描述
VESTAMID L-GF30 BK E70285 is a glass fiber reinforced, heat-stabilized polyamide 12 (PA12) compound from Evonik Operations GmbH, supplied in black color. The material contains approximately 30% glass fibers, an ageing protective agent, and a processing aid for fast and even mold filling.
The distinguishing feature of VESTAMID L-GF30 BK E70285 is its good IR laser transparency. Despite being black in color, the compound has high transparency in a specific wavelength range of lasers, allowing it to be laser-welded by a diode-pumped or solid-state laser in the range of λ = 808–1064 nm . This makes it an excellent choice for automotive connector applications where laser welding is used to join plastic components .
Using glass fiber reinforcement, the strength and heat deflection temperature of the compound are significantly increased . Further advantages include the characteristic properties of PA12: low water absorption, good dimensional stability, and nearly constant properties at changing ambient humidity .
VESTAMID L-GF30 BK E70285 is supplied as cylindrical pellets, ready for processing, in moisture-proof bags. The use of colorants may change property values. Inside the original and undamaged packaging, the product has a shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C .
For more VESTAMID grades and technical information, please visit our Engineering Plastics product page.
Key Features of VESTAMID L-GF30 BK E70285
| # | Feature | Benefit |
|---|---|---|
| 1 | Good IR Laser Transparency | Enables laser welding despite black color |
| 2 | Laser-Weldable (808–1064 nm) | Compatible with diode-pumped and solid-state lasers |
| 3 | 30% Glass Fiber Reinforcement | Significantly increased strength and heat deflection temperature |
| 4 | Heat Stabilized | Maintains properties at elevated temperatures |
| 5 | High Tensile Modulus | 6,800 MPa (dry) for structural rigidity |
| 6 | Good Heat Resistance | HDT @ 0.45 MPa: 175°C |
| 7 | Low Water Absorption | Excellent dimensional stability under changing humidity |
| 8 | Nearly Constant Properties | Reliable performance across varying ambient conditions |
| 9 | Electrically Isolating | Suitable for electrical and electronic applications |
| 10 | Semi-crystalline | Provides good chemical resistance and mechanical properties |
| 11 | Black Color | Pre-colored for aesthetic and functional applications |
| 12 | Automotive Approved | Suitable for automotive connector applications |
Typical Applications for VESTAMID L-GF30 BK E70285
| Industry | Typical Components & Considerations |
|---|---|
| Automotive Connectors | Laser-welded connectors – utilizing good IR laser transparency and weldability |
| Automotive Under-Hood | Components in complex automotive piping systems – requiring high strength and fuel resistance |
| Electrical & Electronics | High-voltage cable insulation, connectors – requiring electrical isolation and dimensional stability |
| Automotive Fuel Systems | Fuel lines, brake lines, cable sheaths – requiring chemical resistance and heat stability |
| Precision Engineering | Impellers, control valve housings, precision injection molded parts – utilizing high strength and low friction |
Typical Properties of VESTAMID L-GF30 BK E70285
| Property | Value (dry / cond) | Test Method |
|---|---|---|
| Physical | ||
| Density | 1.24 g/cm³ | ISO 1183 |
| Water Absorption (Saturation, 23°C) | ~1.1% | Sim. to ISO 62 |
| Moisture Absorption (23°C, 50% RH) | ~0.5% | Sim. to ISO 62 |
| Molding Shrinkage – Parallel | 0.3% | ISO 294-4, 2577 |
| Molding Shrinkage – Normal | 0.9% | ISO 294-4, 2577 |
| Melt Volume-Flow Rate (MVR, 250°C/5 kg) | 11 cm³/10 min | ISO 1133 |
| Mechanical | ||
| Tensile Modulus | 6,800 MPa | ISO 527 |
| Yield Stress | ~114 MPa | ISO 527 |
| Nominal Strain at Break | ~5% | ISO 527 |
| Charpy Notched Impact (23°C) | ~23 kJ/m² | ISO 179/1eA |
| Thermal | ||
| Melting Temperature | 178°C | ISO 11357 |
| HDT @ 0.45 MPa | 175°C | ISO 75-1/-2 |
| HDT @ 1.80 MPa | 165°C | ISO 75-1/-2 |
| Vicat Softening Temperature | 175°C | ISO 306 |
| Electrical | ||
| Volume Resistivity | 1E13 Ω·cm | IEC 60093 |
| Dielectric Strength | 44 kV/mm | IEC 60243-1 |
| Comparative Tracking Index (CTI) | > 600 V | IEC 60112 |
| Flammability | ||
| Flammability @ 1.6 mm | HB | UL 94 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for VESTAMID L-GF30 BK E70285 .
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Pigmentation – The use of colorants may change property values .
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for VESTAMID L-GF30 BK E70285. Request the latest official TDS from our sales team.
Processing Guidelines for VESTAMID L-GF30 BK E70285
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 80°C |
| Drying Time | 8 – 16 hours |
| Suggested Max Moisture | < 0.1% |
| Processing (Melt) Temperature | 200 – 240°C |
| Optimum Melt Temperature | 220 – 230°C |
| Mold Temperature | 40 – 80°C |
| Injection Pressure | Medium to high |
| Hold Pressure | 30 – 70 MPa |
| Screw L/D Ratio | 20:1 (recommended) |
| Screw Compression Ratio | 2.5:1 – 3.0:1 |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at ≤ 30°C |
Critical Processing Warnings for VESTAMID L-GF30 BK E70285
⚠️ Drying Requirement – VESTAMID L-GF30 BK E70285 should be dried prior to processing to ensure maximum part quality. Suggested maximum moisture content is < 0.1%.
⚠️ Processing Temperature – The recommended processing (melt) temperature range is 200–240°C. Avoid exceeding 240°C to prevent material degradation.
⚠️ Laser Welding – This grade is specifically designed for laser welding applications. The material is laser-weldable by a diode-pumped or solid-state laser in the range of λ = 808–1064 nm . Ensure proper laser parameters and part design for optimal weld strength.
⚠️ Glass Fiber Reinforcement – Contains 30% glass fibers, which may require consideration for equipment wear and proper screw design. Use hardened screws and barrels for extended service life.
⚠️ Pigmentation – The use of colorants may change property values .
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C .
Comparison: VESTAMID L-GF30 BK E70285 vs. VESTAMID L-GF30 BK 9.7506
| Feature | VESTAMID L-GF30 BK E70285 | VESTAMID L-GF30 BK 9.7506 |
|---|---|---|
| Reinforcement | 30% Glass Fibers | 30% Glass Fibers |
| Key Feature | IR laser transparent, laser-weldable | High strength, heat stabilized |
| Laser Weldability | Yes (808–1064 nm) | No |
| Tensile Modulus | 6,800 MPa | 6,800 MPa |
| HDT @ 0.45 MPa | 175°C | 175°C |
| Density | 1.24 g/cm³ | ~1.24 g/cm³ |
| Primary Application | Laser-welded automotive connectors | Automotive under-hood, precision engineering |
Related Products
-
Engineering Plastics – Browse all engineering plastic materials
-
VESTAMID L-GF30 BK 9.7506 – 30% glass fiber reinforced PA12 for high-strength applications
-
VESTAMID L-GF30 BK 9.7503 – 30% milled glass fiber reinforced PA12 for low-warpage applications
-
VESTAMID L-GF15 – 15% glass fiber reinforced PA12 for rigid and tough parts
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for VESTAMID L-GF30 BK E70285
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
| UL Yellow Card | UL safety certification (E100211) |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (VESTAMID L-GF30 BK E70285) and document type you require.
FAQ about VESTAMID L-GF30 BK E70285
Q1: What is VESTAMID L-GF30 BK E70285?
A: VESTAMID L-GF30 BK E70285 is a glass fiber reinforced, heat-stabilized polyamide 12 (PA12) compound from Evonik, supplied in black color, specifically designed for injection molding with good IR laser transparency .
Q2: What makes VESTAMID L-GF30 BK E70285 unique?
A: Its key distinguishing feature is good IR laser transparency despite being black in color, allowing it to be laser-welded by a diode-pumped or solid-state laser in the range of 808–1064 nm .
Q3: What are the key features of VESTAMID L-GF30 BK E70285?
A: 30% glass fiber reinforcement; heat stabilized; good IR laser transparency; laser-weldable (808–1064 nm); high tensile modulus (6,800 MPa); good heat resistance (HDT 175°C at 0.45 MPa); low water absorption; nearly constant properties at changing ambient humidity; electrically isolating .
Q4: What are the typical applications for VESTAMID L-GF30 BK E70285?
A: Laser-welded automotive connectors, automotive under-hood components, high-voltage cable insulation, fuel lines, brake lines, and precision injection molded parts .
Q5: What is the density of VESTAMID L-GF30 BK E70285?
A: 1.24 g/cm³ (ISO 1183) .
Q6: What is the tensile modulus of VESTAMID L-GF30 BK E70285?
A: 6,800 MPa (ISO 527) .
Q7: What is the HDT of VESTAMID L-GF30 BK E70285?
A: HDT @ 0.45 MPa is 175°C and HDT @ 1.80 MPa is 165°C (ISO 75-1/-2).
Q8: Is VESTAMID L-GF30 BK E70285 laser-weldable?
A: Yes, it is laser-weldable by a diode-pumped or solid-state laser in the range of λ = 808–1064 nm .
Q9: What is the recommended drying condition for VESTAMID L-GF30 BK E70285?
A: Dry at 80°C for 8–16 hours. Maximum moisture content should be < 0.1%.
Q10: What is the recommended processing temperature for VESTAMID L-GF30 BK E70285?
A: Processing (melt) temperature: 200–240°C.
Q11: What regions is VESTAMID L-GF30 BK E70285 available in?
A: North America and Europe .
Q12: What is the shelf life of VESTAMID L-GF30 BK E70285?
A: At least 2 years when stored in dry rooms at temperatures not exceeding 30°C .
Q13: What is the water absorption of VESTAMID L-GF30 BK E70285?
A: PA12 compounds typically absorb only small amounts of water, providing excellent dimensional stability under changing ambient humidity .
Q14: What is the MVR of VESTAMID L-GF30 BK E70285?
A: 11 cm³/10 min (250°C/5 kg, ISO 1133) .
Q15: What is the molding shrinkage of VESTAMID L-GF30 BK E70285?
A: 0.3% parallel and 0.9% normal (ISO 294-4, 2577) .
Q16: What is the color of VESTAMID L-GF30 BK E70285?
A: Black.
Q17: What is the UL Yellow Card number for VESTAMID L-GF30 BK E70285?
A: E100211 .
Q18: What is the volume resistivity of VESTAMID L-GF30 BK E70285?
A: 1E13 Ω·cm (IEC 60093).
Q19: What is the dielectric strength of VESTAMID L-GF30 BK E70285?
A: 44 kV/mm (IEC 60243-1).
Q20: What is the CTI of VESTAMID L-GF30 BK E70285?
A: > 600 V (IEC 60112).
