描述
Fortron FX515T1 is a 15% glass fiber reinforced, impact modified polyphenylene sulfide (PPS) injection molding grade from Celanese Corporation. This grade offers good impact resistance combined with the inherent thermal and chemical resistance of PPS, making it suitable for demanding automotive and food contact applications.
With 15% glass fiber reinforcement and impact modification, Fortron FX515T1 delivers significantly improved toughness compared to standard glass-filled PPS grades, while maintaining excellent dimensional stability and heat resistance. The impact modification provides enhanced ductility, with a tensile strain at break of 2.1% and Charpy notched impact strength of 10 kJ/m².
Fortron FX515T1 is also suitable for food contact applications, complying with FDA and EU food contact regulations. The material meets RENAULT UB02b automotive specification.
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron FX515T1
-
15% Glass Fiber Reinforcement – Enhanced mechanical properties and dimensional stability
-
Impact Modified – Good impact resistance; Charpy notched impact of 10 kJ/m²; Charpy unnotched impact of 40 kJ/m²
-
Good Mechanical Properties – Tensile modulus of 6,000 MPa; tensile strength of 100 MPa; flexural modulus of 5,800 MPa; flexural strength of 150 MPa
-
Excellent Heat Resistance – HDT of 220°C at 1.80 MPa
-
Good Dimensional Stability – Low molding shrinkage: 0.6% parallel, 0.3% normal
-
Inherent Flame Retardancy – V-0 flame retardant (halogen-free)
-
Excellent Chemical Resistance – Resists solvents, acids, bases, and automotive fuels below 200°C
-
Very Low Moisture Absorption – <0.02% water absorption
-
Food Contact Compliant – FDA and EU food contact approved
-
Automotive Approved – Meets RENAULT UB02b specification
-
Good Flow – Suitable for complex injection molded parts
-
Global Supply – Available across North America, Europe, Asia Pacific, Latin America, Africa & Middle East
Typical Applications for Fortron FX515T1
| Industry | Typical Components & Considerations |
|---|---|
| Automotive | Under-hood components, clips, fasteners, connectors, sensors – meeting RENAULT UB02b specification and requiring chemical resistance and impact resistance |
| Food Processing | Food contact equipment, conveyor components, food handling parts – utilizing FDA/EU food contact compliance and good impact resistance |
| Electrical & Electronics | Connectors, coil bobbins, relay housings – requiring V-0 flammability and dimensional stability |
| Industrial | Pump and valve components, chemical processing equipment – requiring corrosion resistance |
| Metal Replacement | Applications requiring lighter, tougher alternative to metal |
Typical Properties of Fortron FX515T1
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1370 kg/m³ (1.37 g/cm³) | ISO 1183 |
| Molding Shrinkage – Parallel | 0.6% | ISO 294-4 |
| Molding Shrinkage – Normal | 0.3% | ISO 294-4 |
| Mechanical | ||
| Tensile Modulus | 6,000 MPa | ISO 527-1/-2 |
| Tensile Stress at Break | 100 MPa | ISO 527-1/-2 |
| Tensile Strain at Break | 2.1% | ISO 527-1/-2 |
| Flexural Modulus | 5,800 MPa | ISO 178 |
| Flexural Strength | 150 MPa | ISO 178 |
| Flexural Strain at Failure | 3.1% | ISO 178 |
| Poisson’s Ratio | 0.35 [C] | — |
| Impact | ||
| Charpy Unnotched Impact (23°C) | 40 kJ/m² | ISO 179/1eU |
| Charpy Notched Impact (23°C) | 10 kJ/m² | ISO 179/1eA |
| Thermal | ||
| HDT @ 1.80 MPa | 220°C | ISO 75-1/-2 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron FX515T1.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for Fortron FX515T1. Request the latest official TDS from our sales team.
📌 Food Contact Certification – Always verify current FDA/EU compliance status for your specific application and region.
Processing Guidelines for Fortron FX515T1
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 130°C |
| Drying Time (Dehumidified Dryer) | 2 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Dew Point Requirement | ≤ -30°C |
| Optimum Melt Temperature | 330°C |
| Min. Melt Temperature | 310°C |
| Max. Melt Temperature | 340°C |
| Optimum Mold Temperature | 120°C |
| Min. Mold Temperature | 80°C |
| Max. Mold Temperature | 160°C |
| Screw Tangential Speed | 0.2 – 0.3 m/s |
| Hold Pressure Range | 30 – 70 MPa |
| Back Pressure | ≤ 3.5 MPa |
| Ejection Temperature | 196°C |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for Fortron FX515T1
⚠️ Drying Requirement – Fortron FX515T1 requires drying prior to processing. Because of the necessary low maximum residual moisture content, the use of dry air dryers is recommended. The dew point should be ≤ -30°C. The time between drying and processing should be as short as possible.
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02%. Proper drying is essential to prevent void formation and ensure optimal part quality.
⚠️ Melt Temperature – The recommended melt temperature range is 310–340°C, with an optimum of 330°C. Avoid exceeding 340°C to prevent material degradation.
⚠️ Impact Modified Grade – This grade is specifically formulated for impact resistance and toughness. Processing parameters should be optimized to maintain impact modification performance.
⚠️ Food Contact Compliance – Fortron FX515T1 is suitable for food contact applications. For food contact applications, verify that the latest regulatory certifications remain valid for your specific use case.
⚠️ Automotive Specification – Fortron FX515T1 meets RENAULT UB02b specification. Ensure proper part design to meet automotive quality requirements.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. For subsequent storage, the material should be stored dry until processed.
Comparison: Fortron FX515T1 vs. Fortron FX4382T1
| Feature | Fortron FX515T1 | Fortron FX4382T1 |
|---|---|---|
| Filler Content | 15% Glass Fiber | Unfilled |
| Key Feature | Impact modified + Food contact | Impact modified + Food contact |
| Tensile Modulus | 6,000 MPa | 2,300 MPa |
| Tensile Strength | 100 MPa | 50 MPa |
| Elongation at Break | 2.1% | 25% |
| Charpy Notched Impact | 10 kJ/m² | 40 kJ/m² |
| HDT @ 1.80 MPa | 220°C | 100°C |
| Density | 1.37 g/cm³ | 1.25 g/cm³ |
| Food Contact | FDA/EU Compliant | FDA/EU Compliant |
| Primary Application | Automotive + Food processing | Food processing + Extrusion |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron FX4382T1 – Unfilled impact modified PPS with food contact compliance
-
Fortron FX40T1 – Unfilled impact-modified high toughness PPS
-
Fortron 1140L4 – 40% glass reinforced PPS, standard injection molding grade
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron FX515T1
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Fortron FX515T1 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for Fortron FX515T1 |
| Food Contact Certification | FDA and EU food contact compliance documentation |
| UL Yellow Card | UL safety certification |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron FX515T1) and document type you require.
FAQ about Fortron FX515T1
Q1: What is Fortron FX515T1?
A: Fortron FX515T1 is a 15% glass fiber reinforced, impact modified PPS injection molding grade from Celanese, suitable for automotive and food contact applications.
Q2: What are the key features of Fortron FX515T1?
A: 15% glass reinforcement; impact modified; tensile modulus 6,000 MPa; tensile strength 100 MPa; HDT 220°C; Charpy notched impact 10 kJ/m²; V-0 flame retardant; FDA/EU food contact compliant; meets RENAULT UB02b specification.
Q3: What are the typical applications for Fortron FX515T1?
A: Automotive under-hood components, food processing equipment, connectors, electrical components, and industrial parts.
Q4: What is the recommended drying condition?
A: Dry at 130°C for 2–4 hours using a dehumidified air dryer with dew point ≤ -30°C. Maximum residual moisture should be ≤ 0.02%.
Q5: What is the density of Fortron FX515T1?
A: 1.37 g/cm³ (1370 kg/m³).
Q6: What is the HDT @ 1.80 MPa of Fortron FX515T1?
A: 220°C.
Q7: What regions is Fortron FX515T1 available in?
A: North America, Europe, Asia Pacific, Latin America, Africa & Middle East.
Q8: Is Fortron FX515T1 flame retardant?
A: Yes, it is inherently flame-retardant (V-0).
Q9: What automotive specifications does Fortron FX515T1 meet?
A: RENAULT UB02b.
Q10: Is Fortron FX515T1 suitable for food contact applications?
A: Yes, it is suitable for injection molding and food contact applications.
Q11: What is the tensile modulus of Fortron FX515T1?
A: 6,000 MPa.
Q12: What is the Charpy notched impact strength?
A: 10 kJ/m² at 23°C.
CTA (Call to Action)
Ready to order Fortron FX515T1?
To get a precise quotation and professional technical support for Fortron FX515T1, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (automotive, food processing, injection molding, etc.)
-
Document requirements (TDS, SDS, COA, UL docs, food contact certification)
Sample Policy:
-
Samples of Fortron FX515T1 are for laboratory validation tests only, not for production use.
-
Buyer bears international sample-shipping freight.
-
If bulk-product performance deviates from sample reference, the manufacturer’s official TDS serves as the authoritative benchmark.
Take action now:
📧 Email Us – ruiqingchem@gmail.com
📝 Send Inquiry – Use our quick inquiry form
💬 Live Chat – Click the bottom-right chat widget to speak directly with our team
After-Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality-related claims must be submitted within 7 working days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim-document preparation. |
| Technical Support | Remote technical guidance available. On-site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original manufacturer typical values for Fortron FX515T1. Our company acts as supplier/trader rather than original manufacturer. Final performance depends on processing conditions and part design. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for product failure caused by improper processing or improper usage. Always reference the latest manufacturer official TDS of Fortron FX515T1 as the definitive specification.
