VESTAMID LX9043 NC is a semi-crystalline, low-viscosity polyamide 12 molding compound from Evonik Operations GmbH developed for the production of hollow industrial and technical parts by rotational molding.
The current product information describes the grade as a heat-stabilized PA12 molding compound with improved demoldability. This makes it very different from conventional VESTAMID tube-extrusion or injection-molding grades. Its formulation is specifically intended to support hollow-part manufacturing and easier release from the mold.
A key feature of VESTAMID LX9043 NC is its low viscosity. The current grade-specific data lists an MVR of approximately 63 cm³/10 min at 230°C / 5 kg. The relatively high flow helps the material spread and form a uniform polymer layer during processing.
The material also contains a release agent, which supports improved demolding after the part has cooled and crystallized. This is especially useful in rotational molding, where large hollow components can otherwise be difficult to remove from the mold without damage.
Evonik positions the material for industrial and engineering applications requiring hollow plastic products of different sizes. Current characteristics also list thermoforming in addition to rotational molding.
PA12 provides an important advantage in these applications because it absorbs only small amounts of water. VESTAMID LX9043 NC has a published water absorption of approximately 1.5%, while the measured moisture content in the current product information is approximately 0.07 wt.%. As a result, molded components maintain good dimensional stability when ambient humidity changes.
Mechanical performance is also notable. The dry tensile modulus is approximately 1,110 MPa, yield stress is approximately 39 MPa, and the typical nominal strain at break is approximately 344%. This gives the material a useful combination of moderate stiffness and very high ductility.
Impact performance remains strong at low temperature. Unnotched Charpy specimens show no break at both 23°C and -30°C, while notched Charpy impact strength is approximately 5 kJ/m² at 23°C and 4 kJ/m² at -30°C.
The grade is supplied as natural-color cylindrical pellets in moisture-proof packaging, ready for processing. Evonik states that the material has a shelf life of at least two years in original undamaged packaging stored dry at temperatures not exceeding 30°C.
For more PA12 materials, visit our PA12 Polyamide 12 Product Category →.
For official manufacturer information about the VESTAMID family, visit the Evonik VESTAMID Page →.
Key Features of VESTAMID LX9043 NC
| Feature | Benefit |
|---|---|
| Low Viscosity | Supports good flow and uniform material distribution |
| Rotational Molding Grade | Designed for hollow industrial and technical parts |
| Improved Demoldability | Release-agent package supports easier mold release |
| Heat Stabilized | Supports demanding processing and service environments |
| Semi-Crystalline PA12 | Provides toughness, chemical resistance and dimensional stability |
| High Elongation | Typical nominal strain at break around 344% |
| Low Water Absorption | Helps reduce humidity-related dimensional variation |
| Strong Impact Performance | Unnotched Charpy shows no break at 23°C and -30°C |
| Balanced Shrinkage | 0.9% parallel and 1.2% normal in standardized tests |
| Electrical Insulation | Current product information identifies the grade as insulating |
| Halogen-Free | Listed as halogen-free |
| Phosphorus-Free | Listed as phosphorus-free |
The combination of low viscosity and improved demolding is the defining processing advantage of VESTAMID LX9043 NC.
Typical Applications for VESTAMID LX9043 NC
VESTAMID LX9043 NC is primarily intended for hollow industrial and technical components.
| Application Area | Typical Use |
|---|---|
| Rotationally Molded Hollow Parts | Hollow PA12 components of different sizes |
| Industrial Containers | Selected technical containers requiring PA12 toughness |
| Technical Reservoirs | Hollow engineering parts requiring dimensional stability |
| Protective Housings | Large or complex hollow components |
| Industrial Covers | Lightweight hollow or shell-type engineering parts |
| Engineering Components | Parts requiring toughness and low moisture sensitivity |
| Thermoformed Components | Selected parts processed using thermoforming |
| General-Purpose Hollow Articles | Industrial and technical molded products |
The current Evonik product description identifies general-purpose industrial and engineering hollow articles as the main application area rather than automotive tubing or cable extrusion.
Typical Properties of VESTAMID LX9043 NC
Physical & Rheological Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Density | 1.01 g/cm³ | ISO 1183 |
| Water Absorption | 1.5% | Similar to ISO 62 |
| Moisture Content | 0.07 wt.% | ISO 15512 |
| Shore D Hardness | 70 | ASTM D2240 |
| Melt Volume-Flow Rate (MVR) | 63 cm³/10 min | ISO 1133 |
| MVR Test Condition | 230°C / 5 kg | — |
| Molding Shrinkage – Parallel | 0.9% | ISO 294-4 / 2577 |
| Molding Shrinkage – Normal | 1.2% | ISO 294-4 / 2577 |
| Melt Viscosity @ 100 s⁻¹ | 449 Pa·s | Manufacturer data |
| Melt Viscosity Test Temperature | 220°C | — |
| Relative Solution Viscosity | 1.75 | ISO 307 |
The MVR of 63 cm³/10 min confirms the low-viscosity positioning of VESTAMID LX9043 NC.
Mechanical Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Tensile Modulus | 1,110 MPa | ISO 527 |
| Yield Stress | 39 MPa | ISO 527 |
| Yield Strain | 13% | ISO 527 |
| Stress at 50% Strain | 31 MPa | ISO 527 |
| Stress at Break | 62 MPa | ISO 527 |
| Nominal Strain at Break | >50% | ISO 527 |
| Typical Nominal Strain at Break | 344% | ISO 527 |
| Charpy Impact Strength, 23°C | No Break | ISO 179/1eU |
| Charpy Impact Strength, -30°C | No Break | ISO 179/1eU |
| Charpy Notched Impact, 23°C | 5 kJ/m² | ISO 179/1eA |
| Charpy Notched Impact, -30°C | 4 kJ/m² | ISO 179/1eA |
| Flexural Modulus, 23°C | 1,010 MPa | ISO 178 |
| Flexural Strength, 23°C | 46 MPa | ISO 178 |
The combination of approximately 344% typical nominal strain at break and no-break unnotched impact behavior shows that VESTAMID LX9043 NC is highly ductile.
Thermal Properties
| Property | Typical Value | Test Method |
|---|---|---|
| Melting Temperature | 178°C | ISO 11357-1/-3 |
| Glass Transition Temperature | 40°C | ISO 11357-1/-2 |
| HDT @ 1.80 MPa | 46°C | ISO 75-1/-2 |
| HDT @ 8.00 MPa | 96°C | ISO 75-1/-2 |
| Vicat Softening Temperature A | 174°C | ISO 306 |
| Vicat Softening Temperature B | 133°C | ISO 306 |
| ASTM Melting Temperature | 178°C | ASTM D3418 |
These values describe standardized test behavior. Final service-temperature suitability should be evaluated with the actual hollow-part design and loading conditions.
Functional Characteristics
| Property | Published Positioning |
|---|---|
| Processing | Rotational Molding, Thermoforming |
| Viscosity | Low Viscosity |
| Additives | Release Agent |
| Filler | Unfilled |
| Heat Resistance | Heat Stabilized |
| Electrical Behavior | Insulating |
| Optics | Laser Transparent / Opaque |
| Halogen Content | Halogen-Free |
| Phosphorus Content | Phosphorus-Free |
| Color | Natural |
Why Choose VESTAMID LX9043 NC?
The main reason to choose VESTAMID LX9043 NC is its processing profile for hollow PA12 parts.
Rotational molding requires the material to distribute evenly against the mold surface while the mold rotates through the heating cycle. A low-viscosity grade can support better flow and surface coverage than a high-viscosity PA12.
The release-agent package provides an additional advantage after cooling. Improved demoldability can reduce the risk of damage when removing a large hollow part from the tool.
The material also provides the inherent advantages of PA12. Low water absorption supports dimensional stability, while high ductility helps the part tolerate deformation and impact.
The approximately 1,110 MPa tensile modulus provides useful structural stiffness without making the material excessively rigid. At the same time, the typical nominal strain at break of approximately 344% gives substantial deformation capacity.
Low-temperature impact performance is another advantage. Unnotched Charpy specimens show no break at -30°C, which is relevant for outdoor or industrial applications exposed to cold environments.
For processors that need a natural-color, low-viscosity, easy-release PA12 for rotationally molded hollow parts, VESTAMID LX9043 NC is therefore much more application-specific than a standard injection-molding grade.
Processing Guidelines for VESTAMID LX9043 NC
VESTAMID LX9043 NC is primarily characterized for rotational molding and thermoforming.
The current grade-specific product information also publishes the following processing recommendations:
| Processing Parameter | Published Value |
|---|---|
| Pre-Drying Temperature | 70–80°C |
| Pre-Drying Time | 5–12 hours |
| Target Processing Moisture | ≤0.1% |
| Melt Temperature | 210–220°C |
| Mold Temperature | 60–80°C |
| Feed Temperature | 40–60°C |
| Circumferential Speed | 50–200 mm/s |
| Back Pressure | 5–10 MPa |
| Property-Test Melt Temperature | 220°C |
| Property-Test Mold Temperature | 80°C |
These published values provide useful processing references, but rotational-molding cycle conditions still depend strongly on the machine, mold size, wall thickness, heating medium and cooling method.
For rotational molding, the following variables should be optimized together:
- Material charge weight
- Mold geometry
- Heating cycle
- Mold-surface temperature
- Rotation ratio
- Cooling rate
- Target wall thickness
- Venting
- Demolding temperature
- Final dimensional tolerance
Because the grade is supplied as cylindrical pellets, processors should follow their established rotational-molding preparation and feed procedure for the selected equipment.
The material is supplied in moisture-proof packaging. If the original bag remains intact, moisture pickup is minimized. If the material has been exposed to ambient humidity, the published pre-drying recommendation is 70–80°C for 5–12 hours, with a target processing moisture of ≤0.1%.
VESTAMID LX9043 NC vs. VESTAMID LX9042 NC
| Feature | VESTAMID LX9043 NC | VESTAMID LX9042 NC |
|---|---|---|
| Base Polymer | PA12 | PA12 |
| Color | Natural | Natural |
| Viscosity | Low | Not specifically classified in current public data |
| Primary Process | Rotational Molding / Thermoforming | Injection Molding |
| Release Agent | Yes | Yes |
| Heat Stabilized | Yes | Yes |
| Nucleated | Not the defining feature | Yes |
| Main Product Form | Hollow molded articles | Injection-molded technical parts |
| MVR | 63 cm³/10 min @ 230°C / 5 kg | 9 cm³/10 min @ 220°C / 2.16 kg |
| Main Selection Reason | Low-viscosity hollow-part molding | Easy-release short-cycle injection molding |
The MVR values use different test conditions, so they should not be compared numerically as a direct flow ratio.
Choose VESTAMID LX9043 NC when the application is a rotationally molded hollow industrial or technical component.
Choose VESTAMID LX9042 NC when the project is a high-volume injection-molded part requiring nucleation and easy demolding.
Related Products
VESTAMID LX9042 NC – Heat-stabilized, nucleated PA12 with highly effective mold release for injection molding.
VESTAMID LX9039 NC – Unmodified medium-viscosity PA12 without stabilizers or processing aids.
VESTAMID L1940 NC – Medium-viscosity, heat-stabilized PA12 for injection molding and extrusion.
View More PA12 Polyamide 12 Materials →
Technical Documents for VESTAMID LX9043 NC
| Document Type | Description |
|---|---|
| TDS | Grade-specific physical, mechanical, thermal, rheological and processing data |
| SDS | Safety Data Sheet |
| COA | Batch-specific Certificate of Analysis where available |
| Processing Information | Rotational molding, thermoforming and drying guidance |
| Chemical Resistance Data | PA12 resistance information for relevant service media |
| Application Support | Hollow-part design and material-selection guidance |
Need technical documents for VESTAMID LX9043 NC?
📧 Email: ruiqingchem@gmail.com
📝 Online form: Contact Us →
Please state VESTAMID LX9043 NC and the required document type when submitting your inquiry.
FAQ About VESTAMID LX9043 NC
Q1: What is VESTAMID LX9043 NC?
VESTAMID LX9043 NC is a natural-color, low-viscosity, heat-stabilized PA12 from Evonik with improved demoldability for rotational molding of hollow industrial and technical parts.
Q2: What is the main application of VESTAMID LX9043 NC?
Its main application is rotational molding of hollow plastic articles, with thermoforming also listed as a supported process.
Q3: Is VESTAMID LX9043 NC low viscosity?
Yes. Evonik specifically classifies the grade as low viscosity.
Q4: What is the MVR of VESTAMID LX9043 NC?
The current typical MVR is approximately 63 cm³/10 min at 230°C / 5 kg according to ISO 1133.
Q5: What is the density of VESTAMID LX9043 NC?
The typical density is approximately 1.01 g/cm³ according to ISO 1183.
Q6: What is the tensile modulus of VESTAMID LX9043 NC?
The typical dry tensile modulus is approximately 1,110 MPa according to ISO 527.
Q7: What is the elongation of VESTAMID LX9043 NC?
The current data lists nominal strain at break above 50%, with a typical nominal strain at break of approximately 344%.
Q8: What is the melting temperature?
The typical melting temperature is approximately 178°C according to ISO 11357.
Q9: What drying conditions are recommended?
Current grade-specific processing information lists 70–80°C for 5–12 hours, with target processing moisture of ≤0.1%.
