ULTEM 1110 – Enhanced Flow Unreinforced PEI Resin by SABIC

ULTEM Resin 1110 is an enhanced flow, unreinforced, amorphous polyetherimide (PEI) engineering thermoplastic manufactured by SABIC. As an authorized distributor and trader, we supply genuine SABIC materials with full traceability. For more product options and company information, please visit our website at https://szrqchem.com/.

ULTEM 1110 is a general purpose, enhanced flow grade that delivers an outstanding balance of mechanical, thermal, and electrical properties. Key attributes include:

• Enhanced Flow – Improved flow characteristics for easier processing and better mold filling of complex parts

• High Heat Resistance – Glass transition temperature (Tg) of 217°C; RTI (Relative Thermal Index) of 170°C

• Inherent Flame Retardancy – UL94 V-0 (0.75mm) and 5VA (3.0mm) ratings without additives; oxygen index of 47%

• High Strength & Modulus – Tensile strength of 110 MPa; tensile modulus of 3,720 MPa

• Excellent Dimensional Stability – Low creep sensitivity and low shrinkage (0.50-0.70%)

• High Pigment Load Capacity – Supports high pigment loads for custom color applications

• Good Chemical Resistance – Resists automotive fluids, aircraft fluids, alcohols, acids, and weak aqueous solutions

• Low Smoke & Toxicity – Meets aerospace and mass transit requirements

• Hydrolytic Stability – Good resistance to moisture and hydrolysis

Key Features of ULTEM 1110

• Enhanced Flow Grade – Improved flow characteristics compared to standard PEI grades, enabling easier processing and filling of complex, thin-walled parts

• High Heat Resistance – Glass transition temperature of 217°C; heat deflection temperature of 199°C at 1.8 MPa; RTI of 170°C

• Inherent Flame Retardancy – UL94 V-0 (0.75mm) and 5VA (3.0mm) ratings; oxygen index of 47%

• High Mechanical Strength – Tensile strength of 110 MPa; tensile modulus of 3,720 MPa; flexural modulus of 3,720 MPa

• Excellent Dimensional Stability – Low mold shrinkage (0.50-0.70%); low creep sensitivity and low warpage

• High Pigment Load Capacity – Supports high pigment loads for custom color applications

• Good Chemical Resistance – Excellent resistance to automotive fluids, aircraft fluids, alcohols, acids, and weak aqueous solutions

• Hydrolytic Stability – Good resistance to moisture and hydrolysis

• Outstanding Electrical Properties – Excellent electrical insulation; arc resistance PLC 5

• Low Smoke & Low Toxicity – Inherently low smoke and toxicity; suitable for aerospace and mass transit applications

• ECO Conforming & RoHS Compliant – Meets environmental compliance standards

• Versatile Processing – Suitable for injection molding

Typical Applications for ULTEM 1110

Typical Properties

Important Notes on Typical Data:

• Values listed are typical and sourced from SABIC official data sheets. They do not constitute binding product specification.

• Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.

• Final performance depends on processing conditions, mold design, and part geometry.

• SABIC official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.

Processing Guidelines

Critical Processing Warnings:

• Drying: ULTEM 1110 is hygroscopic and must be dried to <0.02% moisture before processing. Dry at 150°C for 4-6 hours.

• Melt Temperature: Recommended melt temperature range is 350-400°C. Avoid excessive residence times to prevent thermal degradation.

• Enhanced Flow: This grade offers improved flow characteristics for easier processing and better mold filling of complex parts.

• Mold Temperature: Higher mold temperatures (135-165°C) improve flow and reduce residual stress.

• Gate Design: Use large gates and runners to minimize flow resistance and reduce molded-in stress.

• Regrind: Regrind can be used up to 20-25% with virgin material, provided it is clean and properly dried.

Related Products

• Explore PEI / Polyetherimide – Browse all ULTEM PEI resin options

• Explore Engineering Plastics – Browse all engineering plastic materials

• About Our Company – Learn more about our supply capabilities and quality assurance

Technical Documents

Request any document above by:

• Email: ruiqingchem@gmail.com

• Online form: Our contact page

We reply within one working business day. Please clearly state product (ULTEM 1110) and document type you require.

FAQ

Q1: What is ULTEM 1110 and what is it used for?
A: ULTEM 1110 is an enhanced flow, unreinforced polyetherimide (PEI) resin manufactured by SABIC. It combines high heat resistance (Tg 217°C), inherent flame retardancy (UL94 V-0 & 5VA), and improved flow for easier processing. It is widely used in electrical/electronic components, home appliances, automotive under-hood applications, consumer goods, and industrial components.

Q2: What is the difference between ULTEM 1000 and ULTEM 1110?
A: ULTEM 1110 offers enhanced flow compared to ULTEM 1000 (MFR 16 vs 9.0 g/10min), making it easier to process and fill complex molds. It also has slightly higher density (1.36 vs 1.27 g/cm³). Both grades share similar heat resistance, flame retardancy, and mechanical properties.

Q3: What is the glass transition temperature of ULTEM 1110?
A: The glass transition temperature (Tg) is 217°C.

Q4: What is the density of ULTEM 1110?
A: The density is 1.36 g/cm³.

Q5: Is ULTEM 1110 flame retardant?
A: Yes. ULTEM 1110 is inherently flame retardant with UL94 V-0 (0.75mm) and 5VA (3.0mm) ratings.

Q6: What processing methods can be used for ULTEM 1110?
A: ULTEM 1110 is primarily processed by injection molding.

Q7: What is the MFR of ULTEM 1110?
A: The Melt Flow Rate is 16 g/10min at 337°C, 6.6kg.

Q8: Is ULTEM 1110 RoHS compliant?
A: Yes. ULTEM 1110 complies with RoHS and is ECO conforming.

Q9: Does ULTEM 1110 have good chemical resistance?
A: Yes. ULTEM 1110 offers good chemical resistance for an amorphous material, resisting automotive fluids, aircraft fluids, alcohols, acids, and weak aqueous solutions.

Q10: What is the lead time for orders?
A: Regular orders ship within 7-10 working days after payment confirmation. Large-volume or urgent orders can be negotiated separately.

CTA (Call to Action)

Ready to order ULTEM 1110?

To get a precise quotation and professional technical support, please share:

• Required quantity (kg)

• Destination port or delivery address

• Target application (electrical, appliances, automotive, consumer, etc.)

• Processing method (injection molding, etc.)

• Color requirement (natural amber or custom color)

• Document requirement (TDS, SDS, UL, FDA compliance, COA, etc.)

Sample Policy:

• Samples are for laboratory validation tests only, not for production use.

• Buyer bears international sample-shipping freight.

• If bulk-product performance deviates from sample reference, SABIC official TDS serves as the authoritative benchmark.

Take action now:

• 📧 Email Us – ruiqingchem@gmail.com

• 📝 Send Inquiry – Use our quick inquiry form

• 💬 Live Chat – Click the bottom-right chat widget to speak directly with our team

After-Sales Support

Disclaimer

DISCLAIMER: All technical data is referenced from original SABIC typical values for ULTEM 1110. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on processing conditions, mold design, and part geometry. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for product failure caused by improper processing or improper usage. Always reference the latest SABIC official TDS of ULTEM 1110 as the definitive specification.
