532-6118 Sparkling Beige (also referred to as Pearl White) is an ETFE powder topcoat from Chemours‘ Teflon industrial coatings portfolio, genuinely manufactured by Chemours and imported as original product. As an authorized distributor and trader, we supply genuine material with full traceability and direct access to official Chemours technical documentation. For more product options and company information, please visit our website at https://szrqchem.com/.
532-6118 is a special filled grade ETFE (ethylene tetrafluoroethylene) powder engineered as a high build topcoat for multi‑coat systems. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene. While not fully fluorinated, ETFE exhibits excellent chemical resistance and is the toughest among fluoroplastics. The coating sinters to form a very dense, nonporous film with exceptional chemical corrosion resistance.
What distinguishes 532-6118 is its exceptional permeation resistance and high build capability. It is a special filled grade with very high resistance against water vapor permeation. In an Atlas cell test with boiling water, the coating showed no blistering, bubbling, or delamination after one year of exposure, even when applied at a thickness of only 350 µm. With a maximum total film build of 25.0 mils (approx. 635 µm) , 532-6118 offers exceptional thick film protection for demanding industrial applications.
The sparkling beige / pearl white pigmented finish provides a distinctive industrial appearance while offering superior protection against chemical permeation. As a powder coating, 532-6118 contains zero VOCs, offering significant environmental and worker safety advantages.
With regular stock availability, we support both trial orders and large‑volume bulk shipments for chemical processing, semiconductor equipment, food processing, and other demanding industrial applications.
Key Features of 532-6118 ETFE High Build Powder Topcoat
-
ETFE High Performance – ETFE is the toughest among fluoroplastics with excellent chemical resistance, offering superior durability compared to other fluoropolymers.
-
Exceptional Permeation Resistance – Special filled grade with very high resistance against water vapor permeation. Tested and proven – no blistering after one year in boiling water at 350 µm thickness.
-
High Build / Thick Film Capability – Single coat up to 10.0 mils (254 µm) ; maximum total film build up to 25.0 mils (approx. 635 µm). Recommended total DFT: 650 – 1,000 µm (25.6 – 39.4 mil).
-
Sparkling Beige / Pearl White Finish – Distinctive sparkling beige (pearl white) pigmented finish for easy visual identification and consistent industrial appearance.
-
Excellent Chemical Resistance – Coating sinters to form a very dense, nonporous film with outstanding chemical corrosion resistance.
-
High Temperature Resistance – Continuous service up to 149°C (300°F) with intermittent service up to 316°C (600°F).
-
Excellent Dielectric Strength – Provides high dielectric strength for electrical applications.
-
Zero VOC Formulation – Powder coating contains 0 g/kg VOC, offering significant environmental and worker safety advantages.
-
Broad Substrate Compatibility – Compatible with aluminum, stainless steel, and carbon steel substrates.
-
System Compatibility – Interchangeable and compatible with liquid and powder topcoats.
Typical Applications for 532-6118 Sparkling Beige
| Industry | Typical Components & Considerations |
|---|---|
| Chemical Processing | Reaction vessels, agitators, pipelines, pumps, tanks, valves – resists strong acids and alkalis, ensures equipment stability and service life |
| Semiconductor Equipment | High‑purity components, circuit board baking trays – stable at high temperatures, no harmful substance release |
| Food Processing | Bakeware, conveyor belts, cutting tools – ensures easy release and cleaning (Note: Not FDA compliant) |
| Pharmaceutical Manufacturing | Pharmaceutical production equipment – requires high purity and chemical resistance |
| Plastic & Rubber Industry | Rollers, shoe molds, rubber glove molds, tire molds – prevents sticking, extends mold life |
| Textile Industry | Rollers for yarn sizing – prevents high‑viscosity chemical slurry adhesion |
| Medical Devices | Surgical instruments, infusion tubes – reduces friction, improves durability |
| Aerospace | Aircraft engine components, fuel system piping – stable performance in extreme environments |
| Power & Energy | Power generation equipment – chemical resistance and high dielectric strength |
| Valve & Pump Components | Industrial valves, pumps – corrosion protection and permeation resistance |
Material Advantages
532-6118 ETFE High Build Powder Topcoat delivers:
-
Exceptional Permeation Resistance – The filled formulation provides outstanding protection against water vapor and chemical permeation, making it ideal for chemical processing equipment, storage tanks, and other applications requiring barrier protection.
-
Superior Durability – ETFE is the toughest among fluoroplastics, offering excellent impact resistance and mechanical strength.
-
High Build Capability – Supports total film thickness up to 25.0 mils (approx. 635 µm) , providing enhanced abrasion resistance, corrosion protection, and extended service life.
-
Chemical Inertness – Forms a very dense, nonporous film that resists most acids, bases, and solvents.
-
Thermal Stability – Maintains performance at continuous service temperatures up to 149°C (300°F), with intermittent service up to 316°C (600°F).
-
Zero VOC – Powder formulation contains no VOCs, offering significant environmental and worker safety advantages.
-
Proven Performance – Tested in Atlas cell with boiling water – no blistering after one year of exposure at 350 µm thickness.
-
Broad Substrate Compatibility – Applicable to aluminum, stainless steel, and carbon steel.
-
System Flexibility – Interchangeable and compatible with liquid and powder topcoats for multi‑coat systems.
Chemours, as the inventor of Teflon, brings over 80 years of fluoro‑polymer expertise, ensuring batch‑to‑batch consistency, reliable supply, and full technical support.
Typical Properties
| Property | 532-6118 Sparkling Beige | Unit / Remarks |
|---|---|---|
| Product Type | ETFE High Build Powder Topcoat – Filled Grade | – |
| Color | Sparkling Beige / Pearl White | 闪烁米黄色/珍珠白 |
| Form | Powder | – |
| FDA Compliance | No – Not FDA compliant per 21CFR | – |
| CAS Number | 25038-71-5 | – |
| Max Continuous Service Temp. | 149°C (300°F) | – |
| Intermittent Service Temp. | 316°C (600°F) | – |
| Cure Temperature | 316°C (600°F) | – |
| Single Coat Film Build | 3.0 – 10.0 mil (76 – 254 µm) | – |
| Recommended DFT per Coat | Up to 200 µm (7.9 mil) | – |
| Max Total Film Build | 25.0 mil (approx. 635 µm) | – |
| Recommended Total DFT | 650 – 1,000 µm (25.6 – 39.4 mil) | – |
| Chemical Resistance | Excellent – resists acids, alkalis, solvents | – |
| Permeation Resistance | Exceptional – special filled grade | – |
| Application Method | Electrostatic Spray | – |
| Packaging | 4 kg, 5 kg, 20 kg pails / bags | – |
| Shelf Life | 18 months | Unopened, proper storage |
Important Notes on Typical Data:
-
Values listed are typical and sourced from Chemours official data sheets. They do not constitute binding product specification.
-
Physical constants are averages only and may vary up to ±5% of the values shown.
-
Final performance depends on substrate preparation, application method, and curing conditions.
-
Chemours original TDS shall serve as definitive technical reference. Request the latest official TDS from our sales team.
Processing Guidelines
| Step | Process |
|---|---|
| Substrate | Aluminum, stainless steel, carbon steel |
| Surface Preparation | Remove all grease and contaminants. Use organic solvents to dissolve grease and heat to approximately 400°C to volatilize, then grit blast to roughen the surface |
| Powder Preparation | Homogenize powder before opening bag |
| Screening | Screen through appropriate mesh to prevent application defects |
| Primer Application | Primer required – 532-6118 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher |
| Topcoat Application | Apply via electrostatic spray (powder gun) |
| Single Coat DFT | Up to 200 µm (7.9 mil) per coat |
| Max Total DFT | Up to 635 µm (25.0 mil) |
| Recommended Total DFT | 650 – 1,000 µm (25.6 – 39.4 mil) |
| Spray Distance | 20-30 cm from substrate |
| Curing | 316°C (600°F) ; cure time depends on part mass and film thickness |
| Storage | Store in original, sealed containers in a cool, dry place away from direct sunlight |
| Shelf Life | 18 months in unopened, clean, dry storage |
Critical Processing Warnings:
-
Primer Required: 532-6118 is a topcoat and must be used with a compatible primer system. If powder primer is used with a complete powder system, efficiency is higher.
-
Do Not Apply as Single Coat: This topcoat is designed for use with primer systems and should not be applied as a single coat system.
-
Surface Preparation: Proper surface preparation is critical for adhesion. Remove all grease and contaminants from the surface.
-
High Build Application: For thick film applications, multiple coats may be required. Recommended total DFT: 650 – 1,000 µm (25.6 – 39.4 mil).
-
Curing: Cure time and temperature depend on part mass and oven characteristics. Always verify with test pieces.
-
Storage: Store in original, sealed containers in a cool, dry place away from direct sunlight.
-
Shelf Life: 18 months in unopened, clean, dry storage.
Related Products
- Explore Teflon ETFE Coatings – Browse all Teflon ETFE industrial coating options
-
850G-300 Clear – Teflon PTFE Acid Primer – Acid primer for PTFE, PFA, and FEP topcoat systems
-
953G-506 Dark Violet – FEP Waterborne Primer – FEP primer for multi-coat food contact systems
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents
| Document Type | Description & Source |
|---|---|
| Chemours Official TDS | Complete physical, thermal, and mechanical properties of 532-6118, issued by Chemours original |
| Chemours Official SDS | GHS‑compliant chemical safety documentation, original Chemours document |
| Chemours Distributor Authorization Certificate | Proof of our authorized‑distributor qualification for Chemours Teflon series, available upon request |
| COA (Certificate of Analysis) | Batch‑specific quality certification |
| Application & Usage Guide | Detailed application guidance for ETFE high build powder coating systems |
Request any document above by:
-
Email:
ruiqingchem@gmail.com -
Online form: Our contact page
We reply within one working business day. Please clearly state product (532-6118 Sparkling Beige) and document type you require.
FAQ
Q1: What is 532-6118 Sparkling Beige and what is it used for?
A: 532-6118 Sparkling Beige is an ETFE (ethylene tetrafluoroethylene) high build powder topcoat from the Teflon industrial coatings portfolio. It is a special filled grade with exceptional permeation resistance, offering thick film capability up to 25 mils. It is widely used in chemical processing equipment, semiconductor equipment, food processing, pharmaceutical manufacturing, aerospace, and general industrial applications.
Q2: Is 532-6118 Sparkling Beige PFA or ETFE?
A: 532-6118 is ETFE (ethylene tetrafluoroethylene), not PFA. ETFE is a thermoplastic copolymer of ethylene and tetrafluoroethylene and is the toughest among fluoroplastics.
Q3: Is 532-6118 Sparkling Beige FDA compliant?
A: No. 532-6118 is not FDA compliant for food contact applications per 21CFR.
Q4: What is the maximum film build of 532-6118 Sparkling Beige?
A: Single coat up to 10.0 mils (254 µm); maximum total film build up to 25.0 mils (approx. 635 µm). Recommended total DFT: 650 – 1,000 µm (25.6 – 39.4 mil).
Q5: What is the temperature range of 532-6118 Sparkling Beige?
A: Continuous service up to 149°C (300°F) with intermittent service up to 316°C (600°F).
Q6: What is the permeation resistance of 532-6118 Sparkling Beige?
A: 532-6118 is a special filled grade with very high resistance against water vapor permeation. In Atlas cell boiling water test, no blistering after one year at 350 µm thickness.
Q7: Is primer required for 532-6118 Sparkling Beige?
A: Yes. 532-6118 is a topcoat and must be used with a compatible primer system.
Q8: What is the CAS number of 532-6118 Sparkling Beige?
A: The CAS number is 25038-71-5.
Q9: What is the shelf life of 532-6118 Sparkling Beige?
A: The shelf life is 18 months in unopened, proper storage.
Q10: What is the lead time for orders?
A: Regular orders ship within 7‑10 working days after payment confirmation. Large‑volume or urgent orders can be negotiated.
CTA (Call to Action)
Ready to order 532-6118 Sparkling Beige?
To get a precise quotation and professional technical support, please share:
-
Required quantity (kg)
-
Destination port or delivery address
-
Target application (chemical processing, semiconductor, food processing, aerospace, etc.)
-
Required total film thickness (up to 25 mils)
-
Primer requirement
-
Document requirement (TDS, SDS, COA, etc.)
Sample Policy:
-
Samples are for laboratory validation tests only, not for production use.
-
Buyer bears international sample‑shipping freight.
-
If bulk‑product performance deviates from sample reference, Chemours official TDS serves as the authoritative benchmark.
Take action now:
-
📧 Email Us –
ruiqingchem@gmail.com -
📝 Send Inquiry – Use our quick inquiry form
-
💬 Live Chat – Click the bottom‑right chat widget to speak directly with our team
After‑Sales Support
| Service | Details |
|---|---|
| Quality Inspection Period | All quality‑related claims must be submitted within 7 working‑days after delivery, supported by test data and photographic evidence. |
| Return / Exchange Policy | Confirmed product defects caused by our side trigger replacement or refund. Terms and conditions apply. |
| Logistics Damage | Report shipping damage directly to carrier immediately upon goods receipt. We assist with claim‑document preparation. |
| Technical Support | Remote technical guidance available. On‑site troubleshooting can be arranged upon special request. |
| Export Documentation | We supply commercial invoice, packing list, bill of lading, COA, and additional compliance certificates on request. |
Disclaimer
DISCLAIMER: All technical data is referenced from original Chemours typical values for 532-6118 Sparkling Beige. Our company acts as authorized distributor/trader rather than original manufacturer. Final performance depends on substrate preparation, application method, and curing conditions. Buyers shall independently validate product suitability for individual applications. Our firm bears no liability for coating failure caused by improper application or improper usage. Always reference the latest Chemours official TDS of 532-6118 Sparkling Beige as the definitive specification.
