描述
Fortron MT9140L6 is a 40% glass fiber reinforced polyphenylene sulfide (PPS) injection molding grade from Celanese Corporation, specifically developed for medical and food handling applications with a low melt viscosity for high flow performance . The “MT” designation indicates Medical Technology, signifying its compliance with stringent medical and food contact regulations .
This grade is a linear, semi-crystalline, inherently flame-retardant PPS that is relatively impermeable to gases, hydrocarbons, and other liquids . It provides high dimensional stability, low coefficient of friction, low shrinkage, excellent mechanical properties, creep resistance at high temperatures, high continuous use temperature (160°C to 240°C), and very low moisture absorption .
Fortron MT9140L6 offers high hardness and rigidity at elevated temperatures and excellent resistance to corrosion, hydrolysis, oxidation, heat, and paraffin buildup . It shows excellent chemical resistance to all solvents below 200°C, acids, bases, typical and alternative automotive fuels, and petroleum fluids at elevated temperatures . The high flow characteristic makes it particularly suitable for thin-walled parts with long flow lengths .
Regulatory Compliance:
-
FDA Food Contact Notification (FCN-No. 40) for repeat-use applications
-
ISO 10993 biocompatibility
-
USP Class VI certification
-
Listed in FDA Drug Master File (DMF 14844) and Device Master File (MAF 1097)
-
BfR and FDA 21 CFR food contact certified
-
RoHS, PFOS and PFOA compliant
-
Sterilization compatible: Ethylene Oxide (EtO), Steam, Gamma Irradiation
-
Low residual monomers and no animal products
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron MT9140L6
| # | Feature | Benefit |
|---|---|---|
| 1 | High Flow / Low Melt Viscosity | Enables molding of thin-walled parts with long flow lengths |
| 2 | Medical Grade (MT) | ISO 10993 & USP Class VI compliant for medical device applications |
| 3 | FDA Food Contact Approved | FCN-No. 40 for repeat-use food handling applications |
| 4 | Drug & Device Master Files | Listed in FDA DMF and MAF for regulatory support |
| 5 | Multiple Sterilization Methods | Compatible with EtO, steam, and gamma irradiation sterilization |
| 6 | 40% Glass Fiber Reinforcement | High strength, stiffness, and dimensional stability |
| 7 | High Strength | Tensile stress at break of 190 MPa |
| 8 | High Stiffness | Flexural modulus of 14,000 MPa |
| 9 | Excellent Heat Resistance | HDT of 270°C at 1.80 MPa |
| 10 | Inherent Flame Retardancy | V-0 flame retardant (halogen-free) |
| 11 | Good Impact Properties | Notched impact of 9 kJ/m² at 23°C |
| 12 | Excellent Chemical Resistance | Resists solvents, acids, bases, and automotive fuels below 200°C |
| 13 | Very Low Moisture Absorption | 0.02% water absorption for dimensional stability |
| 14 | Low Shrinkage | 0.2-0.6% parallel, 0.4-0.6% transverse |
| 15 | Low Residual Monomers | Suitable for sensitive medical applications |
| 16 | No Animal Products | Compliant with medical and food safety requirements |
Typical Applications for Fortron MT9140L6
| Industry | Typical Components & Considerations |
|---|---|
| Thin-Wall Medical Devices | Thin-walled surgical instrument components, diagnostic equipment housings – utilizing high flow for complex thin-wall geometries and ISO 10993 & USP Class VI compliance |
| Medical & Dental Instruments | Surgical instruments, dental devices – utilizing biocompatibility and sterilization resistance (EtO, steam, gamma) |
| Food Processing & Handling | Food contact equipment, conveyor components, food handling parts – utilizing FDA FCN-No. 40 approval |
| Pharmaceutical | Drug contact components, pharmaceutical processing equipment – utilizing FDA Drug Master File listing |
| Laboratory Equipment | Analytical instrument components, labware – utilizing chemical resistance and dimensional stability |
| Sterilization Equipment | Components for sterilization equipment used in hospitals and medical clinics – utilizing chemical, steam, and high temperature resistance |
Typical Properties of Fortron MT9140L6
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.65 g/cm³ (1650 kg/m³) | ISO 1183 |
| Water Absorption (Saturation) | 0.02% | Sim. to ISO 62 |
| Molding Shrinkage – Parallel | 0.2 – 0.6% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.4 – 0.6% | ISO 294-4 |
| Mechanical | ||
| Tensile Modulus | ~14,000 MPa | ISO 527 |
| Tensile Stress at Break | 190 MPa | ISO 527 |
| Tensile Strain at Break | 1.8% | ISO 527 |
| Flexural Modulus | 14,000 MPa | ISO 178 |
| Flexural Strength | 280 MPa | ISO 178 |
| Impact | ||
| Charpy Unnotched Impact (23°C) | 48 kJ/m² | ISO 179/1eU |
| Charpy Notched Impact (23°C) | 9 kJ/m² | ISO 179/1eA |
| Izod Notched Impact (23°C) | 10 kJ/m² | ISO 180/1A |
| Izod Unnotched Impact (23°C) | 32 kJ/m² | ISO 180/1U |
| Hardness, Rockwell M | 100 | ISO 2039-2 |
| Thermal | ||
| Melting Temperature | 280°C | ISO 11357 |
| Glass Transition Temperature | 90°C | ISO 11357 |
| HDT @ 1.80 MPa | 270°C | ISO 75 |
| HDT @ 8.00 MPa | 200°C | ISO 75 |
| Continuous Use Temperature | 160 – 240°C | — |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron MT9140L6 .
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for Fortron MT9140L6. Request the latest official TDS from our sales team.
📌 Regulatory Compliance – For medical and food contact applications, always verify current regulatory certifications (FDA, ISO 10993, USP Class VI) remain valid for your specific application and region.
Processing Guidelines for Fortron MT9140L6
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 130°C |
| Drying Time (Dehumidified Dryer) | 2 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Dew Point Requirement | ≤ -30°C |
| Optimum Melt Temperature | 330°C |
| Min. Melt Temperature | 310°C |
| Max. Melt Temperature | 340°C |
| Hot Runner Temperature | 330 – 340°C |
| Optimum Mold Temperature | 150°C |
| Min. Mold Temperature | 140°C |
| Max. Mold Temperature | 160°C |
| Hold Pressure Range | 30 – 70 MPa |
| Back Pressure | ≤ 3.5 MPa |
| Screw Tangential Speed | 0.2 – 0.3 m/s |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for Fortron MT9140L6
⚠️ Drying Requirement – Fortron MT9140L6 requires drying prior to processing. Because of the necessary low maximum residual moisture content, the use of dry air dryers with dew point ≤ -30°C is recommended. The time between drying and processing should be as short as possible .
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02% . Proper drying is essential to prevent void formation and ensure optimal part quality.
⚠️ Melt Temperature – The recommended melt temperature range is 310–340°C, with an optimum of 330°C . Avoid exceeding 340°C to prevent material degradation.
⚠️ High Flow Grade – Fortron MT9140L6 features low melt viscosity for high flow, specifically designed for thin-walled parts with long flow lengths . Adjust processing parameters accordingly to optimize fill and reduce pressure requirements.
⚠️ Medical Grade – The “MT” designation indicates this grade is specifically developed for medical industry applications . For medical applications, ensure all processing and handling procedures maintain material purity and compliance.
⚠️ Food Contact Compliance – Fortron MT9140L6 complies with FDA Food Contact Notification FCN-No. 40 for repeat-use applications . For food contact applications, verify that processing conditions and any secondary operations do not compromise compliance.
⚠️ Reinforced Grade – Contains 40% glass fiber reinforcement, which may require consideration for equipment wear and proper screw design.
⚠️ Sterilization Compatibility – This grade is compatible with EtO, steam, and gamma irradiation sterilization . For medical applications, validate sterilization methods with actual part geometry.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. For subsequent storage, the material should be stored dry until processed.
Comparison: Fortron MT9140L6 vs. Fortron MT9140L4
| Feature | Fortron MT9140L6 | Fortron MT9140L4 |
|---|---|---|
| Glass Fiber Content | 40% | 40% |
| Melt Viscosity | Low (High Flow) | Standard Flow |
| Key Feature | High flow for thin-wall applications | Standard flow |
| Primary Application | Thin-walled parts with long flow lengths | General medical/food applications |
| Tensile Strength | 190 MPa | ~190 MPa |
| Flexural Modulus | 14,000 MPa | ~14,000 MPa |
| HDT @ 1.80 MPa | 270°C | ~270°C |
| Medical Compliance | ISO 10993, USP Class VI | ISO 10993, USP Class VI |
| FDA Food Contact | FCN-No. 40 approved | FCN-No. 40 approved |
| DMF/MAF Listed | Yes | Yes |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron MT9140L4 – 40% glass reinforced PPS, medical grade, standard flow
-
Fortron MT9120L4 – 20% glass reinforced PPS, medical grade
-
Fortron LM1140L4 – 40% glass reinforced PPS, laser markable grade
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron MT9140L6
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Fortron MT9140L6 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for Fortron MT9140L6 |
| UL Yellow Card | UL safety certification (E107854) |
| FDA Food Contact Notification | FCN-No. 40 compliance documentation |
| Biocompatibility Certification | ISO 10993 and USP Class VI documentation |
| Drug Master File | DMF 14844 documentation |
| Device Master File | MAF 1097 documentation |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron MT9140L6) and document type you require.
FAQ about Fortron MT9140L6
Q1: What is Fortron MT9140L6?
A: Fortron MT9140L6 is a 40% glass fiber reinforced PPS injection molding grade from Celanese with low melt viscosity for high flow, specifically developed for medical and food handling applications .
Q2: What does the “MT” designation mean?
A: “MT” stands for Medical Technology, indicating this grade is specifically developed for medical industry applications .
Q3: How does Fortron MT9140L6 differ from Fortron MT9140L4?
A: Fortron MT9140L6 has low melt viscosity (high flow) for thin-walled parts with long flow lengths, while MT9140L4 has standard flow .
Q4: What are the key features of Fortron MT9140L6?
A: 40% glass reinforcement; high flow/low melt viscosity; medical grade with ISO 10993 & USP Class VI compliance; FDA food contact approved (FCN-No. 40); tensile strength 190 MPa; flexural modulus 14,000 MPa; HDT 270°C; V-0 flame retardant; compatible with EtO, steam, and gamma sterilization .
Q5: What are the typical applications for Fortron MT9140L6?
A: Thin-walled medical devices, surgical instruments, food processing equipment, pharmaceutical components, dental instruments, and sterilization equipment .
Q6: What is the recommended drying condition for Fortron MT9140L6?
A: Dry at 130°C for 2–4 hours using a dehumidified air dryer with dew point ≤ -30°C. Maximum residual moisture should be ≤ 0.02% .
Q7: What is the density of Fortron MT9140L6?
A: 1.65 g/cm³ (1650 kg/m³) .
Q8: What is the HDT @ 1.80 MPa of Fortron MT9140L6?
A: 270°C .
Q9: What regions is Fortron MT9140L6 available in?
A: North America, Europe, South & Central America, and Near East/Africa .
Q10: Is Fortron MT9140L6 flame retardant?
A: Yes, it is inherently flame-retardant (V-0) .
Q11: Is Fortron MT9140L6 FDA compliant for food contact?
A: Yes, it complies with FDA Food Contact Notification FCN-No. 40 for repeat-use applications .
Q12: Is Fortron MT9140L6 biocompatible?
A: Yes, it complies with ISO 10993 and USP Class VI biocompatibility standards .
Q13: What sterilization methods are compatible with Fortron MT9140L6?
A: It is compatible with Ethylene Oxide (EtO), steam, and gamma irradiation sterilization .
Q14: Is Fortron MT9140L6 listed in FDA Master Files?
A: Yes, it is listed in the Drug Master File (DMF 14844) and Device Master File (MAF 1097) .
Q15: What is the tensile strength of Fortron MT9140L6?
A: 190 MPa .
Q16: What is the Charpy notched impact strength of Fortron MT9140L6?
A: 9 kJ/m² at 23°C .
Q17: Is Fortron MT9140L6 suitable for thin-wall applications?
A: Yes, it is specifically designed for thin-walled parts with long flow lengths due to its low melt viscosity .
Q18: Does Fortron MT9140L6 contain animal products?
A: No, it contains no animal products .
