VESTAMID L2124 BK 9.7507 is a black, high-viscosity, plasticized polyamide 12 compound manufactured by Evonik Operations GmbH. It is specifically designed for extrusion of flexible tubing and hoses, with particular emphasis on oil and petrochemical applications.
The grade is positioned as a PA12-P high-viscosity extrusion material. The plasticized PA12 matrix gives finished tubing greater flexibility than rigid unplasticized PA12, while the high melt viscosity provides the melt strength needed to maintain stable tube geometry after the material exits the extrusion die.
Evonik describes VESTAMID L2124 BK 9.7507 as suitable for tubing according to DIN 73 378, Type PA 12-PHL. This makes the grade relevant for technical tube systems where a recognized PA12 tubing classification is required.
One of the major advantages of this material is dimensional control during pipe extrusion. High melt viscosity helps the extrudate maintain its outside diameter and wall thickness before final cooling and calibration.
The PA12 base also absorbs relatively little moisture. Published water absorption is approximately 1.3%, while humidity absorption is approximately 0.5%. This helps parts and tubing made from VESTAMID L2124 BK 9.7507 maintain dimensions and mechanical behavior when environmental humidity changes.
Impact resistance is another important strength. Unnotched Charpy specimens are reported as no break at both 23°C and -30°C. The dry notched Charpy value at 23°C is approximately 150 kJ/m², showing the very tough and ductile nature of this plasticized PA12-P.
The material also has a low coefficient of friction and good resistance to oils, fuels and many industrial chemicals. Current product data includes resistance information for acids, bases, alcohols, hydrocarbons, motor oil, diesel, brake fluid and other media.
Explore additional grades in our PA12 Polyamide 12 Product Category →.
For manufacturer information about VESTAMID PA12 materials, visit the Official Evonik VESTAMID Page →.
Key Features of VESTAMID L2124 BK 9.7507
| Feature | Benefit |
|---|---|
| High Melt Viscosity | Helps maintain dimensional control during pipe and tube extrusion |
| Plasticized PA12-P | Provides flexibility for hoses and semi-rigid tube systems |
| Excellent Impact Strength | Supports demanding industrial and automotive service conditions |
| Good Low-Temperature Toughness | Unnotched specimens remain unbroken at -30°C |
| Heat Stabilized | Supports use in demanding processing and service environments |
| Light / UV Stabilized | Suitable for applications exposed to light or weather |
| Low Moisture Absorption | Helps reduce humidity-related dimensional changes |
| Low Coefficient of Friction | Supports sliding and tube-handling applications |
| Oil Resistance | Useful in oil and petrochemical fluid-handling environments |
| Broad Chemical Resistance | Resists many fuels, alcohols, hydrocarbons and industrial media |
| Lubricated Formulation | Supports stable extrusion and tribological performance |
| Black Color | Supplied as a ready-colored black tubing compound |
The combination of high melt viscosity, plasticization and chemical resistance is the key reason VESTAMID L2124 BK 9.7507 is particularly suitable for flexible technical tube and hose systems.
Typical Applications for VESTAMID L2124 BK 9.7507
VESTAMID L2124 BK 9.7507 is primarily intended for flexible tube, pipe and hose extrusion.
| Application Area | Typical Use |
|---|---|
| Oil & Petrochemical Tubing | Flexible lines requiring oil and hydrocarbon resistance |
| Industrial Hoses | Hose systems exposed to oils, fuels and chemicals |
| Automotive Fluid Lines | Selected flexible tubing where PA12-P performance is required |
| Fuel-Related Tubing | Lines exposed to standard fuels and diesel |
| Lubrication Systems | Tubes carrying oils and lubricating fluids |
| Chemical-Resistant Tubing | Flexible lines exposed to alcohols, hydrocarbons, acids or bases |
| Pneumatic Tubes | Flexible high-viscosity PA12 tube applications |
| Profile Extrusion | Flexible technical profiles requiring PA12 chemical resistance |
The grade is especially well suited to applications where high melt strength and chemical resistance are more important than the extra cold-impact optimization associated with some other L212x grades.
Typical Properties of VESTAMID L2124 BK 9.7507
Physical & Rheological Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Density | 1.03 g/cm³ | ISO 1183 |
| Water Absorption | 1.3% | Similar to ISO 62 |
| Humidity Absorption | 0.5% | Similar to ISO 62 |
| Melt Volume-Flow Rate (MVR) | 9 cm³/10 min | ISO 1133 |
| MVR Test Condition | 230°C / 5 kg | — |
| Molding Shrinkage – Parallel | 0.7% | ISO 294-4 / 2577 |
| Molding Shrinkage – Normal | 1.3% | ISO 294-4 / 2577 |
The low MVR measured under a 5 kg load is consistent with the high-viscosity positioning of VESTAMID L2124 BK 9.7507.
Mechanical Properties
| Property | Typical Value (Dry / Conditioned) | Test Method |
|---|---|---|
| Tensile Modulus | 400 / 420 MPa | ISO 527 |
| Yield Stress | 28 / 27 MPa | ISO 527 |
| Yield Strain | 33 / 29% | ISO 527 |
| Nominal Strain at Break | >50 / >50% | ISO 527 |
| Tensile Creep Modulus, 1 h | — / 310 MPa | ISO 899-1 |
| Tensile Creep Modulus, 1000 h | — / 290 MPa | ISO 899-1 |
| Charpy Impact Strength, 23°C | No Break / No Break | ISO 179/1eU |
| Charpy Impact Strength, -30°C | No Break / No Break | ISO 179/1eU |
| Charpy Notched Impact, 23°C | 150 kJ/m² dry | ISO 179/1eA |
| Charpy Notched Impact, -30°C | 6 / 7 kJ/m² | ISO 179/1eA |
The high room-temperature notched impact performance shows why VESTAMID L2124 BK 9.7507 is suitable for flexible hose and tube systems that may experience bending, vibration or impact.
Thermal Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Melting Temperature | 171°C | ISO 11357-1/-3 |
| HDT @ 1.80 MPa | 45°C | ISO 75-1/-2 |
| HDT @ 0.45 MPa | 98°C | ISO 75-1/-2 |
| Vicat Softening Temperature B | 125°C | ISO 306 |
| CTE – Parallel | 170 × 10⁻⁶/K | ISO 11359-1/-2 |
| CTE – Normal | 160 × 10⁻⁶/K | ISO 11359-1/-2 |
| Flammability @ 1.6 mm | HB | IEC 60695-11-10 |
Electrical Properties
| Property | Typical Value (Dry / Conditioned) | Test Method |
|---|---|---|
| Volume Resistivity | 1 × 10¹⁰ / 1 × 10⁹ Ω·m | IEC 62631-3-1 |
| Surface Resistivity | — / 2 × 10¹³ Ω | IEC 62631-3-2 |
| Relative Permittivity, 100 Hz | 12 / 15 | IEC 62631-2-1 |
| Relative Permittivity, 1 MHz | 3.8 / 4.1 | IEC 62631-2-1 |
| Dielectric Strength | 37 / 30 kV/mm | IEC 60243-1 |
| Comparative Tracking Index (CTI) | 600 / 600 | IEC 60112 |
| Insulation Group | I | DIN EN 60664-1 |
These values confirm that VESTAMID L2124 BK 9.7507 is electrically insulating rather than an antistatic or conductive grade.
Why Choose VESTAMID L2124 BK 9.7507?
The main reason to choose VESTAMID L2124 BK 9.7507 is its balance of flexibility, extrusion stability and chemical resistance.
Flexible tube extrusion requires sufficient melt strength. A material that is too low in viscosity may sag or lose geometry before calibration. The high melt viscosity of L2124 helps support more stable tube dimensions after the die.
Plasticization is equally important. The resulting tubing is more flexible and more suitable for hose-like applications than rigid unplasticized PA12.
PA12 also offers a major moisture advantage. Because it absorbs relatively little water, dimensions and mechanical properties change less with humidity than many conventional polyamides.
For oil and petrochemical environments, chemical resistance is a critical selection factor. Current product data for VESTAMID L2124 BK 9.7507 includes exposure to standard fuels, diesel, motor oil, hydrocarbons, alcohols, brake fluid and several aqueous chemical solutions.
This combination makes the grade a strong candidate for flexible technical tubing where durability, chemical resistance and reliable extrusion behavior are required together.
Processing Guidelines for VESTAMID L2124 BK 9.7507
VESTAMID L2124 BK 9.7507 is primarily intended for pipe/tube extrusion, profile extrusion and other extrusion processes. Current material information also lists injection molding.
| Processing Item | Published / Recommended Guidance |
|---|---|
| Primary Processing | Pipe / Tube Extrusion, Profile Extrusion |
| Additional Processing | Injection Molding, Other Extrusion |
| Recommended Melt Temperature Range | Approx. 200–240°C |
| ISO Test Melt Temperature | 220°C |
| ISO Test Mold Temperature | 60°C |
| ISO Test Injection Velocity | 200 mm/s |
| ISO Test Holding Pressure | 70 MPa |
| Recommended Mold Temperature Range | Approx. 30–100°C |
| Supply Condition | Ready-to-process pellets in moisture-proof bags |
The specific material data gives a rheological melt-temperature window of approximately 200–240°C. Actual extrusion temperatures should be optimized according to tube diameter, wall thickness, output rate and extrusion-equipment design.
The material is supplied in moisture-proof packaging and is ready for processing when the packaging remains intact. If pellets absorb moisture after prolonged exposure to ambient air, drying should follow Evonik’s general VESTAMID processing recommendations.
For precision tubing, die design, calibration, vacuum level, cooling-water temperature and haul-off speed should be optimized together to maintain outside diameter and wall thickness.
Inside original, undamaged packaging, the published shelf life is at least two years when stored dry at temperatures not exceeding 30°C.
VESTAMID L2124 BK 9.7507 vs. VESTAMID L2123 BK 9.7507
| Feature | VESTAMID L2124 BK 9.7507 | VESTAMID L2123 BK 9.7507 |
|---|---|---|
| Base Polymer | Plasticized PA12-P | Plasticized / impact-modified PA12 |
| Viscosity | High | High |
| Primary Positioning | Oil & petrochemical flexible tubing | Automotive tubing with optimized cold-impact performance |
| Tensile Modulus, Dry | Approx. 400 MPa | Approx. 420 MPa |
| Notched Impact, 23°C | Approx. 150 kJ/m² dry | Approx. 106 kJ/m² dry |
| Notched Impact, -30°C | Approx. 6 kJ/m² dry | Approx. 13 kJ/m² dry |
| Main Advantage | Oil/chemical resistance + high-viscosity tubing extrusion | Better low-temperature impact performance |
Choose VESTAMID L2124 BK 9.7507 when the main requirement is flexible tubing for oil, petrochemical or chemically demanding environments.
Choose VESTAMID L2123 BK 9.7507 when optimized low-temperature impact performance is the higher priority, especially for automotive line systems.
Related Products
VESTAMID L2123 BK 9.7507 – High-viscosity impact-modified PA12 for flexible automotive tubing with enhanced cold-impact performance.
VESTAMID L2121 NC – High-viscosity plasticized PA12 for semi-rigid fuel, vacuum and hydraulic tubing.
VESTAMID L2140 NC – Higher-stiffness PA12 extrusion grade for cable and technical applications.
View More PA12 Polyamide 12 Materials →
Technical Documents for VESTAMID L2124 BK 9.7507
| Document Type | Description |
|---|---|
| TDS | Technical Data Sheet with physical, mechanical, thermal, electrical and rheological properties |
| SDS | Safety Data Sheet |
| COA | Batch-specific Certificate of Analysis where available |
| Chemical Resistance Data | Resistance information for oils, fuels, alcohols, hydrocarbons and other media |
| Compliance Documents | Relevant automotive and regulatory documentation subject to availability |
Need technical documents for VESTAMID L2124 BK 9.7507?
📧 Email: ruiqingchem@gmail.com
📝 Online form: Contact Us →
Please state VESTAMID L2124 BK 9.7507 and the required document type when submitting your inquiry.
FAQ About VESTAMID L2124 BK 9.7507
Q1: What is VESTAMID L2124 BK 9.7507?
VESTAMID L2124 BK 9.7507 is a black, high-viscosity, plasticized PA12-P compound from Evonik for flexible tubing and hose extrusion, especially in oil and petrochemical applications.
Q2: What are the main applications of VESTAMID L2124 BK 9.7507?
Typical applications include oil and petrochemical tubing, flexible industrial hoses, fuel-related lines, lubrication lines and chemical-resistant tube systems.
Q3: Is VESTAMID L2124 BK 9.7507 a high-viscosity grade?
Yes. The material is specifically described by Evonik as a high melt viscosity PA12 compound with good dimensional control during pipe extrusion.
Q4: What is the density of VESTAMID L2124 BK 9.7507?
The typical density is approximately 1.03 g/cm³ according to ISO 1183.
Q5: What is the MVR of VESTAMID L2124 BK 9.7507?
The typical melt volume-flow rate is approximately 9 cm³/10 min at 230°C / 5 kg according to ISO 1133.
Q6: What is the tensile modulus of VESTAMID L2124 BK 9.7507?
The typical tensile modulus is approximately 400 MPa dry and 420 MPa conditioned according to ISO 527.
Q7: What is the melting temperature of VESTAMID L2124 BK 9.7507?
The typical melting temperature is approximately 171°C.
Q8: What processing temperature is recommended for VESTAMID L2124 BK 9.7507?
Current material information gives a melt-processing range of approximately 200–240°C. The ISO specimen-production condition uses a melt temperature of 220°C.
Q9: Is VESTAMID L2124 BK 9.7507 resistant to oil and fuel?
Yes. Current material data includes resistance information for motor oil, insulating oil, standard fuels, diesel fuel, hydrocarbons and other chemical media.
