Galden D02TS – -97℃ Ultra Low Temperature Dielectric Fluid for Electronic Testing

Galden D02TS is an ultra-low temperature perfluoropolyether (PFPE) dielectric fluid specifically engineered for electronic quality testing and high-reliability component screening. Manufactured by Syensqo (formerly Solvay), this PFPE electronic fluid features an industry-leading pour point of -97°C and a boiling point of 165°C, offering exceptional performance across extreme temperature ranges. Its outstanding dielectric properties, high chemical and thermal stability, combined with its capacity to operate at very low as well as elevated temperatures, make it ideal for electronic quality testing.

Galden D02TS maintains excellent fluidity at temperatures as low as -97°C, enabling reliable testing of hermetically sealed electronic components under extreme cold conditions. Its volume resistance of 5×10¹⁵ ohms·cm and dielectric strength of 40 kV ensure safe operation during energized testing of sensitive electronic assemblies. The fluid’s low surface tension (16 dyne/cm) and low viscosity (1.70 cSt at 25°C) allow it to penetrate micro-gaps for thorough testing coverage.

🔹 Genuine Syensqo Imported Stock & Electronic Testing Support
We supply stable spot inventory of genuine Galden D02TS ultra-low temperature dielectric fluid. Complete official TDS, SDS and batch COA documents are available for electronics manufacturers, testing laboratories, and semiconductor qualification engineers. Contact us for competitive bulk pricing and technical guidance on electronic testing applications.

📩 Request Galden D02TS Quotation, TDS & Sample

✅ Complete SDS & customs clearance documents provided

Core Advantages of Galden D02TS Ultra Low Temperature Dielectric Fluid

• Industry-leading -97°C pour point for extreme low-temperature electronic testing
• 165°C boiling point for reliable high-temperature testing capability
• Volume resistance of 5×10¹⁵ ohms·cm for safe energized testing
• Dielectric strength of 40 kV (2.54mm gap) for high-voltage insulation
• Low viscosity (1.70 cSt at 25°C) for excellent penetration into micro-gaps
• High chemical and thermal stability across extreme temperature ranges
• Non-flammable, inert, and safe for use in testing environments

Main Applications

• Hermetic seal micro-leak detection for aerospace & military encapsulated electronics
• Ultra-low temperature cold-soak reliability screening for sealed semiconductor sensors
• Electronic quality testing of hermetically sealed components
• Low-temperature thermal cycling and reliability testing
• Dielectric fluid for electronic component testing and qualification
• Test fluid for high-reliability electronic assemblies

Full Technical Parameters (Syensqo Official Data)

Note: All listed figures are typical lab test reference values instead of binding factory specifications. Complete independent qualification testing is required before mass production deployment.

Handling and Storage Recommendations

Official Technical Documentation

Frequently Asked Questions

What is the pour point and boiling point of Galden D02TS?

Galden D02TS has an ultra-low pour point of -97°C and a boiling point of 165°C, making it ideal for extreme low-temperature electronic testing and thermal cycling applications.

What makes Galden D02TS suitable for electronic quality testing?

Its ultra-low temperature capability (-97°C pour point), combined with excellent dielectric properties (volume resistance 5×10¹⁵ ohms·cm, dielectric strength 40 kV), makes it ideal for hermetic seal testing and low-temperature electronic reliability screening.

What is the difference between Galden D02TS and Galden D02?

Galden D02TS is the updated formulation with enhanced low-temperature performance and optimized properties for electronic quality testing applications, featuring a -97°C pour point and 165°C boiling point.

Is Galden D02TS compatible with electronic components?

Yes. Its high chemical stability and excellent dielectric properties make it fully compatible with sensitive electronic components and assemblies during reliability testing.

What is the recommended storage condition for Galden D02TS?

Store sealed original containers in dry, well-ventilated area away from heat sources and direct sunlight. Keep containers tightly closed when not in use to prevent contamination.

What official documents can I obtain for Galden D02TS?

We supply original factory TDS, SDS and batch COA to support your electronic testing qualification, factory audit and quality assurance requirements.

Related Galden PFPE Product Series

Compare Galden fluorinated fluids for different temperature testing requirements.

Get Galden D02TS Bulk Pricing & Electronic Testing Support

We stock genuine Syensqo Galden D02TS ultra-low temperature dielectric fluid for electronics manufacturers and testing laboratories. Reach out for competitive pricing, lab trial samples and complete technical certification files.

Request Galden D02TS Dielectric Fluid Technical Details

Disclaimer: All technical figures displayed are lab reference data and not legally binding product specifications. Buyers must carry out independent compatibility and cycle testing prior to bulk order placement. Minor performance deviation may exist across different production batches.
