Galden HT135A 135℃ High Performance PFPE Heat Transfer Fluid – Aerospace Grade
Material: PFPE (Perfluoropolyether)
Boiling Point: 135℃
Pour Point: -100℃
Viscosity (25℃): 1.00 cSt
Packing: 5 KG / drum
Galden HT135A is an aerospace-grade perfluoropolyether (PFPE) heat transfer fluid within the Galden HT series. Produced by Syensqo, formerly Solvay, this inert, dielectric and non‑flammable fluid has a boiling point of 135 °C, a pour point of -100 °C, and a kinematic viscosity of 1.00 cSt at 25 °C. It is officially listed as AIRBUS APPROVED (AIRBUS HOMOLOGADO), making it a trusted choice for demanding aerospace and defense thermal management applications.
Galden HT135A is engineered for avionics cooling, test baths, high-voltage environments, and automated test equipment (ATE) systems. Its PFPE chemical体系 provides excellent chemical inertness, high dielectric strength (40 kV at 2.54mm gap), and outstanding thermal stability. The fluid is non-flammable, non-toxic, evaporates without residue, and offers broad compatibility with metals, elastomers, and plastics.
🔹 Genuine Syensqo Imported Stock & Aerospace Support
We supply stable spot inventory of genuine Syensqo Galden HT135A aerospace-grade PFPE heat transfer fluid. Complete official TDS, SDS and batch COA documents are available. Contact us for competitive bulk pricing and technical guidance on avionics cooling and aerospace thermal management applications.
📩 Request Galden HT135A Quotation, TDS & Sample
✅ Complete SDS & customs clearance documents provided
Core Advantages of Galden HT135A Aerospace Grade PFPE Fluid
- Airbus approved — officially listed as AIRBUS APPROVED for aerospace applications
- 135 ℃ precise boiling point — ideal for avionics cooling and thermal testing
- High dielectric strength — 40 kV at 2.54mm gap for safe use in high-voltage environments
- Excellent chemical inertness — compatible with metals, elastomers, and plastics
- Non-flammable and non-toxic — safe for operators and sensitive components
- Evaporates without residue — clean operation, no post-test cleaning required
- Low pour point of -100 ℃ — reliable performance in cold start conditions
Main Applications
- Avionics cooling and aerospace electronics thermal management
- Test baths and automated test equipment (ATE) systems
- High-voltage environments and electrical insulation
- Aerospace MRO (maintenance, repair, and overhaul)
- Fixed-wing aircraft interiors and thermal control systems
- Environmental simulation and thermal cycling testing
Full Technical Parameters
| Property | Typical Value | Test Condition |
| Base Material | Perfluoropolyether (PFPE) | — |
| Visual Appearance | Clear Colorless Liquid | Ambient 25℃ |
| Average Molecular Weight | 610 amu | GPC Test |
| Boiling Point | 135 ℃ | Standard Atmosphere |
| Pour Point | -100 ℃ | ASTM D97 |
| Density (25℃) | 1.72 g/cm³ | 25℃ |
| Kinematic Viscosity (25℃) | 1.00 cSt | 25℃ |
| Surface Tension | 17 dyne/cm | 25℃ |
| Vapor Pressure | 5.8 torr | — |
| Heat of Vaporization | 16.0 cal/g | At Boiling Point |
| Specific Heat Capacity (25℃) | 0.23 cal/g/℃ | 25℃ |
| Thermal Conductivity (25℃) | 0.065 W/m℃ | 25℃ |
| Coefficient of Expansion | 0.001 cm³/cm³℃ | — |
| Solubility of Air | 26.0 ml gas/100ml liquid | — |
| Solubility of Water | < 10.0 wppm | — |
| Refractive Index | 1.28 | ASTM D542 |
| Dielectric Constant | 1.92 | ASTM D150 |
| Dielectric Strength (2.54mm gap) | 40 kV | ASTM D149 |
| Volume Resistance | 1.5×10¹⁵ ohms·cm | ASTM D257 |
| Dissipation Factor (1 kHz) | 2.0×10⁻⁴ | ASTM D150 |
Note: All listed figures are typical values. Complete independent qualification testing is required before mass production deployment.
Handling and Storage Recommendations
| Storage Rules | Store sealed original containers in a dry, well-ventilated area away from heat sources and direct sunlight |
| Forbidden Environments | Avoid exposure to open flames, strong oxidizing agents and reactive metal powders |
| Aerospace System Design | Use closed-loop circulation system design for avionics cooling applications; maintain system purity and sealing |
| Operation Protection | Maintain adequate ventilation; wear nitrile protective gloves and anti-splash safety goggles during handling |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | Galden HT135A original factory technical data sheet | Request TDS |
| SDS | Safety data sheet covering transport, storage and handling guidelines | Request SDS |
| COA | Batch specific certificate of analysis for incoming goods inspection | Request COA |
Frequently Asked Questions
What is Galden HT135A used for?
Galden HT135A is an aerospace-grade PFPE heat transfer fluid used for avionics cooling, test baths, high-voltage environments, and thermal testing applications. It is Airbus approved and widely used in fixed-wing aircraft MRO and testing.
How does Galden HT135A differ from standard Galden HT135?
Galden HT135A is the aerospace-grade version of HT135, officially listed by Syensqo with specific market positioning toward Aerospace applications. It carries Airbus approval (AIRBUS APPROVED) and is engineered for avionics cooling, ATE systems, and high-reliability thermal management.
What is the boiling point of Galden HT135A?
Galden HT135A has a boiling point of 135°C, density of 1.72 g/cm³ at 25°C, and kinematic viscosity of 1.00 cSt at 25°C. Its pour point is -100°C.
Is Galden HT135A Airbus approved?
Yes. Galden HT135A is officially listed as AIRBUS APPROVED (AIRBUS HOMOLOGADO), making it suitable for use in aerospace MRO, avionics cooling, and fixed-wing aircraft thermal management applications.
What is the recommended storage condition for Galden HT135A?
Store sealed original containers in a dry, well-ventilated area away from heat sources and direct sunlight. For avionics cooling systems, maintain system purity and sealing.
What technical documents are available for Galden HT135A?
We supply original factory TDS, SDS and batch COA. These documents support your aerospace qualification and quality assurance requirements.
Related Galden HT Series Heat Transfer Fluids
Compare Galden HT series fluids for different temperature and application requirements.
| Product Grade | Boiling Point | Core Application |
| Galden HT110 | 110℃ | Low Viscosity Medium Temperature |
| Galden HT135A | 135℃ | Aerospace Grade / Airbus Approved |
| Galden HT170 | 170℃ | Low Viscosity High Temperature |
| Galden HT200 | 200℃ | Balanced Performance Grade |
Get Galden HT135A Bulk Pricing & Aerospace Support
We stock genuine Syensqo Galden HT135A aerospace-grade PFPE heat transfer fluid for avionics cooling and aerospace thermal management applications. Reach out for competitive pricing, lab trial samples and complete technical certification files.
Request Galden HT135A Aerospace Fluid Technical Details
Disclaimer: All technical figures displayed are for information purposes only and are not legally binding product specifications. Buyers must carry out independent compatibility and cycle testing prior to bulk order placement. Minor performance deviation may exist across different production batches.
