描述
Krytox XHT-BDX Grease is an extreme high-temperature PFPE (perfluoropolyether) extra bonding grade grease from Chemours’ Krytox performance lubricants portfolio, genuinely manufactured by Chemours and imported as original product. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Chemours technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.
Krytox XHT-BDX Grease is a special extreme high-temperature grease formulated with a non-melting thickener and extra bonding / extra strong adhesion to substrate, allowing use at temperatures above the melting point of common greases. The base oil is a highly viscous PFPE oil with a viscosity of 738 cSt at 40°C, providing excellent viscosity retention and lower evaporation at high temperatures.
While most petroleum-based products degrade below 99°C (210°F), Krytox XHT-BDX Grease operates across a significantly broader range: continuously from -15°C to 350°C (5°F to 662°F) with spikes up to 400°C (752°F) when used with proper metallurgy and periodic relubrication. The grease is nonflammable and chemically inert, containing no hydrogen in its molecular structure. It will not burn or support combustion, even in 100% liquid or gaseous oxygen environments.
Krytox XHT-BDX Grease is not FDA compliant and is not intended for food contact applications. It is suitable for extreme industrial and aerospace applications where conventional greases fail.
Key Features of Krytox XHT-BDX Grease
-
Extra Bonding / Extra Strong Adhesion – Formulated for extra strong bonding to substrate, providing enhanced adhesion even under extreme conditions
-
Extreme High-Temperature Performance – Continuous operation from -15°C to 350°C (5°F to 662°F), with spike capability up to 400°C (752°F)
-
Non-Melting Thickener – Formulated with a special non-melting high-temperature thickener, allowing use at temperatures above the melting point of standard PTFE-thickened greases
-
Nonflammable – Contains no hydrogen; will not burn or support combustion, even in pure oxygen environments
-
Chemically Inert – Resistant to oxygen and virtually all chemicals; insoluble in most solvents
-
Low Oil Evaporation – Volatility of only 1.5% after 22 hours at 260°C, minimizing lubricant loss and extending performance in extreme heat
-
Excellent Wetting – Low surface tension promotes effective wetting of metallic surfaces
-
Extended Lubrication Intervals – Long equipment life and reduced maintenance frequency
-
High Viscosity Base Oil – 738 cSt at 40°C provides excellent viscosity retention at high temperatures
-
Timken OK Load: 60 lbs – Good extreme pressure performance
Typical Applications for Krytox XHT-BDX Grease
| Industry | Typical Components & Considerations |
|---|---|
| Bearings | Low-speed bearings operating at extreme temperatures; pillow block housings; conveyor bearings; corrugator and paper machine bearings; textile calender roll bearings; brick kiln car bearings |
| High-Temperature Ovens & Furnaces | High-temperature fans, ventilation fan bearings; conveyor systems in glass and aluminum plants; tenter frames |
| Welding Equipment | Welding machines |
| Textile Equipment | Textile equipment, dryer cans, process rolls |
| Aerospace | Aerospace thermal processing equipment; severe duty lubrication systems exposed to continuous heat |
| Industrial Processing | Paint plant conveyor bearings; aluminum can manufacturing bearings |
| Valves & Seals | Valve lubrication; O-ring seals |
| General Industrial | Severe duty lubrication systems exposed to continuous heat; applications where conventional grease thickeners melt or degrade |
Material Advantages
Krytox XHT-BDX Grease is a high-performance PFPE grease that delivers:
-
Extra Bonding Adhesion – The extra bonding / extra strong adhesion to substrate formulation ensures the grease stays in place and provides reliable lubrication even in extreme conditions where standard greases would flow away
-
Unmatched High-Temperature Capability – Continuous operation up to 350°C (662°F) with spikes to 400°C (752°F), far exceeding the capabilities of conventional greases
-
Non-Melting Stability – The non-melting thickener maintains grease consistency and stability at temperatures that would melt standard PTFE-thickened greases
-
Inherent Safety – Nonflammable and chemically inert, making it safe for use in oxygen-rich, chemical, and extreme thermal environments
-
Extended Service Life – Low evaporation (1.5% at 260°C) and high thermal stability reduce the need for frequent relubrication, lowering maintenance costs and downtime
-
Excellent Material Compatibility – Compatible with most metals, elastomers, and plastics; low surface tension ensures effective wetting of metallic surfaces
-
High Viscosity Retention – The 738 cSt base oil provides excellent viscosity at elevated temperatures, ensuring reliable lubrication where lower-viscosity oils would fail
-
Corrosion Resistance – Minimal corrosion observed under high-temperature testing; molybdenum-containing metals show improved corrosion resistance
Chemours, as the inventor of Krytox, brings decades of PFPE lubricant expertise, ensuring batch-to-batch consistency, reliable supply, and full technical support.
Typical Properties
| Property | Krytox XHT-BDX Grease | Unit / Remarks |
|---|---|---|
| Product Type | PFPE Extreme High-Temperature Extra Bonding Grease | – |
| Color | White / Creamy | |
| NLGI Grade | 1.5 | |
| Base Chemistry | Perfluoropolyether (PFPE) | |
| Thickener Type | Non-melting high-temperature | |
| Base Oil Viscosity @ 40°C | 738 cSt | |
| Base Oil Viscosity @ 100°C | 65 cSt | |
| Specific Gravity | 1.99 – 2.00 | |
| Timken OK Load | 60 lbs | |
| Continuous Service Temp. | -15°C to 350°C (5°F to 662°F) | |
| Temperature Spikes | Up to 400°C (752°F) | |
| Oil Pour Point | -20°C | |
| Volatility (22 hrs @ 260°C) | 1.5% | |
| Oil Separation (30 hrs @ 99°C) | 5% | |
| Chemical Behavior | Nonflammable, chemically inert | |
| Packaging | 57 g syringe; 2 oz, 8 oz tubes; 0.5 kg, 1 kg jars; 5 kg, 20 kg pails | – |
| Country of Origin | USA |
Important Notes on Typical Data:
-
Values listed are typical and sourced from Chemours official data sheets. They do not constitute binding product specification.
-
Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificate.
-
Final performance depends on application conditions, operating environment, and relubrication intervals.
-
Chemours official TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
XHT-BD vs XHT-BDX vs XHT-BDZ Comparison
| Property | XHT-BD | XHT-BDX | XHT-BDZ |
|---|---|---|---|
| Standard NLGI Penetration Grade | 1.5 | 1.5 | 1.5 |
| Estimated Useful Temp. Range | -20°C to 300°C | -15°C to 350°C | -5°C to 360°C |
| Temperature Spikes | Up to 330°C | Up to 400°C | ≥400°C |
| Oil Pour Point | -25°C | -20°C | – |
| Base Oil Viscosity @ 40°C | 500 cSt | 738 cSt | 1,023 cSt |
| Base Oil Viscosity @ 100°C | 47 cSt | 65 cSt | 88 cSt |
| Key Feature | Standard | Extra Bonding | Highest Temp |
Processing & Application Guidelines
| Consideration | Details |
|---|---|
| Application | Apply to clean surfaces. Grease should be applied using standard grease application equipment (grease gun, automatic lubricators, or manual application). Ensure surfaces are free from contaminants before application |
| Operating Speed | Designed for low-speed bearings or pillow housings. Will shear at high speeds, causing loss of oil in sealed bearings |
| Temperature Monitoring | Oil evaporation gradually increases above 330°C (626°F). Periodic relubrication may be required at extreme temperatures |
| Relubrication | Required to achieve optimum life at temperatures above 330°C |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight |
| Shelf Life | Extended shelf life up to 999 months; refer to product packaging for specific expiration date |
Critical Application Warnings:
-
Not for Food Contact: Krytox XHT-BDX Grease is not FDA compliant and is not approved for food contact applications. Do not use in applications requiring food-grade lubricants.
-
Speed Limitations: Designed for low-speed applications. Not recommended for high-speed sealed bearings due to shear effects.
-
Temperature Considerations: While the grease can withstand temperatures up to 350°C continuously, oil evaporation increases above 330°C. Regular monitoring and relubrication are essential for optimal performance at extreme temperatures.
-
Surface Preparation: Ensure clean application surfaces to maximize lubricant adhesion and performance.
-
Material Compatibility: Compatible with most metals, elastomers, and plastics. However, always verify compatibility with specific materials in your application.
Related Products
-
Explore Krytox XHT Series – Browse all Krytox XHT extreme high-temperature lubricants
-
Explore Krytox Lubricants – Browse all Krytox performance lubricant options
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| Chemours Official TDS | Complete physical, thermal, and mechanical properties of Krytox XHT-BDX Grease, issued by Chemours original |
| Chemours Official SDS | GHS-compliant chemical safety documentation, original Chemours document |
| Chemours Distributor Authorization Certificate | Proof of our authorized-distributor qualification for Chemours Krytox series, available upon request |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (Krytox XHT-BDX Grease) and document type you require.
FAQ
Q1: What is Krytox XHT-BDX Grease and what is it used for?
A: Krytox XHT-BDX Grease is an extreme high-temperature PFPE extra bonding grade grease from Chemours. It is formulated with a non-melting thickener for continuous operation from -15°C to 350°C (5°F to 662°F) with spikes up to 400°C (752°F). It is widely used in low-speed bearings, pillow block housings, high-temperature ovens, textile equipment, welding machines, conveyor systems, aluminum can manufacturing, and other extreme thermal applications.
Q2: What is the difference between XHT-BD and XHT-BDX?
A: XHT-BDX is the extra bonding grade version with stronger adhesion to substrate. It also offers a broader temperature range: -15°C to 350°C (vs -20°C to 300°C for XHT-BD) and a higher base oil viscosity (738 cSt vs 500 cSt at 40°C).
Q3: What is the NLGI grade of Krytox XHT-BDX Grease?
A: Krytox XHT-BDX Grease has an NLGI grade of 1.5.
Q4: What is the base oil viscosity of Krytox XHT-BDX Grease?
A: The base oil viscosity is 738 cSt at 40°C and 65 cSt at 100°C.
Q5: Is Krytox XHT-BDX Grease FDA compliant?
A: No. Krytox XHT-BDX Grease is not FDA compliant and is not approved for food contact applications. It is suitable for industrial applications where food-grade certification is not required.
Q6: Is Krytox XHT-BDX Grease flammable?
A: No. Krytox XHT-BDX Grease is nonflammable and chemically inert. It will not burn or support combustion, even in oxygen-rich environments.
Q7: What is the maximum operating temperature of Krytox XHT-BDX Grease?
A: Continuous service up to 350°C (662°F), with temperature spikes up to 400°C (752°F) when used with proper metallurgy and periodic relubrication.
Q8: Is Krytox XHT-BDX Grease suitable for high-speed bearings?
A: No. Krytox XHT-BDX Grease is designed for low-speed bearings or pillow housings. It will shear at high speeds, causing loss of oil in sealed bearings.
Q9: What is the volatility of Krytox XHT-BDX Grease?
A: The grease has a volatility of 1.5% after 22 hours at 260°C (500°F), indicating very low oil evaporation even at extreme temperatures.
Q10: What is the Timken OK Load of Krytox XHT-BDX Grease?
A: The Timken OK Load is 60 lbs, indicating good extreme pressure performance.
Q11: What packaging options are available for Krytox XHT-BDX Grease?
A: Available in 57 g syringe; 2 oz and 8 oz tubes; 0.5 kg and 1 kg jars; as well as 5 kg and 20 kg pails.
Q12: What is the shelf life of Krytox XHT-BDX Grease?
A: Krytox XHT-BDX Grease has an extended shelf life of up to 999 months when stored in unopened, proper conditions. Refer to product packaging for specific expiration dates.
Q13: What is the lead time for orders?
A: Regular orders ship within 7-10 working days after payment confirmation. Large-volume or urgent orders can be negotiated separately.
CTA (Call to Action)
Ready to order Krytox XHT-BDX Grease?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (bearings, ovens, textile equipment, welding, aluminum can manufacturing, etc.)
-
Operating temperature range
-
Packaging preference (syringe, tube, jars, or pails)
-
Document requirement (TDS, SDS, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, Chemours official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working-days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original Chemours typical values for Krytox XHT-BDX Grease. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on application conditions, operating environment, and maintenance practices. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for lubricant failure caused by improper application or improper usage. Always reference the latest Chemours official TDS of Krytox XHT-BDX Grease as the definitive specification.
