; low smoke and toxicity
-
High Mechanical Strength – Tensile modulus of 6,800 MPa; tensile strength at break of 140 MPa; flexural modulus of 6,500 MPa; flexural strength of 210 MPa
-
Excellent Dimensional Stability – Low creep sensitivity and low shrinkage (0.30-0.50%); low warpage
-
Good Chemical Resistance – Resists automotive and aircraft fluids, aliphatic hydrocarbons, alcohols, acids, and weak aqueous solutions
-
Hydrolytic Stability – Good resistance to moisture and hydrolysis
-
Good Metal Adhesion – Suitable for applications requiring metal bonding
-
Low Smoke & Low Toxicity – Inherently low smoke and toxicity; suitable for aerospace and mass transit applications
-
ECO Conforming – Meets environmental compliance standards
-
Versatile Processing – Suitable for injection molding
Typical Applications for ULTEM 2210F
| Industry | Typical Applications |
|---|---|
| Food Contact & Packaging | Flexible food packaging, food & beverage, consumer packaging – FDA compliant |
| Food Service Equipment | Microwave and air-fryer containers, convection oven components, airline food service trays, coffee machine and juicer components |
| Aerospace | Aircraft interiors – low smoke and toxicity |
| Electrical & Electronics | High-temperature connectors, IC sockets, electrical components |
| Automotive | Under-hood sensors, connectors |
| Consumer Goods | Home appliances, commercial appliances, personal accessories, home decoration |
| Industrial | High-performance structural components, precision parts |
Typical Properties
| Property | ULTEM 2210F (ISO) | Unit | Test Method |
|---|---|---|---|
| Density | 1.42 | g/cm³ | ISO 1183 |
| MVR (360°C/5kg) | 10 | cm³/10min | ISO 1133 |
| Tensile Modulus | 6,800 | MPa | ISO 527 |
| Tensile Stress at Break | 140 | MPa | ISO 527 |
| Strain at Break | 2.0 | % | ISO 527 |
| Flexural Modulus | 6,500 | MPa | ISO 178 |
| Flexural Strength | 210 | MPa | ISO 178 |
| Charpy Impact (Notched, 23°C) | 9.0 | kJ/m² | ISO 179/2C |
| Charpy Impact (Unnotched, 23°C) | 35 | kJ/m² | ISO 179/1eU |
| Izod Impact (Unnotched, 23°C) | 30 | kJ/m² | ISO 180/1U |
| Ball Indentation Hardness | 150 | MPa | ISO 2039-1 |
| Heat Deflection Temp. (1.8 MPa) | 205 | °C | ISO 75-2/Ae |
| Vicat Softening Temp. (A50) | 223 | °C | ISO 306 |
| Vicat Softening Temp. (B50) | 212 | °C | ISO 306 |
| Vicat Softening Temp. (B120) | 218 | °C | ISO 306 |
| UL RTI (Elec/Imp/Str) | 170 | °C | UL 746B |
| Thermal Conductivity | 0.28 | W/(m·K) | ISO 8302 |
| Volume Resistivity | 1.0×10¹⁵ | Ω·cm | IEC 60093 |
| Dielectric Strength (1.6mm, oil) | 26 | kV/mm | IEC 60243-1 |
| UL 94 Flammability | V-0 (0.4mm), 5VA (1.9mm) | – | IEC 60695 |
Important Notes on Typical Data:
-
Values listed are typical and sourced from SABIC official data sheets. They do not constitute binding product specification.
-
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
-
Final performance depends on processing conditions, mold design, and part geometry.
-
SABIC official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Parameter | Recommended Conditions |
|---|---|
| Drying | 150°C for 4-6 hours |
| Recommended Moisture | ≤0.02% |
| Melt Temperature | 350 – 400°C |
| Rear Zone Temperature | 330 – 400°C |
| Middle Zone Temperature | 340 – 400°C |
| Front Zone Temperature | 345 – 400°C |
| Nozzle Temperature | 345 – 400°C |
| Mold Temperature | 135 – 165°C |
| Back Pressure | 0.3 – 0.7 MPa |
| Screw Speed | 40 – 70 rpm |
Critical Processing Warnings:
-
Drying: ULTEM 2210F is hygroscopic and must be dried to <0.02% moisture before processing. Dry at 150°C for 4-6 hours.
-
Enhanced Flow: This grade offers improved flow characteristics for easier processing and better mold filling of complex parts.
-
Melt Temperature: Recommended melt temperature range is 350-400°C. Avoid excessive residence times to prevent thermal degradation.
-
Mold Temperature: Higher mold temperatures (135-165°C) improve flow and reduce residual stress.
-
Gate Design: Use large gates and runners to minimize flow resistance and reduce molded-in stress.
-
Regrind: Regrind can be used up to 20-25% with virgin material, provided it is clean and properly dried.
-
Food Contact Compliance: This material is US FDA Food Contact compliant in recognized colors. This material is food contact compliant in most jurisdictions – exceptions may exist, request a declaration for details.
