描述
Fortron LM1140L4 is a 40% glass fiber reinforced polyphenylene sulfide (PPS) grade from Celanese Corporation, recognized as the strongest and toughest product available in the Fortron PPS portfolio .
This grade is laser markable, making it ideal for applications requiring permanent part identification and traceability . It exhibits excellent heat and chemical resistance, good electrical properties, and is inherently flame-retardant . The high hardness and rigidity at elevated temperatures allow for good load bearing performance, and this product has good weldability due to the modest filler level .
As a linear, semi-crystalline PPS, Fortron LM1140L4 is relatively impermeable to gases, hydrocarbons, and other liquids compared to other materials. It provides high dimensional stability, low coefficient of friction, low shrinkage, excellent mechanical properties, creep resistance at high temperatures, a high continuous use temperature (160°C to 240°C), and very low moisture absorption.
The material exhibits excellent chemical resistance to all solvents below 200°C, acids, bases, typical and alternative automotive fuels, and petroleum fluids at elevated temperatures. It is RoHS, PFOS, and PFOA compliant.
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron LM1140L4
| # | Feature | Benefit |
|---|---|---|
| 1 | Strongest & Toughest Grade | Unmatched mechanical performance in the Fortron PPS portfolio |
| 2 | Laser Markable | Enables permanent part identification and traceability |
| 3 | 40% Glass Fiber Reinforcement | High strength, stiffness, and dimensional stability |
| 4 | High Strength | Tensile stress at break of 195-200 MPa |
| 5 | High Stiffness | Tensile modulus of 14,700 MPa |
| 6 | Excellent Heat Resistance | HDT of 270°C at 1.80 MPa |
| 7 | Inherent Flame Retardancy | V-0 at 0.38mm and 1.5mm thickness |
| 8 | Good Impact Properties | Notched impact of 10 kJ/m² at 23°C and -30°C |
| 9 | Excellent Chemical Resistance | Resists solvents, acids, bases, and automotive fuels below 200°C |
| 10 | Very Low Moisture Absorption | Ensures dimensional stability in humid environments |
| 11 | Good Weldability | Suitable for secondary welding operations |
| 12 | Good Load Bearing Performance | High hardness and rigidity at elevated temperatures |
| 13 | Versatile Processing | Suitable for injection molding |
| 14 | Regulatory Compliance | RoHS, PFOS, and PFOA compliant |
Typical Applications for Fortron LM1140L4
| Industry | Typical Components & Considerations |
|---|---|
| Automotive | Heaters, pumps, valves, fuel rails – requiring strength and resistance to aggressive chemicals |
| Electrical & Electronics | Bobbins, lamp housings, brush holders – utilizing V-0 flammability and dimensional stability |
| Industrial | Distillation column packings, microwave oven rings – requiring high temperature resistance and chemical resistance |
| General Components | Parts requiring strength, toughness, and resistance to aggressive chemicals |
Typical Properties of Fortron LM1140L4
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.65 g/cm³ | ISO 1183 |
| Molding Shrinkage – Parallel | 0.3% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.6% | ISO 294-4 |
| Specific Heat Capacity of Melt | 1500 J/(kg·K) | Internal Method |
| Mechanical | ||
| Tensile Modulus | 14,700 MPa | ISO 527 |
| Tensile Stress at Break | 195-200 MPa | ISO 527 |
| Tensile Strain at Break | 1.9% | ISO 527 |
| Flexural Modulus | 14,500 MPa | ISO 178 |
| Flexural Strength | 280 MPa | ISO 178 |
| Compressive Modulus | 15,000 MPa | ISO 604 |
| Compressive Strength | 265 MPa | ISO 604 |
| Impact | ||
| Charpy Unnotched Impact (23°C) | 53 kJ/m² | ISO 179/1eU |
| Charpy Unnotched Impact (-30°C) | 53 kJ/m² | ISO 179/1eU |
| Charpy Notched Impact (23°C) | 10 kJ/m² | ISO 179/1eA |
| Charpy Notched Impact (-30°C) | 10 kJ/m² | ISO 179/1eA |
| Izod Notched Impact (23°C) | 10 kJ/m² | ISO 180/1A |
| Izod Unnotched Impact (23°C) | 34 kJ/m² | ISO 180/1U |
| Hardness, Rockwell M | 100 | ISO 2039-2 |
| Poisson’s Ratio | 0.33 | ISO 527 |
| Thermal | ||
| Melting Temperature | 280°C | ISO 11357 |
| Glass Transition Temperature | 90°C | ISO 11357 |
| HDT @ 1.80 MPa | 270°C | ISO 75 |
| HDT @ 8.00 MPa | 215°C | ISO 75 |
| CTE – Parallel | 26 × 10⁻⁶/K | ISO 11359 |
| CTE – Transverse | 42 × 10⁻⁶/K | ISO 11359 |
| Flammability | ||
| Flammability @ 0.38mm | V-0 | UL 94 |
| Flammability @ 1.5mm | V-0 | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron LM1140L4.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for Fortron LM1140L4. Request the latest official TDS from our sales team.
Processing Guidelines for Fortron LM1140L4
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 130 – 140°C |
| Drying Time (Dehumidified Dryer) | 3 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Optimum Melt Temperature | 330°C |
| Min. Melt Temperature | 310°C |
| Max. Melt Temperature | 340°C |
| Manifold / Hot Runner Temperature | 330 – 340°C |
| Optimum Mold Temperature | 150°C |
| Min. Mold Temperature | 140°C |
| Max. Mold Temperature | 160°C |
| Hold Pressure Range | 30 – 70 MPa |
| Back Pressure | ≤ 3.5 MPa |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for Fortron LM1140L4
⚠️ Drying Requirement – Fortron LM1140L4 requires drying prior to processing. Because of the necessary low maximum residual moisture content, the use of dry air dryers is recommended. The time between drying and processing should be as short as possible.
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02%. Proper drying is essential to prevent void formation and ensure optimal part quality.
⚠️ Melt Temperature – The recommended melt temperature range is 310–340°C, with an optimum of 330°C. Avoid exceeding 340°C to prevent material degradation.
⚠️ Strongest & Toughest Grade – Fortron LM1140L4 is recognized as the strongest and toughest product available in the Fortron PPS portfolio . Ensure proper part design to maximize mechanical performance.
⚠️ Laser Markable – This grade is laser markable, enabling permanent part identification . For optimal laser marking results, consult your laser equipment manufacturer for recommended settings.
⚠️ Reinforced Grade – Contains 40% glass fiber reinforcement, which may require consideration for equipment wear and proper screw design.
⚠️ Weldability – This product has good weldability due to the modest filler level . For welding operations, ensure proper process parameters are used.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. For subsequent storage, the material should be stored dry until processed.
Comparison: Fortron LM1140L4 vs. Fortron 1140L4
| Feature | Fortron LM1140L4 | Fortron 1140L4 |
|---|---|---|
| Glass Fiber Content | 40% | 40% |
| Key Feature | Strongest & toughest grade + Laser markable | High strength standard grade |
| Laser Markable | Yes | No |
| Tensile Strength | 195-200 MPa | ~195 MPa |
| Tensile Modulus | 14,700 MPa | ~14,700 MPa |
| HDT @ 1.80 MPa | 270°C | ~270°C |
| Flame Retardancy | V-0 @ 0.38mm | V-0 @ 0.38mm |
| Primary Application | Automotive, electronics, laser marking | General injection molding |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron 1140L4 – 40% glass reinforced PPS, standard injection molding grade
-
Fortron 1140L6 – 40% glass reinforced PPS, easy flow for thin-wall applications
-
Fortron ICE 504L – Fast crystallizing 40% glass reinforced PPS
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron LM1140L4
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Fortron LM1140L4 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for Fortron LM1140L4 |
| UL Yellow Card | UL safety certification (E107854) |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron LM1140L4) and document type you require.
FAQ about Fortron LM1140L4
Q1: What is Fortron LM1140L4?
A: Fortron LM1140L4 is a 40% glass fiber reinforced PPS grade from Celanese, recognized as the strongest and toughest product available in the Fortron PPS portfolio .
Q2: What does the “LM” designation mean?
A: The “LM” designation indicates this grade is laser markable, making it ideal for applications requiring permanent part identification and traceability .
Q3: What are the key features of Fortron LM1140L4?
A: 40% glass reinforcement; strongest & toughest grade; laser markable; tensile strength 195-200 MPa; tensile modulus 14,700 MPa; HDT 270°C; V-0 at 0.38mm; excellent chemical resistance; good weldability.
Q4: What are the typical applications for Fortron LM1140L4?
A: Automotive components (heaters, pumps, valves, fuel rails), electronic components (bobbins, lamp housings, brush holders), and industrial components requiring strength and resistance to aggressive chemicals .
Q5: What is the recommended drying condition for Fortron LM1140L4?
A: Dry at 130–140°C for 3–4 hours using a dehumidified air dryer. Maximum residual moisture should be ≤ 0.02%.
Q6: What is the density of Fortron LM1140L4?
A: 1.65 g/cm³ .
Q7: What is the HDT @ 1.80 MPa of Fortron LM1140L4?
A: 270°C .
Q8: What regions is Fortron LM1140L4 available in?
A: North America, Europe, Asia Pacific, Latin America, Africa & Middle East.
Q9: Is Fortron LM1140L4 flame retardant?
A: Yes, it is inherently flame-retardant with V-0 rating at 0.38mm and 1.5mm thickness .
Q10: Is Fortron LM1140L4 laser markable?
A: Yes, it is laser markable, enabling permanent part identification and traceability .
Q11: What is the Charpy notched impact strength of Fortron LM1140L4?
A: 10 kJ/m² at 23°C and -30°C .
Q12: Does Fortron LM1140L4 have good weldability?
A: Yes, this product has good weldability due to the modest filler level .
Q13: Is Fortron LM1140L4 RoHS compliant?
A: Yes, it complies with RoHS, PFOS, and PFOA regulations.
Q14: What is the tensile strength of Fortron LM1140L4?
A: 195-200 MPa .
Q15: What is the difference between Fortron LM1140L4 and Fortron 1140L4?
A: Fortron LM1140L4 is the laser markable version of the 40% glass reinforced grade, while Fortron 1140L4 is the standard version. Both share similar mechanical properties, but LM1140L4 offers the added benefit of laser markability for part identification.
