Fortron 1342L4 is a 40% glass fiber reinforced, PTFE-modified polyphenylene sulfide (PPS) injection molding grade from Celanese Corporation. This grade is specifically designed as a low-wear tribological grade, ideally suited for bearings, gears, and other sliding friction/wear applications .
The PTFE modification provides significantly improved friction and wear properties compared to standard glass reinforced PPS grades . This makes Fortron 1342L4 an excellent choice for moving parts requiring self-lubrication and long service life under friction conditions.
As a linear, semi-crystalline PPS, this grade is relatively impermeable to gases, hydrocarbons, and other liquids compared to other materials . It provides high dimensional stability, low coefficient of friction, low shrinkage (0.2% flow, 0.5% transverse) , excellent mechanical properties, creep resistance at high temperatures, a high continuous use temperature (160°C to 240°C), and very low moisture absorption (0.02%) .
This grade offers high hardness, high rigidity, and exhibits excellent resistance to corrosion, hydrolysis, oxidation, heat, and paraffin buildup . It shows excellent chemical resistance to all solvents below 200°C, acids, bases, typical and alternative automotive fuels, and petroleum fluids at elevated temperatures . The material complies with RoHS, PFOS, and PFOA regulations .
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron 1342L4
-
40% Glass Fiber + PTFE Modification – Enhanced mechanical properties with low friction and wear characteristics
-
Low Wear / Low Friction – PTFE-modified tribological grade for demanding sliding applications
-
Low Coefficient of Friction – Dynamic coefficient of friction versus steel: 0.16; static: 0.20
-
High Strength – Tensile strength of 165 MPa
-
High Stiffness – Tensile modulus of 14,400 MPa; flexural modulus of 13,700 MPa
-
Excellent Heat Resistance – HDT of 270°C at 1.80 MPa ; melting temperature of 280°C
-
Inherent Flame Retardancy – V-0 at 0.75mm and 1.5mm thickness
-
Excellent Chemical Resistance – Resists all solvents below 200°C, acids, bases, automotive fuels, and petroleum fluids
-
Very Low Moisture Absorption – 0.02% water absorption
-
High Dimensional Stability – Low shrinkage: 0.2% parallel, 0.5% transverse
-
Lead-Free Soldering – Suitable for lead-free soldering applications
-
Metal Replacement – Suitable for metal replacement applications
-
Global Supply – Available across North America, Europe, South and Central America, Asia Pacific, Near East/Africa
Typical Applications for Fortron 1342L4
| Industry | Typical Components & Considerations |
|---|---|
| Bearings | Plain bearings, thrust bearings, sleeve bearings – requiring low friction and wear resistance |
| Gears | Precision gears, gear components – requiring dimensional stability and tribological performance |
| Sliding Friction Applications | Wear pads, guide rails, seals, sliding components – requiring low coefficient of friction |
| Automotive | Fuel system components, pump internals, transmission parts – requiring chemical resistance and tribological performance |
| Electrical & Electronics | Connectors, sensors, housings – requiring flame retardancy and dimensional stability |
Typical Properties of Fortron 1342L4
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.69 g/cm³ | ISO 1183 |
| Water Absorption (Saturation) | 0.02% | ISO 62 |
| Molding Shrinkage – Parallel | 0.2% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.5% | ISO 294-4 |
| Mechanical | ||
| Tensile Modulus | 14,400 MPa | ISO 527-2/1A |
| Tensile Strength at Break | 165 MPa | ISO 527 |
| Tensile Strain at Break | 1.6% | ISO 527 |
| Flexural Modulus | 13,700 MPa | ISO 178 |
| Friction | ||
| Coefficient of Friction – Dynamic (vs. Steel) | 0.16 | ASTM D1894 |
| Coefficient of Friction – Static (vs. Steel) | 0.20 | ASTM D1894 / ISO 8295 |
| Impact | ||
| Charpy Notched Impact (23°C) | 8.5 kJ/m² | ISO 179/1eA |
| Charpy Unnotched Impact (23°C) | 44 kJ/m² | ISO 179/1eU |
| Izod Notched Impact (23°C) | 8.5 kJ/m² | ISO 180/1A |
| Thermal | ||
| Melting Temperature | 280°C | ISO 11357 |
| Glass Transition Temperature | 90°C | ISO 11357 |
| HDT @ 1.80 MPa | 270°C | ISO 75 |
| HDT @ 8.00 MPa | 215°C | ISO 75 |
| CTE – Parallel | 22 × 10⁻⁶/K | ISO 11359 |
| CTE – Transverse | 40 × 10⁻⁶/K | ISO 11359 |
| Flammability | ||
| Flammability @ 0.75mm | V-0 | UL 94 |
| Flammability @ 1.5mm | V-0 | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron 1342L4.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for Fortron 1342L4. Request the latest official TDS from our sales team.
Processing Guidelines for Fortron 1342L4
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 130 – 140°C |
| Drying Time | 3 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Dew Point Requirement | ≤ -30°C |
| Melt Temperature Range | 320 – 340°C |
| Optimum Melt Temperature | 330°C |
| Optimum Mold Temperature | 150°C |
| Min. Mold Temperature | 140°C |
| Max. Mold Temperature | 160°C |
| Hold Pressure Range | 30 – 70 MPa |
| Back Pressure | ≤ 3 MPa |
| Screw Tangential Speed | 0.2 – 0.3 m/s |
| Ejection Temperature | 215°C |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings for Fortron 1342L4
⚠️ Drying Requirement – Fortron 1342L4 requires drying prior to processing. Predrying in a dehumidified air dryer at 130–140°C for 3–4 hours is recommended . The time between drying and processing should be as short as possible .
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02% . Use of dry air dryers with dew point ≤ -30°C is recommended .
⚠️ Melt Temperature – The recommended melt temperature range is 320–340°C, with an optimum of 330°C. Avoid exceeding 340°C to prevent material degradation .
⚠️ Mold Temperature – Minimum mold wall temperature of 140°C is required to achieve maximum crystallizable potential. Mercedes-Benz recommends a tool temperature of at least 135°C .
⚠️ PTFE-Modified Grade – This grade contains PTFE for low friction and wear. Processing parameters should be adjusted to accommodate the PTFE modification .
⚠️ Reinforced Grade – Contains 40% glass fiber reinforcement, which may require consideration for equipment wear and proper screw design. A shut-off nozzle is preferred to a free-flow nozzle . On injection molding machines with 15-25 D long three-section screws, the material is processable .
⚠️ Injection Rate – A medium injection rate is normally preferred. All mold cavities must be effectively vented .
⚠️ Storage – For subsequent storage, the material should be stored dry in the dryer until processed (≤ 60 hours) .
Comparison: Fortron 1342L4 vs. Other 40% Glass Reinforced PPS Grades
| Feature | Fortron 1342L4 | Fortron 1140L4 | Fortron 1140L6 |
|---|---|---|---|
| Additive | PTFE | None | None |
| Key Feature | Low wear / low friction | General injection molding | Easy flow, thin-wall |
| Primary Application | Bearings, gears, sliding friction | Structural components | Thin-wall parts |
| Tensile Strength | 165 MPa | 195-200 MPa | 195-200 MPa |
| Flexural Modulus | 13,700 MPa | 14,000-14,500 MPa | 14,000-14,500 MPa |
| HDT @ 1.80 MPa | 270°C | 265-270°C | 265-270°C |
| Density | 1.69 g/cm³ | 1.60-1.65 g/cm³ | 1.60-1.65 g/cm³ |
| Coefficient of Friction | 0.16 (dynamic vs. steel) | Higher | Higher |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron 1140L4 – 40% glass reinforced PPS, standard injection molding grade
-
Fortron 1140L6 – 40% glass reinforced PPS, easy flow for thin-wall applications
-
Fortron 1140T4 – 40% glass reinforced, impact modified PPS
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron 1342L4
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties of Fortron 1342L4 |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification for Fortron 1342L4 |
| UL Yellow Card | UL safety certification (E107854) |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron 1342L4) and document type you require.
FAQ about Fortron 1342L4
Q1: What is Fortron 1342L4?
A: Fortron 1342L4 is a 40% glass fiber reinforced, PTFE-modified PPS injection molding grade from Celanese, designed as a low-wear tribological grade for bearings, gears, and sliding friction applications .
Q2: What makes Fortron 1342L4 different from standard PPS grades?
A: Fortron 1342L4 contains PTFE, which provides significantly lower friction and improved wear resistance compared to standard glass reinforced PPS grades .
Q3: What are the key features of Fortron 1342L4?
A: 40% glass reinforcement; PTFE-modified for low wear and low friction; tensile strength 165 MPa; tensile modulus 14,400 MPa; HDT 270°C; V-0 at 0.75mm; excellent chemical and heat resistance .
Q4: What are the typical applications for Fortron 1342L4?
A: Bearings, gears, wear pads, guide rails, seals, sliding components, automotive fuel system parts, and pump internals .
Q5: What is the coefficient of friction of Fortron 1342L4?
A: Dynamic coefficient of friction versus steel: 0.16; static coefficient versus steel: 0.20 .
Q6: What is the recommended drying condition for Fortron 1342L4?
A: Dry at 130–140°C for 3–4 hours using a dehumidified air dryer with dew point ≤ -30°C. Maximum residual moisture should be ≤ 0.02% .
Q7: What is the density of Fortron 1342L4?
A: 1.69 g/cm³ .
Q8: What is the HDT @ 1.80 MPa of Fortron 1342L4?
A: 270°C .
Q9: What regions is Fortron 1342L4 available in?
A: North America, Europe, South and Central America, Asia Pacific, Near East/Africa .
Q10: Is Fortron 1342L4 flame retardant?
A: Yes, V-0 at 0.75mm and 1.5mm thickness (UL 94) .
Q11: Is Fortron 1342L4 RoHS compliant?
A: Yes, it complies with RoHS, PFOS, and PFOA regulations .
Q12: What color options are available?
A: Natural and Black (SD3002 BLACK H) .
