描述
CYROLITE MD 6N S000 High Flow UV Acrylic USP VI
Material: PMMA-based Polymer
MVR: 12 cm³/10min
Transmission: 92%
Vicat: 96°C
Refractive Index: 1.49
Packing: 25kg / 500kg
CYROLITE MD 6N S000 combines high flow (MVR 12) with exceptional UV transparency (92%) and high heat resistance (96°C Vicat) — engineered for UV spectroscopy applications in diagnostic test packs, cuvettes, and microfluidics.
CYROLITE MD 6N S000 is an amorphous thermoplastic molding compound based on PMMA, specifically designed for the medical diagnostic industry requiring UV spectroscopy for fluid evaluation. With an MVR of 12 cm³/10min, this grade delivers maximum flow characteristics for filling complex diagnostic molds while maintaining exceptional optical clarity with 92% luminous transmittance at 3mm thickness.
CYROLITE MD 6N S000 offers high heat deflection temperature with Vicat softening point of 96°C, ensuring dimensional stability in demanding diagnostic environments. The material complies with United States Pharmacopeia Class VI and ISO 10993-1 biocompatibility standards, making it suitable for patient-contact diagnostic devices. Processable on standard injection molding machines with 3-zone general purpose screws for engineering thermoplastics. Typical applications include diagnostic test packs, cuvettes, microfluidics, and crystallography trays where UV spectroscopy and high flow are critical.
Genuine Roehm CYROLITE Imported Stock and Technical Support
We supply stable spot inventory of genuine CYROLITE MD 6N S000 high flow UV diagnostic acrylic. Official TDS, batch COA, and biocompatibility documentation (USP Class VI, ISO 10993) are available for medical diagnostic applications.
Request CYROLITE MD 6N S000 Quotation, TDS, and Sample
Complete TDS, COA, and regulatory documentation available
Core Advantages of CYROLITE MD 6N S000
- Maximum flow characteristics — MVR 12 cm³/10min for complex diagnostic mold filling
- Exceptional UV transparency — 92% luminous transmittance for UV spectroscopy applications
- High refractive index — 1.49 for precision optical performance in diagnostic devices
- High heat resistance — 96°C Vicat softening temperature for dimensional stability
- Superior optical clarity — consistent light transmission with excellent clarity
- Excellent dimensional stability — precise and consistent component geometry
- Medical grade compliance — USP Class VI and ISO 10993-1 biocompatibility
- Cost-effective alternative to glass — total cost-of-use advantage in diagnostic devices
Main Applications
- Diagnostic test packs — integrated diagnostic devices requiring UV spectroscopy
- Cuvettes — UV spectroscopy sample holders
- Microfluidics — precision fluid handling components
- Crystallography trays — protein crystallization applications
Full Technical Parameters
| Property | Typical Value | Test Method |
| Material Type | PMMA-based polymer | — |
| Medical Compliance | USP Class VI, ISO 10993-1 | — |
| Melt Volume Rate MVR (230°C/3.8kg) | 12 cm³/10min | ISO 1133 |
| Light Transmission (3mm) | 92% | ISO 13468-2 |
| Refractive Index | 1.49 | ISO 489 |
| Tensile Modulus | 3200 MPa | ISO 527 |
| Stress at Break | 67 MPa | ISO 527 |
| Strain at Break | 3% | ISO 527 |
| Charpy Impact Strength (23°C) | 20 kJ/m² | ISO 179/1eU |
| Vicat Softening Temperature | 96°C | ISO 306 |
| Coeff. of Linear Thermal Expansion (0-50°C) | 8.0×10⁻⁵ /°C | ISO 11359 |
| Flammability UL 94 (1.5mm) | HB | IEC 60695-11-10 |
| Density | 1.19 g/cm³ | ISO 1183 |
Note: All listed figures are typical values and may vary by production batch. Complete independent qualification testing is required before mass production deployment.
Recommended Processing Conditions
| Parameter | Recommended Value |
| Processing Method | Injection Molding |
| Screw Type | 3-zone general purpose screw for engineering thermoplastics |
| Melt Temperature | 230-250°C (typical) |
| Mold Temperature | 50-80°C (typical) |
Handling and Storage Recommendations
| Storage Rules | Store in dry, cool conditions away from direct sunlight and heat sources. |
| Packaging | 25kg polyethylene bags or 500kg boxes with PE lining; other packaging on request. |
| Operation Protection | Follow standard safety practices for handling thermoplastic pellets. Use appropriate PPE during processing. |
Official Technical Documentation
| Document Type | Document Introduction | Document Request |
| TDS | CYROLITE MD 6N S000 original factory technical data sheet | Request TDS |
| COA | Batch-specific certificate of analysis | Request COA |
| Biocompatibility | USP Class VI and ISO 10993-1 documentation | Request Documentation |
Frequently Asked Questions
What is CYROLITE MD 6N S000?
CYROLITE MD 6N S000 is a high flow UV transparent medical acrylic with MVR 12, 92% light transmission, 1.49 refractive index, 96°C Vicat softening temperature, and USP Class VI biocompatibility for diagnostic applications.
What is the melt volume rate of CYROLITE MD 6N S000?
CYROLITE MD 6N S000 has an MVR of 12 cm³/10min (230°C/3.8kg), providing maximum flow characteristics for filling complex diagnostic molds.
What makes CYROLITE MD 6N S000 different from L40?
CYROLITE MD 6N S000 offers higher heat resistance (96°C Vicat vs 82°C) with MVR 12, while L40 has higher MFR (26.0) for thin-wall molding. Choose 6N S000 for applications requiring both high flow and high heat resistance in UV spectroscopy.
Does CYROLITE MD 6N S000 have high UV transmittance?
Yes. CYROLITE MD 6N S000 features exceptional ultra-violet light transmittance with 92% luminous transmittance at 3mm thickness, making it ideal for UV spectroscopy applications in diagnostic equipment.
What medical certifications does CYROLITE MD 6N S000 hold?
CYROLITE MD 6N S000 complies with United States Pharmacopeia Class VI and ISO 10993-1 biocompatibility requirements for medical diagnostic devices.
What applications is CYROLITE MD 6N S000 suitable for?
CYROLITE MD 6N S000 is ideal for diagnostic test packs, cuvettes, microfluidics, crystallography trays, and other medical devices requiring UV spectroscopy and high flow injection molding.
Related CYROLITE Products
Compare CYROLITE medical diagnostic polymers for different application requirements.
| Product | Key Feature | Flow Rate | Vicat | Transmission | Core Application |
| 6N S000 | High flow + UV + high heat | MVR 12 | 96°C | 92% | Test packs, cuvettes, microfluidics |
| L40 | Highest flow + lubricant | MFR 26.0 | 82°C | 92% | Thin-wall cuvettes, rotors |
| ZK6 | 3x impact + bonds to PVC | MFR 1.7 | 94°C | 91.5% | IV hubs, connectors, housings |
| H12 | High flow + UV transparency | MFR 7.0 | 95°C | 92% | Cuvettes, microfluidics |
Get CYROLITE MD 6N S000 Bulk Pricing and Technical Support
We supply genuine CYROLITE MD 6N S000 high flow UV diagnostic acrylic for medical diagnostic applications. Contact us for bulk pricing, sample availability, technical documents, and application support.
Request CYROLITE MD 6N S000 Technical Details
Disclaimer: All technical data on this page are for general guidance only and are not product specifications. Buyers must carry out independent trials and verify suitability before bulk ordering. Actual values may vary between production lots.
