PLEXIGLAS 7H PMMA Molding Compound Extrusion Grade High Melt Strength
Material: PMMA (Acrylic)
Process: Extrusion
MVR: 1.4 cm³/10min
AMECA: Listed
Packing: 25kg bag / 500kg box
PLEXIGLAS 7H is a high melt strength PMMA molding compound specially designed for demanding extrusion applications. With an extremely low MVR of 1.4 cm³/10min at 230°C/3.8kg, it delivers exceptional melt strength for stable processing of large profiles, sheets, tubes, and multi-skin sheets. It combines the familiar properties of PLEXIGLAS molding compounds — 92% light transmission, outstanding weather resistance, high mechanical strength, surface hardness, and mar resistance — with high heat deflection temperature (Vicat 103°C, HDT 100°C at 0.45 MPa) and AMECA listing.
PLEXIGLAS 7H is particularly suitable for extruding optical and technical profiles and sheets. Typical applications include sheets, tubes, multi-skin sheets, coextrusion of window profiles, and similar extrusion applications requiring high melt strength and structural integrity. Processable on extruders with 3-zone general purpose screws for engineering thermoplastics at melt and die temperatures of 220-260°C.
Genuine Röhm PLEXIGLAS Imported Stock and Technical Support
We supply stable spot inventory of genuine PLEXIGLAS 7H PMMA extrusion compound. Official TDS, batch COA, and AMECA documentation are available for sheet, tube, and profile extrusion applications.
Request PLEXIGLAS 7H Quotation, TDS, and Sample
Complete TDS, COA, and technical documentation available
Core Advantages of PLEXIGLAS 7H PMMA Extrusion Compound
- Extremely high melt strength: MVR 1.4 — exceptional stability for large profile and sheet extrusion
- Extrusion grade — specially formulated for sheets, tubes, multi-skin sheets, and coextrusion
- High heat resistance: Vicat 103°C — HDT 100°C at 0.45 MPa
- High light transmission: 92% — excellent optical clarity with haze <0.5%
- AMECA listed — certified for automotive and construction regulatory compliance
- High mechanical strength — tensile modulus 3200 MPa, stress at break 76 MPa
- Excellent weather resistance — UV stable for outdoor and long-term use
- Free colorability — crystal clarity allows custom color formulations
Main Applications
- Extruded sheets — solid sheets for signage, glazing, and display applications
- Tubes and pipes — extruded tubes for lighting and technical applications
- Multi-skin sheets — lightweight structured sheets for construction and signage
- Coextrusion of window profiles — decorative and functional window profile layers
- Technical profiles — custom extruded profiles for industrial applications
Full Technical Parameters
| Property | Typical Value | Test Method |
| Material Type | Amorphous thermoplastic (PMMA) | — |
| Processing Method | Extrusion | — |
| Density | 1.19 g/cm³ | ISO 1183 |
| Tensile Modulus (1mm/min) | 3200 MPa | ISO 527 |
| Stress at Break (5mm/min) | 76 MPa | ISO 527 |
| Strain at Break (5mm/min) | 5.5% | ISO 527 |
| Charpy Impact Strength (23°C) | 20 kJ/m² | ISO 179/1eU |
| Vicat Softening Temperature (B/50) | 103°C | ISO 306 |
| Glass Transition Temperature | 112°C | ISO 11357 |
| HDT (0.45 MPa) | 100°C | ISO 75 |
| HDT (1.8 MPa) | 95°C | ISO 75 |
| CTE (0-50°C) | 8 × 10⁻⁵ /°C | ISO 11359 |
| MVR (230°C/3.8kg) | 1.4 cm³/10min | ISO 1133 |
| Luminous Transmittance (d=3mm) | 92% | ISO 13468-2 |
| Haze | <0.5% | ASTM D1003 |
| Refractive Index (589nm/23°C) | 1.49 | ISO 489 |
| Flammability (UL 94, 1.5mm) | HB | IEC 60695-11-10 |
| Fire Class | E | DIN EN 13501-1 |
| AMECA Listing | Yes | — |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Recommended Processing Conditions
| Parameter | Recommended Value |
| Processing Method | Extrusion (3-zone general purpose screws) |
| Predrying Temperature | ≤93°C |
| Predrying Time (Desiccant Dryer) | 2-3 hours |
| Melt Temperature | 220-260°C |
| Die Temperature (Extrusion) | 220-260°C |
| Screw Type | 3-zone general purpose screw for engineering thermoplastics |
Handling and Storage Recommendations
| Storage Rules | Store in dry, cool conditions away from direct sunlight and heat sources. |
| Packaging | 25kg polyethylene bags or 500kg boxes with PE lining. |
| Predrying | Dry at ≤93°C for 2-3 hours before processing. Moisture can cause surface defects. |
| Operation Protection | Follow standard safety practices for handling thermoplastic pellets. Use appropriate PPE during processing. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | PLEXIGLAS 7H original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
Frequently Asked Questions
What is PLEXIGLAS 7H?
PLEXIGLAS 7H is a high melt strength PMMA molding compound designed for extrusion applications. It offers excellent mechanical properties, high heat deflection temperature, 92% light transmission, and AMECA listing for sheets, tubes, and multi-skin sheets.
What is the difference between PLEXIGLAS 7M and 7H?
Both are extrusion grades. PLEXIGLAS 7H has extremely high melt strength (MVR 1.4) for demanding extrusion applications like sheets, tubes, and multi-skin sheets. PLEXIGLAS 7M has better flow for lighting profiles and panels.
What is the MVR of PLEXIGLAS 7H?
PLEXIGLAS 7H has an MVR of 1.4 cm³/10min at 230°C/3.8kg, indicating extremely high melt strength for stable extrusion of large profiles, sheets, and multi-skin structures.
What applications is PLEXIGLAS 7H suitable for?
PLEXIGLAS 7H is ideal for extruded sheets, tubes, multi-skin sheets, coextrusion of window profiles, and similar extrusion applications requiring high melt strength and excellent optical clarity.
Is PLEXIGLAS 7H AMECA listed?
Yes. PLEXIGLAS 7H is AMECA listed, making it suitable for automotive and construction applications requiring regulatory compliance.
What are the processing conditions for PLEXIGLAS 7H?
Recommended conditions: predrying at ≤93°C for 2-3 hours, melt and die temperature 220-260°C. Process on extruders with 3-zone general purpose screws for engineering thermoplastics.
Related PLEXIGLAS Products
Compare PLEXIGLAS molding compounds for different processing and application requirements.
| Product | Processing | MVR | Vicat B/50 | Core Application |
| PLEXIGLAS 7H | Extrusion | 1.4 | 103°C | Sheets, tubes, multi-skin |
| PLEXIGLAS 7M | Extrusion | — | — | Lighting profiles, panels |
| PLEXIGLAS 7N | Injection Molding | 6 | 103°C | Automotive lighting, lenses |
Get PLEXIGLAS 7H Bulk Pricing and Technical Support
We supply genuine PLEXIGLAS 7H PMMA extrusion compound for sheet, tube, multi-skin sheet, and profile extrusion applications. Contact us for bulk pricing, sample availability, technical documents, and application support.
Request PLEXIGLAS 7H Technical Details
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
