Fortron 1140L6 DW is a 40% glass fiber reinforced polyphenylene sulfide (PPS) injection molding grade from Celanese Corporation. This grade is an easier flow version of Fortron 1140L4, developed specifically for drinking water contact applications —the “DW” designation indicates its suitability for this purpose .
Fortron 1140L6 DW offers essentially the same mechanical characteristics as 1140L4 but with improved flow, making it especially suitable for thin-walled parts with long flow lengths . The material combines high strength, excellent heat and chemical resistance, and inherent flame retardancy.
As a linear, semi-crystalline PPS, it demonstrates excellent chemical resistance to all solvents below 200°C, acids, bases, automotive fuels, and petroleum fluids at elevated temperatures . It provides high dimensional stability with very low moisture absorption (0.02%) and is RoHS, PFOS, and PFOA compliant .
For more PPS grades and technical information, please visit our PPS/Polyphenylene Sulfide product page. You can also explore Celanese’s official Fortron PPS portfolio for additional manufacturer insights.
Key Features of Fortron 1140L6 DW
-
40% Glass Fiber Reinforcement – High strength and stiffness
-
Easy Flow – Easier flow version of 1140L4, specifically designed for thin-walled parts with long flow lengths
-
Drinking Water Approved – Developed for drinking water contact applications – the “DW” designation
-
High Strength – Tensile strength of 195 MPa
-
High Stiffness – Tensile modulus of 14,700 MPa; flexural modulus of 14,500 MPa
-
Excellent Heat Resistance – HDT of 270°C at 1.80 MPa; melting temperature of 280°C
-
Inherent Flame Retardancy – V-0 at 0.38mm and 1.5mm thickness
-
Excellent Chemical Resistance – Resists all solvents below 200°C, acids, bases, and automotive fuels
-
Very Low Moisture Absorption – 0.02% water absorption
-
Regulatory Compliance – RoHS, PFOS, and PFOA compliant; NSF drinking water certifications available
-
Global Supply – Available across North America, Europe, Asia Pacific, Latin America, Africa & Middle East
Typical Applications for Fortron 1140L6 DW
| Industry | Typical Components & Considerations |
|---|---|
| Drinking Water Contact | Pump housings, valves, fittings – developed for potable water applications with “DW” approval |
| Thin-Wall Electronics | High-density thin-wall connectors, coil bobbins, SMT components, micro switches – utilizing easy flow for long flow paths and thin walls |
| Pump Components | Small pump impellers, pump bodies, pump internals – requiring high strength, chemical resistance, and dimensional stability |
| Automotive | Automotive sensors, housings, fuel system components – requiring resistance to aggressive chemicals and heat |
| Lead-Free Soldering | Electronic components suitable for lead-free soldering processes |
Typical Properties of Fortron 1140L6 DW
| Property | Value | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.65 g/cm³ (1650 kg/m³) | ISO 1183 |
| Water Absorption (Saturation) | 0.02% | ISO 62 |
| Molding Shrinkage – Parallel | 0.3% | ISO 294-4 |
| Molding Shrinkage – Transverse | 0.6% | ISO 294-4 |
| Mechanical | ||
| Tensile Modulus | 14,700 MPa | ISO 527 |
| Tensile Stress at Break | 195 MPa | ISO 527 |
| Tensile Strain at Break | 1.9% | ISO 527 |
| Flexural Modulus | 14,500 MPa | ISO 178 |
| Flexural Strength | 285 MPa | ISO 178 |
| Impact | ||
| Charpy Notched Impact (23°C) | 10 kJ/m² | ISO 179/1eA |
| Charpy Unnotched Impact (23°C) | 53 kJ/m² | ISO 179/1eU |
| Thermal | ||
| Melting Temperature | 280°C | ISO 11357 |
| Glass Transition Temperature | 90°C | ISO 11357 |
| HDT @ 1.80 MPa | 270°C | ISO 75 |
| HDT @ 8.00 MPa | 215°C | ISO 75 |
| CTE – Flow | 26 × 10⁻⁶/K | ISO 11359 |
| CTE – Transverse | 42 × 10⁻⁶/K | ISO 11359 |
| Electrical | ||
| Volume Resistivity | >1×10¹³ Ω·m | IEC 62631 |
| Flammability | ||
| Flammability @ 0.38mm | V-0 | UL 94 |
| Flammability @ 1.5mm | V-0 | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for Fortron 1140L6 DW .
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines for Fortron 1140L6 DW
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 130 – 140°C |
| Drying Time | 3 – 4 hours |
| Suggested Max Moisture | ≤ 0.02% |
| Dew Point Requirement | ≤ -30°C |
| Optimum Melt Temperature | 320 – 340°C |
| Mold Temperature | ≥ 140°C |
| Shut-off Nozzle | Preferred to free-flow nozzle |
| Screw Length | 15 – 25 D (three-section screw) |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight |
Critical Processing Warnings
⚠️ Drying Requirement – Fortron 1140L6 DW requires drying prior to processing. Predry in a dehumidified air dryer at 130–140°C for 3–4 hours . The time between drying and processing should be as short as possible.
⚠️ Moisture Control – Maximum residual moisture content should be ≤ 0.02%.
⚠️ Melt Temperature – The recommended melt temperature range is 320–340°C. Avoid exceeding 340°C to prevent material degradation .
⚠️ Easy Flow Characteristics – This grade is an easier flow version of 1140L4. Adjust processing parameters accordingly for thin-wall and long flow length applications .
⚠️ Drinking Water Compliance – The “DW” designation indicates this grade is developed for drinking water contact. Ensure all secondary processing and assembly materials also meet drinking water compliance requirements .
⚠️ Reinforced Grade – Contains 40% glass fiber reinforcement, which may require consideration for equipment wear and proper screw design. A shut-off nozzle is preferred to a free-flow nozzle .
Comparison: Fortron 1140L6 DW vs. Other 40% Glass Reinforced Fortron Grades
| Feature | Fortron 1140L6 DW | Fortron 1140L4 | Fortron 1140L4 HR | Fortron 1140L0 |
|---|---|---|---|---|
| Key Feature | Easy flow + Drinking water approved | Standard injection molding | Improved hydrolysis resistance | Extrusion (rods, slabs) |
| Flow | Easier flow | Standard flow | Standard flow | Extrusion grade |
| Tensile Strength | 195 MPa | 195-200 MPa | 200 MPa | 124-185 MPa |
| Tensile Modulus | 14,700 MPa | 14,700 MPa | 15,600 MPa | 7,600-12,000 MPa |
| HDT @ 1.80 MPa | 270°C | 265-270°C | 270°C | 240°C |
| Density | 1.65 g/cm³ | 1.60-1.65 g/cm³ | 1.66-1.70 g/cm³ | 1.65-1.66 g/cm³ |
| Special Feature | Thin-wall + Drinking water | — | Hydrolysis resistance for coolants | Rod/slab/profile extrusion |
Related Products
-
PPS/Polyphenylene Sulfide – View our full range of PPS products
-
Fortron 1140L4 – 40% glass reinforced PPS, standard injection molding grade
-
Fortron 1140L4 HR – 40% glass reinforced PPS with improved hydrolysis resistance
-
Fortron 1140L0 – 40% glass reinforced PPS for extrusion (rods, slabs, profiles)
-
Fortron 1132L4 – 30% glass reinforced PPS for high-strength injection molding
-
Explore Engineering Plastics – Browse all engineering plastic materials
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for Fortron 1140L6 DW
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| UL Yellow Card | UL safety certification (E107854) |
| Drinking Water Compliance Certificate | Certification for drinking water contact applications |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (Fortron 1140L6 DW) and document type you require.
FAQ about Fortron 1140L6 DW
Q1: What is Fortron 1140L6 DW?
A: Fortron 1140L6 DW is a 40% glass fiber reinforced PPS injection molding grade from Celanese, offering easier flow than 1140L4, specifically developed for drinking water contact applications .
Q2: What does the “DW” suffix mean?
A: The “DW” suffix designates Drinking Water, indicating this grade has been developed for drinking water contact applications .
Q3: How does Fortron 1140L6 DW differ from Fortron 1140L4?
A: Fortron 1140L6 DW is an easier flow version of 1140L4 with drinking water approval. It offers essentially the same mechanical characteristics but with improved flow for thin-walled parts with long flow paths .
Q4: What are the key features of Fortron 1140L6 DW?
A: 40% glass reinforcement; easy flow for thin-wall parts; drinking water approved; tensile strength 195 MPa; HDT 270°C; V-0 at 0.38mm; excellent chemical resistance .
Q5: What are the typical applications for Fortron 1140L6 DW?
A: Drinking water pumps and valves, thin-wall electronic connectors, coil bobbins, automotive sensors, SMT components, and pump impellers .
Q6: What is the recommended drying condition?
A: Dry at 130–140°C for 3–4 hours using a dehumidified air dryer with dew point ≤ -30°C .
Q7: What is the density?
A: 1.65 g/cm³ (1650 kg/m³) .
Q8: What is the HDT @ 1.80 MPa?
A: 270°C .
Q9: What regions is Fortron 1140L6 DW available in?
A: North America, Europe, Asia Pacific, Latin America, Africa & Middle East .
Q10: Is Fortron 1140L6 DW flame retardant?
A: Yes, V-0 at 0.38mm and 1.5mm thickness (UL 94) .
Q11: Is Fortron 1140L6 DW suitable for thin-wall applications?
A: Yes, it is specifically designed for thin-walled parts requiring long flow lengths .
Q12: Is Fortron 1140L6 DW NSF certified for drinking water?
A: Yes, it is developed for drinking water contact and has NSF certification .
