3M Novec 1908 Electronic Grade Coating Highest Solids PCB Protection
Type: Electronic Grade Fluoropolymer
Solids: 8.0 wt%
Thickness: 0.4-5.0 µm
Dielectric Strength: 3700 V/mil
Packing: 5KG / 20KG drum
3M Novec 1908 Electronic Grade Coating is the highest solids version (8.0 wt%) in the Novec coating product line, delivering the thickest protective film (0.4-5.0 microns) for maximum moisture and corrosion protection of printed circuit boards and electronic components. This clear, low-viscosity fluorinated polymer solution is diluted in a blend of 3M Novec 7100 and 7200 Engineered Fluids, providing excellent surface wetting and uniform coating coverage. With the highest viscosity (2.24 cP) and solids content among Novec coatings, Novec 1908 offers the most robust protection for demanding electronics applications.
Novec 1908 provides superior dielectric performance with a dielectric breakdown strength of 3700 V/mil and a low dielectric constant of 2.8. Its glass transition temperature of 52°C ensures excellent thermal stability. The coating delivers outstanding hydrophobic and oleophobic properties with water contact angle of 105° and hexadecane angle of 65°, repelling water, hydrocarbons, silicones, and photoresists effectively. It adheres well to metals, glass, ceramics, polymers, and laminates, and withstands 175°C for 24 hours while maintaining repellency. Environmentally, it is nonflammable, non-ozone-depleting, low in toxicity, low GWP, RoHS compliant, and VOC exempt (per U.S. EPA). With a 2-year shelf life and easy application by spray, dip, or syringe dispensing, Novec 1908 is the ultimate choice for high-reliability PCB protection and conformal coating applications.
Genuine 3M Imported Stock and Technical Support
We supply stable spot inventory of genuine 3M Novec 1908 electronic grade coating. Official TDS, SDS, and batch COA documents are available for PCB protection, conformal coating, and high-reliability electronics applications.
Request Novec 1908 Coating Quotation, TDS, SDS, and Sample
Complete SDS, COA, and technical documentation available
Core Advantages of 3M Novec 1908 Electronic Grade Coating
- Highest solids content: 8.0 wt% — maximum protective film thickness (0.4-5.0 µm) in the Novec coating series
- Maximum coating thickness: 0.4-5.0 µm — superior moisture barrier and corrosion protection
- Highest viscosity: 2.24 cP — optimal flow characteristics for uniform coating coverage
- Superior dielectric strength: 3700 V/mil — excellent electrical insulation for high-voltage PCBs
- Low dielectric constant: 2.8 — ideal for high-frequency and high-speed applications
- Hydrophobic and oleophobic — water contact angle 105°, repels liquids and contaminants
- No curing required — dries at room temperature in minutes, no post-application bake
- VOC exempt (U.S. EPA) — environmentally compliant for electronics manufacturing
Main Applications
- PCB moisture and corrosion protection — for high-reliability electronics in harsh environments
- Conformal coating alternative — maximum protection replacement for traditional conformal coatings
- Display connection protection — protection of anisotropic conductive film (ACF) connections
- Protection against corrosive gases — for components exposed to aggressive industrial environments
- Anti-migration coating — prevents migration of lubricants and photoresists
Full Technical Parameters
| Property | Typical Value | Test Method |
| Coating Type | Fluorinated polymer in HFE solvent blend | — |
| Solids Content | 8.0 wt% | — |
| Solvent System | Novec 7100 + 7200 Blend | — |
| Appearance (Solution) | Clear colorless liquid | Visual |
| Coating Appearance | Transparent, colorless | Visual |
| Density | 1.44 g/ml | ASTM D891 |
| Viscosity | 2.24 cP | — |
| Boiling Point | 75°C | ASTM D1120-94 |
| Flash Point | None | Closed cup |
| Coating Thickness | 0.4-5.0 microns | — |
| Glass Transition Temperature | 52°C | DSC |
| Water Contact Angle (static) | 105° | Goniometer |
| Hexadecane Contact Angle | 65° | Goniometer |
| Refractive Index | 1.3841 | — |
| Dielectric Constant (@1kHz, 30% RH) | 2.8 | ASTM D150 |
| Dissipation Factor (@1kHz, 30% RH) | 0.011 | ASTM D150 |
| Dielectric Breakdown Strength (35% RH) | 3700 V/mil | ASTM D149 |
| Thermal Stability | Up to 175°C for 24 hours | — |
| Solder-Through Repairability | Yes | — |
| Flammability | UL 94 V-0 | UL 94 |
| VOC Status | Exempt (U.S. EPA) | — |
| RoHS | Compliant | — |
| Shelf Life | 2 years | — |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Handling and Storage Recommendations
| Storage Conditions | Store at 16-27°C (60-80°F) and <60% R.H. in original unopened containers. |
| Shelf Life | 2 years from date of manufacture when stored as recommended. |
| Application Precautions | Surfaces must be clean and dry before application. Do not spray without proper ventilation and PPE. |
| Thermal Limits | Do not heat solution above 150°C; dry film should not exceed 250°C to avoid decomposition. |
| Operation Protection | Use with adequate ventilation and appropriate PPE. Read SDS before use. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | 3M Novec 1908 original factory technical data sheet | Request TDS |
| SDS | Safety data sheet covering transport, storage, and handling guidelines | Request SDS |
| COA | Batch-specific certificate of analysis with solids and purity specifications | Request COA |
Frequently Asked Questions
What is 3M Novec 1908 Electronic Grade Coating?
3M Novec 1908 is the highest solids version (8 wt%) in the Novec coating series, providing the thickest transparent coating (0.4-5.0 µm) for maximum moisture and corrosion protection of PCBs and electronic components.
What is the difference between Novec 1908 and Novec 1904?
Novec 1908 has double the solids content (8% vs 4%), higher viscosity (2.24 cP vs 1.11 cP), and thicker coating (0.4-5.0 µm vs 0.25-4.0 µm), providing the maximum protective film thickness in the Novec coating product line.
Is Novec 1908 coating environmentally friendly?
Yes. Novec 1908 is nonflammable, non-ozone-depleting, low in toxicity, low GWP, RoHS compliant, and VOC exempt per U.S. EPA.
What is the shelf life of Novec 1908 coating?
Novec 1908 has a shelf life of 2 years from date of manufacture when stored in original unopened container at 16-27°C and <60% RH.
What is the dielectric strength of Novec 1908?
Novec 1908 offers high dielectric breakdown strength of 3700 V/mil, providing superior electrical insulation for demanding PCB protection applications.
Can Novec 1908 coating be removed for rework?
Yes. Novec 1908 allows solder-through repairability and can be removed with Novec 72DA or 7200 Engineered Fluids for component rework.
What is the glass transition temperature of Novec 1908?
Novec 1908 has a glass transition temperature (Tg) of 52°C, providing excellent thermal stability for high-temperature PCB applications.
Related 3M Novec Products
Compare 3M Novec electronic grade coatings for different protection requirements.
| Product | Solids | Coating Thickness | Viscosity | Dielectric Strength | Best For |
| Novec 1908 | 8.0 wt% | 0.4-5.0 µm | 2.24 cP | 3700 V/mil | Maximum protection |
| Novec 1904 | 4.0 wt% | 0.25-4.0 µm | 1.11 cP | 3700 V/mil | Spray application |
| Novec 1902 | 2.0 wt% | 0.1-1.0 µm | 0.81 cP | 2000 V/mil | Higher boiling |
Get 3M Novec 1908 Coating Bulk Pricing and Technical Support
We supply genuine 3M Novec 1908 electronic grade coating for maximum PCB protection, conformal coating, and high-reliability electronics applications. Contact us for bulk pricing, sample availability, technical documents, and application support.
Request Novec 1908 Coating Technical Details
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
