描述
NORYL PX0888 Resin is a non-reinforced, heat stabilized blend of polyphenylene ether (PPE) and high impact polystyrene (HIPS), manufactured by SABIC. This injection moldable grade exhibits very low moisture absorption, hydrolytic stability, dimensional stability, good foam adhesion, and property retention over a wide temperature range.
NORYL PX0888 Resin offers low creep sensitivity and high heat resistance. It is inherently UL94 HB rated. This product does not contain PFAS intentionally added during the manufacturing process.
NORYL PX0888 is an excellent candidate for automotive interior applications such as instrument panels, audio components, speaker housings, and interior trim.
For more NORYL grades and technical information, please visit our PPO/PPE product page.
Key Features of NORYL PX0888 Resin
-
Non-Reinforced PPE/HIPS Blend – Unfilled formulation for balanced performance
-
Heat Stabilized – Maintains properties under thermal exposure
-
Low Moisture Absorption – Water absorption of 0.1% (23°C, 24 hrs)
-
Hydrolytic Stability – Resists degradation in wet environments
-
Dimensional Stability – Precise part geometry with low warpage
-
Good Foam Adhesion – Excellent bonding in foam applications
-
Wide Temperature Range – Maintains properties across broad temperature spectrum
-
Low Creep Sensitivity – Maintains dimensional integrity under sustained load
-
High Heat Resistance – HDT of 127–130°C at 0.45 MPa
-
UL94 HB Rated – Inherent flame rating
-
No PFAS Intentionally Added – Compliant with environmental regulations
-
Low Specific Gravity – Density of 1.04–1.06 g/cm³
-
Injection Moldable – Suitable for standard injection molding processes
Typical Applications for NORYL PX0888 Resin
| Industry | Typical Components & Considerations |
|---|---|
| Automotive Interiors | Instrument panels – high heat resistance, dimensional stability, wide temperature range |
| Automotive Audio | Audio components, speaker housings – good foam adhesion, low moisture absorption |
| Automotive Interior Trim | Interior trim components – heat stabilized, property retention |
| Injection Molding | Various automotive interior parts – excellent processability |
Typical Properties of NORYL PX0888 Resin
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density / Specific Gravity | 1.04 – 1.06 g/cm³ | ASTM D792 / ISO 1183 |
| Water Absorption (23°C/24hrs) | 0.1% | ASTM D570 |
| Moisture Absorption (23°C / 50% RH) | 0.06% | ISO 62 |
| Linear Mold Shrinkage, Flow (3.2mm) | 0.5 – 0.7% | SABIC Method |
| Melt Volume Rate (MVR) (300°C/2.16kg) | 6 cm³/10min | ISO 1133 |
| Melt Volume Rate (MVR) (280°C/5.0kg) | 5 cm³/10min | ISO 1133 |
| Mechanical (ASTM) | ||
| Tensile Stress, Yield (Type I, 50 mm/min) | 58 MPa | ASTM D638 |
| Tensile Strain, Break (Type I, 50 mm/min) | 30% | ASTM D638 |
| Flexural Stress, Yield (2.6 mm/min, 100 mm span) | 93 MPa | ASTM D790 |
| Flexural Modulus (2.6 mm/min, 100 mm span) | 2,350 MPa | ASTM D790 |
| Hardness, Rockwell R | 118 | ASTM D785 |
| Mechanical (ISO) | ||
| Tensile Modulus (1 mm/min) | 2,200 MPa | ISO 527 |
| Tensile Stress, Yield (50 mm/min) | 55 MPa | ISO 527 |
| Tensile Stress, Break (50 mm/min) | 50 MPa | ISO 527 |
| Tensile Strain, Yield (50 mm/min) | 4% | ISO 527 |
| Tensile Strain, Break (50 mm/min) | 15% | ISO 527 |
| Flexural Modulus (2 mm/min) | 2,200 MPa | ISO 178 |
| Flexural Stress, Yield (2 mm/min) | 80 MPa | ISO 178 |
| Ball Indentation Hardness (H358/30) | 130 MPa | ISO 2039-1 |
| Impact (ISO) | ||
| Izod Impact, Notched (23°C) | 12 kJ/m² | ISO 180/1A |
| Izod Impact, Notched (-30°C) | 8 kJ/m² | ISO 180/1A |
| Charpy Notched Impact (23°C) | 15 kJ/m² | ISO 179/1eA |
| Charpy Notched Impact (-30°C) | 8 kJ/m² | ISO 179/1eA |
| Thermal (ASTM) | ||
| HDT @ 0.45 MPa (66 psi, 6.4mm, unannealed) | 129°C | ASTM D648 |
| HDT @ 1.82 MPa (264 psi, 6.4mm, unannealed) | 127°C | ASTM D648 |
| CTE, Flow (0°C to 100°C) | 7.38E-05 1/°C | ASTM E831 |
| Thermal (ISO) | ||
| HDT/Be, 0.45 MPa | 130°C | ISO 75/Be |
| HDT/Ae, 1.8 MPa | 115°C | ISO 75/Ae |
| Vicat Softening Temp (A/50) | 150°C | ISO 306 |
| Vicat Softening Temp (B/50) | 140°C | ISO 306 |
| Vicat Softening Temp (B/120) | 140°C | ISO 306 |
| Flammability | ||
| Flame Rating | UL94 HB | UL 94 |
Important Notes on Typical Data:
Values listed are typical and sourced from manufacturer data sheets. They do not constitute binding product specification.
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
Final performance depends on processing conditions and part design.
Manufacturer official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for NORYL PX0888 Resin
| Step | Process |
|---|---|
| Processing Method | Injection molding |
| Drying Time | 3 – 4 hours |
| Maximum Moisture Content | ≤ 0.02% |
| Front Zone 3 Temperature | 270 – 310°C |
| Back Pressure | 0.3 – 0.7 MPa |
| Melt Temperature | 270 – 310°C |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings:
Drying: Proper drying is critical to prevent hydrolysis and achieve optimal mechanical properties. Dry for 3–4 hours prior to processing.
Injection Molding: NORYL PX0888 is specifically designed for injection molding.
UL94 HB Rating: This grade is inherently UL94 HB rated. Ensure processing conditions maintain compliance.
No PFAS: This product does not contain PFAS intentionally added during the manufacturing process.
Storage: Store in original, sealed packaging in a cool, dry place away from direct sunlight.
Related Products
Explore Engineering Plastics – Browse all engineering plastic materials
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for NORYL PX0888 Resin
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of NORYL PX0888 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| UL Yellow Card | UL safety certification |
Request any document above by:
Email: ruiqingchem@gmail.com
Online form: Our contact page
We reply within one working business day. Please clearly state product (NORYL PX0888) and document type you require.
FAQ about NORYL PX0888 Resin
Q1: What is NORYL PX0888?
A: NORYL PX0888 is a non-reinforced, heat stabilized blend of polyphenylene ether (PPE) and high impact polystyrene (HIPS) from SABIC. It is an injection moldable grade that exhibits very low moisture absorption, hydrolytic stability, dimensional stability, good foam adhesion, and property retention over a wide temperature range.
Q2: What are the key features of NORYL PX0888?
A: It offers non-reinforced PPE/HIPS blend, heat stabilization, very low moisture absorption (0.1% at 23°C/24hrs), hydrolytic stability, dimensional stability, good foam adhesion, wide temperature range property retention, low creep sensitivity, high heat resistance (HDT 127–130°C at 0.45 MPa), UL94 HB flame rating, low specific gravity (1.04–1.06 g/cm³), and No PFAS intentionally added.
Q3: What are the typical applications for NORYL PX0888?
A: Typical applications include automotive interior components such as instrument panels, audio components, speaker housings, and interior trim.
Q4: What is the flame rating of NORYL PX0888?
A: NORYL PX0888 is inherently UL94 HB rated.
Q5: What is the recommended processing method for NORYL PX0888?
A: NORYL PX0888 is designed for injection molding.
Q6: What is the recommended drying condition for NORYL PX0888?
A: Dry for 3 – 4 hours prior to processing.
Q7: What is the recommended melt temperature for NORYL PX0888?
A: 270 – 310°C.
Q8: What is the Vicat softening temperature of NORYL PX0888?
A: The Vicat softening temperature is 150°C (Rate A/50) and 140°C (Rate B/50 and B/120) per ISO 306.
Q9: What is the heat deflection temperature of NORYL PX0888?
A: The HDT at 0.45 MPa is 129–130°C and at 1.82 MPa is 115–127°C.
Q10: Is NORYL PX0888 suitable for automotive applications?
A: Yes, NORYL PX0888 is an excellent candidate for automotive interior applications such as instrument panels, audio components, speaker housings, and interior trim.
Q11: Does NORYL PX0888 contain PFAS?
A: No, this product does not contain PFAS intentionally added during the manufacturing process.
Q12: What regions is NORYL PX0888 available in?
A: It is available in the Americas (North America, South and Central America), Europe, and Asia Pacific.
Q13: What is the lead time for orders?
A: Regular orders ship within 7-10 working days after payment confirmation. Large-volume orders can be negotiated separately.
