描述
532-6310 Clear is an ETFE powder topcoat from Chemours‘ Teflon industrial coatings portfolio, genuinely manufactured by Chemours and imported as original product. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Chemours technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.
532-6310 Clear is an ETFE (ethylene tetrafluoroethylene) powder topcoat specifically engineered for high build / thick film applications. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene. Although not fully fluorinated, ETFE has excellent chemical resistance and is the toughest of the fluoroplastics. This resin is extremely tough, abrasion resistant, and has excellent chemical resistance. ETFE is also an excellent electrical insulator and has good nonstick and low friction properties.
The 532-631x product line is designed for high-build topcoats, has outstanding resistance to heat, and is specially formulated to resist sagging in thick films. The transparent finish preserves the appearance of the underlying substrate while delivering superior protection against chemical corrosion. The coating sintered film is very dense and nonporous, providing excellent chemical resistance.
532-6310 is FDA compliant for food contact applications per 21CFR when used in combination with a compliant layer and properly cured, making it suitable for food processing equipment, industrial bakeware, and other food‑contact uses. As a powder coating, 532-6310 contains zero VOCs, offering significant environmental and worker safety advantages.
With regular stock availability, we support both trial orders and large‑volume bulk shipments for chemical processing, semiconductor equipment, food processing, pharmaceutical manufacturing, and other demanding industrial applications.
Key Features of 532-6310 Clear ETFE Powder Topcoat
-
High Build / Thick Film Capability – Single coat 4.0-6.0 mil (102-152 µm); maximum total film build up to 25.0 mils (approx. 635 µm). Film thicknesses up to 1,000 µm can be achieved for a highly durable finish.
-
Sag Resistance – Specially formulated to resist sagging in thick films, ensuring uniform coating even at high film builds.
-
Extremely Tough & Abrasion Resistant – ETFE is the toughest of the fluoroplastics, providing superior mechanical strength and wear resistance.
-
Excellent Chemical Resistance – Sintered coating forms a very dense, nonporous film with outstanding resistance to chemical corrosion.
-
FDA Food Contact Compliant – FDA compliant for food contact applications per 21CFR when used with a compliant layer and properly cured.
-
High Temperature Resistance – Continuous service up to 149°C (300°F) with intermittent service up to 302°C (575°F).
-
Good Nonstick & Low Friction Properties – Provides good nonstick release and low friction characteristics.
-
Excellent Dielectric Strength – ETFE is an excellent electrical insulator, suitable for electrical and semiconductor applications.
-
Zero VOC Formulation – Powder coating contains 0 g/kg VOC, offering significant environmental and worker safety advantages.
-
Broad Substrate Compatibility – Compatible with carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
-
System Compatibility – Interchangeable and compatible with liquid and powder topcoats.
Typical Applications for 532-6310 Clear
| Industry | Typical Components & Considerations |
|---|---|
| Chemical Processing | Heat exchangers, chemical storage tanks, reaction vessels, agitators, pipelines, pumps, valves – resists strong acids and alkalis |
| Semiconductor Equipment | High‑purity components, circuit board baking trays – stable at high temperatures, no harmful substance release |
| Food Processing | Food processing equipment, bakeware, conveyor belts – FDA compliant applications |
| Pharmaceutical Manufacturing | Pharmaceutical production equipment – requires high purity and chemical resistance |
| Power & Energy | Power generation equipment – chemical resistance and high dielectric strength |
| Automatic Welding Equipment | Welding fixtures and tooling – spatter resistance and easy cleaning |
| Mold & Tooling | Injection molds, rubber molds, plastic molds – release properties and extended mold life |
| Automotive Components | Carburetor shafts, linkage devices, cruise control parts – dry lubrication and corrosion resistance |
| Aerospace | Aerospace fasteners, cryogenic components – wide temperature range and high build durability |
| Valve & Pump Components | Industrial valves, pumps – corrosion protection and thick film durability |
| General Industrial | Components requiring ETFE nonstick properties with high build, transparent finish |
Material Advantages
532-6310 Clear ETFE Powder Topcoat delivers:
-
High Build Capability – Supports total film thickness up to 25.0 mils (approx. 635 µm) , providing enhanced abrasion resistance, corrosion protection, and extended service life. Single coat film build of 4.0-6.0 mil (102-152 µm) enables efficient application.
-
Sag Resistance in Thick Films – Specially formulated to resist sagging, ensuring uniform coating quality even at maximum film builds.
-
Exceptional Toughness – ETFE is the toughest of the fluoroplastics, offering superior impact resistance and mechanical strength compared to PTFE, FEP, or PFA.
-
Excellent Chemical Resistance – Forms a very dense, nonporous film with outstanding resistance to chemical corrosion.
-
Abrasion Resistance – Extremely tough and wear-resistant, extending service life in demanding applications.
-
Food Safety – FDA compliant for food contact per 21CFR when used with a compliant layer, enabling use in food processing and food‑contact applications.
-
Thermal Stability – Maintains performance at continuous service temperatures up to 149°C (300°F), with intermittent service up to 302°C (575°F).
-
High Dielectric Strength – Excellent electrical insulation properties for electrical and semiconductor applications.
-
Zero VOC – Powder formulation contains no VOCs, offering significant environmental and worker safety advantages.
-
Good Nonstick & Low Friction – Provides good release properties and low friction characteristics.
-
Broad Substrate Compatibility – Applicable to carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
-
System Flexibility – Interchangeable and compatible with liquid and powder topcoats for multi‑coat systems.
Chemours, as the inventor of Teflon, brings over 80 years of fluoro‑polymer expertise, ensuring batch‑to‑batch consistency, reliable supply, and full technical support.
Typical Properties
| Property | 532-6310 Clear | Unit / Remarks |
|---|---|---|
| Product Type | ETFE High Build Powder Topcoat | – |
| Color | Clear / Transparent | 透明无色 |
| Form | Powder | Zero VOC |
| Coating System | Topcoat – High Build | Must be used with primer |
| FDA Compliance | Yes – Food Contact per 21CFR | When properly cured |
| CAS Number | 25038-71-5 | – |
| Max Continuous Service Temp. | 149°C (300°F) | – |
| Intermittent Service Temp. | 302°C (575°F) | – |
| Cure Temperature | 302°C (575°F) | – |
| Single Coat Film Build | 4.0 – 6.0 mil (102 – 152 µm) | – |
| Max Total Film Build | 25.0 mil (approx. 635 µm) | High Build |
| Chemical Resistance | Excellent – resists acids, alkalis, solvents | – |
| Abrasion Resistance | Excellent – extremely tough | – |
| Dielectric Strength | Very good | – |
| Application Method | Electrostatic Spray | – |
| Packaging | 4 kg, 5 kg, 10 kg, 20 kg pails / bags | – |
| Shelf Life | 18 months | Unopened, proper storage |
Important Notes on Typical Data:
-
Values listed are typical and sourced from Chemours official data sheets. They do not constitute binding product specification.
-
Physical constants are averages only and may vary up to ±5% of the values shown.
-
Final performance depends on substrate preparation, application method, and curing conditions.
-
Chemours original TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Substrate | Carbon steel, aluminum, stainless steel, steel alloys, brass, magnesium |
| Surface Preparation | Remove all grease and contaminants. Use organic solvents to dissolve grease and heat to approximately 400°C to volatilize, then grit blast to roughen the surface |
| Powder Preparation | Homogenize powder before opening bag |
| Screening | Screen through appropriate mesh to prevent application defects |
| Primer Application | Primer required – 532-6310 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher |
| Application Method | Apply via electrostatic spray (powder gun) |
| Single Coat DFT | 4.0 – 6.0 mil (102 – 152 µm) |
| Max Total DFT | 25.0 mil (approx. 635 µm) |
| Curing | 302°C (575°F) ; cure time depends on part mass and film thickness |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight |
| Shelf Life | 18 months in unopened, clean, dry storage |
Critical Processing Warnings:
-
Primer Required: 532-6310 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher.
-
Do Not Apply as Single Coat: This topcoat is designed for use with primer systems and should not be applied as a single coat system.
-
Surface Preparation: Proper surface preparation is critical for adhesion. Remove all grease and contaminants from the surface.
-
High Build Application: Specially formulated to resist sagging in thick films. Single coat 4.0-6.0 mil (102-152 µm), max total 25.0 mil (635 µm).
-
Curing: Cure time and temperature depend on part mass and oven characteristics. Always verify with test pieces.
-
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight.
-
Shelf Life: 18 months in unopened, clean, dry storage.
Related Products
-
Explore Teflon ETFE Coatings – Browse all Teflon ETFE industrial coating options
-
532-6200 White – ETFE Ultrasmooth Powder Topcoat – White version for ultra-smooth topcoat applications
-
532-6210 Clear – ETFE Ultrasmooth Powder Topcoat – Clear version for ultra-smooth topcoat applications
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| Chemours Official TDS | Complete physical, thermal, and mechanical properties of 532-6310 Clear, issued by Chemours original |
| Chemours Official SDS | GHS‑compliant chemical safety documentation, original Chemours document |
| Chemours Distributor Authorization Certificate | Proof of our authorized‑distributor qualification for Chemours Teflon series, available upon request |
| FDA Compliance Declaration | FDA food contact compliance statement per 21CFR |
| COA (Certificate of Analysis) | Batch‑specific quality certification |
| Application & Usage Guide | Detailed application guidance for ETFE high build powder coating systems |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (532-6310 Clear) and document type you require.
FAQ
Q1: What is 532-6310 Clear and what is it used for?
A: 532-6310 Clear is an ETFE (ethylene tetrafluoroethylene) powder topcoat from the Teflon industrial coatings portfolio. It is specifically designed for high build / thick film applications with single coat 4.0-6.0 mil (102-152 µm) and max total film build up to 25.0 mils (approx. 635 µm) . It is widely used in chemical processing equipment, semiconductor equipment, food processing, pharmaceutical manufacturing, power generation, and general industrial applications.
Q2: Is 532-6310 Clear FDA compliant?
A: Yes. 532-6310 is FDA compliant for food contact applications per 21CFR when used in combination with a compliant layer and properly cured.
Q3: What makes 532-6310 different from other ETFE powders?
A: 532-6310 is part of the 532-631x product line designed for high-build topcoats. It offers single coat film build of 4.0-6.0 mil (102-152 µm) and max total film build of 25.0 mils (635 µm) , and is specially formulated to resist sagging in thick films.
Q4: What is the difference between 532-6310 and 532-6210?
A: 532-6310 is a high build topcoat with single coat 4.0-6.0 mil and max total 25.0 mil, while 532-6210 is an ultrasmooth topcoat with single coat 2.0-3.0 mil and max total 6.0 mil. 532-6310 has a higher cure temperature (302°C / 575°F vs 288°C / 550°F) and is designed for thick film applications.
Q5: Is primer required for 532-6310 Clear?
A: Yes. 532-6310 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher.
Q6: What is the temperature range of 532-6310 Clear?
A: Continuous service up to 149°C (300°F) with intermittent service up to 302°C (575°F).
Q7: What is the recommended film build for 532-6310 Clear?
A: Single coat 4.0-6.0 mil (102-152 µm); maximum total film build 25.0 mil (approx. 635 µm) . Film thicknesses up to 1,000 µm can be achieved.
Q8: What substrates can 532-6310 Clear be applied to?
A: It can be applied to carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
Q9: Is 532-6310 Clear PFA or ETFE?
A: 532-6310 is ETFE (ethylene tetrafluoroethylene), not PFA. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene and is the toughest among fluoroplastics.
Q10: What is the CAS number of 532-6310 Clear?
A: The CAS number is 25038-71-5.
Q11: What is the shelf life of 532-6310 Clear?
A: The shelf life is 18 months in unopened, proper storage.
Q12: What is the lead time for orders?
A: Regular orders ship within 7‑10 working days after payment confirmation. Large‑volume or urgent orders can be negotiated.
CTA (Call to Action)
Ready to order 532-6310 Clear?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (chemical processing, semiconductor, food processing, pharmaceutical, power generation, etc.)
-
Required total film thickness (up to 25.0 mils)
-
Primer requirement
-
Document requirement (TDS, SDS, FDA compliance, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample‑shipping freight.
-
If bulk‑product performance deviates from sample reference, Chemours official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom‑right chat widget to speak directly with our team
After‑Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality‑related claims must be submitted within 7 working‑days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim‑document preparation. |
| Technical Support | Remote technical guidance available. On‑site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates (e.g., FDA) on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original Chemours typical values for 532-6310 Clear. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on substrate preparation, application method, and curing conditions. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for coating failure caused by improper application or improper usage. Always reference the latest Chemours official TDS of 532-6310 Clear as the definitive specification.
