3M Novec 1702 Electronic Grade Coating Ultrathin Low Standoff Protection
Type: Electronic Grade Fluoropolymer
Solids: 0.2 wt%
Coating Thickness: <100 nm
VOC Status: Exempt
Packing: 5KG / 20KG drum
3M Novec 1702 Electronic Grade Coating is a low solids version of Novec 1700, designed specifically for applications requiring an even thinner protective film. This clear, low-viscosity solution of a fluorinated acrylic polymer in hydrofluoroether solvent dries to a transparent film less than 100 nanometers thick — ideal for coating under low stand-off components where clearance is limited. It provides excellent moisture and corrosion protection for printed circuit boards and electronic components with outstanding hydrophobic and oleophobic properties.
Novec 1702 offers all the advantages of Novec 1700 with an even lower profile. It requires no curing, dries at room temperature in seconds, and can be handled in under two minutes. The coating provides excellent repellency against water, hydrocarbons, silicones, and photoresists, with water contact angle of 105° and hexadecane angle of 65°. It is easily removable for rework using Novec 7100DL Engineered Fluid and allows solder-through repairability. Environmentally, it is nonflammable, non-ozone-depleting, low in toxicity, low GWP, RoHS compliant, and VOC exempt (per U.S. EPA). With a 4-year shelf life and compatibility with metals, glass, and epoxy laminates, Novec 1702 is a versatile, cost-effective alternative to traditional conformal coatings.
Genuine 3M Imported Stock and Technical Support
We supply stable spot inventory of genuine 3M Novec 1702 electronic grade coating. Official TDS, SDS, and batch COA documents are available for PCB protection, anti-migration, and low stand-off coating applications.
Request Novec 1702 Coating Quotation, TDS, SDS, and Sample
Complete SDS, COA, and technical documentation available
Core Advantages of 3M Novec 1702 Electronic Grade Coating
- Ultrathin coating: <100 nm — ideal for low stand-off components and tight clearance applications
- Low solids formulation: 0.2 wt% — even thinner than Novec 1700 for maximum clearance
- Hydrophobic and oleophobic — water contact angle 105°, hexadecane angle 65°
- No curing required — dries at room temperature in seconds, handle in under two minutes
- Solder-through repairability — components can be reworked without removing the coating
- Removable for rework — easily removed with Novec 7100DL Engineered Fluid
- VOC exempt (U.S. EPA) — environmentally compliant for electronics manufacturing
- Low GWP and zero ODP — sustainable alternative to traditional coatings
Main Applications
- PCB moisture and corrosion protection — for consumer, industrial, and automotive electronics
- Low stand-off component coating — coats under low-profile SMT components where clearance is limited
- Anti-migration coating — prevents migration of lubricants and photoresists in displays and spindle motors
- Anti-stiction coating — for MEMS, micromotors, and liquid crystal displays
- Sacrificial surface treatment — selectively removable with Novec engineered fluids for rework
Full Technical Parameters
| Property | Typical Value | Test Method |
| Coating Type | Fluorinated acrylic polymer in HFE solvent | — |
| Solids Content | 0.2 wt% | — |
| Appearance (Solution) | Clear colorless liquid | Visual |
| Coating Appearance | Transparent, colorless | Visual |
| Specific Gravity | 1.5 | — |
| Boiling Point (Solvent) | 61°C | ASTM D1120-94 |
| Flash Point | None | Closed cup |
| Coating Thickness | <100 nm | — |
| Glass Transition Temperature | 44.5°C | DSC |
| Water Contact Angle (static) | 105° | Goniometer |
| Hexadecane Contact Angle | 65° | Goniometer |
| Refractive Index | 1.39 | — |
| Dielectric Constant (@1kHz, 30% RH) | 3.1 | ASTM D150 |
| Dissipation Factor (@1kHz, 30% RH) | 0.0089 | ASTM D150 |
| Dielectric Breakdown Strength (35% RH) | 1000 V/mil | ASTM D149 |
| Thermal Stability | Up to 175°C for 24 hours | — |
| Solder-Through Repairability | Yes | — |
| Removability | Novec 7100DL Engineered Fluid | — |
| Flammability | UL 94 V-0 | UL 94 |
| VOC Status | Exempt (U.S. EPA) | — |
| RoHS | Compliant | — |
| Shelf Life | 4 years | — |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Handling and Storage Recommendations
| Storage Conditions | Store at 16-27°C (60-80°F) and <60% R.H. in original unopened containers. |
| Shelf Life | 4 years from date of manufacture when stored as recommended. |
| Application Precautions | Keep water out of coating bath. Surfaces must be clean and dry before application. Dipping is the preferred method. |
| Thermal Limits | Do not heat solution above 150°C; dry film should not exceed 250°C to avoid decomposition. |
| Removal | Use 3M Novec 7100DL Engineered Fluid for removal and rework. |
| Operation Protection | Use with adequate ventilation and appropriate PPE. Read SDS before use. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | 3M Novec 1702 original factory technical data sheet | Request TDS |
| SDS | Safety data sheet covering transport, storage, and handling guidelines | Request SDS |
| COA | Batch-specific certificate of analysis with solids and purity specifications | Request COA |
Frequently Asked Questions
What is 3M Novec 1702 Electronic Grade Coating?
3M Novec 1702 is a low solids version (0.2 wt%) of Novec 1700 coating, providing an even thinner transparent fluoropolymer film (<100 nm) for moisture and corrosion protection of PCBs and electronic components, especially under low stand-off components.
How does Novec 1702 differ from Novec 1700?
Novec 1702 has a lower solids content (0.2% vs 2.0%) and provides a thinner coating (<100 nm vs 0.1-1.0 µm), making it ideal for coating under low stand-off components where clearance is limited.
How is Novec 1702 coating applied?
Novec 1702 can be applied by dipping (preferred), spraying, or syringe dispensing. It dries quickly at room temperature without curing and can be handled in under two minutes.
Is Novec 1702 coating removable and repairable?
Yes. Novec 1702 allows solder-through repairability and can be easily removed with Novec 7100DL Engineered Fluid for rework and repair.
Is Novec 1702 coating environmentally friendly?
Yes. Novec 1702 is nonflammable, non-ozone-depleting, low in toxicity, low GWP, RoHS compliant, and VOC exempt per U.S. EPA.
What is the shelf life of Novec 1702 coating?
Novec 1702 has a shelf life of four years from date of manufacture when stored in original unopened container at 16-27°C and <60% RH.
Related 3M Novec Products
Compare 3M Novec electronic grade coatings for different protection requirements.
| Product | Solids Content | Coating Thickness | Best For |
| Novec 1702 | 0.2 wt% | <100 nm | Low stand-off components, tight clearances |
| Novec 1700 | 2.0 wt% | 0.1-1.0 µm | Standard PCB and component protection |
Get 3M Novec 1702 Coating Bulk Pricing and Technical Support
We supply genuine 3M Novec 1702 electronic grade coating for PCB protection, low stand-off component coating, anti-migration, and anti-stiction applications. Contact us for bulk pricing, sample availability, technical documents, and application support.
Request Novec 1702 Coating Technical Details
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
