描述
858G-116 Ruby Red is a waterborne 858G-116 Ruby Red PFA Thin Film Topcoat from Chemours‘ Teflon industrial coatings portfolio, genuinely manufactured by Chemours and imported as original product. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Chemours technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.
This 858G-116 Ruby Red PFA Topcoat is a waterborne PFA (perfluoroalkoxy) topcoat engineered as the final layer for multi‑coat systems. PFA is a melt‑processable fluoropolymer that melts and flows during baking to form nonporous, smooth, and highly durable films. These multi‑coat systems provide higher continuous use temperatures (260°C / 500°F), have a high dielectric strength, and are considered tougher than PTFE or FEP.
What distinguishes 858G-116 is its thin film capability and distinctive ruby red finish. It is specifically designed for thin film applications, with coating thickness ranging from a few microns to 200 microns. The ruby red pigmented finish provides a distinctive industrial appearance while offering superior protection against corrosion and chemical attack. The coating surface energy is extremely low, with material adhesion significantly less than uncoated surfaces. The friction coefficient is ultra-low, with static friction reduced by over 70% compared to bare metal.
The 858G-116 Ruby Red PFA Topcoat delivers exceptional chemical resistance, making it suitable for chemical processing equipment, food processing applications, semiconductor equipment, and other demanding industrial applications. As a waterborne coating, it offers low VOC emissions, making it an environmentally responsible choice for modern industrial facilities.
With regular stock availability, we support both trial orders and large‑volume bulk shipments for chemical processing, food processing, semiconductor, aerospace, and other demanding industrial applications.
Key Features of 858G-116 Ruby Red PFA Topcoat
-
Thin Film Capability – Designed for thin film applications, coating thickness from a few microns to 200 microns.
-
Ruby Red Finish – Distinctive ruby red pigmented finish for easy visual identification and consistent industrial appearance.
-
PFA High Performance – PFA provides higher continuous use temperatures (260°C / 500°F), high dielectric strength, and is tougher than PTFE or FEP.
-
Excellent Non‑Stick Release – Coating surface energy is extremely low; material adhesion is significantly less than uncoated surfaces.
-
Ultra‑Low Coefficient of Friction – Static friction reduced by over 70% compared to bare metal.
-
High Temperature Resistance – Continuous service up to 260°C (500°F) with intermittent service up to 316°C (600°F).
-
Superior Chemical Resistance – Resists most acids, bases, and solvents; excellent chemical inertness.
-
Waterborne Formulation – Low VOC emissions, environmentally friendly processing, and safer handling for operators.
-
Broad Substrate Compatibility – Can be applied to carbon steel, aluminum, stainless steel, alloy steel, brass, magnesium, as well as non‑metallic materials including glass, fiberglass, and certain rubbers and plastics.
-
Versatile Applications – Suitable for chemical processing, food processing, semiconductor, aerospace, and general industrial applications.
Typical Applications for 858G-116 Ruby Red
| Industry | Typical Components & Considerations |
|---|---|
| Chemical Processing | Reaction vessels, agitators, pipelines, pumps – resists strong acids and alkalis, ensures equipment stability and service life |
| Food Processing | Bakeware, conveyor belts, cutting tools – ensures easy release and cleaning, improves processing efficiency |
| Semiconductor Equipment | High‑purity components, circuit board baking trays – stable at high temperatures, no harmful substance release |
| Plastic & Rubber Industry | Rollers, shoe molds, rubber glove molds, tire molds – prevents sticking, extends mold life |
| Textile Industry | Rollers for yarn sizing – prevents high‑viscosity chemical slurry adhesion |
| Medical Devices | Surgical instruments, infusion tubes – reduces friction, improves durability |
| Aerospace | Aircraft engine components, fuel system piping – stable performance in extreme environments |
| Heat Exchangers | Heat exchanger surfaces – requires nonstick and corrosion protection |
| Mold & Tooling | Injection molds, rubber molds, plastic molds – release properties and extended mold life |
Material Advantages
The 858G-116 Ruby Red PFA Topcoat is a waterborne PFA topcoat that delivers:
-
Thin Film Versatility – Designed for thin film applications, coating thickness from a few microns to 200 microns, offering flexibility for various application requirements.
-
Superior Thermal Stability – Maintains performance at continuous service temperatures up to 260°C (500°F), with intermittent service up to 316°C (600°F).
-
Exceptional Nonstick Performance – Provides outstanding release properties; coating surface energy is extremely low, with material adhesion significantly less than uncoated surfaces.
-
Ultra‑Low Friction – Static friction reduced by over 70% compared to bare metal.
-
Chemical Inertness – Resists most acids, bases, and solvents; excellent chemical inertness.
-
Excellent Corrosion Resistance – Protects substrates from chemical attack and corrosion.
-
Environmental Compliance – Waterborne carrier with low VOC emissions reduces environmental impact compared to solvent‑based alternatives.
-
Broad Substrate Compatibility – Applicable to carbon steel, aluminum, stainless steel, alloy steel, brass, magnesium, as well as non‑metallic materials including glass, fiberglass, and certain rubbers and plastics.
-
Tougher than PTFE or FEP – PFA offers superior toughness and durability compared to PTFE or FEP.
Chemours, as the inventor of Teflon, brings over 80 years of fluoro‑polymer expertise, ensuring batch‑to‑batch consistency, reliable supply, and full technical support.
Typical Properties
| Property | 858G-116 Ruby Red | Unit / Remarks |
|---|---|---|
| Product Type | PFA Waterborne Thin Film Topcoat | – |
| Color | Ruby Red / 红宝石色 | – |
| Carrier | Waterborne (aqueous dispersion) | Low VOC |
| Coating System | Thin Film Topcoat（薄喷型） | Must be used with primer |
| FDA Compliance | No – Not FDA compliant per 21CFR | – |
| Max Continuous Service Temp. | 260°C (500°F) | – |
| Intermittent Service Temp. | 316°C (600°F) | – |
| Coating Thickness Range | From a few microns to 200 microns | – |
| Surface Energy | Extremely low | – |
| Coefficient of Friction | Ultra‑low – 70% lower than steel | Static friction |
| Chemical Resistance | Excellent – resists acids, alkalis, solvents | – |
| Application Method | Spray | – |
| Available Form | Liquid waterborne | Ready to spray |
| Recommended Primer | Compatible PFA/FEP primer required | – |
| Packaging | 4 kg, 5 kg, 10 kg, 20 kg pails | – |
| Shelf Life | 18-24 months | Unopened, proper storage |
Important Notes on Typical Data:
-
Values listed are typical and sourced from Chemours official data sheets. They do not constitute binding product specification.
-
Physical constants are averages only and may vary up to ±5% of the values shown.
-
Final performance depends on substrate preparation, application method, and curing conditions.
-
Chemours original TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Substrate | Carbon steel, aluminum, stainless steel, alloy steel, brass, magnesium, as well as non‑metallic materials including glass, fiberglass, and certain rubbers and plastics |
| Surface Preparation | Degrease then abrasive blasting to achieve proper surface profile for adhesion |
| Coating Preparation | Gently mix until contents are homogeneous. Set mixer speed to create a vortex while avoiding air entrapment |
| Primer Application | 858G-116 is a topcoat and must be used with a compatible PFA/FEP primer system |
| Spray Distance | 20‑30 cm from substrate |
| Coating Thickness | From a few microns to 200 microns |
| Curing | Follow Chemours recommended cure schedule for PFA topcoat systems |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight. Protect from freezing |
| Shelf Life | 18-24 months in unopened, clean, dry storage |
Critical Processing Warnings:
-
Primer Required: 858G-116 is a topcoat and must be used with a compatible PFA/FEP primer system. Unless explicitly noted, most Teflon industrial coatings require primer application.
-
Surface Preparation: Proper surface preparation is critical for adhesion. Use organic solvents to dissolve grease and heat to approximately 400°C to volatilize, then grit blast to roughen the surface.
-
Thin Film Application: Designed for thin film applications, coating thickness from a few microns to 200 microns.
-
Curing: Cure time and temperature depend on primer selection and part mass. Always verify with test pieces.
-
Freeze Protection: Waterborne products must be protected from freezing.
-
Shelf Life: 18-24 months in unopened, clean, dry storage.
Related Products
-
Explore Teflon PTFE Coatings – Browse all Teflon industrial coating options
-
850G-300 Clear – Teflon PTFE Acid Primer – Acid primer for PTFE, PFA, and FEP topcoat systems
-
953G-506 Dark Violet – FEP Waterborne Primer – FEP primer for multi-coat food contact systems
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| Chemours Official TDS | Complete physical, thermal, and mechanical properties of 858G-116 Ruby Red, issued by Chemours original |
| Chemours Official SDS | GHS‑compliant chemical safety documentation, original Chemours document |
| Chemours Distributor Authorization Certificate | Proof of our authorized‑distributor qualification for Chemours Teflon series, available upon request |
| COA (Certificate of Analysis) | Batch‑specific quality certification |
| Application & Usage Guide | Detailed application guidance for PFA thin film topcoat systems |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (858G-116 Ruby Red) and document type you require.
FAQ
Q1: What is 858G-116 Ruby Red and what is it used for?
A: 858G-116 Ruby Red is a waterborne PFA thin film topcoat from the Teflon industrial coatings portfolio. It features a distinctive ruby red finish and is designed for thin film applications with coating thickness ranging from a few microns to 200 microns. It is widely used in chemical processing equipment, food processing, semiconductor equipment, plastic and rubber industry, textile industry, medical devices, aerospace, and general industrial applications.
Q2: Is 858G-116 Ruby Red FDA compliant?
A: No. 858G-116 is not FDA compliant for food contact applications per 21CFR. It is suitable for industrial and non‑food contact applications.
Q3: Is 858G-116 suitable for thin film applications?
A: Yes. 858G-116 is specifically designed for thin film applications, with coating thickness ranging from a few microns to 200 microns.
Q4: Is primer required for 858G-116 Ruby Red?
A: Yes. 858G-116 is a topcoat and must be used with a compatible PFA/FEP primer system.
Q5: What is the temperature range of 858G-116 Ruby Red?
A: Continuous service up to 260°C (500°F) with intermittent service up to 316°C (600°F).
Q6: What is the difference between 858G-116 and 858G-917?
A: Both are Ruby Red PFA topcoats. 858G-116 is a thin film version with coating thickness from a few microns to 200 microns, while 858G-917 is a high build / thick film version with single coat up to 10 mils (250 µm) and total film build up to 40 mils (approx. 1,000 µm).
Q7: What substrates can 858G-116 Ruby Red be applied to?
A: It can be applied to carbon steel, aluminum, stainless steel, alloy steel, brass, magnesium, as well as non‑metallic materials including glass, fiberglass, and certain rubbers and plastics.
Q8: What is the recommended spray distance for 858G-116 Ruby Red?
A: The recommended spray distance is 20‑30 cm from the substrate.
Q9: What is the shelf life of 858G-116 Ruby Red?
A: The shelf life is 18-24 months in unopened, proper storage. Protect from freezing.
Q10: What is the lead time for orders?
A: Regular orders ship within 7‑10 working days after payment confirmation. Large‑volume or urgent orders can be negotiated.
CTA (Call to Action)
Ready to order 858G-116 Ruby Red?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (chemical processing, food processing, semiconductor, aerospace, etc.)
-
Required coating thickness (from a few microns to 200 microns)
-
Primer requirement
-
Document requirement (TDS, SDS, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample‑shipping freight.
-
If bulk‑product performance deviates from sample reference, Chemours official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom‑right chat widget to speak directly with our team
After‑Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality‑related claims must be submitted within 7 working‑days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim‑document preparation. |
| Technical Support | Remote technical guidance available. On‑site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original Chemours typical values for 858G-116 Ruby Red. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on substrate preparation, application method, and curing conditions. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for coating failure caused by improper application or improper usage. Always reference the latest Chemours official TDS of 858G-116 Ruby Red as the definitive specification.
