描述
VESTAMID L-GF30 BK 9.7503 is a glass fiber reinforced, heat-stabilized polyamide 12 (PA12) compound from Evonik Operations GmbH, supplied in black color. The material contains approximately 30% milled glass fibers, an ageing protective agent, and a processing aid for fast and even mold filling.
The use of specialty short glass fibers for reinforcement results in a significantly lower difference between longitudinal and transverse shrinkage compared to common glass fiber-reinforced products. This makes VESTAMID L-GF30 BK 9.7503 especially suitable for low-warpage precision parts and encapsulation applications.
Due to the reinforcement, moldings from this compound exhibit high strength and rigidity, while retaining the characteristic properties of PA12: low water absorption, good dimensional stability, and nearly constant mechanical properties at changing ambient humidity.
As a semi-crystalline material, VESTAMID L-GF30 BK 9.7503 features outstanding chemical resistance against fuels, oils, and greases. The compound is electrically isolating and laser absorbing, enabling laser welding and marking processes. It also exhibits high heat resistance, with an HDT of 170°C at 0.45 MPa.
VESTAMID L-GF30 BK 9.7503 is supplied as cylindrical granules, ready for processing, in moisture-proof bags. Pigmentation may affect values. Inside the original and undamaged packaging, the product has a shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
For more VESTAMID grades and technical information, please visit our Engineering Plastics product page.
Key Features of VESTAMID L-GF30 BK 9.7503
| # | Feature | Benefit |
|---|---|---|
| 1 | 30% Milled Glass Fiber Reinforcement | High strength and rigidity with reduced warpage |
| 2 | Low Warpage | Specialty short glass fibers minimize shrinkage difference between flow and transverse directions |
| 3 | Heat Stabilized | Maintains properties at elevated temperatures |
| 4 | Electrically Isolating | Suitable for electrical and electronic applications |
| 5 | Laser Absorbing | Enables laser welding and marking processes |
| 6 | Low Water Absorption | 1.1% at saturation; excellent dimensional stability under changing humidity |
| 7 | Nearly Constant Mechanical Properties | Reliable performance across varying ambient conditions |
| 8 | Outstanding Chemical Resistance | Excellent resistance to fuels, oils, and greases |
| 9 | High Heat Resistance | HDT @ 0.45 MPa: 170°C; HDT @ 1.80 MPa: 130°C |
| 10 | Good Electrical Properties | Dielectric strength of 48 kV/mm; volume resistivity of 1E13 Ohm·m |
| 11 | Semi-crystalline | Provides good chemical resistance and mechanical properties |
| 12 | Black Color | Pre-colored black for functional applications |
Typical Applications for VESTAMID L-GF30 BK 9.7503
| Industry | Typical Components & Considerations |
|---|---|
| Encapsulation | Encapsulation parts requiring low warpage, electrical isolation, and laser absorbing properties |
| Precision Engineering | Low-warpage precision parts, dimensional stable components – utilizing milled glass fiber reinforcement |
| Automotive | Under-hood components, fuel system components, sensor housings – requiring chemical resistance and heat stability |
| Electrical & Electronics | Electrically isolating components, connectors, housings – requiring heat stabilization |
| Industrial | Components requiring resistance to fuels, oils, and greases |
| Medical Technology | Catheters, medical device components – requiring chemical resistance and dimensional stability |
Typical Properties of VESTAMID L-GF30 BK 9.7503
| Property | Value (dry / cond) | Test Method |
|---|---|---|
| Physical | ||
| Density | 1,240 kg/m³ | ISO 1183 |
| Water Absorption (Saturation, 23°C) | 1.1% | Sim. to ISO 62 |
| Humidity Absorption (23°C, 50% RH) | 0.5% | Sim. to ISO 62 |
| Molding Shrinkage – Parallel | 0.5% | ISO 294-4, 2577 |
| Molding Shrinkage – Normal | 0.5% | ISO 294-4, 2577 |
| Melt Volume-Flow Rate (MVR, 250°C/5 kg) | 27 cm³/10 min | ISO 1133 |
| Mechanical | ||
| Tensile Modulus | 3,800 / 2,970 MPa | ISO 527 |
| Yield Stress | 65 / 58 MPa | ISO 527 |
| Yield Strain | 5 / 8 % | ISO 527 |
| Nominal Strain at Break | 11 / 15 % | ISO 527 |
| Impact | ||
| Charpy Unnotched Impact (23°C) | 75 / 82 kJ/m² (C) | ISO 179/1eU |
| Charpy Unnotched Impact (-30°C) | 65 / 72 kJ/m² (C) | ISO 179/1eU |
| Charpy Notched Impact (23°C) | 7 / 6 kJ/m² (C) | ISO 179/1eA |
| Charpy Notched Impact (-30°C) | 6 / 5 kJ/m² (C) | ISO 179/1eA |
| Thermal | ||
| Melting Temperature (10°C/min) | 177°C | ISO 11357-1/-3 |
| Glass Transition Temperature (10°C/min) | 44°C | ISO 11357-1/-2 |
| HDT @ 1.80 MPa | 130°C | ISO 75-1/-2 |
| HDT @ 0.45 MPa | 170°C | ISO 75-1/-2 |
| Vicat Softening Temperature (Method B) | 170°C | ISO 306 |
| Electrical | ||
| Relative Permittivity (100 Hz) | 4.2 / 5.3 | IEC 62631-2-1 |
| Relative Permittivity (1 MHz) | 3.5 / 3.5 | IEC 62631-2-1 |
| Dissipation Factor (100 Hz) | 360 / 860 E-4 | IEC 62631-2-1 |
| Dissipation Factor (1 MHz) | 340 / 460 E-4 | IEC 62631-2-1 |
| Volume Resistivity | 1E13 / 1.5E12 Ohm·m | IEC 62631-3-1 |
| Electric Strength | 48 / 45 kV/mm | IEC 60243-1 |
| Flammability | ||
| Flammability @ 1.5 mm | HB | IEC 60695-11-10 |
Important Notes on Typical Data
📌 Values are typical – The data listed above is sourced from manufacturer data sheets for reference only and does not constitute binding product specifications for VESTAMID L-GF30 BK 9.7503.
📌 Batch variations – Batch-to-batch deviations may exist. For critical applications, validate performance with batch-specific COA certificates.
📌 Pigmentation – The use of colorants or pigmentation may affect property values.
📌 Final performance – Actual performance depends on processing conditions and part design. Refer to ISO testing standards for detailed methodology.
📌 Authoritative reference – The manufacturer’s official TDS shall serve as the definitive technical reference for VESTAMID L-GF30 BK 9.7503. Request the latest official TDS from our sales team.
Processing Guidelines for VESTAMID L-GF30 BK 9.7503
| Step | Process |
|---|---|
| Processing Methods | Injection Molding |
| Drying Recommended | Yes |
| Drying Temperature | 80°C |
| Drying Time | 8 – 16 hours |
| Suggested Max Moisture | < 0.1% |
| Melt Temperature | 250°C |
| Mold Temperature | 80°C |
| Injection Velocity | 200 mm/s |
| Storage | Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at ≤ 30°C |
Critical Processing Warnings for VESTAMID L-GF30 BK 9.7503
⚠️ Drying Requirement – VESTAMID L-GF30 BK 9.7503 should be dried prior to processing to ensure maximum part quality. Suggested maximum moisture content is < 0.1%.
⚠️ Processing Temperature – The recommended melt temperature is 250°C and mold temperature is 80°C, with an injection velocity of 200 mm/s. Avoid exceeding 260°C to prevent material degradation.
⚠️ Milled Glass Fiber Reinforcement – Contains 30% milled glass fibers, which may require consideration for equipment wear and proper screw design. Use hardened screws and barrels for extended service life.
⚠️ Laser Absorbing – This grade is laser absorbing, enabling laser welding and marking processes. Ensure proper laser parameters for optimal results.
⚠️ Pigmentation – The use of colorants or pigmentation may affect property values.
⚠️ Storage – Store in original, sealed packaging in a cool, dry place away from direct sunlight. Shelf life of at least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Comparison: VESTAMID L-GF30 BK 9.7503 vs. VESTAMID L-GF30
| Feature | VESTAMID L-GF30 BK 9.7503 | VESTAMID L-GF30 (General) |
|---|---|---|
| Reinforcement | 30% Milled Glass Fibers | 30% Glass Fibers |
| Key Feature | Low warpage, laser absorbing, black | High strength, heat stabilized |
| Shrinkage (Parallel/Normal) | 0.5% / 0.5% (isotropic) | 0.1–0.3% / 0.6–0.9% (anisotropic) |
| Tensile Modulus | 3,800 MPa | 6,800 MPa |
| HDT @ 0.45 MPa | 170°C | 175°C |
| Density | 1,240 kg/m³ | 1,240 kg/m³ |
| Color | Black | Natural / Black |
| Primary Application | Low-warpage precision parts, encapsulation | Structural components requiring high stiffness |
Related Products
-
Engineering Plastics – Browse all engineering plastic materials
-
VESTAMID L-GF30 – Standard 30% glass fiber reinforced PA12 for high-strength applications
-
VESTAMID L-GF15 – 15% glass fiber reinforced PA12 for rigid and tough parts
-
VESTAMID L-GB30 – 30% glass bead reinforced PA12 for isotropic low-warpage components
-
About Our Company – Learn more about our supply capabilities and quality assurance
Technical Documents for VESTAMID L-GF30 BK 9.7503
| Document Type | Description & Source |
|---|---|
| Manufacturer Official TDS | Complete physical, thermal, and mechanical properties |
| Manufacturer Official SDS | GHS-compliant safety documentation |
| COA (Certificate of Analysis) | Batch-specific quality certification |
Request any document above by:
📧 Email: ruiqingchem@gmail.com
📝 Online form: Our contact page
We reply within one working business day. Please clearly state product (VESTAMID L-GF30 BK 9.7503) and document type you require.
FAQ about VESTAMID L-GF30 BK 9.7503
Q1: What is VESTAMID L-GF30 BK 9.7503?
A: VESTAMID L-GF30 BK 9.7503 is a glass fiber reinforced, heat-stabilized polyamide 12 (PA12) compound from Evonik, supplied in black color, designed for the injection molding of low-warpage precision components.
Q2: What are the key features of VESTAMID L-GF30 BK 9.7503?
A: 30% milled glass fiber reinforcement; low warpage; heat stabilized; electrically isolating; laser absorbing; high strength and rigidity; low water absorption; good dimensional stability; nearly constant mechanical properties at changing ambient humidity; outstanding chemical resistance to fuels, oils, and greases.
Q3: What are the typical applications for VESTAMID L-GF30 BK 9.7503?
A: Encapsulation parts, low-warpage precision parts, automotive under-hood components, fuel system components, sensor housings, and electrically isolating components.
Q4: What is the density of VESTAMID L-GF30 BK 9.7503?
A: 1,240 kg/m³ (1.24 g/cm³), according to ISO 1183.
Q5: What is the tensile modulus of VESTAMID L-GF30 BK 9.7503?
A: 3,800 MPa (dry) / 2,970 MPa (conditioned), according to ISO 527.
Q6: What is the tensile strength of VESTAMID L-GF30 BK 9.7503?
A: Yield stress of 65 MPa (dry) / 58 MPa (conditioned), according to ISO 527.
Q7: What is the molding shrinkage of VESTAMID L-GF30 BK 9.7503?
A: 0.5% parallel and 0.5% normal (ISO 294-4, 2577), demonstrating isotropic shrinkage.
Q8: What is the HDT of VESTAMID L-GF30 BK 9.7503?
A: HDT @ 1.80 MPa is 130°C and HDT @ 0.45 MPa is 170°C (ISO 75-1/-2).
Q9: What is the melting temperature of VESTAMID L-GF30 BK 9.7503?
A: 177°C (ISO 11357-1/-3, 10°C/min).
Q10: What is the recommended processing temperature for VESTAMID L-GF30 BK 9.7503?
A: Melt temperature: 250°C; Mold temperature: 80°C; Injection velocity: 200 mm/s.
Q11: Is VESTAMID L-GF30 BK 9.7503 electrically isolating?
A: Yes, it is electrically isolating, with a volume resistivity of 1E13 Ohm·m (dry) and electric strength of 48 kV/mm (dry).
Q12: What is the water absorption of VESTAMID L-GF30 BK 9.7503?
A: 1.1% at saturation (23°C) and 0.5% at equilibrium (23°C/50% RH), according to Sim. to ISO 62.
Q13: Is VESTAMID L-GF30 BK 9.7503 chemical resistant?
A: Yes, it features outstanding chemical resistance against fuels, oils, and greases.
Q14: What is the shelf life of VESTAMID L-GF30 BK 9.7503?
A: At least 2 years when stored in dry rooms at temperatures not exceeding 30°C.
Q15: What is the UL flammability rating of VESTAMID L-GF30 BK 9.7503?
A: HB at 1.5 mm nominal thickness (IEC 60695-11-10).
Q16: Is VESTAMID L-GF30 BK 9.7503 laser absorbing?
A: Yes, it is laser absorbing, enabling laser welding and marking processes.
Q17: What is the MVR of VESTAMID L-GF30 BK 9.7503?
A: 27 cm³/10 min (250°C/5 kg, ISO 1133).
Q18: What is the Charpy notched impact strength of VESTAMID L-GF30 BK 9.7503?
A: 7 kJ/m² at 23°C and 6 kJ/m² at -30°C (dry, ISO 179/1eA).
Q19: What regions is VESTAMID L-GF30 BK 9.7503 available in?
A: North America and Europe.
Q20: What is the volume resistivity of VESTAMID L-GF30 BK 9.7503?
A: 1E13 Ohm·m (dry) / 1.5E12 Ohm·m (conditioned), according to IEC 62631-3-1.
