VESTAMID L2124 NC is a natural-color, high-viscosity, plasticized polyamide 12 compound manufactured by Evonik Operations GmbH. It is designed primarily for extrusion of flexible tubing and hoses, especially for oil, fuel and petrochemical applications.
The grade is a PA12-P material with a high melt viscosity. This is important in tube extrusion because the polymer must retain sufficient melt strength after leaving the die and before final calibration and cooling. Evonik specifically describes VESTAMID L2124 NC as providing good dimensional control during pipe extrusion.
The plasticized formulation gives the finished tube greater flexibility than rigid unplasticized PA12. This makes the material suitable for applications such as fuel lines, vacuum lines, hydraulic lines and other flexible technical tubing where both toughness and bendability are required.
VESTAMID L2124 NC is also specified for tubing according to DIN 73 378, Type PA 12-PHL. This product positioning makes it especially relevant for technical and automotive tube systems requiring a recognized PA12 tubing material.
Another important advantage is low moisture uptake. Published water absorption is approximately 1.3%, while humidity absorption is approximately 0.5%. Because PA12 absorbs relatively little moisture, its dimensions and mechanical properties change less with humidity than many other polyamides.
The material also offers exceptional impact strength, a low coefficient of friction and good chemical resistance. Current product data includes resistance information for acids, alkalis, alcohols, hydrocarbons, oils, fuels and other industrial media.
Unlike the black L2124 BK 9.7507 version, VESTAMID L2124 NC is supplied in natural color. This can be useful when a neutral base material is preferred or when the processor requires a different downstream color strategy.
Explore additional grades in our PA12 Polyamide 12 Product Category →.
For manufacturer information about the VESTAMID PA12 portfolio, visit the Official Evonik VESTAMID Page →.
Key Features of VESTAMID L2124 NC
| Feature | Benefit |
|---|---|
| High Melt Viscosity | Supports stable tube geometry and dimensional control during extrusion |
| Plasticized PA12-P | Provides flexibility for hoses and semi-rigid tubing |
| Heat Stabilized | Supports demanding processing and service conditions |
| Light / UV Stabilized | Suitable for applications exposed to light or weather |
| Exceptional Impact Strength | Helps tubes withstand handling, vibration and mechanical shock |
| Good Low-Temperature Toughness | Retains useful impact performance at -30°C |
| Low Moisture Absorption | Helps reduce humidity-related dimensional and property changes |
| Low Coefficient of Friction | Supports tube handling, sliding and assembly |
| Oil & Fuel Resistance | Useful for automotive and petrochemical fluid-line applications |
| Broad Chemical Resistance | Resists many alcohols, hydrocarbons, acids, bases and industrial media |
| Natural Color | Suitable where a non-black base material is required |
| Pipe / Tube Extrusion Grade | Developed specifically for flexible tubing and hose production |
The combination of high viscosity, flexibility and chemical resistance is the main reason VESTAMID L2124 NC is selected for demanding tube and hose applications.
Typical Applications for VESTAMID L2124 NC
VESTAMID L2124 NC is primarily intended for extrusion of flexible tubes, pipes and hoses.
| Application Area | Typical Use |
|---|---|
| Fuel Lines | Flexible PA12 tubing requiring fuel and hydrocarbon resistance |
| Oil Lines | Tubing exposed to lubricating oils and petroleum-based fluids |
| Petrochemical Tubing | Flexible technical lines for chemically demanding environments |
| Vacuum Lines | Semi-rigid automotive and industrial vacuum tubing |
| Hydraulic Lines | Flexible PA12-P fluid-transfer tubing |
| Industrial Hoses | Hose systems exposed to oils, fuels and chemicals |
| Steel Cable Sheathing | Protective PA12 covering for steel cable systems |
| Profile Extrusion | Flexible technical profiles requiring toughness and chemical resistance |
Evonik’s VESTAMID product literature has historically positioned L2124 for fuel, vacuum and hydraulic lines as well as steel cable sheathing, while current product information emphasizes flexible tubing and hoses for oil and petrochemical applications.
Typical Properties of VESTAMID L2124 NC
Physical & Rheological Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Density, Dry | 1.03 g/cm³ | ISO 1183 |
| Density, Conditioned | 1.04 g/cm³ | ISO 1183 |
| Water Absorption | 1.3% | Similar to ISO 62 |
| Humidity Absorption | 0.5% | Similar to ISO 62 |
| Melt Volume-Flow Rate (MVR) | 19 cm³/10 min | ISO 1133 |
| MVR Test Condition | 275°C / 5 kg | — |
| Molding Shrinkage – Parallel | 0.7% | ISO 294-4 / 2577 |
| Molding Shrinkage – Normal | 1.6% | ISO 294-4 / 2577 |
The MVR value for VESTAMID L2124 NC is measured at 275°C under a 5 kg load. Because MVR is highly dependent on temperature and load, it should not be directly compared with data measured under different test conditions.
Mechanical Properties
| Property | Typical Value (Dry / Conditioned) | Test Method |
|---|---|---|
| Tensile Modulus | 400 / 350 MPa | ISO 527 |
| Yield Stress | 26 / 22 MPa | ISO 527 |
| Yield Strain | 31 / 27% | ISO 527 |
| Nominal Strain at Break | >50 / >50% | ISO 527 |
| Tensile Creep Modulus, 1 h | — / 350 MPa | ISO 899-1 |
| Tensile Creep Modulus, 1000 h | — / 270 MPa | ISO 899-1 |
| Charpy Impact Strength, 23°C | No Break | ISO 179/1eU |
| Charpy Impact Strength, -30°C | No Break / No Break | ISO 179/1eU |
| Charpy Notched Impact, 23°C | 140 kJ/m² dry / No Break conditioned | ISO 179/1eA |
| Charpy Notched Impact, -30°C | 6 / 6 kJ/m² | ISO 179/1eA |
The low tensile modulus and very high impact performance show the flexible and tough character of VESTAMID L2124 NC, which is well matched to tube and hose applications.
Thermal & Flammability Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Melting Temperature | 169°C | ISO 11357-1/-3 |
| HDT @ 1.80 MPa | 45°C | ISO 75-1/-2 |
| HDT @ 0.45 MPa | 98°C | ISO 75-1/-2 |
| Vicat Softening Temperature B | 125°C | ISO 306 |
| CTE – Parallel | 180 × 10⁻⁶/K | ISO 11359-1/-2 |
| CTE – Normal | 170 × 10⁻⁶/K | ISO 11359-1/-2 |
| Flammability @ 1.5 mm nominal | HB | IEC 60695-11-10 |
| Tested Thickness | 1.6 mm | — |
Electrical Properties
| Property | Typical Value (Dry / Conditioned) | Test Method |
|---|---|---|
| Volume Resistivity | 1 × 10¹⁰ / 2 × 10⁹ Ω·m | IEC 62631-3-1 |
| Surface Resistivity | — / 1 × 10¹² Ω | IEC 62631-3-2 |
| Relative Permittivity, 100 Hz | 12 / 16 | IEC 62631-2-1 |
| Relative Permittivity, 1 MHz | 3.8 / 4.2 | IEC 62631-2-1 |
| Dissipation Factor, 100 Hz | 1600 / 1600 × 10⁻⁴ | IEC 62631-2-1 |
| Dissipation Factor, 1 MHz | 1500 / 2000 × 10⁻⁴ | IEC 62631-2-1 |
| Electric Strength | 32 / 27 kV/mm | IEC 60243-1 |
| Comparative Tracking Index (CTI) | 600 / 600 | IEC 60112 |
These values confirm that VESTAMID L2124 NC is an electrically insulating plasticized PA12 rather than a conductive or antistatic grade.
Why Choose VESTAMID L2124 NC?
The main reason to choose VESTAMID L2124 NC is its balance of melt strength, flexibility and resistance to oils and chemicals.
Tube extrusion requires sufficient melt viscosity to maintain the geometry of the hot extrudate before calibration. Evonik specifically highlights the high melt viscosity and good dimensional control of L2124 during pipe extrusion.
The plasticized formulation provides a flexible tube rather than a rigid PA12 component. This is important for fuel, hydraulic, vacuum and industrial hose systems that need to bend during installation and tolerate continuous movement or vibration.
PA12’s low moisture absorption provides another advantage. The material changes relatively little with ambient humidity, helping maintain tube dimensions and consistent mechanical behavior.
Chemical resistance is particularly relevant to this grade. Published data covers multiple automotive and industrial fluids, including standard fuels, diesel fuel, motor oil, hydrocarbons, alcohols, acids and alkaline solutions.
For processors who need the L2124 performance package but do not want a black pre-colored resin, VESTAMID L2124 NC provides the natural-color version of this high-viscosity tubing family.
Processing Guidelines for VESTAMID L2124 NC
VESTAMID L2124 NC is intended primarily for pipe/tube extrusion, profile extrusion and other extrusion processes. Current product information also lists injection molding.
| Processing Item | Published / Recommended Guidance |
|---|---|
| Primary Processing | Pipe / Tube Extrusion, Profile Extrusion |
| Additional Processing | Injection Molding, Other Extrusion |
| ISO Test Melt Temperature | 220°C |
| ISO Test Mold Temperature | 60°C |
| ISO Test Injection Velocity | 200 mm/s |
| ISO Test Holding Pressure | 70 MPa |
| Supply Condition | Pellets / Granules in moisture-protective packaging |
| Storage | Dry storage at ≤30°C in original undamaged packaging |
The ISO conditions above are used to prepare standardized injection-molded test specimens. They should not be treated as a universal extrusion temperature profile.
For actual tube production, the extruder barrel profile, die temperature, line speed, vacuum calibration and cooling conditions should be optimized according to tube diameter, wall thickness and output rate.
Evonik recommends following its general VESTAMID processing guidance. Material from intact moisture-proof packaging can normally be processed directly. If the pellets have absorbed moisture after extended exposure to ambient air, drying should be carried out before production.
Inside original and undamaged packaging, the published shelf life of VESTAMID L2124 NC is at least two years when stored in dry rooms at temperatures not exceeding 30°C.
VESTAMID L2124 NC vs. VESTAMID L2124 BK 9.7507
| Feature | VESTAMID L2124 NC | VESTAMID L2124 BK 9.7507 |
|---|---|---|
| Base Polymer | PA12-P | PA12-P |
| Viscosity | High | High |
| Color | Natural | Black |
| Primary Application | Flexible oil, fuel and petrochemical tubing | Flexible oil, fuel and petrochemical tubing |
| High Melt Viscosity | Yes | Yes |
| DIN 73 378 Type PA 12-PHL | Yes | Yes |
| Main Selection Difference | Natural-color base | Ready-colored black formulation |
| Technical Data | Use NC-specific datasheet | Use BK 9.7507-specific datasheet |
Choose VESTAMID L2124 NC when the L2124 high-viscosity tube-extrusion performance is required in a natural-color formulation.
Choose VESTAMID L2124 BK 9.7507 when a ready-colored black grade is preferred. Because pigmentation can affect individual property values, the exact color-grade datasheet should be used for final qualification.
Related Products
VESTAMID L2124 BK 9.7507 – Black high-viscosity plasticized PA12 for oil and petrochemical tubing.
VESTAMID L2123 – High-viscosity plasticized PA12 with enhanced cold-impact performance for automotive air-line systems.
VESTAMID L2121 NC – High-viscosity plasticized PA12 for semi-rigid fuel, vacuum and hydraulic tubing.
View More PA12 Polyamide 12 Materials →
Technical Documents for VESTAMID L2124 NC
| Document Type | Description |
|---|---|
| TDS | Technical Data Sheet with physical, mechanical, thermal, electrical and processing properties |
| SDS | Safety Data Sheet |
| COA | Batch-specific Certificate of Analysis where available |
| Chemical Resistance Data | Resistance information for fuels, oils, alcohols, hydrocarbons and other media |
| Compliance Documents | Relevant automotive and regulatory documentation subject to availability |
Need technical documents for VESTAMID L2124 NC?
📧 Email: ruiqingchem@gmail.com
📝 Online form: Contact Us →
Please state VESTAMID L2124 NC and the required document type when submitting your inquiry.
FAQ About VESTAMID L2124 NC
Q1: What is VESTAMID L2124 NC?
VESTAMID L2124 NC is a natural-color, high-viscosity, plasticized PA12-P compound from Evonik designed for flexible tubing and hose extrusion, particularly oil, fuel and petrochemical applications.
Q2: What are the main applications of VESTAMID L2124 NC?
Typical applications include fuel lines, vacuum lines, hydraulic lines, oil tubing, industrial hoses, petrochemical tubing and steel cable sheathing.
Q3: Is VESTAMID L2124 NC a high-viscosity grade?
Yes. Evonik specifically characterizes the grade by its high melt viscosity and good dimensional control during pipe extrusion.
Q4: What is the density of VESTAMID L2124 NC?
The typical dry density is approximately 1.03 g/cm³, while the conditioned density is approximately 1.04 g/cm³.
Q5: What is the MVR of VESTAMID L2124 NC?
The typical MVR is approximately 19 cm³/10 min at 275°C / 5 kg according to ISO 1133.
Q6: What is the tensile modulus of VESTAMID L2124 NC?
The typical tensile modulus is approximately 400 MPa dry and 350 MPa conditioned according to ISO 527.
Q7: What is the melting temperature of VESTAMID L2124 NC?
The typical melting temperature is approximately 169°C according to ISO 11357.
Q8: What processing temperature is used for VESTAMID L2124 NC?
The current product data lists 220°C melt temperature and 60°C mold temperature for standardized ISO injection-molded test specimens. Actual tube-extrusion temperatures should be optimized for the production line rather than copied directly from the test-specimen conditions.
Q9: Is VESTAMID L2124 NC resistant to oil and fuel?
Yes. The grade is specifically positioned for oil and petrochemical applications, and published chemical-resistance data includes standard fuels, diesel fuel, motor oil, hydrocarbons and alcohols.
