Micromax 4899R Silver Termination Paste, MLC Capacitors
Type: Silver Termination Paste
Application: MLC Capacitors
Solid Content: 74.5-76.5%
Viscosity: 45-75 Pa.s
Shelf Life: 6 months
MacDermid Alpha Micromax 4899R is a solderable silver termination paste designed for multilayer ceramic capacitors (MLC). Featuring Pb/Cd/phthalate-free formulation, 850°C 40-minute firing, and dip application with good solderability and adhesion over a wide range of capacitor bodies per TDS specifications.
Micromax 4899R is a solderable silver termination paste designed for lead attachment to multilayer ceramic capacitors. This cadmium-free and lead-free termination offers good solderability and high adhesion over a wide range of capacitor bodies. The paste is ideal for applications where platable terminations are not desired but where soldering conditions are required. It is optimized for carrier plate-type dipping applications with a viscosity of 45-75 Pa.s per TDS specifications.
With a solid content of 74.5-76.5%, Micromax 4899R is applied by dipping and dried using a belt dryer at 160-180°C for 15 minutes. The paste fires at 850°C peak with a 40-minute cycle and 10-minute peak hold. The composition is compatible with ceramic capacitor bodies and delivers reliable solderability and adhesion. Available in standard packaging with 6-month shelf life per TDS specifications.
Genuine MacDermid Alpha Micromax Imported Stock & Technical Support
We maintain stable inventory of authentic MacDermid Alpha Micromax 4899R silver termination paste. Factory-original TDS and batch-specific COA can be provided upon request for your MLC capacitor termination projects.
Request Sample, TDS & Quotation
Complete TDS, COA, and regulatory documentation available
Key Features of MacDermid Alpha Micromax 4899R
- Solderable silver termination — designed for MLC capacitor lead attachment per TDS specifications
- Pb/Cd/phthalate free — formulated without intentional addition of restricted substances per TDS specifications
- Good solderability and adhesion — consistent performance over a wide range of capacitor bodies per TDS specifications
- Dip application optimized — carrier plate-type dipping with 45-75 Pa.s viscosity per TDS specifications
- 74.5-76.5% solid content — high solids for efficient termination deposition per TDS specifications
- 850°C 40-minute firing — 10-minute peak hold for consistent termination performance per TDS specifications
- Wide capacitor body compatibility — good adhesion and solderability on various capacitor types per TDS specifications
- 6-month shelf life — stable storage in unopened containers per TDS specifications
Primary Applications
- Multilayer ceramic capacitors (MLC) — termination for MLC capacitor lead attachment per TDS specifications
- Surface mount termination — silver termination for surface mounted capacitor applications per TDS specifications
- Capacitor body termination — termination for various capacitor body types requiring solderability
- Non-platable termination alternative — termination solution where platable terminations are not desired per TDS specifications
Full Technical Specifications
| Property | Typical Value | TDS Reference |
| Product Type | Solderable silver termination paste | TDS: silver termination |
| Application | MLC capacitors / Surface mount termination | TDS: multilayer capacitors |
| Packaging Specification | Standard container | — |
| Solid Content | 74.5-76.5% | TDS: 74.5 to 76.5 % |
| Viscosity (Brookfield RVT 10 rpm) | 45-75 Pa.s | TDS: 45 to 75 Pa.s |
| Application Method | Carrier plate-type dipping | TDS: carrier plate-type dipping |
| Application Temperature | 21-25°C | TDS: 21°C – 25°C |
| Drying Peak Temperature | 160-180°C | TDS: 160 – 180°C peak |
| Drying Cycle | 15 min | TDS: 15 minute cycle |
| Firing Peak Temperature | 850°C | TDS: 850°C peak |
| Firing Cycle | 40 min | TDS: 40 minute cycle |
| Peak Hold Time | 10 min | TDS: 10 minutes at peak |
| Firing Atmosphere | Air (oxidizing) | TDS: air, oxidizing |
| Substrate Compatibility | Ceramic capacitor bodies | TDS: ceramic capacitor bodies |
| Thinner | Micromax 4553 | TDS: 4553 |
| Shelf Life | 6 months | TDS: 6 months |
| Storage Temperature | 5-30°C | TDS: 5-30°C |
Note: All listed values are typical and may vary by batch. Independent qualification testing is required prior to production use.
Recommended Processing Conditions
| Parameter | Recommended Value | TDS Reference |
| Mixing Prior to Use | Slow gentle hand-stirring with clean spatula, 1-2 minutes | TDS: 1-2 minutes |
| Mixing (Alternative) | Slow jar rolling for 24 hours | TDS: 24 hours |
| Application Method | Carrier plate-type dipping | TDS: carrier plate-type dipping |
| Application Temperature | 21-25°C | TDS: 21°C – 25°C |
| Drying Peak Temperature | 160-180°C | TDS: 160 – 180°C |
| Drying Cycle | 15 minutes | TDS: 15 minute cycle |
| Firing Peak Temperature | 850°C | TDS: 850°C peak |
| Firing Cycle | 40 minutes (10 min at peak) | TDS: 40 minute cycle |
| Firing Atmosphere | Air (oxidizing) | TDS: air, oxidizing |
| Substrate | Ceramic capacitor bodies | TDS: ceramic capacitor bodies |
| Thinner | Micromax 4553 | TDS: 4553 |
Handling and Storage Recommendations
| Storage Rules | Store in tightly sealed containers in clean, stable environment at 5-30°C. | TDS: 5-30°C |
| Shelf Life | 6 months in unopened containers from date of shipment. | TDS: 6 months |
| Pre-use Preparation | Thoroughly mix prior to use. Some settling may occur during storage. | TDS: thoroughly mix |
| Thinning | Not normally required; use Micromax 4553 thinner sparingly for evaporative losses. | TDS: 4553 |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | MacDermid Alpha Micromax 4899R original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
| SDS | Safety Data Sheet for handling and storage | Request SDS |
Frequently Asked Questions
What is Micromax 4899R?
Micromax 4899R is a solderable silver termination paste for MLC capacitors with Pb/Cd/phthalate-free formulation and 850°C firing per TDS specifications.
What is the application method for Micromax 4899R?
Carrier plate-type dipping per TDS specifications.
What is the solid content of Micromax 4899R?
74.5-76.5% per TDS specifications.
What is the firing cycle for Micromax 4899R?
850°C peak with a 40-minute cycle and 10-minute peak hold per TDS specifications.
Is Micromax 4899R Pb/Cd-free?
Yes, it is Pb/Cd/phthalate free per TDS specifications.
What substrates are compatible with Micromax 4899R?
Ceramic capacitor bodies per TDS specifications.
What packaging options are available for Micromax 4899R?
Standard packaging containers are available. Contact our sales team for specific requirements.
Get MacDermid Alpha Micromax 4899R Bulk Pricing and Technical Support
We supply authentic MacDermid Alpha Micromax 4899R silver termination paste for MLC capacitor applications. Contact our team for bulk quotations, sample availability, technical documentation, and application support.
Inquire Bulk Price & Technical Support
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
