TPX MX002O – Transparent Heat-Resistant PMP Resin by Mitsui Chemicals

TPX MX002O is a transparent polymethylpentene (PMP) copolymer resin manufactured by Mitsui Chemicals, Inc. – the world’s sole producer of TPX brand PMP resins. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Mitsui Chemicals technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.

TPX is a crystalline polyolefin made from 4-methylpentene-1, produced by Mitsui Chemicals’ special technology of molecular design and catalyst. TPX MX002O is a low modulus, low density, heat resistant polymethylpentene that offers an exceptional combination of properties:

• Excellent transparency equivalent to glass and acrylic (94% light transmittance)

• Lowest density among thermoplastic polymers – only 0.834 g/cm³

• Superior releasability – easy release from molds

• High gas permeability – suitable for gas separation and breathable applications

• Good chemical resistance – durable against acids, alkalis, and alcohol

TPX MX002O is certified for food packaging materials by United States Code of Federal Regulations Title 21 (FDA) and Japan Hygienic Olefin and Styrene Plastics Association (JHOSPA).

Recommended for injection molding, T-Die casting extrusion, direct blow molding, and extrusion by profile, mandrel, pipe and fiber spinning.

Key Features of TPX MX002O

• Lowest Specific Gravity Among Plastics – Density of only 0.834 g/cm³ – one of the lightest polymer materials among thermoplastics

• Superior Optical Clarity – Light transmittance of 94% with haze as low as 0.7%; refractive index of 1.463

• High Heat Resistance – Melting point of 224-225°C; Vicat softening point of 149°C

• Low Modulus / High Flexibility – Flexural modulus of 480-540 MPa; tensile modulus of 510-900 MPa

• Excellent Release Properties – Superior releasability; low surface tension prevents sticking and contamination

• Good Chemical Resistance – Durable against acids, alkalis, and alcohol; very low water absorption (<0.01%)

• High Gas Permeability – Exhibits high gas permeability

• Excellent Electrical Properties – Volume resistivity >10¹⁶ Ω·cm; dielectric constant of 2.12-2.15

• Low Refractive Index – Refractive index of 1.463

• FDA Compliant – Certified for food contact applications per FDA 21 CFR

• Halogen-Free – Environmentally-friendly material

• Versatile Processing – Suitable for injection molding, extrusion (T-Die casting, profile, mandrel, pipe), blow molding, and fiber spinning

• UL 94 HB – UL 94 flammability rating of HB

Typical Applications for TPX MX002O

Material Advantages

TPX MX002O is a high-performance transparent resin that delivers:

• High Gas Permeability – Exhibits high gas permeability, making it suitable for applications requiring breathability or gas exchange, such as hollow fiber membranes

• Lightest Thermoplastic – With a density of only 0.834 g/cm³, TPX MX002O significantly reduces part weight compared to PC, PMMA, or glass

• Exceptional Clarity – 94% light transmittance rivals PMMA while offering superior heat resistance and chemical resistance

• Superior Releasability – Low surface tension simplifies mold release and reduces cleaning downtime

• Excellent Chemical Resistance – Strong against acids, alkalis, and alcohol; low water absorption (<0.01%) ensures dimensional stability

• FDA Compliance – Approved for food contact, enabling use in food packaging and food processing applications

• Design Flexibility – Can be processed by injection molding, T-Die casting extrusion, blow molding, and fiber spinning

• Excellent Electrical Insulation – High volume resistivity (>10¹⁶ Ω·cm) and low dielectric constant (2.12-2.15)

• Proven Reliability – Manufactured by Mitsui Chemicals, the world’s sole producer of TPX resins

• Environmental Friendliness – Halogen-free polymer with low density that reduces transportation environmental load

Typical Properties

Important Notes on Typical Data:

• Values listed are typical and sourced from Mitsui Chemicals official data sheets. They do not constitute binding product specification.

• Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.

• Final performance depends on processing conditions, mold design, and part geometry.

• Mitsui Chemicals official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.

Processing Guidelines

Critical Processing Warnings:

• Drying: TPX MX002O is not hygroscopic and typically does not require drying. If moisture is a concern, dry at 80-100°C for 2-3 hours.

• Recommended Processing: Suitable for injection molding, T-Die casting extrusion, direct blow molding, and extrusion by profile, mandrel, pipe and fiber spinning.

• Gate Design: Pin gate is the most suitable for TPX molds due to excellent flowability. Avoid large gates that can cause residual stress and gate cracks.

• Cooling: Sufficient and well-balanced cooling channels are essential due to TPX’s crystalline nature and larger shrinkage compared to amorphous polymers.

• Surface Finish: Highly polished mold surface is recommended for excellent transparency.

• Shrinkage: Mold design should account for higher shrinkage (MD: 1.6%, TD: 1.3%). Off-center gates are recommended to prevent warpage.

• Regrind: Regrind can be used up to 20-30% with virgin material, provided it is clean and properly dried.

Related Products

• Explore TPX Transparent Resins – Browse all TPX resin options

• Explore Engineering Plastics – Browse all engineering plastic materials

• About Our Company – Learn more about our supply capabilities and quality assurance

Technical Documents

Request any document above by:

• Email: ruiqingchem@gmail.com

• Online form: Our contact page

We reply within one working business day. Please clearly state product (TPX MX002O) and document type you require.

FAQ

Q1: What is TPX MX002O and what is it used for?
A: TPX MX002O is a low modulus, low density, transparent polymethylpentene (PMP) resin manufactured by Mitsui Chemicals. It combines excellent transparency (94% light transmittance), high gas permeability, superior releasability, and heat resistance (MP 224-225°C). It is widely used in FPC release films, LED molds, food containers, rubber hose mandrels, medical/laboratory equipment, and resin modification.

Q2: What is the difference between TPX MX002O and TPX MX002?
A: TPX MX002O is an improved or variant grade of MX002, both are low modulus PMP resins
