532-6210 Clear is an ETFE powder topcoat from Chemours‘ Teflon industrial coatings portfolio, genuinely manufactured by Chemours and imported as original product. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Chemours technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.
532-6210 Clear is an ETFE (ethylene tetrafluoroethylene) powder topcoat specifically engineered for ultra-smooth, clear surface finishes. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene. Although not fully fluorinated, ETFE has excellent chemical resistance and is the toughest of the fluoroplastics. This resin is extremely tough, abrasion resistant, and has excellent chemical resistance. ETFE is also an excellent electrical insulator and has good nonstick and low friction properties.
The 532-62xx product line is specifically designed for ultra-smooth topcoats. The transparent finish preserves the appearance of the underlying substrate while delivering superior protection against chemical corrosion. The coating sintered film is very dense and nonporous, providing excellent chemical resistance. Finishing with 532-6210 gives a very smooth glossy appearance to the system.
532-6210 is FDA compliant for food contact applications per 21CFR when used in combination with a compliant layer and properly cured, making it suitable for food processing equipment, industrial bakeware, and other food‑contact uses. As a powder coating, 532-6210 contains zero VOCs, offering significant environmental and worker safety advantages.
With regular stock availability, we support both trial orders and large‑volume bulk shipments for chemical processing, semiconductor equipment, food processing, pharmaceutical manufacturing, and other demanding industrial applications.
Key Features of 532-6210 Clear ETFE Powder Topcoat
-
Ultrasmooth Transparent Finish – Specifically designed for ultra-smooth topcoat applications; 532-62xx product line delivers exceptionally smooth, glossy, clear surface finishes.
-
Extremely Tough & Abrasion Resistant – ETFE is the toughest of the fluoroplastics, providing superior mechanical strength and wear resistance.
-
Excellent Chemical Resistance – Sintered coating forms a very dense, nonporous film with outstanding resistance to chemical corrosion.
-
FDA Food Contact Compliant – FDA compliant for food contact applications per 21CFR when used with a compliant layer and properly cured.
-
High Temperature Resistance – Continuous service up to 150°C (300°F) with intermittent service up to 316°C (600°F).
-
Good Nonstick & Low Friction Properties – Provides good nonstick release and low friction characteristics.
-
Excellent Dielectric Strength – ETFE is an excellent electrical insulator, suitable for electrical and semiconductor applications.
-
Zero VOC Formulation – Powder coating contains 0 g/kg VOC, offering significant environmental and worker safety advantages.
-
Flexible Film Build – Single coat 2.0-3.0 mil (50-76 µm), total film build up to 6.0 mil (approx. 152 µm).
-
Broad Substrate Compatibility – Compatible with carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
-
System Compatibility – Interchangeable and compatible with liquid and powder topcoats.
Typical Applications for 532-6210 Clear
| Industry | Typical Components & Considerations |
|---|---|
| Food Processing | Bakeware, conveyor belts, cutting tools – FDA compliant, ensures easy release and cleaning |
| Chemical Processing | Reaction vessels, agitators, pipelines, pumps, valves – resists strong acids and alkalis |
| Semiconductor Equipment | High‑purity components, circuit board baking trays – stable at high temperatures, no harmful substance release |
| Pharmaceutical Manufacturing | Pharmaceutical production equipment – requires high purity and chemical resistance |
| Plastic & Rubber Industry | Rollers, shoe molds, rubber glove molds, tire molds – prevents sticking, extends mold life |
| Textile Industry | Rollers for yarn sizing – prevents high‑viscosity chemical slurry adhesion |
| Medical Devices | Surgical instruments, infusion tubes – reduces friction, improves durability |
| Aerospace | Aircraft engine components, fuel system piping – stable performance in extreme environments |
| Power & Energy | Power generation equipment – chemical resistance and high dielectric strength |
| Valve & Pump Components | Industrial valves, pumps – corrosion protection and smooth surface finish |
| General Industrial | Components requiring ETFE nonstick properties with ultra-smooth, clear finish |
Material Advantages
532-6210 Clear ETFE Powder Topcoat delivers:
-
Ultrasmooth Transparent Surface Finish – The 532-62xx product line is specifically designed for ultra-smooth topcoats, providing superior surface quality with a glossy, clear appearance for applications where smoothness and transparency are critical.
-
Exceptional Toughness – ETFE is the toughest of the fluoroplastics, offering superior impact resistance and mechanical strength compared to PTFE, FEP, or PFA.
-
Excellent Chemical Resistance – Forms a very dense, nonporous film with outstanding resistance to chemical corrosion.
-
Abrasion Resistance – Extremely tough and wear-resistant, extending service life in demanding applications.
-
Food Safety – FDA compliant for food contact per 21CFR when used with a compliant layer, enabling use in food processing and food‑contact applications.
-
Thermal Stability – Maintains performance at continuous service temperatures up to 150°C (300°F), with intermittent service up to 316°C (600°F).
-
High Dielectric Strength – Excellent electrical insulation properties for electrical and semiconductor applications.
-
Zero VOC – Powder formulation contains no VOCs, offering significant environmental and worker safety advantages.
-
Good Nonstick & Low Friction – Provides good release properties and low friction characteristics.
-
Broad Substrate Compatibility – Applicable to carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
-
System Flexibility – Interchangeable and compatible with liquid and powder topcoats for multi‑coat systems.
Chemours, as the inventor of Teflon, brings over 80 years of fluoro‑polymer expertise, ensuring batch‑to‑batch consistency, reliable supply, and full technical support.
Typical Properties
| Property | 532-6210 Clear | Unit / Remarks |
|---|---|---|
| Product Type | ETFE Ultrasmooth Powder Topcoat | – |
| Color | Clear / Transparent | 无色透明 |
| Form | Powder | Zero VOC |
| Coating System | Topcoat – Ultrasmooth | Must be used with primer |
| FDA Compliance | Yes – Food Contact per 21CFR | When properly cured |
| CAS Number | 25038-71-5 | – |
| Coverage | 22.0 m²/kg (110 ft²/gal) | – |
| Average Particle Size | 20-40 μm | Laser diffraction |
| Bulk Density | 55-85 g/100 cc | – |
| Density | 1.73 kg/L (14.44 lbs/gal) | – |
| Max Continuous Service Temp. | 150°C (300°F) | – |
| Intermittent Service Temp. | 316°C (600°F) | – |
| Cure Temperature | 270-290°C (520-555°F) | 20-30 minutes |
| Single Coat Film Build | 2.0 – 3.0 mil (50 – 76 µm) | – |
| Recommended DFT per Coat | Up to 100 µm (3.9 mil) | – |
| Max Total Film Build | 6.0 mil (approx. 152 µm) | – |
| Recommended Total DFT | Up to 250 µm (9.8 mil) | – |
| Chemical Resistance | Excellent – resists acids, alkalis, solvents | – |
| Abrasion Resistance | Excellent – extremely tough | – |
| Dielectric Strength | Excellent | – |
| Application Method | Electrostatic Spray / Fluidized Bed | – |
| Recommended Primer | Liquid 699N-129, Powder 532G-6405 | – |
| Packaging | 4 kg, 5 kg, 10 kg, 20 kg pails / bags | – |
| Shelf Life | 18 months | Unopened, proper storage |
Important Notes on Typical Data:
-
Values listed are typical and sourced from Chemours official data sheets. They do not constitute binding product specification.
-
Physical constants are averages only and may vary up to ±5% of the values shown.
-
Theoretical coverage at dry film thickness of 25 μm (1.0 mil) based on 100% application efficiency. It does not take normal production losses into account.
-
Final performance depends on substrate preparation, application method, and curing conditions.
-
Chemours original TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Substrate | Carbon steel, aluminum, stainless steel, steel alloys, brass, magnesium |
| Surface Preparation | Remove all grease and contaminants. Use organic solvents to dissolve grease and heat to approximately 400°C to volatilize, then grit blast to roughen the surface |
| Powder Preparation | Homogenize powder before opening bag |
| Screening | 30 mesh (approx. 550 μm) stainless steel or nylon. Insufficient screening can result in application defects |
| Primer Application | Recommended primer: Liquid 699N-129 or Powder 532G-6405. If powder primer is used with a complete powder system, efficiency is higher |
| Application Method | Use fluidized bed with or without vibration system (depends on powder quantity and particle size). On flat and/or conductive parts, high voltage and higher amperage can be used. On insulated and complex parts, amperage should be lowered |
| Recommended General Settings | • Product supply: 30–50% • Air carrier: 3.0 nm³/hr • Fluidization bed: 0.3 nm³/hr • Electrode fluidization: Flat jet 0.2 nm³/hr • Amperage: 10 μA • Voltage: 60 kV |
| Spray Distance | 20-30 cm from substrate |
| Single Coat DFT | 2.0 – 3.0 mil (50 – 76 µm) |
| Recommended DFT per Coat | Up to 100 µm (3.9 mil) |
| Max Total DFT | 6.0 mil (approx. 152 µm) |
| Recommended Total DFT | Up to 250 µm (9.8 mil) |
| Drying (Metal Temp.) | Powders can be applied dry on wet. Full coating system should be dried before final cure |
| Curing | 20-30 minutes at 270-290°C (520-555°F) . Prolonged exposure at or above the maximum bake temperature can affect performance |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight |
| Shelf Life | 18 months in unopened, clean, dry storage |
Critical Processing Warnings:
-
Primer Required: 532-6210 is a topcoat and must be used with a compatible primer system (e.g., Liquid 699N-129 or Powder 532G-6405). If powder primer is used with a complete powder system, efficiency is higher.
-
Do Not Apply as Single Coat: This topcoat is designed for use with primer systems and should not be applied as a single coat system.
-
Surface Preparation: Proper surface preparation is critical for adhesion. Remove all grease and contaminants from the surface.
-
Ultrasmooth Finish: The 532-62xx product line is specifically designed for ultra-smooth topcoats. Ensure proper application parameters for optimal smoothness.
-
Screening: Insufficient screening can result in application defects.
-
Curing: Cure time and temperature depend on part mass and oven characteristics. Always verify with test pieces.
-
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight.
-
Shelf Life: 18 months in unopened, clean, dry storage.
