描述
532-6200 White is an ETFE powder topcoat from Chemours‘ Teflon industrial coatings portfolio, genuinely manufactured by Chemours and imported as original product. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Chemours technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.
532-6200 White is an ETFE (ethylene tetrafluoroethylene) powder topcoat specifically engineered for ultra-smooth surface finishes. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene. Although not fully fluorinated, ETFE has excellent chemical resistance and is the toughest of the fluoroplastics. This resin is extremely tough, abrasion resistant, and has excellent chemical resistance. ETFE is also an excellent electrical insulator and has good nonstick and low friction properties.
The 532-62xx product line is designed for ultra-smooth topcoats. The white pigmented finish provides a clean, professional industrial appearance while delivering superior protection against chemical corrosion. The coating sintered film is very dense and nonporous, providing excellent chemical resistance.
532-6200 is FDA compliant for food contact applications per 21CFR when used in combination with a compliant layer and properly cured, making it suitable for food processing equipment, industrial bakeware, and other food‑contact uses. As a powder coating, 532-6200 contains zero VOCs, offering significant environmental and worker safety advantages.
With regular stock availability, we support both trial orders and large‑volume bulk shipments for chemical processing, semiconductor equipment, food processing, pharmaceutical manufacturing, and other demanding industrial applications.
Key Features of 532-6200 White ETFE Powder Topcoat
-
Ultrasmooth Finish – Specifically designed for ultra-smooth topcoat applications; 532-62xx product line delivers exceptionally smooth surface finishes.
-
Extremely Tough & Abrasion Resistant – ETFE is the toughest of the fluoroplastics, providing superior mechanical strength and wear resistance.
-
Excellent Chemical Resistance – Sintered coating forms a very dense, nonporous film with outstanding resistance to chemical corrosion.
-
FDA Food Contact Compliant – FDA compliant for food contact applications per 21CFR when used with a compliant layer and properly cured.
-
High Temperature Resistance – Continuous service up to 149°C (300°F) with intermittent service up to 316°C (600°F).
-
Good Nonstick & Low Friction Properties – Provides good nonstick release and low friction characteristics.
-
Excellent Dielectric Strength – ETFE is an excellent electrical insulator, suitable for electrical and semiconductor applications.
-
Zero VOC Formulation – Powder coating contains 0 g/kg VOC, offering significant environmental and worker safety advantages.
-
Flexible Film Build – Single coat 2.0-3.0 mil (50-76 µm), total film build up to 6.0 mil (approx. 152 µm).
-
Broad Substrate Compatibility – Compatible with carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
-
System Compatibility – Interchangeable and compatible with liquid and powder topcoats.
Typical Applications for 532-6200 White
| Industry | Typical Components & Considerations |
|---|---|
| Food Processing | Bakeware, conveyor belts, cutting tools – FDA compliant, ensures easy release and cleaning |
| Chemical Processing | Reaction vessels, agitators, pipelines, pumps, valves – resists strong acids and alkalis |
| Semiconductor Equipment | High‑purity components, circuit board baking trays – stable at high temperatures, no harmful substance release |
| Pharmaceutical Manufacturing | Pharmaceutical production equipment – requires high purity and chemical resistance |
| Plastic & Rubber Industry | Rollers, shoe molds, rubber glove molds, tire molds – prevents sticking, extends mold life |
| Textile Industry | Rollers for yarn sizing – prevents high‑viscosity chemical slurry adhesion |
| Medical Devices | Surgical instruments, infusion tubes – reduces friction, improves durability |
| Aerospace | Aircraft engine components, fuel system piping – stable performance in extreme environments |
| Power & Energy | Power generation equipment – chemical resistance and high dielectric strength |
| Valve & Pump Components | Industrial valves, pumps – corrosion protection and smooth surface finish |
| General Industrial | Components requiring ETFE nonstick properties with ultra-smooth, white finish |
Material Advantages
532-6200 White ETFE Powder Topcoat delivers:
-
Ultrasmooth Surface Finish – The 532-62xx product line is specifically designed for ultra-smooth topcoats, providing superior surface quality for applications where smoothness is critical.
-
Exceptional Toughness – ETFE is the toughest of the fluoroplastics, offering superior impact resistance and mechanical strength compared to PTFE, FEP, or PFA.
-
Excellent Chemical Resistance – Forms a very dense, nonporous film with outstanding resistance to chemical corrosion.
-
Abrasion Resistance – Extremely tough and wear-resistant, extending service life in demanding applications.
-
Food Safety – FDA compliant for food contact per 21CFR when used with a compliant layer, enabling use in food processing and food‑contact applications.
-
Thermal Stability – Maintains performance at continuous service temperatures up to 149°C (300°F), with intermittent service up to 316°C (600°F).
-
High Dielectric Strength – Excellent electrical insulation properties for electrical and semiconductor applications.
-
Zero VOC – Powder formulation contains no VOCs, offering significant environmental and worker safety advantages.
-
Good Nonstick & Low Friction – Provides good release properties and low friction characteristics.
-
Broad Substrate Compatibility – Applicable to carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
-
System Flexibility – Interchangeable and compatible with liquid and powder topcoats for multi‑coat systems.
Chemours, as the inventor of Teflon, brings over 80 years of fluoro‑polymer expertise, ensuring batch‑to‑batch consistency, reliable supply, and full technical support.
Typical Properties
| Property | 532-6200 White | Unit / Remarks |
|---|---|---|
| Product Type | ETFE Ultrasmooth Powder Topcoat | – |
| Color | White | – |
| Form | Powder | Zero VOC |
| Coating System | Topcoat – Ultrasmooth | Must be used with primer |
| FDA Compliance | Yes – Food Contact per 21CFR | When properly cured |
| CAS Number | 25038-71-5 | – |
| Max Continuous Service Temp. | 149°C (300°F) | – |
| Intermittent Service Temp. | 316°C (600°F) | – |
| Cure Temperature | 288°C (550°F) | – |
| Single Coat Film Build | 2.0 – 3.0 mil (50 – 76 µm) | – |
| Recommended DFT per Coat | Up to 100 µm (3.9 mil) | – |
| Max Total Film Build | 6.0 mil (approx. 152 µm) | – |
| Total Recommended DFT | Up to 250 µm (9.8 mil) | – |
| Chemical Resistance | Excellent – resists acids, alkalis, solvents | – |
| Abrasion Resistance | Excellent – extremely tough | – |
| Dielectric Strength | Excellent | – |
| Application Method | Electrostatic Spray | – |
| Packaging | 4 kg, 5 kg, 10 kg, 20 kg pails / bags | – |
| Shelf Life | 18 months | Unopened, proper storage |
Important Notes on Typical Data:
-
Values listed are typical and sourced from Chemours official data sheets. They do not constitute binding product specification.
-
Physical constants are averages only and may vary up to ±5% of the values shown.
-
Final performance depends on substrate preparation, application method, and curing conditions.
-
Chemours original TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Substrate | Carbon steel, aluminum, stainless steel, steel alloys, brass, magnesium |
| Surface Preparation | Remove all grease and contaminants. Use organic solvents to dissolve grease and heat to approximately 400°C to volatilize, then grit blast to roughen the surface |
| Powder Preparation | Homogenize powder before opening bag |
| Screening | Screen through appropriate mesh to prevent application defects |
| Primer Application | Primer required – 532-6200 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher |
| Topcoat Application | Apply via electrostatic spray (powder gun) |
| Spray Distance | 20-30 cm from substrate |
| Single Coat DFT | 2.0 – 3.0 mil (50 – 76 µm) |
| Recommended DFT per Coat | Up to 100 µm (3.9 mil) |
| Max Total DFT | 6.0 mil (approx. 152 µm) |
| Total Recommended DFT | Up to 250 µm (9.8 mil) |
| Curing | 288°C (550°F); cure time depends on part mass and film thickness |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight |
| Shelf Life | 18 months in unopened, clean, dry storage |
Critical Processing Warnings:
-
Primer Required: 532-6200 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher.
-
Do Not Apply as Single Coat: This topcoat is designed for use with primer systems and should not be applied as a single coat system.
-
Surface Preparation: Proper surface preparation is critical for adhesion. Remove all grease and contaminants from the surface.
-
Ultrasmooth Finish: The 532-62xx product line is specifically designed for ultra-smooth topcoats. Ensure proper application parameters for optimal smoothness.
-
Curing: Cure time and temperature depend on part mass and oven characteristics. Always verify with test pieces.
-
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight.
-
Shelf Life: 18 months in unopened, clean, dry storage.
Related Products
-
Explore Teflon ETFE Coatings – Browse all Teflon ETFE industrial coating options
-
Explore Teflon PTFE Coatings – Browse all Teflon PTFE industrial coating options
-
850G-300 Clear – Teflon PTFE Acid Primer – Acid primer for PTFE, PFA, and FEP topcoat systems
-
953G-506 Dark Violet – FEP Waterborne Primer – FEP primer for multi-coat food contact systems
-
About Our Company – Learn more about our supply capabilities and quality assurance
External Reference
For authoritative information, please refer to the following official resources:
-
Chemours Official Website – Corporate headquarters and product portfolio overview
-
Teflon Industrial Coatings Product Center – Official technical literature and application guides
Technical Documents
| Document Type | Description & Source |
|---|---|
| Chemours Official TDS | Complete physical, thermal, and mechanical properties of 532-6200 White, issued by Chemours original |
| Chemours Official SDS | GHS‑compliant chemical safety documentation, original Chemours document |
| Chemours Distributor Authorization Certificate | Proof of our authorized‑distributor qualification for Chemours Teflon series, available upon request |
| FDA Compliance Declaration | FDA food contact compliance statement per 21CFR |
| COA (Certificate of Analysis) | Batch‑specific quality certification |
| Application & Usage Guide | Detailed application guidance for ETFE powder coating systems |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (532-6200 White) and document type you require.
FAQ
Q1: What is 532-6200 White and what is it used for?
A: 532-6200 White is an ETFE (ethylene tetrafluoroethylene) powder topcoat from the Teflon industrial coatings portfolio. It is specifically designed for ultra-smooth surface finishes and is the toughest of the fluoroplastics. It is widely used in chemical processing equipment, semiconductor equipment, food processing, pharmaceutical manufacturing, aerospace, and general industrial applications.
Q2: Is 532-6200 White FDA compliant?
A: Yes. 532-6200 is FDA compliant for food contact applications per 21CFR when used in combination with a compliant layer and properly cured.
Q3: What makes 532-6200 different from other ETFE powders?
A: 532-6200 is part of the 532-62xx product line designed for ultra-smooth topcoats. It provides exceptionally smooth surface finishes while maintaining the toughness, abrasion resistance, and chemical resistance of ETFE.
Q4: Is primer required for 532-6200 White?
A: Yes. 532-6200 is a topcoat and must be used with a compatible primer system.
Q5: What is the temperature range of 532-6200 White?
A: Continuous service up to 149°C (300°F) with intermittent service up to 316°C (600°F).
Q6: What is the recommended film build for 532-6200 White?
A: Single coat 2.0-3.0 mil (50-76 µm); recommended DFT per coat up to 100 µm (3.9 mil); total recommended DFT up to 250 µm (9.8 mil); max total film build 6.0 mil (approx. 152 µm).
Q7: What substrates can 532-6200 White be applied to?
A: It can be applied to carbon steel, aluminum, stainless steel, steel alloys, brass, and magnesium.
Q8: Is 532-6200 White PFA or ETFE?
A: 532-6200 is ETFE (ethylene tetrafluoroethylene), not PFA. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene and is the toughest among fluoroplastics.
Q9: What is the CAS number of 532-6200 White?
A: The CAS number is 25038-71-5.
Q10: What is the shelf life of 532-6200 White?
A: The shelf life is 18 months in unopened, proper storage.
Q11: What is the lead time for orders?
A: Regular orders ship within 7‑10 working days after payment confirmation. Large‑volume or urgent orders can be negotiated.
CTA (Call to Action)
Ready to order 532-6200 White?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (chemical processing, semiconductor, food processing, pharmaceutical, aerospace, etc.)
-
Required film thickness
-
Primer requirement
-
Document requirement (TDS, SDS, FDA compliance, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample‑shipping freight.
-
If bulk‑product performance deviates from sample reference, Chemours official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom‑right chat widget to speak directly with our team
After‑Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality‑related claims must be submitted within 7 working‑days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim‑document preparation. |
| Technical Support | Remote technical guidance available. On‑site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates (e.g., FDA) on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original Chemours typical values for 532-6200 White. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on substrate preparation, application method, and curing conditions. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for coating failure caused by improper application or improper usage. Always reference the latest Chemours official TDS of 532-6200 White as the definitive specification.
